RedBack Lasers DGL1010VS User manual


CONTENTS
User Safety 2
Introduction and DGL1010VS Accessories 3
DGL1010VS Diagram 4
Operating Instructions 6
Batteries 6
Power and Tilt Mode 7
Grade Setting 8
Vertical Rotation Mode 11
Laser Receiver LR715/LR720 13
Calibration Self Check & Technical Specications 15
Warranty 16
User Safety
• Laser output sign lies near the output aperture.
• Do not stare directly into laser beam.
• Do not disassemble the instrument or attempt to
perform any internal servicing. Repairs and service
should be performed only authorised service
centres of Redback Lasers.
• This instrument complies with the safety
Classication standards of laser radiation.
2
CAUTION: Class 3r laser <5mW at 635nm.
Do NOT stare into laser beam or aim at
another person.
Follow relevant Australian Standards
Copyright © CMI LasersTM RedBack lasersTM and Level1LasersTM . All rights reserved CMI Industries Pty Ltd 2014
No artwork or photographs produced by CMI Industries Pty Ltd may be used copied or reproduced without the written consent
from CMI Industries Pty Ltd

3
DGL1010VS INTRODUCTION
Congratulations on purchasing the DGL1010VS an electronic self levelling
dual grade rotating laser level built tough to handle the harshest of job sites.
The DGL1010VS is ideal for building, plumbing and earthmoving, simply
set it up on a tripod, turn on, it electronically self levels and the laser starts
rotating. Then using the supplied receiver you can set up your levels or
grades.
The DGL1010VS has fully automatic dual grade setting capability simply
punch in the desired grade to three decimal places either on the keypad or
remote and the laser does the rest. The sophisticated grade and levelling
technology continually re levels and re-sets the grade if required.
The DGL1010VS also features a smart long range remote control complete
with an LCD display duplicating the display on the laser level itself. This
make setting grades and the DGL1010VS other features a snap.
The DGL1010VS can also be used on its side for vertical alignment and site
square layout and has scan modes essential for indoor visible use.
The DGL1010VS comes with superior rechargeable Li-ion batteries but
can also use Std “D” Size batteries if needed and comes with a Five Year
RedBack Warranty. (See page 16)
www.redbacklasers.com.au
DGL1010VS Included Accessories
• DGL1010VSLaserUnit
• HardShellCarryCase
• RechargeableLi-ionBatteries
• Charger
• LaserReceiver(LR715 or LR720)
• ReceiverStaffClamp
• GradeAlignmentScope
• SmartRemoteControl
• Side Plate for Squaring
• Axis Adjustment Plate
• InstructionManual

4
DGL1010VS DIAGRAMS
DGL1010VS Laser Unit 1
2
3
1. Alignment Scope
2. Scope Mount
3.RotatingHead
4.HeavyRubberisedCasing
5. Keypad
6. LCD Display
Keypad
5
4
Power On/Off (laser level)
Setting Grade %
Tilt On/Off
Manual Mode
6
Setting Grade
Axis
Remote
Channel Select
Re-Level &
Backlight
Scan Modes & Adjustment
Vibration, Wind
Setting
Rotation & Speed

5
www.redbacklasers.com.au
Smart Remote Control
Receiver - LR715
LCD Display
Power On/Off (remote)
Tilt On/Off
Reception
Sensors
Rubber Casing
LCD Display
(Repeated on rear)
Bubble Vial
(top and side)
Control Panel
Ruberised Casing
Setting Grade Axis
Setting Grade %
Manual Mode
Vibration, Wind Setting
Remote Channel Select
Re-Level & Backlight
Rotation & Speed
Scan Modes & Adjustment
Receiver - LR720
Magnets
(top and side)

