Red Stone RGW Series User manual

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc.
Redstone Manual RGW Series
User Manual
RGW4
RGW8
RGW48
RGW96
Website: http://www.redstonesystems.com
Email: [email protected]om
Document Version: 202205

User Manual RGW Series VoIP Gateway
Amendment Records
Document Rev. 01 (May 2022)
This manual is applicable to Redstone’s RGW series VoIP Gateway V371.
Copyright © 2022 Redstone Systems, Inc. All Rights Reserved.
All or part of this document may not be excerpted, reproduced and transmitted in any form or by any means
without prior written permission from the company.

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 3
Contents
Amendment Records....................................................................................................................................................2
Contents...........................................................................................................................................................................3
Figures..............................................................................................................................................................................6
Tables ...............................................................................................................................................................................9
1 Overview.....................................................................................................................................................................11
1.1 Product Introduction............................................................................................................................................................11
1.2 Functions and Features .....................................................................................................................................................12
1.3 Equipment Structure...........................................................................................................................................................13
1.3.1 RGW4.......................................................................................................................................................................13
1.3.2 RGW8.......................................................................................................................................................................15
1.3.3 RGW48....................................................................................................................................................................17
1.3.4RGW96 .....................................................................................................................................................................19
1.4 Web Management Page....................................................................................................................................................23
1.4.1 Layout.......................................................................................................................................................................23
1.4.2 Buttons Used on Gateway Management Interface............................................................................................23
2 Parameters Setting...................................................................................................................................................24
2.1 Login.....................................................................................................................................................................................24
2.1.1 Obtaining Gateway IP Address ............................................................................................................................24
2.1.2 Logging On to Web GUI........................................................................................................................................24
2.1.3 Privileges of Administrator and Operator (Web GUI)........................................................................................25
2.1.4 Accessing Through SSH .......................................................................................................................................26
2.1.5 SSH user Permissions...........................................................................................................................................26
2.2 Basic Configuration.............................................................................................................................................................26
2.2.1 Status.......................................................................................................................................................................26
2.2.2 Network....................................................................................................................................................................27
2.2.3 VLAN........................................................................................................................................................................29
2.2.4 System.....................................................................................................................................................................31
2.2.5 SIP............................................................................................................................................................................33
2.2.6 High Availability.......................................................................................................................................................35
2.2.7 TLS&SRTP..............................................................................................................................................................36
2.2.8 MGCP.......................................................................................................................................................................37
2.2.9 FoIP..........................................................................................................................................................................39
2.2.10 Alarm......................................................................................................................................................................42
2.3 Line .......................................................................................................................................................................................43
2.3.1 Phone Number........................................................................................................................................................43
2.3.2 Subscriber Line Features......................................................................................................................................44
2.3.3 Subscriber Line Batch (Unavailable on the RGW4) ..........................................................................................46
2.3.4 Subscriber Line Characteristics............................................................................................................................47
2.4 Trunk.....................................................................................................................................................................................50
2.4.1 Phone Number........................................................................................................................................................50

