READY To ASSEMBLE STAIRCASE BOOKSHELF BUNK BED User manual

Page 1 of 12
BUNK SAFETY WARNING
Size of Mattress and Foundation
The length and width of the upper and lower bunk mattress and foundation are as follows :
Width
37 ½”- 38 ½”
52”- 53”
LengthSize
74”- 75”
74”- 75”
Twin
Full
Thickness
9 ½” max
9 ½” max
You must use only this size mattress.
Ensure thickness of upper and lower mattress and foundation combined does not exceed 9 ½”
and that the mattress is at least 5” below upper edge of guardrails.
This Bunk Bed uses a slat kit for mattress foundation.
Replacement Parts
SAFETY WARNINGS
! !
( 1 )
( 2 )
( 3 )
( 4 )
( 5 )
( 6 )
( 7 )
( 8 )
( 9 )
(10)
(11)
(12)
(13)
Follow the information on the warnings appearing on the upper bunk end structure
and on the carton. Do not remove warning label from bed.
Always use the recommended size mattresses or mattress support, or both,
to help prevent the likehood of entrapment or falls.
Surface of mattress must be at least 5 in. (127mm) below the upper edge of guardrails.
Do not allow children under 6 years of age to use the upper bunk.
Periodically check and ensure that the guardrail, ladder, and other component are
in their proper position, free from damage, and that all connectors are tight.
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
Always use ladder for entering or leaving upper bunk.
Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
Use of a night light may provide added safety precaution for a child using the upper bunk.
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed
next to the wall, the guardrail that runs the full length of the bed should be placed against
the wall to prevent entrapment between the bed and the wall.
The use of water or sleep flotation mattresses is prohibited.
STRANGULATION HAZARD : Never attach or hang items to any part of the bunk bed
that are not designed for use with the bed; for example, but not limited to, hooks, belts
and jump ropes.
Keep these instructions for future reference.
Replacement parts, including additional guardrails, may be obtained from any
dealer

READY
ASSEMBLY INSTRUCTIONS
HARDWARE
Adult Assembly
Allen wrench
Phillips Head
Customer Supplied
Screwdriver
Thank you for choosing our new bunk bed.
This practical design offers the utmost in versatility.
(FULL - FULL)
instructions carefully. Familiariz yourself with the different parts.e
Please note that you will require a Phillips head screwdriver and an Allen wrench.
AJCB M6 X 3 ” - 16 pcs1/8
Spare - 2 pcs
B
EJ
K
L
M
F
G
H
I
C
D
Barrel Nut - pcs16
Allen Screw 2" 36- pcs L Bracket 6- pcs
Large L Bracket 1-pc
Wood Buttons 4 s-pc
Allen Wrench 2 s-pc
Allen Screw 2 3/4" 4- pcs
Metal Pins 4- pcs
Wood Screw 1" 2- pcs
Wood Screw 5/8" 15- pcs
Wooden Dowel 26- pcs
Allen Screw 2 3/8" 8- pcs
Spare - 2 pcs
Spare - pc2s
Spare - pc2s
Spare - pc2s
Spare - pc1
Spare - pc1
Spare - pc2s
Spare - pc2s
NOTE: WE INCLUDE SPARE HARDWARE IN CASE THE ALLEN WRENCH, JCB, BARREL NUTALLEN SCREW, , WOODEN DOWEL
OR WOOD SCREW ARE DAMAGED DURING ASSEMBLY.
STAIRCASE CAN BE SET UP AT EITHER
END OF THE BUNK BED
Page of212
STAIRCASE BOOKSHELF BUNK BED
STAIRCASE BOOKSHELF BUNK BED FF
Before assembling your Staircase Bookshelf bunk bed, please read through these