6www.redbacklasers.com.au
DGL1010VS OPERATING INSTRUCTIONS
Battery Instructions
To charge this battery pack simply inserting the charger plug into the charging
socket found on the hinged battery compartment cover. You can also charge
the Li-ion pack without it inserted into the laser itself utilising the charging
socket on the battery pack. The charger LED is illuminated red during the
charging process and will turn green once the batteries are fully charged.
When the power symbol on the laser levels LCD shows low, the rechargeable
battery needs recharging or standard batteries need replacing. Note the
charger will only charge the supplied rechargeable battery pack. The battery
symbol on the remote control LCD indicates the power level of the remotes
batteries.
Handy Hints
•
Prior to initial use, charge the rechargeable batteries for at least 8
hours.
•
Runningrechargeablebatteriescompletelyatwillincreasebatterylife.
•
The DGL1010VS can operate off mains by plugging the charger (for
indoor use only) into the unit when re-chargeable pack is inserted.
•
Remember the DGL1010VS can operate using standard batteries when
rechargeable pack is out of charge.
•
The rechargeable pack can be charged either when inserted into the
laser or separate to it.
The DGL1010VS has two battery options either 3 x standard “D” size Alkaline
or the Li-ion rechargeable pack. For standard 3 x “D” alkaline operation
simply insert into the standard battery caddy in the direction indicated, insert
caddy into recess and tighten the locking screw.
To use the rechargeable battery
pack rst remove standard
batteries if inserted and place
rechargeable pack into the
same battery recess, tightening
locking screw.

7
www.redbacklasers.com.au
Turning Laser On
Press Power button on the laser’s keypad to turn on the DGL1010VS.
Batteries are low if power bar on the LCD panel is showing low. After turning
the laser on, the laser will auto level and rotate. Note that the power button
on the remote only operates the remote and not the laser. The DGL1010VS
has a massive self levelling range, in other words the body of the laser can
be set up on the tripod along way out of level and the electronic mechanism
will self level the rotating head to be level. If the body of the laser is set up
outside of this self levelling range the laser will emit a continuous beeping
sound. Turn off the laser and re-set the body of the laser more level and
turn on again.
Tilt Mode
Tilt mode is somewhat similar to tilt on a pinball table in that if when running
theDGL1010VSdetectssignicantdisturbanceormovementthatcouldalter
the accuracy of your work the laser will “Tilt” (stop working) and the laser
beamsandtheword“TILT”ontheLCDscreenwillash.
Tilt mode automatically activates after 30 seconds of laser operation. To
turn the tilt feature off use the “tilt” button on either the keypad or the
remote control. The word “TILT” will come up on both LCD screens when
activated.
If during operating the laser “tilts” then you will need to re level the laser by
pressing the level button on the remote or keypad, wait a few seconds
for it to level and then re-check your work to maintain maximum accuracy.
It is recommended to use tilt mode when optimal accuracy is required or
when there is a chance that machinery or worker may interfere inadvertently
with the lasers level.

8
DGL1010VS OPERATING INSTRUCTIONS
Setting Slope/Grades (refer to diagram page 9)
The DGL1010VS can digital dial in a grade as a percentage to three decimal
places. In Slope (Grade) Mode you can set a Grade in either the X or the Y
Axis of up to 10.000% see the markings on top of laser for axis alignment.
In Slope (Grade) mode the “TILT” and “V-W-S” features can still be used.
The DGL1010VS is dual grade, so a grade can be set on the X and Y axis
simultaneously. Slope (Grade) can be set from either the laser’s keypad or
the remote and the grade being selected is shown on both LCD displays.
Usingthescopeandaxisadjustmentplateaidsaccuratealignmentofaxis.
• Turn the laser on, allow to level and begin rotating.
• To select a grade on the “X” axis (see markings on top casing) press
and hold 2 seconds the “X/Y” button on the keypad/Remote. The
“X”and“+”willashontheLCDscreensagradecannowbeseton
the “X” axis.
• To select a negative grade i.e slope up in the direction of the “-X” (on
casing) press the down arrow button . To change back to a positive
slope press the up arrow button .
• Next press (short press) the “X/Y” button to shift the active digit one
placetotheright.Usetheuparrowtoincreasethepercentage
required and use the down arrow to reduce it. For example we
wanttoseta1.666%slopesoleavethisrstdigitto“0”.(Thisrst
digit is only if you want to set the maximum possible percentage grade
of 10.000% in that situation you would set the digit to “1”)
• Press (short press) the “X/Y” button to shift the active digit another
place to the right and use the up and down arrows to select the required
number, in this example “1”. Then repeat the operation again press
“X/Y” button and arrows to select the next three digits to “6” until we
get the 01.666% in our example.
• Next long press (2 seconds) the “X/Y” button this makes the “Y”
axisactive(ash)andagradecanbesetinthesamemannerthe“X”
Axis was set or if no second grade is required leave all digits as “0”. To
seal in these grades and to tell the laser to set them another long press
of the “X/Y” button is required or no not enter anything for 8 seconds,
The laser will beep and after a few seconds of setting the grades the
laser will rotate with the desired grade/grades. The laser will take
longer to set larger and dual grades.