User Manual RGW Series VoIP Gateway
2.4.2 Trunk Features........................................................................................................................................................50
2.4.3 Trunk Batch (Unavailable on the RGW4)............................................................................................................52
2.4.4 Trunk Characteristics.............................................................................................................................................53
2.5 Routing.................................................................................................................................................................................55
2.5.1 Digit Map..................................................................................................................................................................55
2.5.2 Routing Table..........................................................................................................................................................57
2.5.3 Examples of Routing Rules...................................................................................................................................62
2.6 Advanced Configuration.....................................................................................................................................................63
2.6.1 System.....................................................................................................................................................................63
2.6.2 Auto Provisioning....................................................................................................................................................64
2.6.3 Management System Type (SNMP and TR069) ...............................................................................................65
2.6.4Certificate (Available on the RGW4/RGW8)........................................................................................................67
2.6.5 Media Stream..........................................................................................................................................................67
2.6.6 SIP Configuration ...................................................................................................................................................69
2.6.7 RADIUS (Unavailable on the RGW4)..................................................................................................................72
2.6.8 Greeting...................................................................................................................................................................73
2.6.9 Call Progress Tone Plan........................................................................................................................................74
2.6.10 Feature Access Codes........................................................................................................................................75
2.6.11 Clock Service........................................................................................................................................................77
2.7 Security..................................................................................................................................................................................80
2.7.1 Access Security......................................................................................................................................................80
2.7.2 Access list................................................................................................................................................................81
2.7.3 Brute Force Login Prevention...............................................................................................................................82
2.7.4 ACL-based Traffic Filtering ...................................................................................................................................84
2.7.5 Packet Rate Limiting Based Dynamic Blacklisting.............................................................................................85
2.7.6 Voice Security.........................................................................................................................................................87
2.7.7 Encryption................................................................................................................................................................87
2.7.8 VPN (Available on the RGW4/RGW8).................................................................................................................89
2.8 Status .....................................................................................................................................................................................90
2.8.2 Call Status...............................................................................................................................................................90
2.8.3 Call History on FXS................................................................................................................................................90
2.8.4 Call History on FXO................................................................................................................................................90
2.8.5 SIP Message Count...............................................................................................................................................91
2.9 Logs.......................................................................................................................................................................................91
2.9.1 System Status.........................................................................................................................................................91
2.9.2 Call Message ..........................................................................................................................................................92
2.9.3 System Startup .......................................................................................................................................................93
2.9.4 Manage Log ............................................................................................................................................................93
2.10 Tools....................................................................................................................................................................................95
2.10.1 Configuration Management.................................................................................................................................95
2.10.2 Upgrade.................................................................................................................................................................95
2.10.3 Restore Factory Settings.....................................................................................................................................97
2.10.4 Capture Recordings on the Port.........................................................................................................................97
2.10.5 IP Capture.............................................................................................................................................................97
2.10.6 Network Diagnosis (RGW4/RGW8)...................................................................................................................98
2.11 Product Information..........................................................................................................................................................98
2.12 Reboot................................................................................................................................................................................99
2.13 Logout.................................................................................................................................................................................99

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 5
3Appendix: VLAN Configuration..............................................................................................................................100
3.1 Automatic Discovery (Not supported by RGW4/RGW8).............................................................................................100
3.1.1 LLDP.......................................................................................................................................................................101
3.1.2 DHCP......................................................................................................................................................................104
3.2 Manual Configuration .......................................................................................................................................................105
3.2.1 Single VLAN ..........................................................................................................................................................105
3.2.2 Multi-Service VLAN...............................................................................................................................................106
4 Making an OpenVPN Client Certification (RGW4/RGW8).............................................................................112
5 Appendix: High Availability Configuration ......................................................................................................115
6 Appendix: Auto Provisioning Configuration...................................................................................................116
7 Appendix: RJ45 and RJ11 Corresponding Relations....................................................................................117

User Manual RGW Series VoIP Gateway
Figures
Figure 1-1 RGW4 Front Panel ..................................................................................................................................................13
Figure 1-2 RGW4 Back Panel...................................................................................................................................................14
Figure 1-3 RGW8 Front Panel ..................................................................................................................................................15
Figure 1-4 RGW8 Back Panel...................................................................................................................................................16
Figure 1-5 RJ45 to RS232 Serial Cable ..................................................................................................................................16
Figure 1-6 USB to RS232 Converter Cable............................................................................................................................16
Figure 1-7 RGW48 Front Panel................................................................................................................................................18
Figure 1-8 RGW48 Back Panel-AC..........................................................................................................................................19
Figure 1-9 RGW96 Front Panel................................................................................................................................................20
Figure 1-10RGW96 Back Panel-AC.........................................................................................................................................21
Figure 1-11RGW96 Back Panel-DC.........................................................................................................................................21
Figure 1-12 Web GUI..................................................................................................................................................................23
Figure 2-1 Login Interface for RGW8 Gateway Configuration..............................................................................................25
Figure 2-2 Status Interface........................................................................................................................................................27
Figure 2-3 Network Configuration Interface (RGW4/RGW8)................................................................................................27
Figure 2-4 Network Configuration Interface (RGW48/RGW96) ...........................................................................................28
Figure 2-5 VLAN Configuration Interface ................................................................................................................................30
Figure 2-6 System Configuration Interface..............................................................................................................................31
Figure 2-7 SIP Configuration Interface ....................................................................................................................................34
Figure 2-8 High Availability Configuration Interface...............................................................................................................36
Figure 2-9 TLS&SRTP Configuration Interface ......................................................................................................................37
Figure 2-10 MGCP Configuration Interface.............................................................................................................................38
Figure 2-11 Fax Configuration Interface (RGW4/RGW8)......................................................................................................40
Figure 2-12 RGW48/RGW96 Fax Configuration Interface....................................................................................................40
Figure 2-13 Alarm Icon...............................................................................................................................................................42
Figure 2-14 Alarms Interface.....................................................................................................................................................43
Figure 2-15 Configuration Interface for Batch Configuration (Phone Number)..................................................................43
Figure 2-16 Subscriber Line Configuration Interface .............................................................................................................44
Figure 2-17 Feature Batch Configuration Interface................................................................................................................47
Figure 2-18 Subscriber Line Characteristics Configuration Interface..................................................................................48
Figure 2-19 Phone Number Configuration Interface..............................................................................................................50
Figure 2-20 Trunk Line Features Configuration Interface .....................................................................................................51
Figure 2-21 Trunk Batch Configuration Interface....................................................................................................................53
Figure 2-22 Trunk Characteristics Configuration Interface....................................................................................................54
Figure 2-23 Configuration Interface for Digit Map ..................................................................................................................56
Figure 2-24 Routing Table Configuration Interface................................................................................................................58
Figure 2-25 Interface of system advanced configuration.......................................................................................................63
Figure 2-26 Interface of Auto Provisioning Configuration......................................................................................................64
Figure 2-27 SNMP Configuration Interface .............................................................................................................................65
Figure 2-28 TR069 Configuration Interface.............................................................................................................................66
Figure 2-29 Certificate Configuration Interface.......................................................................................................................67
Figure 2-30 Media Stream Configuration Interface................................................................................................................67
Figure 2-31 RGW48/RGW96 Media Stream Configuration Interface..................................................................................68

