Realme RMV2002 User manual

BLUETOOTH SOUNDBAR WITH WIRED SUBWOOFER
MODEL: realme soundbar
PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATION
AND KEEP IT FOR FUTURE REFERENCE
MODEL: RMV2002

2
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE PART INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
DANGEROUS VOLTAGE:The lighting flash with arrowhead symbol within
an equilateral triangle is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may
be of sucient magnitude to constitute a risk of electric shock to persons.
ATTENTION:The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
injury. Please make sure it is arranged so that it will not drape over a tabletop,
etc. Where it can be pulled on by children or tripped over accidentally.
WARNING: USE UNDER SUPERVISION OF AN ADULT DUE TO LONG
CORD
This unit has a long cord that can be easily tripped on or pulled on, causing

3
Before using the unit, be sure to read all operating instructions carefully,
1. Read these instructions
IMPORTANT SAFETY INSTRUCTIONS
2. Keep these instructions
The safety and operating instructions should be kept for future reference.
3. Heed all warnings
All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions
All operation and use instructions should be followed.
5. Do not use this apparatus near water
The appliance should not be used near water; for example, near a bath tub,
6. Clean only with dry cloth
The appliance should be cleaned only as recommended by the manufacturer.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
please note that these are general precautions. Some of the following may
not pertain to this unit.
All the safety and operating instructions should be read before the appliance is
operated.
washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming
pool.
Slots and openings in the cabinet and in the back or bottom are provided for
ventilation, to ensure reliable operation of the product and to protect it from
overheating. These openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed, sofa, rug, or similar
surface. This product should never be placed near or over a radiator or heat
source. This product should not be placed in a built-in installation, such as a
bookcase or rack unless proper ventilation is provided or the manufacturer's
instructions have been adhered to.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the grounding-type plug. A
grounding type plug has two prongs and a third grounding prong. The third
prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
Portable Cart Warning
to avoid injury from tip-over.
When a cart is used, use caution when moving the
cart/apparatus combination

4
An appliance and cart combination should be moved with care. Quick stop,
excessive force and uneven surfaces may cause the appliance and cart
combination to overturn.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
To protect your product from a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet. This will prevent
damage to the product due to lightning and power-line surges.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, do not operate
normally, or has been dropped.
15. Power source
This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your appliance dealer or local power company. For products
intended to operate from battery power, or other source, refer to the operation
instructions.
16. Power lines
An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of
fire or electric shock.
18. Object and liquid entry
Never push objects of any kind into the product through openings as they may
touch dangerous voltage points or short out parts that could result in fire or
electric shock. Never spill or spray any type of liquid on the product.
19. Service
Do not attempt to service this product yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
20. Replacement parts
When replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the same
characteristics as the original parts. Unauthorized substitutions may result in
fire or electric shock or other hazards.
21. Safety check
Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper
operating condition.

5
22. Wall or ceiling mounting
The product should be mounted to a wall or ceiling only as recommended by
the manufacturer.
23. Damage requiring service
Unplug this product from the wall outlet and refer service to qualified service
personnel under the following conditions.
a) When the power- supply cord or plug is damaged.
b) If liquid has been spilled or objects have fallen into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, as an adjustment of other controls may result in damage and will
require extensive work by a qualified technician to restore the product to its
normal operation.
e) If the product has been dropped or the cabinet has been damaged.
f) When the product exhibits a distinct change in performance- this indicates a
need for service.
PACKAGE CONTAINS
1.realme soudbar
4.Remote Control 5. Power adapter
2. User Manual
3. Subwoofer
7. 4xScrews 8. 4xPlastic plugs
10. HDMI cable
9. 2xBatteries 11. Coaxial cable
6. 2xMetal Bracket

6
MOUNTING
1. Mounting Distance
33.6 inches
2. Mounting to the wooden wall
(853mm)
33.6 inches
A. Mark the position of the mounting screws on the wall.
C. Put the sound bar onto the mounting screws, make it firm and stable.
B. Drill the screws directly into the marks you have made on the wall and
leave 0.25 inches length to hook the soundbar.
3. Mounting to the brick wall
33.6 inches
A. Mark the position of the mounting screws on the wall.
E. Put the sound bar onto the mounting screws, make it firm and stable.
B. Drill 2 holes on wall with a powerful electric drill.
C. Insert the fixing plugs and hammer into the holes.
D. Secure the screws into the fixing plugs and leave 0.25 inches length to
hook the soundbar.