9
Direction Setting (-) for negative (+) for positive
First Digits of Percentage
Next Three Digits
“X” Axis
“Y” Axis
NOTE: In grade mode if nothing is entered for 8 seconds, whatever has
already been entered will be set and the laser will grade and rotate. If you
have not entered all the numbers then re-enter grade mode by pressing the
X/Ybuttonandnishenteringallthedigitsyourequire.
www.redbacklasers.com.au

10
DGL1010VS OPERATING INSTRUCTIONS
Rotation Speed Setting
The DGL1010VS has 3 rotation speeds; 300rpm, 600rpm and 1100rpm with
the default being 600rpm. For most situations this default value will be
ideal but when using machine receivers better results may be achieved with
a different rotation speed at different distances. Also when used indoors
visually different speeds may be clearer to see. Rotation Speed Button.
V-W-S Vibration and Wind Sensor Setting
LCD Display Light
The DGL1010VS has a backlight feature for the LCD display which is turned
on and off with the Level/Light button a long press will toggle between
on and off. The Same button on the remote control will operate the back
light on the remote control LCD display.
The DGL1010VS when sensing any movement will temporarily stop the
rotation of the laser, re-level and start up again. However, sometimes in
high wind or near heavy machinery, vibrations may cause the laser to pause
rotation like this so regularly that it slows your work down.
The “V-W-S” button is a vibration/wind sensor, activating this will
desensitise the laser to these vibrations and so allow you to continue to
work without it stopping all the time. When you turn on the “V-W-S” the
“TILT” function is also activated this ensures that even though you have
desensitised the laser it is still protected from major knocks or movement
that may affect the accuracy of your levelling/grading job.
Manual Levelling Mode
Manual mode stops the auto levelling mechanism operating so enabling you
to set the body of laser at any angle you want and have it rotating. This can
be useful for setting large manual grades on dam walls or indoor alignment
such as roof lines or balustrades.
“V-W-S” and “TILT” cannot be used in manual mode and any movement or
change of angle of the laser will not be indicated to the user.
• To enter manual mode rst power up laser then press and hold (2
seconds) Manual button “MAN” will be displayed on the LCD
displays, press again to disable. On remote is the Man/Sleep button.

The DGL1010VS can be used on its side for vertical alignment or together
with the dot laser out of the front to produce a 90 degree square for site
layout. The DGL1010VS can be placed on its side either directly on a tripod
or on its included side plate with the datum marker and roughly levelled
using the adjustment feet and bubble vial, this brings the laser into self
levelling range where the electronics take over. Press On/Off button to
self level.
Note in vertical rotation mode features such as “TILT”, “V-W-S” and “Scan”
can still be used the same as when in normal horizontal rotation mode.
Once levelled and rotating you can electronically aim the dot laser to a target
left to right by pressing and holding the grade/slope arrow button the
longer you hold the faster the dot moves. This is useful for site layout
squaring;
• Place datum marker over the datum point marking the conjunction of
the 90 degree lines.
• Roughly align laser housing so dot is striking target point along the one
line of the 90 degrees, then use the direction buttons to electronically
netunethisalignment.
• Once the dot is on the target use the receiver to pick up the rotating line
on the second line of the 90 degree. Your square is now set.
11
Vertical Rotation Operation (refer to diagram page 4)