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 7
Figure 2-32 SIP Related Configuration Interface....................................................................................................................69
Figure 2-33 RADIUS Configuration Interface..........................................................................................................................72
Figure 2-34 Greeting Interface..................................................................................................................................................73
Figure 2-35 Call Progress Tone Configuration Interface.......................................................................................................74
Figure 2-36 Feature Codes Configuration Interface...............................................................................................................76
Figure 2-37 Clock Service Interface.........................................................................................................................................78
Figure 2-38 Access Configuration Interface............................................................................................................................80
Figure 2-39 Access list configuration Interface.......................................................................................................................82
Figure 2-40 Brute Force Login Prevention (Login Retry Lockout) Configuration Interface...............................................83
Figure 2-41 Brute Force Login Prevention (Lockout IP Addresses) Interface....................................................................83
Figure 2-42 Static Defense Configuration Interface...............................................................................................................84
Figure 2-43 Dynamic Defense Configuration Interface..........................................................................................................85
Figure 2-44 Dynamic Defense (Blocked IP Addresses) Interface........................................................................................86
Figure 2-45 Voice Security Configuration Interface................................................................................................................87
Figure 2-46 Encryption Configuration Interface......................................................................................................................88
Figure 2-47 VPN Configuration Interface.................................................................................................................................89
Figure 2-48 Call Status Interface..............................................................................................................................................90
Figure 2-49 Interface of Call History on FXS...........................................................................................................................90
Figure 2-50 Interface of Call on FXO........................................................................................................................................91
Figure 2-51 SIP Message Count Interface..............................................................................................................................91
Figure 2-52 System Status Interface........................................................................................................................................92
Figure 2-53 Call Message Interface .........................................................................................................................................93
Figure 2-54 Interface of System Startup..................................................................................................................................93
Figure 2-55 Manage Log Interface ...........................................................................................................................................94
Figure 2-56 Log Saving Interface..............................................................................................................................................94
Figure 2-57 Path Saving Interface............................................................................................................................................95
Figure 2-58 Configuration Management Interface..................................................................................................................95
Figure 2-59 Upgrade Interface..................................................................................................................................................96
Figure 2-60 Upgrading interface by .img file ...........................................................................................................................96
Figure 2-61 Upgrade Interface..................................................................................................................................................96
Figure 2-62 Restore Factory Settings Interface (RGW4/RGW8) .........................................................................................97
Figure 2-63 Interface for Capturing Port Recordings.............................................................................................................97
Figure 2-64 Ethereal Capture Interface....................................................................................................................................98
Figure 2-65 Automatic Diagnosis Interface .............................................................................................................................98
Figure 2-66 Ping Diagnosis Interface...........................................................................................................................................98
Figure 3-1 Scenario Diagram..................................................................................................................................................101
Figure 3-2 Procedure of Handling LLDP Message Carrying a VLAN ID .................................................................................102
Figure 3-3 Procedure of Handling the LLDP Message with no VLAN ID ................................................................................103
Figure 3-4 LLDP Message.......................................................................................................................................................103
Figure 3-5 Adding a VLAN ID to the Message to Be Sent..................................................................................................104
Figure 3-6 Configuring the Single VLAN................................................................................................................................106
Figure 3-7 A Data Packet Carrying a Corresponding VLAN Tag in the Single VLAN Mode..........................................106
Figure 3-8 Configuring Voice VLAN to Work in Mode 1......................................................................................................107
Figure 3-9 Configuring Voice VLAN to Work in Mode 2......................................................................................................108
Figure 3-10 Configuring Management VLAN........................................................................................................................109
Figure 3-11 Network Environment..........................................................................................................................................109
Figure 3-12 Configuring Multi-Service VLAN........................................................................................................................110
Figure 3-13 IP Addresses of the Device in Multi-Service VLAN.........................................................................................110