7
PRODUCT OVERVIEW
M
TOP PANEL
REAR PANEL
OPT COAX
ARC
USB
AUX POWER
SUB
DC IN
6 7 8 9 10 11 12
1 2 3 4 5
2. Play/Pause button: press to play or pause.
6. Optical in jack
7. Coaxial jack
8. ARC in jack
9. Subwoofer out jack
10. AUX in jack
11. USB slot
12. DC IN jack
4. Volume down button: press and hold to decrease the volume level, press
to skip to previous track.
5. Volume up button: press and hold to increase the volume level, press to
skip to next track.
1. Mode button: press repeatedly to switch to bluetooth, ARC, USB, optical,
AUX in or coaxial mode.
3. Power on/o button: press to power on or o.

8
FRONT VIEW
13 14 15 16 17 18
13. Remote sensor: for remote control
15. LED indicator 2: ARC mode, light blue
16. LED indicator 3: blinking green for indicating volume level, it will turn red
17. LED indicator 4: optical mode,light blue
18. LED indicator 5: AUX in mode,light blue
14. LED indicator 1: bluetooth mode, blinks blue for pairing, stay blue when
connected successfully.
while the unit enters standby mode.
NOTE: when LED 1 and LED 2 light blue, it indicates USB mode.
when LED 4 and LED 5 light blue, it indicates coaxial mode.
SUBWOOFER
19 20
19. Speaker
20. Cable plug: insert to the SUB jack on the rear panel for amplification.
SUB

1. Power on/o button
2. Bluetooth mode button
3. Previous button
4. Play/pause button
5. EQ mode(MOVIE,MUSIC,NEWS) button
6. Aux/Arc mode button
7.Optical/Coaxial mode button
8. Mute mode button
9. Volume up button
10. Next button
11.Volume down button
12. USB mode button
9
REMOTE CONTROL

10
The remote control sensor at the front of the soundbar is sensitive to the remote
control’s commands up to a maximum of 7 metres away and within a maximum
arc of 30 degrees.Please note that the operating distance may vary depending
on the brightness of the room.
FRONT VIEW
30 30
275.5inches(7m)
POWER SUPPLY
NOTE:The AC input of the adater is 100~240V, 50/60Hz, the output is 24V, 2A.
1. Insert the plug into the other part as shown in step 1.
1
2
3
2. Insert the DC plug to the DC IN jack on the rear of the unit.
3. Insert the AC plug into the AC outlet.
POWER
DC IN AC Outlet
20V,2.5A.20V,2.5A.

11
BLUETOOTH OPERATION
1. Pairing a Bluetooth Device for the first time.
>ll
>l
l<
2. Press the POWER button on the unit or the remote control to switch on
the unit.
3. Press the BT button on the remote control or press the M button on the
unit repeatedly until the LED 1 blinking blue to switch to bluetooth mode.
4. Using the native controls on your Bluetooth device, select the
“realme soundbar” in your Bluetooth settings to pair and try to connect.
5. When successfully paired and connected, a beep will issue from the unit.
After initial pairing, the unit will stay paired unless unpaired manually.
6. If your device should become unpaired or it is unable to connect, repeat the
above steps.After successful paired, the LED 1 indicator will be solid blue.
7.During playing:
Press the or button on remote control to skip tracks.
Press the button on remote control to pause, press it again to resume.
Or Press the button on the unit to pause, press it again to resume.
Or press the - or + button on the unit to skip tracks.
Note:
The unit will be automatically connected with the last connected Bluetooth
device if their Bluetooth function are activated and they are in working range.
8. If you want to disconnect the current connection, press and hold the button
on the unit or press and hold the BT button on remote control for about 2
seconds to disconnect.