PARTS LIST
01
11
21
22
04
04
06
07
07
08
08
08
23
24
08
09
12
13
14
12
16 17
18
15
12
19
10
20
06
05
02
03
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
HARDWARE
A UPPER PANEL
B UPPER PANEL
LEFT, RIGHT END CAP
SHORT GUARD RAIL
LOWER PANEL
FRONT, BACK GUARD RAIL
LONG SRAIL
FLOOR STORAGE SIDE PANEL
BOTTOM CROSS BRACE
1 BOX
1 BOX
1 BOX
LONG SIDE PANEL
BOOKSHELF SIDE PANEL
FLOOR STORAGE TOP PANEL
BOOKSHELF BACK PANEL 1
BOOKSHELF TOP PANEL 1
BOOKSHELF BACK PANEL 2
BOOKSHELF TOP PANEL 2
BOOKSHELF BACK PANEL 3
BOOKSHELF TOP PANEL 3
BACK SHORT GUARD RAIL
1 BOX
1 BOX
21
22
23
24
SIDE SHORT GUARD RAIL
HAND GUARD RAIL
FULL UPPER BUNK SLAT KIT
FULL LOWER BUNK SLAT KIT
1 BOX
Page of31
STAIRCASE BOOKSHELF BUNK BED FF 2

STEP
STEP
08
02
03
A
B
B
Attach the long rails (0 ) to the upper panels (02) , using JCB M6 X 3 ” (A) and barrel nut ( ).8 (03) 1/8 B
MTighten with the Allen wrench ( ).
08
Adult Assembly
A
B
M
JCB M6 X 3 ”1/8
Barrel Nut
Allen wrench
A
A
B
B
23
1
2
A
Lay the slat kit ( ) onto the bed. Fix in place using wood screws provided in the slat kit box.full upper bunk 23
FOR SLAT KIT ASSEMBLY follow assembly instructions included with slat kit.
Adult Assembly
Phillips head
Customer Supplied
screwdriver
Page of41
STAIRCASE BOOKSHELF BUNK BED FF 2

STEP 3
STEP 4
Adult Assembly
D
Allen Screw 3/82”
M
Allen wrench
Attach the guard rails ( ) to the upper panel assemblies using ( )front, back 07 Allen screw D .
Tighten with the Allen wrench ( ).M
07
05
05
04
04
07
D
E
E
D
D
D
D
D
D
D
CC
Insert wooden dowel (C) to the locator holes will receive C as shown below. short 5Attach the guard rail (0 )
left, right 4 Allen screw E Mto the end caps (0 ), using ( ),Tighten with the Allen wrench ( ).
Note : Screw holes on end caps
go on inside of guard rails.
Adult Assembly
C
E
Wooden Dowel
Allen Screw 2 ”
M
Allen wrench
Page of 2
STAIRCASE BOOKSHELF BUNK BED FF 5 1

STEP 5
STEP 6
Attach the short guard rail assemblies to the upper panel assemblies as shown below, using wood screw ( ),H
tighten with the Phillips head screwdriver. ( Customer supplied )
SHORT GUARD RAIL ASSEMBLIES
INSIDE VIEW
Note : Screw holes on end caps
go on inside of guard rails.
Phillips head
Customer Supplied
screwdriver
H
WOOD SCREW
D6 X 1”
Adult Assembly
H
H
H
Attach the long rails ( ) to the lower panel ( ) using JCB M6 X 3 ½” (A), and barrel nut ( ).08 06 B
Tighten with the Allen wrench ( ).M
Adult Assembly
08
08
06
06
A
A
A
A
B
B
B
B
A
B
M
JCB M6 X 3 ”1/8
Barrel Nut
Allen wrench
Page of61
STAIRCASE BOOKSHELF BUNK BED FF 2

STEP 7
STEP 8
Lay the full slat kit ( ) onto the bed. Fix in place using wood screws provided in thelower bunk 24
slat kit box. FOR SLAT KIT ASSEMBLY follow assembly instructions included with slat kit.
Adult Assembly
Phillips head
Customer Supplied
screwdriver
24
Insert metal pins ( ) into the holes on top of the lower panels. Lift the upper panels onto the lowerG
panels as shown, and fit the metal pins into the holes in the bottom of the upper panel legs.
G
G
G
G
This step requires
two strong people.
This step requires
two strong people.
CAUTION
!
Adult Assembly
Metal Pins
G
FULL / FULL
Page of71
STAIRCASE BOOKSHELF BUNK BED FF 2