12 www.redbacklasers.com.au
Rotation Scan Modes - For Indoor Visibility
The DGL1010VS is also useful for indoor visual levelling and alignment, with
Scan Mode you can produce horizontal level lines on walls or when operated
on its side, vertical lines.
The Scan Mode stops the laser from rotating and toggles the beam left to
right, intensifying the beam making the laser more usable indoors as a visible
laser. To activate scan mode press the Scan Mode button .You can set
the scan angle to 180o, 45o, 10oand DOT each press of the scan mode button
toggles through the different angles. To shift the beam use the left and right
Scan Adjustment buttons . Scan Mode can be operated by both the
Control key pad on the laser and also the Remote Control. To return the
DGL1010VS back to rotating mode press the Rotation button .
DGL1010VS OPERATING INSTRUCTIONS
Remote Control Operation (refer to diagram page 5)
The DGL1010VS has a sophisticated radio frequency remote control with full
LCD display that provides real time information to and from the laser. Radio
frequency means that you have you an exceptional range of up to 50m it
also means easier communication even from within the cab of a machine.
TheLCDDisplaymeansthatallthefeaturesofthelaserareatyounger
tips, you can even instantly see from the display if the laser has “tilted” and
press the level button to getting it going again without leaving the cab.
The receiver has multiple channels the default being channel #1 the channel
number is displayed on both the LCD on the DGL1010VS and the remote
bottom left corner. If you have a second DGL1010VS on site the channel
can be changed on the second laser and remote so as not to interfere, this is
done by pressing the Remote button and toggling to the next channel.
Note this needs to be set separately on both the laser and remote unit so
both show the same channel number, if the laser does not detect a turned
on remote on the selected channel the antenna symbol on the bottom left
corner of the laser LCD has a line through it.

13
www.redbacklasers.com.au
Laser Receiver LR715 standard issue (refer to diagram page 5)
The LR715 is a heavy duty dual sided display rotating laser receiver, it can be
either hand held or with the staff bracket clamped onto a staff. The bubble
vials can be used to keep the receiver level.
• A press of the power button toggles the receiver on and off.
• The Speaker button toggles through 3 speaker volumes.
• Pressing the Coarse/Fine Mode button toggles through 3 levels,
therstbeingnemodeindicatedbyontheLCD,theaccuracy
of level is at its highest with 1mm tolerance movement by the receiver
before showing off level. The next coarser mode allows 2mm
before showing off level the third press shows no symbol on the LCD
and allows 3mm before showing off level, these two coarser modes are
more suitable for general site levelling.
• The Back Light button toggles the LCD display back light.
The LR715 has two large LCD displays with progressive bars indicating when
the laser gets closer to the level mark. Move the receiver up and down slowly
and watch the display change when the solid tone is heard and the centre
line is shown then the receiver is at the height of the laser beam plane. The
receiver will auto power down after 10 minutes when not receiving laser
pulses. Note receivers do not work in Scan mode.
RECEIVER INSTRUCTIONS
Indicates laser beam is below
line - slide receiver down.
Indicates laser beam is above
line - slide receiver up.
Indicates laser beam is on the
line.
Power and Battery Life Indicator
Coarse/Fine and Speaker Indicator
DGL1010VS OPERATING INSTRUCTIONS
The DGL1010VS sold as a standard package includes the RedBack LR715
receiver. The DGL1010VSR720P special package includes the LR720 receiver.

