REALINN RL6200BT Assembly instructions

REALINN
RL6200BT
Barcode Scanner
Manual Guide
Service mailbox
[e-mail]
[e-mail]

In order to correctly use the bar code scanner, please read the instruction
carefully and do not arbitrarily scan the settings code otherwise some settings
may not be available.
Please keep this instruction for reference in the future.
If you have any question or concern about the operation of the scanner, please
contact us at Email:
serv[email protected]
[email protected]

Contents
Product Specification
.....................................
1
Packing List
.....................................
2
Battery & Charging
....................................
2
Quick Guide
....................................
3
FAQs
....................................
5
Optional Function settings
....................................
8
1. Upload Mode Setting
................................................
8
2. Scanning Mode Setting
................................................
11
3. Beep Setting
................................................
12
4. Anti-duplication Setting
................................................
13
5. Aiming & LED Light Setting
................................................
14
6. Case Sensitivity Setting
................................................
15
7. Restore factory setting
................................................
15
8. Identity Barcode Type
................................................
16
9. Frequently-used End Character Setting
................................................
17
10. Interface Setting
................................................
18
11. Battery Remaining
................................................
18
12. Stand-by Setting
................................................
19
13.Keyboard Language Setting
................................................
20
14. Enable / Disable Barcode Type
................................................
21
15.Insert and Delete Character
................................................
35
ASCII Barcode Table
................................................
39

1
Product Specification
Model-Number
RL6200BT
Connection
Bluetooth+2.4GHz Wireless + Wired
Memory
16MB = 100,000 barcodes
Battery capacity
2000mAh
Voltage
DC 5V
Standby current
30mA
Charging power
5V-400mA
Printing Contract
>25%
Light source
624nm LED
LED life
12000 hours
Button life
5000,000 times
Camera
640*480 CMOS
Illumination
6500K LEDs
Indication
Buzzer & LED
Resolution
4 mil
CPU
ARM 32-bit Cortex
Printing Contract
>25%
Decoding speed
500 times/sec
Scanning angle
Angle of rotation360°, inclination± 65°,declination ± 60°
Anti-interference
0-100000Lux Max
Drop test
2.0m
Certificate
CE，FCC，RoHS ，IP54
Applicable 1D barcode
UPC-A，UPC-E，EAN-8，EAN-13，Code 128， Code 39，Code 93，
Code 11，Interleaved 2 of 5，Standard 2 of 5，Industrial 2 of 5,Coda bar
MSI ，etc.
Applicable 2D barcode
QR Code, Data Matrix，PDF417，Aztec code，Maxicode，etc

2
Packing List
•Bar code scanner*1
•USB Cable*1
•Instruction Manual*1
•USB Wireless Receiver*1
Battery & Charging
The scanner is powered by 2000mAh rechargeable battery.
Please ensure that the scanner has enough power before use.
Battery level indication:
1). Plug in the USB receiver，the blue indicator light of the scanner is on all the time, it
indicates that the battery is sufficient.
2). The lower battery warning: 6 times continuous beeps and the light on the top of
scanner blinks continuously. You need to charge the scanner.
Insert one end of USB cable into the bottom of scanner, and insert another end to
computer USB interface or 5V DC USB interface power
Charging indication:
1. Normal charging: The red light is steady on.
2. Fully charged: The blue light is on, red light goes out.
NOTE:
1. Please use computer USB interface or special 5V DC power adapter for charging, the
abnormal power will cause permanent damage to scanner and battery.
2. To know how much the battery is left, please refer to page 18.

3
Quick Guide
The scanner has 3 connection modes: Bluetooth mode, wireless mode and wired
mode.
Mode 1：Bluetooth mode
1.Turning on the scanner. Scan below “ Bluetooth HID ” and “ Match“ codes in
order. The Bluetooth indicator blinking quickly indicate that the scanner is discoverable
by the Host.
Bluetooth Mode
Match
2.On the Host, use the dedicated Bluetooth application to search for new devices.
Select the “ BarCode Scanner HID” from the list of available devices. When the
scanner finish pairing with the Host, the Bluetooth indicator remains on and the buzzer
beeps “di”.
3. Scan “ Instant upload mode” code allow the scanner to upload barcodes to host
instantly.

