Scout 1000 PMD System™Introduction
RECEIVER SENSOR
The Scout 1000 PMD System is a portable, real time perimeter monitoring system.
The Scout 1000 PMD System consists of one Receiver and two Sensors. The two
Sensors come from the factory Pre-programmed to the Receiver in columns 1 and
2. The Receiver can be programmed with up to six Sensors (additional Sensors sold
separately).
The range from a Sensor to the Receiver is generally 75 to 200 yards line-of-sight.
Trees, bushes, hills or buildings in the line-of-sight will reduce the range. The
Receiver is a wrist worn device that alerts the user in four ways:
1. A vibrating motor
2. A ashing LED backlight
3. An Alarm icon on the LCD display
4. A buzzer that the user can turn on and off
The Scout PMD 1000 can be used with alkaline or rechargeable NiMH batteries. Bat-
teries should be removed when storing units for prolonged periods of time.
1
1
2
2
Sensors
Sensors have no user controls. Simply install two AAA
alkaline batteries and Sensors begin working. The bat-
teries will last for about two years of continuous use. The
detection zone (See Figure 1) extends out from the lens
of the Sensor. Best performance is achieved when the
target being detected passes through the detection zone
from left to right or right to left.
The detection range from the Sensor varies with the
difference in temperature between the target and air
temperature. During winter a target may be detected at
a distance of 75 feet or more from the Sensor. However
during hot weather this distance may be reduced to less
than 30 feet. The Sensors should be set to a height that
is at the center mass of the target being detected. Use
this information when setting up your Sensors.
Figure 1
Receivers
Receivers are powered by two AAA alkaline batteries
that last for at least forty hours of continuous opera-
tion with the backlight turned off and twenty hours with
the backlight on. The Receiver has two user controls
and a backlit LCD display so the user can choose and
view options and status information. The user controls
are momentary pushbutton switches. A LIGHT button
toggles the LED backlight on and off, and a MODE but-
ton turns power on and off and moves through all the
user options.
Figure 2 shows the LCD display with all icons turned on. There are ve rows of icons
with the top four rows arranged into six columns. Each column represents one associ-
ated Sensor if it has been programmed. The icons have the following meaning:
ALARM icons come on for ve seconds after a motion message is received
from the associated Sensor.
SIGNAL icons indicate that the Sensors are in range. Since Sensors send a
message once per minute and remain on for one minute each time a message
is received, the SIGNAL icon will remain on for as long as the Receiver is within com-
munication range of the Sensor. Note that when power is turned on it may take up to
one minute for any SIGNAL icon to appear.
3
3
LCD Display
Figure 2
4
PROGRAM icons appear when the Receiver has been programmed to associate a
particular Sensor with that column. Messages from the Sensor associated with a
particular column control the ALARM and SIGNAL icons in that column. ALARM and
SIGNAL icons will never appear for an unprogrammed column.
SELECT icons appear only in PROGRAM mode. The Select icon indicates which
Sensor number is being programmed.
The fth row of icons is not specic to any Sensor and indicates the Receiver’s
mode: MONITOR, OFF, PROGRAM or ERASE. In the case of OFF and ERASE
modes the remaining time in seconds until activation (receiver turns off or program-
ming is erased) is displayed graphically with a 5 second countdown timer as follows:
Turning the Receiver On and Off
If the Receiver is off, then pressing the MODE button once will turn the Receiver
on. The Receiver always comes on in the MONITOR mode. In MONITOR mode the
Receiver will receive messages from any programmed Sensor. Within one minute
the SIGNAL icons for any programmed Sensors will come on if the Sensors are in
communication range. Motion messages from programmed Sensors will turn on the
ALARM icon for 5 seconds, and simultaneously:
1. Vibrate the motor three times.
2. Flash the LED backlight three times.
3. Beep the buzzer three times if it is turned on.
Pressing the MODE button while in MONITOR mode causes the OFF icon to appear
(see Figure 3) and the countdown timer to start. If the MODE button is not pressed
for 5 seconds, the timer will turn the Receiver OFF. The MODE button is the ON/OFF
switch. All programming is saved when the Receiver is off.
Programming / Erasing the Receiver
If the Receiver is in the OFF mode and the timer has not yet counted down to zero,
then pressing the MODE button will place the Receiver in the PROGRAM mode. The
OFF icon and the timer will disappear and the SELECT icon for column 1 will
appear. The Receiver is now ready to program column 1 whether it is already pro-
grammed or not. Now perform the following programming steps:
1. Bring the Receiver within 6 inches of the Sensor you want associated
with column 1.
2. Initiate a motion message by waving your hand in front of the Sensor.
The Receiver will instantly associate column 1 with this Sensor. The PROGRAM
, SIGNAL and ALARM icons will all appear indicating that programming
was successful. Note that close proximity (less than 6 inches) is critical when pro-
gramming because in PROGRAM mode the Receiver requires the signal strength to
be strong. Weak signals have no effect in PROGRAM mode so there is no possibility
of a distant Sensor inadvertently interfering with programming.
