Rean NSB Series Installation guide

1. Assemble strain relief into the end piece with
the hole.
2. A Slide the bushing onto the cable.
B Insert the cable into the strain relief.
3. Prepare the cable according to the drawing.
4. Insert the wire per channel into the cable
clamps of each connector, check the channel
numbering and the pin numbering of the XLR:
1 = shield
2 + 3 = signal wires
Q
Q
A
B
1
2
Lmax for Size
1 = 180 mm [7.0”]
2 = 300 mm [11.8”]
3 = 420 mm [16.5”]
4 = 540 mm [21.3”]
3
4
ASSEMBLY INSTRUCTION
NSB*- Stage box Modular Connector Box System
|
Page 1

6. Preassemble the frames and the end piece with
attached self tapping screws.
Insert the rear plate.
5. Connect the remaining cables with the
connector plates.
- Female plates for INPUTS
- Male plates for RETURNS
7. A Slide in the assembled connector plates into
the extensions and screw on the end piece with
4 screws.
B Tighten the bushing of the strain relief.
INFORMATION
Type A Type B Type C
Accessories:
groups of 4 connectors in individual row numbers for ”IN”
and ”OUT”are available as accessories.
Matching luminescent self-adhesive stickers, labelling
Assembled Stage box
SLIDE IN
A
B
P
P
5
6
7
8
Draft. Nr.: 3102M0621 Update: 23.01.2012
I I Data subject to change without prior notice. 2012 NEUTRIK . ALL RIGHTS RESERVED.
®
©
Page 2