4
Instant upload mode
4.Open the Notepad or Word in the Host, put the cursor on the blank, read labels for
testing. When scanner decodes successfully, the scanner will beeps once( The beeper
indication can be turned off. See Decoding Volume Setting on page 12)
Mode 2: Wireless mode
1). Turning on the scanner. Pull the trigger again, the green aiming light and white LED
light will show up. （The scanner has been paired with the receiver, and set up already.）
2). Insert the USB receiver into the USB port of computer. The scanner top light will
steady on blue and have “di”beep, it means the scanner paired successful. (Unplug
the USB receiver from the PC’s port, the scanner top light will blink green twice and
then goes out.
3). Open notepad on computer and move cursor to the blank where scanning output
should be placed. Scanning results can be displayed on notepad then.
If the bar code does not displayed, please set up the scanner again according to the
following steps.
Step 1. Scan the code below to start pairing the USB receiver with scanner.The green
light keep blinking.

5
2.4G Wireless Mode Match
Step 2. Unplug the USB receiver and plug it again, then the scanner will have “di--di”
beep , the light on the top of scanner will turn to green and lighting stably, it means the
scanner paired successful.
Step 3. Scan the code “ instant upload mode “to set the scanner instantly upload
barcode.
Instant upload mode
Step 4. Open notepad on computer and move cursor to the blank where scanning
output should be placed. Scanning results can be displayed on notepad then.
( If there is triple quick “di-di-di”beep, that means paired unsuccessful, please
operate the step1 and step 2 again. )
Mode 3. Wired mode
Step 1. Connect the scanner to your computer via USB cable. When the usb cable is
plugged, the scanner will automatically switch to the wired mode by default.
Step 2. Open notepad on computer, move cursor to the blank, scan a barcode to see if
it can be uploaded

6
FAQs:
Q1. If I scan a product bar code, will it include the name of the product in the file
automatically?
Answer：
The scanner works like a keyboard. It does not interpret what the bar code is, it just
"types" out a string of alphabet numeric characters that the bar code represents.
it's up to the database software you are using to interpret what that string of characters
means. Once you acquire the bar codes, you have to correlate them to something more
meaningful by either purchasing a software service that will interpret the barcode and
relate it to a product, or you can use your own internal inventory system like excel to
assign the bar codes to specific products.
After creating the relationship between your bar code and the corresponded
information ,when you enter the bar code into the software by the scanner,your
software will look up the bar code and then output the related information of your
product.
Q2. Why does scanner not read the bar code exactly. When I use the scanner to read
a bar code of an item, I get a different result from the barcode itself.
Example 1: We use Code 39. it puts an * at the beginning and a * at the end. How do
we program the scanner to read whole bar code? The bar code the computer received
is 123456789. The bar code we need is *123456789*.
Solution： To show the start and stop digit of code39, please scan the code“Code39
start&stop digit -On” on page 30.
Example 2: The original bar code is “ abc12345 ” ， the scanning result is
“+A+B+C+D12348”，the scanner put “+” between character.
Solution：Please scan the code “Code39 Full ASCII-On”on page 29.

7
If that is not your case, please send us a clear picture of the bar code and the result you
get, our customer service will help you to solve the problem.
Q3. Some bar codes can not be read, why?
Answer：
A. Incomplete and unclear bar codes might not be read.
B. It is possible that the setting is off by default for some bar code types which are not
commonly used. You need activate a specific bar code type (on page 21) to get it
working. Please feel free to contact our Customer Service Team for further assistance if
you don't know the exact type of bar code that you are referring to.
Q4. Is there any bar codes to remove auto-enter after every scanning?
Answer: To remove the auto-enter, please scan the code “ Disable end
character”on page 17.
Q5. Is there a way to make the scanner work with a white print on a black background?
Answer: To set the scanner to read white bar code on black ground，please scan the
code “White in black background - On”on page 21, 32, 33.
Example 3：There are two separate bar codes together， it scanned the first 12digits
in the barcode but not the last five.
Solution：please scan the code “UPCA- additional 2 digits-On”on page 22.

8
Optional Function settings
You can change the settings of the scanner by scanning the setup bar codes included
in this manual.
1. Upload Mode Setting
1.1. Instant Upload Mode
Read barcodes and upload the information straightly to the file you have opened
already.
** To set the scanner to upload barcode instantly, scan the following code:
Instant upload mode
Scanning indication: The green indicator light flashes once and the buzzer rang "DI"
when the barcode is uploaded successfully.
1.2. Storage Mode
Read bar codes and store the bar codes in scanner’s memory. Then upload the data
to computer in batches when you need them. Storage saves up to 100,000 bar codes.
** To convert scanner from "instant upload mode" to "storage mode", scan the
following bar code “Storage mode“.
Storage mode

