Real-El RS-3 User manual

RS-5 USB Charge
RS-3 USB Charge
POWER STRIP
with USB Charger
USER’S MANUAL

Technical support: www.real-el.com
1
User’s Manual
ENG
RS-3 USB Charge
RS-5 USB Charge
Congratulations on purchasing the ТМ REAL-EL power strip!
Please read this User’s Manual before using the unit and retain this User’s
Manual in a safe place for future reference.
COPYRIGHT
© 2015. ENEL GROUP OU.
This Manual and information contained in it are copyrighted. All rights re-
served.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discre-
pancies may occur. The information in this Manual is given on “as is” terms.
The author and the publisher do not bear any liability to a person or an orga-
nization for loss or damage which has arisen from the information contained
in this Manual.
PACKAGE CONTENTS
•Power strip – 1 pc
•User’s manual – 1 pc
•Warranty card – 1 pc
APPLICATION
RS-3 USB Charge and RS-5 USB Charge power strips with the built-in
USB charger are designed for connection of electrical appliances to the
power supply network and simultaneous charging of two devices.

Technical support: www.real-el.com
2
Power Strip
with USB Charger
ENG
RS-3 USB Charge
RS-5 USB Charge
FEATURES
•Double-pole power switch with LED
•Grounded sockets with protection shutters
•2 USB ports to charge two devices simultaneously
•USB charger is suited for most devices
•Pure copper cable without alloys
SAFETY PRECAUTIONS
•Do not connect the power strip to the electrical network with overrating
voltage.
•Do not connect the load to the power strip with the total power, which
exceeds the power indicated in specifications of this device.
•Do not use the power strip in places with possible ingress of liquid, mois-
ture, dust and high temperature exposure.
•Do not open and do not make any repairs by yourself.
•Connect the power strip to the grounded electrical network.
CONNECTION
•Connect devices-consumers to power strip sockets.
•Connect the power strip to 230 V power supply network, turn on the master
switch, LED will light.
•If required connect a device to be charged to one of USB ports.
OPERATION
•Do not overload the power strip by connection of several powerful de-
vices.
•Turn offa power switch after completion of work, a LED will go out.

Technical support: www.real-el.com
3
User’s Manual
ENG
RS-3 USB Charge
RS-5 USB Charge
Notes:
• Technical specifications given in this table are supplemental infor-
mation and cannot give occasion to claims.
• Technical specifications and package contents are subject to change
without notice due to improvement of ТМ
REAL-EL production.
TECHNICAL SPECIFICATIONS
Parameters and measurement unit
Rated input voltage, V
Operating frequency, Hz
Total power of connected load, kW
Maximum load current, A
Input plug type
Output socket type
USB charger output voltage
Maximum output current of USB
charger, mAh
Cable length, m
Dimensions (L × H × W), mm
Value
~230
50
≤3.68
16
CEE 7/7
3 × CEE 7/3 (RS-5 USB Charge)
5 × CEE 7/3 (RS-5 USB Charge)
5 V ± 5 %
2100
1.8 (RS-3 USB Charge)
1.8; 3 (RS-5 USB Charge)
280 × 40 × 60 (RS-3 USB Charge)
380 × 40 × 60 (RS-5 USB Charge)

Models: RS-3 USB Charge/RS-5 USB Charge
Manufacturer: ENEL GROUP OU, Katusepapi tn 6, Lasnamäe district, Tallinn city,
Harju county, 11412, Estonia. Made in China.
® Registered Trademark of ENEL GROUP OU. Estonia.