User Manual RGW Series VoIP Gateway
Figure 3-14 SIP Data Packet Carrying VLAN Tag of the Voice VLAN in the Multi-Service VLAN Mode.....................111
Figure 3-15 RTP Data Packet Carrying VLAN Tag of the Voice VLAN in the Multi-Service VLAN Mode....................111
Figure 3-16 RTP Data Packet Carrying VLAN Tag of the Management VLAN in the Multi-Service VLAN Mode ......111
Figure 7-1 Schematic Diagram of Subscriber Line Connection .........................................................................................117

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 9
Tables
Table 1-1RGW Series Gateway Hardware Specifications...................................................................................................11
Table 1-2 Configuration Combination of RGW4....................................................................................................................13
Table 1-3 Description of RGW4 Front Panel.........................................................................................................................14
Table 1-4 Description of RGW4 Back Panel..........................................................................................................................14
Table 1-5 Indicator Status of RGW4.......................................................................................................................................14
Table 1-6 Configuration Combination of RGW8....................................................................................................................15
Table 1-7 Voice Interface Cards Supported by the RGW8..................................................................................................15
Table 1-8 Description of RGW8 Front Panel.........................................................................................................................15
Table 1-9 Description of RGW8 Back Panel..........................................................................................................................16
Table 1-10 Indicator Status of RGW8.....................................................................................................................................16
Table 1-11 Configuration Combination of RGW48...............................................................................................................18
Table 1-12 Description of RGW48 Front Panel.....................................................................................................................18
Table 1-13 Description of RGW48 Back Panel.....................................................................................................................19
Table 1-14 Meanings of RGW48 Indicators...........................................................................................................................19
Table 1-15 RGW48 System Operation Status ......................................................................................................................19
Table 1-16 RGW96 Interface Card .........................................................................................................................................20
Table 1-17 Configuration Combination of RGW96...............................................................................................................20
Table 1-18 Description of RGW96 Front Panel.....................................................................................................................20
Table 1-19RGW96 Back Panel ...............................................................................................................................................21
Table 1-20 Meanings of RGW96 Indicators...........................................................................................................................21
Table 1-21RGW96 System Operation State..........................................................................................................................22
Table 1-22 Web GUI Layout Description ...............................................................................................................................23
Table 2-1 Default IP Address of Gateway..............................................................................................................................24
Table 2-2 Default Passwords for logging to Web GUI..........................................................................................................25
Table 2-3 Network Configuration Parameters.......................................................................................................................28
Table 2-4 VLAN Configuration Parameters...........................................................................................................................30
Table 2-5 System Configuration Parameters ........................................................................................................................32
Table 2-6 Codec Methods Supported by Gateways.............................................................................................................32
Table 2-7 SIP Configuration Parameters...............................................................................................................................34
Table 2-8 Parameters...............................................................................................................................................................36
Table 2-9 TLS&SRTP Configuration Parameter...................................................................................................................37
Table 2-10 MGCP Configuration Parameters........................................................................................................................38
Table 2-11 Fax Configuration Parameters.............................................................................................................................40
Table 2-12 Alarm Type.............................................................................................................................................................42
Table 2-13 Configuration Parameters of Batch Configuration (Phone Number)..............................................................43
Table 2-14 Subscriber Line Configuration Parameters........................................................................................................44
Table 2-15 Subscriber Line Characteristics Configuration Parameter...............................................................................48
Table 2-16 Configuration Parameters of FXO Phone Number...........................................................................................50
Table 2-17 Configuration Parameters of Trunk Features....................................................................................................51
Table 2-18 Trunk Characteristics Configuration Parameter................................................................................................54
Table 2-19 Description of Digit Map........................................................................................................................................56
Table 2-20 Number Transformations......................................................................................................................................59
Table 2-21 Routing Table Format...........................................................................................................................................60