9
** To upload data stored in scanner, put the cursor in the blank, and then scan the
setting code “ Upload Data “, it will upload all the stored bar code at a time.
Upload data
** To show total number of stored bar code, put the cursor in the blank, and then
scan the “Show total storage”bar code. It will out put “ Total Counts： xx ”.
Show total storage
** Scan the barcode “ Clear data ”to clear all the stored barcode. (for storage mode
only)
Clear data
Scanning indication:
(1) The indicator light flashes once and the buzzer rang a fast "De-di" when the
barcode is saved successfully in the built-in memory of the scanner
(2) The red indicator light flashes once and the buzzer rang a slow "DI---en" when the
barcode can not be saved in the built-in memory of the scanner. It means the space of
memory is not enough and cannot store any more barcodes. Please upload the saved

10
barcode by scanning the code "Upload Data" and then clear the saved barcode by
scanning code "Clear Data".
(3) When all of the barcodes are been uploaded completely , the buzzer will ring a
short“ de “ sound.
Note:
In storage mode, the bar code will be stored and will not come up on your computer
instantly. The bar code comes up on your computer only when you scan the settings
code "upload data".

11
2. Scanning Mode Setting
Supporting three kinds of scanning modes.
2.1. Manual Trigger mode (default) :
Press the trigger, the scanner will emit light and read the barcode. Release the trigger,
the scanner will stop reading barcode and the light will go off.
** Scan the following codes to set the scanner to Manual trigger mode .
Manual trigger mode (default)
2.2. Continuous Scanning Mode
There’s no need to press the trigger in this mode. The green light of the scanner will be
on at a certain frequency.
The green scanning light will go off once the scanner scans barcode successfully and
the scanner will enter into next scanning automatically after a intermittent time . And
the green scanning light of the scanner will be on again once the waiting time passes
** Scan the following codes to set the scanner to Continuous Scanning Mode.
.
Continuous Scanning Mode

12
2.3. Auto-Sensing Mode
There’s no need to click the trigger under the Auto-sensing Mode. Just move the
barcodes in front of the scanner, a green light band will show up to read the barcode.
The green light band will go off once the scanner scans barcode successfully or pre-set
timeout expires.
** Scan the following codes to set the scanner to Auto-induction Mode .
.
Auto-sensing Mode
Note： In Auto-sensing Mode. It will be better to set the scanner out to be longer
stand-by time interval. Please refer to the instruction on page 19.
3. Beep Setting
Beep-Off
Low volume
Medium volume
High volume -Default

13
4.Anti-duplication Setting
In continuous scanning mode or auto-induction mode, the scanner might read the
same barcode repeatedly.
Here you can set the time interval to avoid this issue.
** Scan one of the following code to set the time interval.
After reading a bar code, at the pre-set time interval, the scanner can not read the same
bar code.
The scanner can read the same bar code only when pre-set time interval passes.
1s
3s
5s
7s
None
Delay forever

14
5. Aiming & LED Light Setting
5.1 Aiming Mode
The green beam that projected by the scanner can help user to find out the best
reading distance.
Normal mode：green beam appears when the user press the trigger
Always on ： green beam always appears when the scanner is electrified
** Scan one of the following code to select the Aiming mode
Normal mode(default)
Always on
5.2 White LED light Mode
The white beam offers auxiliary lighting for reading.
When the white beam projects on the target object, it can improve the decoding
performance and the adaptability of weak ambient light.
Normal mode： white beam appears when the user press the trigger
Always on ：white beam always appears when the scanner is electrified
** Scan one of the following code to select the led light mode
Normal mode(default)
Always on

15
6. Case Sensitivity Setting
The scanner can change all the letter cases of barcode into uppercase or lowercase.
It takes “ Not Altering the Letter Case of barcodes ” as default, letter case of
barcodes can be altered through scanning correspondent bar code below.
Note: Please deactivated caps lock on keyboard first.
** Scan one of the following code to select the letter case
All upper case
All lower case
No transformation（default）
7.Restore factory setting
To set the scanner back to factory setting, please scan this code
Restore default code

16
8. Identify Barcode Type
This is to identify what type of the barcode is, follow the steps below to confirm:
Scan code "Add Code ID " below, then scan your goal barcode, there will be a
character BEFORE the barcode you scanned, and this character states your Barcode
Type. After that, if you don't need this ID any more, scan the code "Turn off ID
(default)" to hide it.
Add Code ID
Scan
Goal Barcode
Turn off ID (default)
CODE ID
Barcode Type
A
UPC-A, UPC-E, EAN-8, EAN-13
B
Code 39, Code 32
C
Codabar
D
Code 128, ISBT 128
E
Code 93
F
Interleaved 2 of 5/ITF, ITF14
G
Industrial 2 of 5, Standard 2 of 5
H
CODE11
J
MSI, MSI/Plessey
K
UCC/EAN-128/GS1-128
L
Bookland EAN/ISBN，ISSN