If you want to program more columns then press the MODE button to move the
SELECT icon through all 6 columns and repeat the programming steps outlined
above. If you do not want to program a column then simply skip the two programming
steps for that column.
When in PROGRAM mode and the SELECT icon is pointing at column 6, pressing
the MODE button once moves the receiver into the ERASE mode. The ERASE icon
appears and the countdown timer starts. If the timer is left to expire, then all program-
ming is erased and all PROGAM , SIGNAL and ALARM icons disappear.
To enter the Monitor mode from Program mode, without erasing all programmed set-
tings, press the mode pushbutton twice, this will skip the Erase mode.
Turning the Buzzer ON and OFF
When in PROGRAM mode and the SELECT icon is pointing to column 6 a special
situation exists. You can program column 6 as described above, or you can also
toggle the buzzer on and off. To toggle the buzzer, press the LIGHT button twice. An
alarm associated with an incoming motion message will be simulated. The vibrating
motor will vibrate, the LED backlight will ash and the buzzer will sound if it was OFF
before. Pressing the LIGHT button twice more will toggle back to the previous state
causing a new alarm, so this feature can be used to determine the buzzer state. Once
you are nished with the buzzer, use the MODE button to return to the MONITOR
mode.
5
6
Product Walk Through
Step 1 1 2 3 4 5 6 Sensors 1-6
The Receiver has just been turned on. It is in MONITOR mode. Columns 1, 2, 4 and 6
were previously programmed to Sensors.
Step 2 1 2 3 4 5 6
A Signal from the Sensor associated with column 2 has just been received indicating
that Sensor #2 is in range and communicating with the Receiver.
Step 3 1 2 3 4 5 6
A Signal from the Sensor associated with column 1 has just been received indicating
that Sensor #1 is in range and communicating with the Receiver.
4
7
Step 4 1 2 3 4 5 6
A Signal from the Sensor associated with column 4 has just been received indicating
that Sensor #4 is in range and communicating with the Receiver.
Step 5 1 2 3 4 5 6
A minute has elapsed since the Receiver was turned on. No Signal icon in
column 6 indicates Sensor #6 is either out of communication range, the batteries are
dead or the Sensor is not working.
Step 6 1 2 3 4 5 6
A motion message from Sensor #2 has just been received indicating a target has
passed through the Detection Zone. The ALARM icon will remain on for 5 sec-
onds. At this time the motor will vibrate three times, the LCD backlight will ash three
times and the buzzer will beep three times (if it is turned on).
8
Step 7 1 2 3 4 5 6
Pressing the MODE button once will take the user from MONITOR mode to the OFF
mode. A 5 second countdown timer will begin and the Receiver will turn off when it
reaches 0. The user can exit the OFF mode before the timer reaches 0 by pressing
the MODE button once, this will take the user to Program mode with the Select icon
appearing in column 1.
Step 8 1 2 3 4 5 6
To program a Sensor to column 3 press the MODE button 2 times, to move the Select
icon to column 3. The Select icon indicates that column 3 is ready to be
programmed. Now perform the following programming steps:
1. Bring the Receiver within 6 inches of the Sensor you want associated
with column 3.
2. Initiate a motion message by waving your hand in front of the Sensor.
9
Step 9 1 2 3 4 5 6
The Receiver has just received a motion message from the Sensor and has associ-
ated the Sensor with column 3. Column 3 is now programmed as indicated by the
PROGRAM icon . The ALARM icon will remain on for 5 seconds.
Step 10 1 2 3 4 5 6
The user has pressed the MODE button 3 times moving the SELECT icon to
column 6. You can program column 6 or you can also toggle the buzzer ON and OFF.
To toggle the buzzer, press the LIGHT button twice. An alarm associated with an
incoming motion message will be simulated. The vibrating motor will vibrate, the LED
backlight will ash and the buzzer will sound (if it was off before). Pressing the LIGHT
button twice more will toggle back to the previous state causing a new alarm, so this
feature can be used to determine the buzzer state (on or off). Once you are nished
with the buzzer, press the MODE button twice to return to the MONITOR mode or
once to go to the ERASE mode.
10
Step 11 1 2 3 4 5 6
The user has pressed the MODE button once and has entered the ERASE mode. The
countdown timer became active and has counted down 2 seconds. If the user does
nothing, then in 3 seconds all programming will be erased. Press the MODE button
once to prevent programming being erased and return to MONITER mode as shown
in Step 12.
Step 12 1 2 3 4 5 6
The user has pressed the MODE button once before the countdown timer expired
and is back in MONITOR mode. The user has moved through all modes and is back
at the starting point.