12
HDMI(ARC) IN OPERATION
1. You will need: An audio source with an ARC Audio Output and a ARC Audio
cable (not included).
2. Connect the ARC Audio cable to the ARC output on the audio source and to
the ARC Input on the soundbar.
3. Press the POWER button on the unit or the remote control to switch on
the unit.
4. Press the AUX/ARC button twice on the remote control or press the M button
on unit repeatedly until the LED 2 lighting blue to switch to ARC mode.
5. Using the native controls on your connected device, make sure the audio
settings are set to ARC or HDMI Audio and are turned on. Audio from the
connected audio source will now be played through the speakers.
OPT COAX
ARC
USB
AUX POWER
SUB
DC IN
L
R
TV
ARC
REAR PANEL
NOTE:Set the digital output mode to PCM mode only on TV.NOTE:Set the digital output mode to PCM mode only on TV.NOTE:Set the digital output mode to PCM mode only on TV.

13
OPTICAL IN OPERATION
1. Connect the OPTICAL OUT jack from the external audio player (such as TV,
DVD player etc.) to the OPT jack on the rear of the unit.
Connection is illustated below:(For PCM format only)
2. Press the POWER button on the unit or the remote control to switch on
the unit.
3. Press the OPT/COAX button on the remote control or press the M button on
the unit repeatedly until the LED 4 lighting blue to switch to optical mode.
Press the OPT/COAX button on the remote control ONCE to switch to
OPT function. Press this button TWICE to switch to COAX function.
Press this button repeatedly to switch to OPT or COAX.
NOTE:
4. Using the native controls on your connected device, make sure the audio
settings are set to PCM or Optical Audio and are turned On. Audio from the
connected audio source will now be played through the speakers.
OPT COAX
ARC
USB
AUX POWER
SUB
DC IN
L
R
TV
OPTICAL OUT
REAR PANEL

14
AUX IN OPERATION
1. This unit can be connected to the TV and listen through the speakers.
2. Plug one end of the AUX IN cable into the AUX jack on the unit.
3. Plug another end of the AUX IN cable into the L&R jacks on the TV.
5. Power on the connected TV and start playing.
4. Press the AUX/ARC button once on the remote control or press the
M button on the unit repeatedly until the LED 5 lighting blue to switch
to AUX IN mode.
OPT COAX
ARC
USB
AUX POWER
SUB
DC IN
L
R
White
Red
TV
REAR PANEL

15
USB OPERATION
2. Insert USB player to play music automatically.
1. Press the USB button on the remote control or press the M button on
the unit repeatedly until the LED 1 and 2 lighting blue to switch to USB mode.
>ll
>l
l<
3.During playing:
Press the or button on remote control to skip tracks.
Press the button on remote control to pause, press it again to resume.
Or Press the button on the unit to pause, press it again to resume.
Or press the - or + button on the unit to skip tracks.
4. Audio played through the connected USB device will now be heard through
the speakers.
OPT COAX
ARC
USB
AUX POWER
SUB
DC IN
USB
REAR PANEL

16
COAXIAL OPERATION
1. Connect the COAXIAL OUT jack from the external audio player (such as TV,
DVD player etc.) to the COAX jack on the rear of the unit.
Connection is illustated below:(For PCM format only)
2. Connect the Digital Coaxial Audio cable to the optical output on the audio
source and to the Coaxial Input on the soundbar.
3. Press the POWER button on the unit or the remote control to switch on
the unit.
4. Press the OPT/COAX button on the remote control twice or press the M
Press the OPT/COAX button on the remote control ONCE to switch to
OPT function. Press this button TWICE to switch to COAX function.
Press this button repeatedly to switch to OPT or COAX mode.
NOTE:
button on the unit repeatedly until the LED 4 and 5 lighting blue to switch to
coaxial mode.
5. Using the native controls on your connected device, make sure the audio
settings are set to PCM or Coaxial Audio and are turned On. Audio from
the connected audio source will now be played through the speakers.
OPT COAX
ARC
USB
AUX POWER
SUB
DC IN
L
R
TV
COAXIAL
REAR PANEL

