READY To ASSEMBLE TRUNDLE BED User manual

Adult assembly
READY
ASSEMBLY INSTRUCTIONS
Before assembling your Trundle bed, please read through these
instructions carefully. Familiarize yourself with the different parts.
TRUNDLE BED
Page 1 of 4
HARDWARE
A D
JCB M6 X 2 3/8 ”( 60mm ) - 4 pcs
Spare - 1 pc
JCB M6 X 1 3/4”( 45mm ) - 17 pcs
Spare - 2 pcs
JCB M6 X 5/8”( 15mm ) - 6 pcs
Spare - 2 pcs
For JCB M6 X 2”(50mm )
Fix L bracket to front panel
BE
CF
Barrel nut - 4 pcs
Spare - 1 pc
L Bracket - 3 pcs
E
Allen wrench - 1 pc
Spare - 1 pc
Allen wrench
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
PO :

PARTS LIST
01
02
03
04
HARDWARE 1 BOX 2 PCS
1 PC
2 PCS
2 SET
1 PC
1 PC
1 PC
FRONT PANEL
FRONT RAIL
BACK RAIL
05
06
07
08
SIDE CROSS RAIL
CENTER CROSS RAIL
REAR BLOCK
SLAT KIT
01
07
03
03
04
04
05
05
05
08
08
06
06
05
07
Attach the side cross rails (05) and center cross rail (06) to the front and back rail (03)(04), using
L bracket (E), JCB M6 X 1 3/4”(B). Tighten with the Allen wrench (F).
02
Page 2 of 4
B
B
E
E
E
B
B
B
B
F
Allen wrench
B
E
L Bracket
JCB M6 X 1 3/4”
TRUNDLE BED
Step 1
Adult assembly
READY

Attach the front panel (02) to the front rail as shown, using JCB M6 X 5/8” (C).
Tighten with the Allen wrench (F).
Lay the slat kit (08) onto the rail assembly as shown, using JCB M6 X 1 3/4” (B).
Tighten with the Allen wrench (F).
Page 3 of 4
02
08
08
C
B
B
B
B
B
B
B
B
C
C
TRUNDLE BED
Step 2
Step 3
F
Allen wrench
C
JCB M6 X 5/8”
Adult assembly
F
Allen wrench
B
JCB M6 X 1 3/4”
Adult assembly
READY

Attach the rear block (07) to the back rail as shown. Using JCB M6 X 2 3/8”(A) barrel nut (D),
tighten with the Allen wrench (F)
Page 4 of 4
D
Barrel nut
F
Allen wrench
A
JCB M6 X 2 3/8”
07
07
A
A
D
D
Congratulations!
Your bed is now ready for use.
We recommend that you periodically check that all screws are tight
and all parts are secure to ensure lasting safety.