LIMITED WARRANTY
Pentar, LLC (“Recon Outdoors”) warrants to the original retail purchaser that product(s) made
by Recon Outdoors and related Recon Outdoors accessories (individually a “Product” and
collectively the “Products”) will be free from defects in materials and workmanship under
normal use and service for a period of one year from the date of initial retail purchase. If any
Product proves to be defective, the customer must return the defective Product to the address
listed below, following the procedure set forth below. However, it is recommended that the
customer rst call Recon Outdoors’ Consumer Support Department at 1-866-647-3266, to
attempt to determine the nature of the problem. Recon Outdoors, at its sole discretion, will
repair, replace, or adjust the defective Product, provided that Recon Outdoors investigation and
factory inspection disclose that (a) such defect developed under normal and proper use and
(b) the Product is covered under this limited warranty. Repair, replacement, or adjustment of
defective Products shall be Recon Outdoors’ sole obligation and the customer’s sole remedy
hereunder. The customer shall pay for shipment of the Products to the Recon Outdoors Service
Center. When service is completed, the Product will be returned to you via ground service
freight prepaid. Recon Outdoors shall not be obligated to perform preventive maintenance,
installation, deinstallation, upgrades, or maintenance. Recon Outdoors reserves the right to (i)
use reconditioned, refurbished, and/or serviceable used parts for warranty or any other repairs
and (ii) make any internal or external design and/or feature changes on or to its products without
any liability to incorporate such changes on or to the Products.
Excluded from this limited warranty and not warranted by Recon Outdoors in any fashion, either
express, implied, or by statute, are:
(a) products and accessories not manufactured by Recon Outdoors and/or not bearing the
“RECON OUTDOORS” brand label (the warranty coverage for products and accessories of
other manufacturers, which may be distributed by Recon Outdoors, is the responsibility of the
manufacturers of such products and accessories in accordance with the terms and duration of
such manufacturers’ warranties);
(b) any Product which has been disassembled, repaired, tampered with, altered, changed, or
modied by persons other than Recon Outdoors’s own authorized service personnel unless
repair by others is made with the written consent of Recon Outdoors;
(c) defects or damage to the Products resulting from wear, tear, misuse, abuse, negligence,
modication, accident, dirt, sand, liquids, impact, improper storage, improper installation, non-
performance of scheduled operator and maintenance items, battery leakage, or use of non-
“RECON OUTDOORS” brand accessories, consumables, or supplies;
(d) supplies and consumables (including but not limited to batteries); and/or
(e) Products which do not contain a validly placed and recorded Recon Outdoors serial number.
EXCEPT FOR THE LIMITED WARRANTY SET FORTH ABOVE, RECON OUTDOORS
MAKES, NO AND DISCLAIMS, ALL OTHER REPRESENTATIONS, GUARANTIES,
CONDITIONS, AND WARRANTIES CONCERNING THE PRODUCTS, WHETHER DIRECT
OR INDIRECT, EXPRESS OR IMPLIED, OR ARISING UNDER ANY STATUTE, ORDINANCE,
COMMERCIAL USAGE OR OTHERWISE, INCLUDING BUT NOT LIMITED TO ANY
WARRANTY OR REPRESENTATION AS TO THE SUITABILITY, DURABILITY, DESIGN,
OPERATION, OR CONDITION OF THE PRODUCTS (OR ANY PART THEREOF) OR THE
11
MERCHANTABILITY OF THE PRODUCTS OR THEIR FITNESS FOR A PARTICULAR
PURPOSE, OR RELATING TO THE INFRINGEMENT OF ANY PATENT, COPYRIGHT,
OR OTHER PROPRIETARY RIGHT USED OR INCLUDED THEREIN. IF ANY IMPLIED
WARRANTIES APPLY AS A MATTER OF LAW, THEY ARE LIMITED IN DURATION TO
THE LENGTH OF THIS LIMITED WARRANTY. SOME STATES MAY NOT RECOGNIZE A
DISCLAIMER OR LIMITATION OF WARRANTIES AND/OR LIMITATION OF LIABILITY SO
THE ABOVE DISCLAIMERS AND EXCLUSIONS MAY NOT APPLY. THE CUSTOMER MAY
ALSO HAVE DIFFERENT AND/OR ADDITIONAL RIGHTS AND REMEDIES THAT VARY
FROM STATE TO STATE.
