Rebotec STAND UP-Standard User manual

1
4
BA No.: 02.04.039/2016-12
User Instructions
REBOTEC®Rehabilitationsmittel GmbH
D-49610 Quakenbrück, Artlandstr. 57-59
Telephone: [phone]
Telefax: +49-(0)5431/9416-66
http://www.rebotec.de
E-mail: [e-mail]
Stand-Up Aids
Technical Specifications (Technical specifications subject to change without notice!)
Product
Seat
Seat Tube
Pedestal
STAND UP-Standard
PUR
Steel, coated
Polyamide, black
STAND-UP-Plus
PUR
Steel, coated
Polyamide, black
Aluminium, chrome
SIT UP-Mini
PUR
Steel, coated
Polyamide, black
SIT UP-Maxi
PUR
Steel, coated
Polyamide, black
Art. No.
Name
Design
Seat Height
from - to
Seat Angle
forwards
Max. Body
Weight
315.10.00
Stand-Up Aid Stand UP
Standard
61.0-86.0 cm
15 degrees
150 kg
316.10.00
Stand-Up Aid Stand UP
Plus
57.0-82.0 cm
15 degrees
150 kg
317.10.00
Stand-Up Aid SIT UP
Mini
53.0-72.0 cm
15 degrees
150 kg
317.20.00
Stand-Up Aid SIT UP
Maxi
59.0-84.0 cm
15 degrees
150 kg
Accessories
Art. No.
Name
Design
317.30.10
Rollers, brakes (5 pcs.)
black
317.30.20
5-arm pedestal
chrome
STAND UP
“Standard“
STAND UP
“Plus“
SIT UP
“Mini“
SIT UP
“Maxi“
Serial No. / Product
06/2005 (Th.B.)
GB
Reuse
The product is intended for reuse. The reuse (life) depends on the product state. Before the
re-use of the device maintenance must be carried out and the appropriate
instructions to security, care and maintenance must be observed.
This review shall exclude a possible improper use caused by obvious or invisible
damage. Please refer to the Medical Device Directive (MDD) and the regulation for operator
(MPBetreibV).
Life
The expected life of the products listed in this manual when used in accordance with safety
instructions, maintenance intervals and care instructions is 3 years.
Beyond this period, the product can be set used only in a safe condition. Maintenance should
be done at least every six months. Specific requirements of the product, due to the use of the
patient, causing shorter maintenance intervals.
Warranty
For our Walking Aids we provide a warranty period of 24 months. Wear parts and product
misuse are excluded.
Advisory!
Always keep the User Instructions for future use
The identical serial number in the user manual is also printed on the nameplate of the product.
For complaints or questions, always provide the model, serial no. and the User Instructions no.

2
3
Maintenance
Care
All plastic parts may be easily cleaned using a mild commercially available plastic cleanser.
Observe instructions for use. For the steel tubing it is sufficient in most cases to wipe it with a
damp cloth, and then wipe dry. For the chrome foot pedestal, wiping with a damp cloth and
wiping dry is also sufficient.
Advisory! Do not use solvent containing or oily cleaner!
Maintenance
The Stand-Up Aid is characterised by a long service lifetime and high reliability. Should it fail
to properly function because, for example the gas filled piston no longer operates, do not
attempt to repair it yourself. Contact the nearest specialised dealer or care provider.
Inadequate or negligent care and maintenance leads to limitations or annulment of product
liability by the Manufacturer.
Allow your Stand-up Aid to be checked over by specialised dealer once a year!
For safety reasons only original spare parts may be used.
Safety Instructions!
Be sure the maximum allowable weight for the Stand-Up Aid is not exceeded!
Before each use of the Stand-Up Aid, carefully check it over for damage. If you have any
doubts, then do not use the Stand-Up Aid. Contact your specialised dealer.
DANGER of falling! Do not bend over too far forwards when sitting on the Stand-Up Aid.
DANGER of slipping! Always use CAUTION when using the Stand-Up Aid with wheels
on moist surfaces, loose carpeting or rugs.
Always maintain a stable position when using the Stand-Up Aid.
If unused for an extended time period, have the Stand-Up Aid inspected by a specialist
before using again.
Intended Use / User Advisory
The Stand-Up Aids are designed for persons with limited standing ability and serve to
increase their ability to stand up, and to relieve the patient’s legs and spine.
Further they are a help for patients being fitted with orthoses.
For individual seating requirements, the seat height and the seat angle are adjustable.
The 5-arm pedestal provides stability. The seat may be washed.
Have your specialised dealer or care provider to advise you on using the Stand-Up Aid
and its adjustment for proper function!
Assembly Instructions
The product is delivered in the package not fully assembled. Before using it for the first time,
the following assembly steps must be performed:
1. Remove the pre-assembled components (seat, gas piston, and pedestal) from the
packaging.
2. Insert the gas piston in the pedestal. Next put the seat adapter on the gas piston.
3. Next press with force the seat onto the gas piston so that the two parts are firmly wedged
together.
4. Carefully check the 2 pieces to be sure they are properly fitted together.
Repeat step 3 if necessary.
First-time Use
They Stand-Up Aid is now ready to use. When using the Stand-Up Aid for the first time, the
following points must be observed:
Height Adjustment
By activating the release lever of the gas-filled piston, you can adjust the height of the
Stand-Up Aid.
Sit down on the Stand-Up Aid and pull the lever up.
- Version: STAND UP-Standard Lever at back of seat
- Version: STAND UP-Plus, SIT UP-Mini and Maxi Lever left of seat
The Stand-Up Aid now lifts up to its uppermost position. By loading the seat accordingly, the
desired height can be regulated.
By releasing the lever, the gas piston blocks by itself.
Adjusting the Seat Angle
Version: STAND UP Standard
Using this wrench, loosen the M8 screw at the seat tube and select the desired seat angle.
After selecting the angle, securely tighten the M8 screw.
Version. STAND UP-Plus, SIT UP-Mini, Maxi
Under the seat there is to the right a lever for adjusting the seat angle.
By lifting the lever up, it is possible to press the seat to the desired angle.
After releasing the lever, the seat locks into position by itself.