C
Wooden Dowel
STEP 9
STEP 10
Insert wooden dowel (C) to the locator holes will receive C as shown below.
Attach bottom cross brace (10) to the floor storage side panel(09)as shown below. Using allen screw (E).
Tighten with allen wrench (M), but don’t fully tighten this yet.
Attach floor storage top panel (13) to the floor storage side panel assemblies. Using allen screw (E).
Tighten with allen wrench (M).
Attach long side panel (11) to the floor storage side panel assemblies. Using allen screw (E).
Tighten with allen wrench (M). After this,Tighten allen screw on the floor storage side panel.
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
EE
E
E
E
E
E
09
09
10
13
11
13
15
17
19
12
12
12
Adult Assembly
E
Adult Assembly
E
Allen Screw 2 ”
M
Allen wrench
Page of81
STAIRCASE BOOKSHELF BUNK BED FF 2

STEP 11
STEP 12
Attach bookshelf side panel (12) to the floor storage side panel assemblies as shown below. Using allen screw (E).
But don’t fully tighten these yet. Leave them a bit loose to make fitting the back panel easier.
Guide bookshelf back panel 1 (14) in carefully so that it won’t jump out of its grooves. Be sure it fits fully into the
groove at the bottom ( in floor storage top panel ).
Adult Assembly
E
Allen Screw 2 ”
M
Allen wrench
Adult Assembly
E
Allen Screw 2 ”
M
Allen wrench
E
E
E
12
12
17
15
14
Attach ( ) to the panel ( ) using ( ) Tightenbookshelf top panel 1 15 bookshelf side 12 allen screw E .
Mwith Allen wrench ( ).
Attach bookshelf top panel assemblies to the floor storage assemblies, using allen screw (E).
Tighten with allen wrench (M).
Guide bookshelf back panel 2 (17) same as step11.
E
E
E
E
E
Page of91
STAIRCASE BOOKSHELF BUNK BED FF 2

STEP 13
STEP 14
Adult Assembly
E
Allen Screw 2 ”
M
Allen wrench
Adult Assembly
E
F
Allen Screw 2 ”
Allen Screw 2 3/4 ”
M
Allen wrench
Attach ( ) to the panel ( ) using ( ) Tightenbookshelf top panel 2 17 bookshelf side 12 allen screw E .
M But don’t fully tighten these yet. Leave them a bit loose to make fittingwith Allen wrench ( ).
the back panel easier.
Attach bookshelf top panel assemblies to the floor storage assemblies as shown below. Using
allen screw (E). Tighten with allen wrench (M).
Install bookshelf back panel 3 (18).
After this, tighten allen screw of
bottom section top panel 2.
Attach ( ) to the sing ( ) Tightenbookshelf top panel 3 19 floor storage assemblies. U allen screw E .
with allen screw (M).
Attach back short guard rail (20) to the staircase bookshelf assemblies as shown below. Using
allen screw (F). Tighten with allen wrench (M).
12
18
17
19
20
E
E
E
E
E
E
E
E
E
E
F
F
STAIRCASE BOOKSHELF BUNK BED FF Page 10 of 12

STEP 15
STEP 16
Attach ( ) to the sing ( )side short guard rail 21 staircase bookshelf assemblies. U allen screw E .
with allen wrench (M).Tighten
Attach ( ) to the sing ( )hand guard rail 22 staircase bookshelf assemblies. U allen screw E (F).
with allen wrench (M). Recheck that all screws are tight.Tighten
Adult Assembly
E
Allen Screw 2 ”
M
Allen wrench
E
E
E
E
E
E
E
F
F
21
22
Adult Assembly
E
F
Allen Screw 2 ”
Allen Screw 2 3/4 ”
M
Allen wrench
STAIRCASE BOOKSHELF BUNK BED FF Page 11 of 12

STEP 17
BACK VIEW
ZOOM IN
Move the bunk bed and staircase assemblies where you want to place them in the room.bookshelf
Attach staircase assembly to the bunk bed assembly as shown below. Fixbookshelf L bracket (J)
to upper bunk panel using wood screws as shown., lower (I)
Fix large L bracket (K) as shown.
Lastly, cover holes with wood buttons (L).
I
I
L
L
I
I
J
J
J
J
I
I
I
I
J
I
I
Adult AssemblyL - Bracket
Wood Button
Wood Screw 5/8" Large L - Bracket
J
L
IK
BOTTOM VIEW
IK
I
ZOOM IN
Page of12 12
Congratulations !
We recommend that you periodically check that all screws are tight
and all parts are secure to ensure lasting safety.
STAIRCASE BOOKSHELF BUNK BED FF
Your Staircase Bookshelf bunk bed is now ready for use.
