ASSEMBLY INSTRUCTION
TINY xlr Cable Connector - RT*FC-B & RT*FC-B-W
|
Page 1
Slide the rubber sealing (1) (RT*FC-B-W only)
and the boot (2) onto the cable.
Insert wires into the terminals and solder
them.
Apply the groundring to the cable and position
it on the insert.
Grounding Option: Ground with housing,
solder #1 to the solder lug of the groundring.
Put chuck onto the cable.
Black chuck: O.D. 2.0 - 3.5 mm
Blue chuck: O.D. 3.0 - 4.5 mm
Slide insert and chuck together into the
housing.
Screw the bushing onto the connector.
The RT*FC-B type is ready.
Rubber sealing assembly on page 2.
Prepare cable as shown.
Attention: Pay attention to the key.
Attention: Pay attention to the guiding key.
A
B
C
E
F
D
1
2
10
3
F
Guiding key
Optional grounding
H
H
Guiding key

Draft. Nr.: BDA 260 / 3102M1801 Update: 08.04.2012
I I Data subject to change without prior notice. 2012 NEUTRIK . ALL RIGHTS RESERVED.
®
©
Page 2
ASSEMBLY INSTRUCTION TINY xlr Cable Connector
I
www.rean-connectors.com
Put the assembly hose onto the connector over the
end of the boot (as shown in picture).
Push the rubber sealing onto the assembly
aid.
Hold the cable and pull the assembly tool
jerkily off the connector (the sealing jacket is
pulled in position).
Finish
Attention: Pay attention to the position of the
latch (see the picture).
SINGLE BAG PACKAGING:
The rubber sealing can be easily applied by hand.
BULK PACKAGING:
For large quantity assemblies an assembly hose is supplied with bulk packaging (-D).
Finish
1
2
3
2
1
3
Attention: Pay attention to the position of the latch
(see the picture).