17
If the unit does not work properly as desired, please check
the following.
No power / function
1、Check whether the power is switched on
or o at the wall.
2、Check whether the power adaptor is
properly connected to power outlet or not.
3、Press the POWER button on the unit or
remote control to power on
1、Disconnect the unit from your device
and reconnect.
2、The external device is too far from the unit.
Put the external BT device close to the unit.
1、Check whether the battery run out or not.
Replace with a new one if necessary.
2、Check whether there is obstacle on the
front of remote sensor.
1、Switch o and unplug the unit. Leave it for
2 minutes and switch it on again.
2、If a particular mode is causing
problems, please try an alternative
connection to your TV such as Optical or
Bluetooth.
3、Out of range ：Point the remote control
to the remote sensor on the unit within 23
feet, +/-30 degree.
1、Check whether cables are properly
installed. If they are, please try alternative
cable to connect to your TV if possible.
2、Check unit is out of standby and in mode.
3、Raise the volume level by pressing
the + Button on the unit
4、Play music/movie in the paired/connected
device and make sure volume level is high
No sound
Function disturbance
Remote control does not
work [properly]
No sound from Bluetooth
connection
Malfunction Possible causes/measures
TROUBLESHOOTING

Power Supply:
Speaker Output Power
Speaker Size & Number
Speaker Size(Wireless):
Working environment
(Temperature)
Relative Humidity
Frequency Response
Bluetooth Version
Bluetooth Distance
Dimension (LxWxH)
Dimension (LxWxH)
Operating frequency
Number of channels
INPUT:100-240V~50/60Hz 1.2A
OUTPUT:DC24V/2A
1 00W (Soundbar 60W+ Subwoofer 40W)
2.0'' Full range speaker x 2
+ 2.0'' Tweeter speaker x 2
5.25" Subwoofer*1
-10~ + 50℃
35% ~ 85%
20Hz -23KHz
V5.0
10M
940mm x93mm x70mm (Soundbar)
250mm x 1 1 0mm x 350mm (Wired Subwoofer)
2.4GHz
79 channels
SPECIFICATIONS AND ACCESSORIES ARE SUBJECT TO CHANGE
WITHOUT NOTICE.
18
SPECIFICATIONS
20V,2.5A.

Thank you for purchasing realme products. If any manufacturing defect problems occur
within 12 months from the date of purchase, user can enjoy our company's warranty service.
Matters Needing Attention:
1.When you buy the product, the sales unit will issue a valid proof of purchase.
2.The warranty card and the proof of purchase should be kept by the user properly, and
it will not be replaced if lost.
3.If the product fails due to non-human factors, the user can present the warranty card
and proof of purchase to the realme customer service center for free maintenance during
the warranty period.
Non-warranty situation:
This warranty does not cover the following cases:
1. Out of warranty period.
2. Damage caused by use not in accordance with the instructions.
3. Damage caused by man-made causes.
4. Failure caused by unauthorized disassembly, maintenance, or modification of the product.
5. Damage caused by force majeure factors (such as floods, earthquakes, lightning, etc.).
6. There is no warranty card, invoice, or warranty card that does not match the invoice
information.
7. The product wears naturally.
8. Other failures and damages that are not caused by the quality of the product itself.
Website : www.realme.com
Email：[e-mail]
Hotline：[phone]
Warranty

Warranty Card（Stub Copy）
Dear user, thank you for using the product of our company.
Please read and keep properly the warranty card after purchasing the product so that we
can provide better services to you.
User Information
User's name
Phone Number
Address
Email
Product Information
Product Model
Product Serial Number
Sales Information
Purchase Date
Invoice Number
Sales Unit
Phone Number
Address
Warranty Card（Customer Copy）
Dear user, thank you for using the product of our company.
Please read and keep properly the warranty card after purchasing the product so that we
can provide better services to you.
User Information
User's name
Phone Number
Address
Email
Product Information
Product Model
Product Serial Number
Sales Information
Purchase Date
Invoice Number
Sales Unit
Phone Number
Address