User Manual RGW Series VoIP Gateway
Table 2-22 Routing Destination...............................................................................................................................................61
Table 2-23 NAT Configuration Parameters............................................................................................................................64
Table 2-24 Auto Provisioning Configuration Parameters.....................................................................................................65
Table 2-25 SNMP Configuration Parameters........................................................................................................................66
Table 2-26 TR069 Configuration Parameters........................................................................................................................66
Table 2-27 Media Stream Configuration Parameter.............................................................................................................68
Table 2-28 SIP Related Configuration Parameter................................................................................................................70
Table 2-29 RADIUS Configuration Parameter ......................................................................................................................72
Table 2-30 Greeting Configuration Parameters....................................................................................................................73
Table 2-31 Call Progress Tone Configuration Parameters..................................................................................................74
Table 2-32 Feature Codes Configuration Parameter...........................................................................................................76
Table 2-33 Clock Service Parameters....................................................................................................................................79
Table 2-34 Access security setting parameters ....................................................................................................................81
Table 2-35 Login Retry Lockout Parameters.........................................................................................................................83
Table 2-36 Brute Force Login Prevention (Lockout IP Addresses) Information...............................................................83
Table 2-37 Static Defense Configuration Parameters..........................................................................................................84
Table 2-38 Dynamic Defense (Rule Configuration) Parameters ........................................................................................85
Table 2-39 Dynamic Defense (Blocked IP Addresses) Information...................................................................................86
Table 2-40 Subsequent choices for moving the Blocked IP Addresses to static defense ..............................................86
Table 2-41 Parameters for voice security ..............................................................................................................................87
Table 2-42 Encryption Configuration Parameters.................................................................................................................88
Table 2-43 VPN Configuration Parameters...........................................................................................................................89
Table 2-44 System Status Parameters...................................................................................................................................92
Table 2-45 Log Management Configuration Parameters.....................................................................................................94
Table 7-46 Pin Specifications for RJ45 Socket Port...........................................................................................................117

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 11
1 Overview
1.1 Product Introduction
RGW Series intelligent VoIP Gateways (RGW Gateways) are designed to bridge the traditional
telecom terminal device into IP networks through SIP or MGCP protocols. The main applications
include:
For carriers and value-added service providers to provide telephone, fax and voice-band data services
to subscribers using IP access methods such as FTTB, HFC, and ADSL;
To bridge the traditional telecom terminal equipment, such as PBXs, to the VoIP core networks of
carriers;
To connect with an enterprise PBX to provide IP-based voice private network solutions for institutions,
enterprises and schools;
To be used as remote access equipment for IP-PBXs in call center deployment
The RGWfamily has four sub-series: RGW4, RGW8,RGW48, and RGW96, which mainly differ in
port capacities.
Table 1-1 RGW Series Gateway Hardware Specifications
Model
Voice
ports
Chassis
Installation
CPU
RAM
Flash
Power
RGW4
2/4
Plastic
Casing
Desktop
Dual-core
processor, 880MHz
256MB
16MB
12 VDC
RGW8
8
Metal
Desktop or rack
Dual-core
processor, 880MHz
256MB
16MB
12 VDC
RGW48
16 - 48
19-inch
wide and
1U High
Rack
TI A8, 1GHz
128MB
32MB
100-240
VAC, -36 to
-72 VDC
(optional)
Dual power
(optional)
RGW96
48- 96
19-inch
wide and
2U High
Rack
TI A8, 1GHz
256MB
32MB
100-240
VAC, -36 to
-72 VDC
(optional)
Dual power
(optional)