THE CUSTOMER ACKNOWLEDGES AND AGREES THAT RECON OUTDOORS SHALL
NOT BE RESPONSIBLE FOR ANY DAMAGES THAT THE CUSTOMER MAY INCUR
FROM DELAYED SHIPMENT, PRODUCT FAILURE, PRODUCT DESIGN, SELECTION, OR
PRODUCTION OR FROM ANY OTHER CAUSE, WHETHER LIABILITY IS ASSERTED IN
CONTRACT, TORT (INCLUDING NEGLIGENCE AND STRICT PRODUCT LIABILITY) OR
OTHERWISE. IN NO EVENT SHALL RECON OUTDOORS BE LIABLE FOR ANY INDIRECT,
INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES OF ANY KIND (INCLUDING
WITHOUT LIMITATION LOSS OF PROFITS OR LOSS OF USE), WHETHER OR NOT
RECON OUTDOORS SHALL BE OR SHOULD BE AWARE OF THE POSSIBILITY OF SUCH
POTENTIAL LOSS OR DAMAGE.
Representations and warranties made by any person, including but not limited to dealers,
representatives, salespersons, or agents of Recon Outdoors, which are inconsistent or in conict
with or in addition to the terms of this limited warranty, shall not be binding upon Recon Outdoors
unless reduced to writing and approved by an expressly authorized ofcer of Recon Outdoors.
This limited warranty is the complete and exclusive statement of warranty which Recon
Outdoors agrees to provide with respect to the Products and it shall supersede all prior and
contemporaneous oral or written agreements, understandings, proposals, and communications
pertaining to the subject matter hereof. This limited warranty is exclusively for the benet of the
original customer and cannot be transferred or assigned.
When eligible service is needed, package the Product carefully using ample padding material
to prevent damage in transit and ship it postage prepaid and insured to the Recon Outdoors
Service Center listed below:
Recon Outdoors
Attention: Camera Service Center
906 Bob Wallace Ave SW # F
Huntsville, Alabama 35801
When returning Products for service, your package must include the following:
1. Original sales receipt showing date and place of purchase. This will be required for in
warranty service.
2. Copy of this limited warranty bearing the Product serial number corresponding to the
serial number on the Product.
3. A detailed description of the problem.
12
RECON OUTDOORS SERVICE POLICY
We understand your passion for hunting and your desire to get back in the woods with your
product. Therefore, we will make every effort to repair your unit within three (3) business days
from the receipt of your unit at our factory. This does not include shipping time to and from
our factory. Units received on Friday are typically shipped by the following Wednesday, units
received Monday are typically shipped by Thursday, etc.
All repair work is performed by factory trained technicians to meet exacting factory
specications. Factory-serviced units go through the same rigorous testing and quality control
inspections as new production units.
After the original warranty period, standard service charges will be assessed for each repair
(physical damage and missing parts are not included). Any repairs made after the original
warranty will be warranted for an additional ninety (90) days after service has been performed
by our factory technicians. You can contact our Customer Service Department for current repair
rates.
We reserve the right to deem any product unserviceable when replacement parts are no longer
available or impossible to obtain. This Service Policy is valid in the United States only. This
policy applies only to Recon Outdoors products returned to our factory in Huntsville, Alabama.
This Service Policy is subject to change without notice.
Returning Your Unit for Service
Please contact our Customer Service Department, either by telephone or email, to obtain a
Return Authorization Number before returning your unit for repair. Please have your product
model name and serial number available before calling the factory. If you contact the factory
by email, please include your product model name and serial number in the email, and use
Request for Repair Authorization Number for your email subject header. You should include
your Repair Authorization Number in all subsequent communications about your unit. You will
need a new Repair Authorization Number each time you return a product for repair.
For service, complete the following steps:
● Obtain a Repair Authorization Number from Recon Outdoors Customer Service
● Tag product with your name, street address (NO PO BOX NUMBERS), phone number
and your assigned Repair Authorization Number
● Include a brief written description of the problem
● Return your product freight prepaid to Recon Outdoors using an insured carrier with delivery
conrmation.
NOTE: Our Customer Service personnel will contact you with a quote for the
service of units that are out of warranty. Payment can be made in the form of a credit
card, money order or personnel check. PLEASE DO NOT SEND CASH.
13
14
WARNING! Disassembly and repair of Recon Outdoors products should be performed only by
factory trained personnel. Any modications of the serial number or attempt to repair the original
equipment or accessories by unauthorized individuals will void the warranty. Handling and/or
opening this unit may result in exposure to lead, in the form of solder.
WARNING! This product contains lead, a chemical known to the state of California to cause
cancer, birth defects and other reproductive harm.
Contacting Recon Outdoors
Contact the Recon Outdoors Customer Service Department in any of the following ways:
By telephone: Monday – Friday 8:00 am to 5:00 pm Central Standard Time
866-647-3266
By e-mail (typically we respond to your email within three (3) business days)
For direct shipping, our address is:
Recon Outdoors
Service Department
906 Bob Wallace Ave Suite F
Huntsville, Alabama 35801
Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired operation.
Warning (Part 15.21)
Changes or modications not expressly approved by the party responsible
for
compliance could void the user’s authority to operate the equipment.
FCC Interference Statement (Part 15.105 (b))
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particu-
lar installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Table of contents