User Manual RGW Series VoIP Gateway
12 Redstone Systems, Inc.
Hardware for RGW series gateways uses high-performance CPUs, ensuring that each product of the
series can achieve full-capacity concurrent calls with high speech quality.
RGW gateways software adopts the stable and reliable embedded Linux operating system (OS),
implementing scores of business phone functions, including: call forwarding, call transfer, call hold,
teleconference, caller identification, Do Not Disturb, ring-back tone, hunt group simultaneous ring,
distinctive ring, one phone with two numbers, and fax. In addition, RGW gateways are featured with
FXO port second stage dialing with voice prompt, routing table with a maximum of 500 entries, phone
digit manipulation, and PSTN failover upon power-off or network disconnection.
RGW gateways support local and remote management operations through Web GUI or SSH,
SNMPv2-based and TR069/TR104/TR106-based centralized management schemes, andauto
provisioning. Maintenance tasks such as modifying configuration, upgrading software, collecting
statistical data, downloading logs, and fault alarms can be performed.
Note: PSTN failover upon power-off or network disconnectionis supported by devices with both the
FXS port and the FXO port.
1.2 Functions and Features
Connect analog telephone, PBX, facsimile machine and POS machine to the IP core network, or
PSTN
Work with a service platform to provide various telephone supplementary services
Support protocols: SIP, MGCP
Support STUN. Detecting changes of the reflexive address of the device via STUN, and then
triggering re-registration to the SIP registrar server.
Flexible configuration of subscriber/trunk interfaces
Support G.711, G.729
Support echo cancellation
Up to 500 routing rules can be stored in gateways
Intercom
Support concurrent calls under full load
Support call progress tones for various countries and regions
Support Line second stage dialing or voice prompt
Support PSTN failover on power or network failure
Security strategy: IP filter, encryption
Support PSTN failover through FXO ports
Support G.711 fax pass-through and T.38 fax relay
Support polarity inverse detection and busy tone detection
3-way calling
Compatible with unified communication solutions, such as CallManager, Lync,Asterisk and
FreeSWITCH
Support SNMPv2 and TR069/TR104/TR106

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 13
Support Web GUI-based management , SSH, automatic software upgrades, and configuration
downloading
Support high availability, implementing a cloud of SIP servers working in primary-standby or load
balancing mode
Support auto provisioning
Support security settings such as accessing whitelists
Message waiting indications (MWI) with high voltage, FSK, or reversed polarity
Support accessing the Web GUI by using HTTPS
Support Ping blocking
Support optional voice interface cards (only supported by the RGW48/RGW96)
Support the VPN client (only available with the RGW4/RGW8)
Support VLAN
Support Redstone Cloud, allowing Redstone devices located behind NAT or firewall to be easily
accessed.
1.3 Equipment Structure
1.3.1 RGW4
The RGW4 adopts a compact plastic structural design and can be placed on a desk.
It provides either two or four FXS/FXO ports.
The RGW4 supports the following models.
Table 1-2 Configuration Combination of RGW4
Models
Number of FXS Ports
Number of FXO Ports
RGW402
2
0
RGW420
0
2
RGW422
2
2
RGW440
0
4
RGW404
4
0
Figure 1-1 RGW4 Front Panel

User Manual RGW Series VoIP Gateway
14 Redstone Systems, Inc.
Table 1-3 Description of RGW4 Front Panel
Item
Description
Power Indicator
WAN
WAN interface indicator
PC
PC interface indicator
FXO/FXS
FXS/FXO port indicator
Figure 1-2 RGW4 Back Panel
Table 1-4 Description of RGW4 Back Panel
Item
Description
PWR
Power interface, 12 VDC input
PC and
WAN
The PC port is used to connect a computer.
The WAN port is used to connect the uplink network.
Both are 10/100 Mbps Ethernet ports (RJ45). They share one IP address, which, by default, is obtained
through DHCP. If no IP address is obtained, 192.168.2.218 is used by default, and you can change it on
Basic > Network page.
FXO/FXS
FXS port or FXO port
Table 1-5 Indicator Status of RGW4
Indicator
Status
Description
PWR(green)
Blinking green
The device is starting.
Steady green
The device is running.
Off
The device is powered off or a power supply fault occurred
STU
(red, green)
Steady red
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
address failed to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing failed.
Blinking red
The device is starting or the KUPDATE is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration failed.
Blinking green
Calling.
Off
Registration has not started.

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 15
Indicator
Status
Description
WAN
(green)
Steady green
A WAN connection is established without any service flow.
Blinking green
A WAN connection is established with service flow.
Off
WAN interface is disconnected.
PC
(green)
Steady green
A link is connected without any service flow.
Blinking green
A service flow is being transmitted.
Off
A link is not connected.
FXS/FXO
(green)
Steady green
Off-hook or call established on FXS port
Blinking green
Ringing of incoming callon FXS port or no line is connected on FXO
port
Off
The port is in idle status
1.3.2 RGW8
The RGW8 adopts a compact metal structural design. It can be placed on a desk or installed in a
standard communications cabinet and provides eight analog ports. RGW8 supports the following types
of configuration.
Table 1-6 Configuration Combination of RGW8
Models
Number of FXS Ports
Number of FXO Ports
RGW8-4S/4
4
4
RGW8-8S
8
0
RGW8-8FXO
0
8
Table 1-7 Voice Interface Cards Supported by the RGW8
Voice Interface Card Types
Number of FXS Ports
Number of FXO Ports
401A-4FXS
4
0
401A-4FXO
0
4
401A-2FXS/2FXO
2
2
Figure 1-3 RGW8 Front Panel
Table 1-8 Description of RGW8 Front Panel
Item
Description
PWR
Power indicator
STU
Status indicator

User Manual RGW Series VoIP Gateway
16 Redstone Systems, Inc.
Item
Description
WAN
WAN interface indicator
PC
PC interface indicator
VOICE
FXS/FXO port indicator
Figure 1-4 RGW8 Back Panel
Table 1-9 Description of RGW8 BackPanel
Item
Description
CON
The console port is used for local management and testing. PCs can be connected to device by linking
the RS232 port to CON port.
Connecting cables need to be produced or purchased.
If the connection is established between the device and the mobile PC with no RS232 ports, please use
the cable together with a USB to an RS232 converter cable.
Cables are shown below in Figure 1-5 and Figure 1-6.
PC/WAN
The PC port is used to connect a computer.
The WAN port is used to connect the uplink network.
Both are 10/100 Mbps Ethernet ports (RJ45). They share one IP address, which, by default, is obtained
through DHCP. If no IP address is obtained, 192.168.2.218 is used by default, and you can change it on
Basic > Network page.
FXO/FXS
FXS port or FXO port
Figure 1-5 RJ45 to RS232 Serial Cable
Figure 1-6 USB to RS232 Converter Cable
Table 1-10 Indicator Status of RGW8
Indicator
Status
Description
PWR (green)
Blinking green
The device is starting.
Steady green
The device is running.
Off
The device is powered off or a power supply fault occurred.

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 17
Indicator
Status
Description
STU
(red, green)
Steady red
The WAN interface failed to acquire the IP address. Possibly the WAN
interface is not connected to a network cable, the WAN interface
address fails to be acquired by DHCP, the IP addresses are conflicted,
and the PPPoE dialing fails.
Blinking red
The device is starting or the KUPDATE is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration failed.
Blinking green
Calling
Off
Registration has not started.
WAN
(green)
Steady green
A WAN connection is established without any service flow.
Blinking green
A WAN connection is established with service flow.
Off
WAN interface is disconnected.
PC
(green)
Steady green
A link is connected without any service flow.
Blinking green
A service flow is being transmitted.
Off
A link is not connected.
VOICE
(Green-FXS,
yellow-FXO)
Indicates line type and device status:
Blinking yellow
The device is starting and the port is an FXO port.
Blinking green
The device is starting and the port is an FXS port.
Off
No line is detected. Possibly the voice interface card is not inserted or
the port is damaged.
Indicates running status:
Steady yellow
Calling in or out via an analog trunk.
Blinking yellow
Ringing of incoming call onFXO portor no line is connected on FXO
port
Steady green
Off-hook or call established
Blinking green
Ringing on incoming call
Off
The port is in idle status
Note: The device starts up for approximate 30s to indicate line type, then indicates running
status.
Indicator of button:
RST
To restore the RGW8 to factory default, press the RST for more than 3 seconds and release it
when the STU light starts blinking in red. This setting will be valid after rebooting the device.
1.3.3 RGW48
Designed with a 1U high and 19-inch wide compact chassis, RGW48 is suitable for installation in a
standard cabinet. RGW48 has a built-in power module with the rating voltage of 100-240 V AC or -48 V
DC (DC is optional). Optionally, the device may use dual power supplies. The interface card of RGW48

User Manual RGW Series VoIP Gateway
18 Redstone Systems, Inc.
uses a RJ-45 socket and is connected to the distribution panel in the equipment room by using CAT-5
cables. RGW48 offers up to 48 analog line ports and supports the following configurations:
Table 1-11 Configuration Combination of RGW48
Models
Number of FXS Ports
Number of FXO Ports
RGW48-16S
16
0
RGW48-32S
32
0
RGW48-48S
48
0
RGW48-16FXO
0
16
RGW48-32FXO
0
32
RGW48-48FXO
0
48
RGW48-8S/8
8
8
RGW48-24S/8
24
8
RGW48-40S/8
40
8
RGW48-16S/16
16
16
RGW48-32S/16
32
16
RGW48-24S/24
24
24
Figure 1-7 RGW48 Front Panel
Table 1-12 Description of RGW48 Front Panel
Item
Remarks
Each interface slot has four RJ45 sockets; each RJ45 socket corresponds with four pairs of analog
lines. CAT-5 cables are used to connect the interface card and distribution panel in equipment
installation. For corresponding relations of RJ45 and RJ11, see 7 Appendix: RJ45 and
RJ11Corresponding Relations.
Note: Numbers of interface slots vary from different configuration. Numbering definition of interface
slots: on the left side of chassis is #1 slot (marked with No.1 to 16), in the middle of chassis is #2 slot
(marked with No.17 to 32), on the right side of chassis is #3 slot (marked with No.33 to 48).
Matrix of 4 x 4 LED status indicators on the interface card. Each column of LED indicator matrix
matches four telephone lines on a RJ45. The first column on the left matches Line 1-4 respectively
from top to bottom, the first column on the right matches Line 13-16 respectively from top to bottom,
and the middle columns in the same manner.

RGW Series VoIP Gateway User Manual
Redstone Systems, Inc. 19
Figure 1-8 RGW48 Back Panel-AC
Table 1-13 Description of RGW48 Back Panel
Item
Description
Ground pole
PWR/STU/ALM
Indicator, see Table 1-14 for description
USB
USB interface
CON
Configuration interface (CON), used for local management and debugging
ETH1/ETH2
Two 10/100 MbpsEthernet ports (RJ45). They share one IP address, which by default is
192.168.2.240, and you can change it on Basic > Network page.
AC power socket, 100-240 VAC voltage input.
Table 1-14 Meanings of RGW48 Indicators
Mark
Function
Status
Description
PWR
Power
Indication
Green
Power on
Off
Power off
STU
Status
Indication
Off
System locked and inactive
Blinking green
Normal operation
ALM
Alarm
Indication
Off
No alarms
Blinking red
New alarms occurred but not confirmed.
Steady Red
System in the process of powered up and not in the normal operation mode
Red
Alarms existed and all alarm information confirmed.
Table 1-15 RGW48 System Operation Status
Glittery Letter
Status
Blinking with C
IP address conflicts
Blinking with D
Device startup failure
Blinking with E
Network failure
Blinking with P
Software upgrading
Blinking with T
App exited (the device cannot be used normally)
1.3.4 RGW96
Designed with a 2U high and 19-inch wide compact chassis, RGW96 is suitable for installation in a
standard cabinet.

User Manual RGW Series VoIP Gateway
20 Redstone Systems, Inc.
The interface card of RGW96uses a RJ-45 socket and is connected to the distribution panel in
equipment room using CAT-5 cables supplied with the unit.
The device of RGW96can hold four interface cards to flexibly configure FXS and FXO ports, and each
card equips 24 ports. RGW96can provide up to 96 ports. It supports the following configurations:
Table 1-16 RGW96 Interface Card
Type
FXS Ports
FXO Ports
24FXS
24
0
24FXO
0
24
16FXS/8
16
8
12FXS/12
12
12
Table 1-17 Configuration Combination of RGW96
Models
Number of FXS
Ports
Number of FXO
Ports
Concurrent calls
Description
RGW96-NA-X
Depend on the models and number of
the interface cards.
Depend on the value of X.
X=C, it is 24
X=D, it is 48
X=E, it is 72
X=F, it is 96
Single AC power
RGW96-NA-X-2AC
Dual AC power
RGW96-NA-X-1DC
Single DC power
RGW96-NA-X-2DC
Dual DC power
Figure 1-9 RGW96 Front Panel
Table 1-18 Description of RGW96 Front Panel
Item
Description
Matrix of 6x4 LED status indicator on interface card. Each column of LED indicator matrix
matches four telephone lines on a RJ45. The first column on the left matches Line 1-4
respectively from top to bottom, the first column on the right matches Line 21-24 respectively
from top to bottom, and the middle columns in the same manner.
SLOT1~4
Four interface slots; each contains one 24-port interface card. CAT-5 cables are used to connect
the interface card and distribution panel in equipment installation. For corresponding relations of
RJ45 and RJ11,see7 Appendix: RJ45 and RJ11Corresponding Relations.
Numbering definition of system interface slots: on the low-left side of chassis is #1 slot (marked
with No.1 to 24), on the low-right side of chassis is #2 slot (marked with No.25 to 48), on the
up-left side of chassis is #3 slot (marked with No.49 to 72), and on the up-right side of chassis is
#4 slot (marked with No.73 to 96).
Note: The interface card is hot swappable, but you should reboot the device after the
replacement of the interface card!