14
Laser Receiver LR720 special R720 package (refer to diagram page 5)
• Topowerupthereceiverpresstheredpowerbuttonthedisplaywillasha
solid tone will sound. The receiver will now pick up any red rotating laser beam
striking the long red reception window on the front of the receiver.
LR720 is supplied with the DGL1010SVR720 special package and differs from the
LR715 in that it displays the actual millimetres from level.
Power Button
ChangeUnitsMeasured
(mm, inch)
Sound Options,
Back Light
Accuracy Options
(1,5 or 9mm)
Custom Zero Set
The LR720 has a 130mm reception range as indicated by the long red window on the
front of the receiver. When displaying the height of the laser compared to the level point
in mm the LR720 will display up to +/- 45mm from level, between 45mm and 65mm
aboveorbelowtheLCDdisplaywillindicate“OUT”andtheappropriateLEDlightswill
ash.Whena measurement isdisplayedit indicates thedistance between leveland
where the laser is actually striking the receiver, the arrows and LED lights indicate which
side of level the laser is. This allows you to quickly and accurately to guide the receiver
to the level of the laser beam being emitted by your rotating laser level.
• To select sound option press the Sound button (long press) which will cycle
through; off, low, high (default) sound levels.
• To select Accuracy press the Accuracy Options button which will cycle through
level bands of; 5mm, 9mm and 1mm (default). The default single line between
thetwoarrowsonthedisplayindicatesnemode1mm,3lines5mmand5lines
is9mm,themmvalueashesupontheLCDdisplaymomentarily.
• Unitsofmeasurecanbeselectedwiththe“units”buttonmillimetresisdefault,
you could also select cm, and inches.
• The “OSET” button is used to set a customised level point other than the default
level point as indicated by markings on the casing. A custom level point can be
set between 20mm above and 20mm below the default level point. A custom
level point is set to where the laser is currently striking (assuming it is within
the +/-20mm band) by pressing the “OSET” button the receiver (while laser is
strikingit)willnowshowasbeinglevelatthatheighttheLCDdisplaywillash
“Oset” to indicate a custom level point has been set. To clear this custom level
and return to the default setting either press the “OSET” button once more or
power off the receiver.
Battery Level
Sound Indicator
Accuracy Indicator
Measurement Above
or Below Level
UnitofMeasure
Light Indicator
Custom Zero
Indicator

15
• Keep laser and accessories stored in protective case.
• Make sure laser is stored dry, dry out before storage to prevent damage.
• Remove batteries when not used for an extended period of time to prevent
leakage.
• The DGL1010VS is a precision instrument and should not be subjected to
excessive knocks, drops or vibrations.
• Self check calibration from time to time.
• For service contact Redback Lasers. www.redbacklasers.com.au
Laser Wavelength 635nm <5mW
Laser Class 3r
Range with Receiver 600m Diam Rotating
HorizontalAccuracy ±1mm/20m
Gradient Setting Single Axis ±10% (max)
Dual Axis ±10% (max)
Rotation Speeds 300rpm, 600rpm
Self Levelling Range ±5
o
Temperature Range -20
o
C - 50
o
C
IP Dust Water Resistance IP66
Power 4 x “D” Alkaline or Li-ion pack
Low Power LCD Display
Size 220x200x280mm
Weight 5Kg
Calibration & Self Check
All Redback Lasers have been checked for calibration and certied by one of our
technicians here in Australia prior to despatch and should under normal conditions
not go out of calibration. A calibration certied sticker with the date and name of
technician is located on the laser itself. It is worth checking calibration from time to
time particularly after any known knocks or drops. An easy way to continually check
calibration is to always double check you work with the laser located in a different
position or use an alternate vertical line. Various other methods for checking calibration
can be found at www.redbacklasers.com.au/downloads or the laser can be
returned to our service department for checking and re-calibration. We at Redback
Lasers provide a once off free calibration and check within the duration of the warranty
period see page 16 for details.
Accuracy Indicator
Measurement Above
or Below Level
Custom Zero
Indicator
DGL1010VS Technical Specications
• The LCD backlight function is activated by the same button as Sound Options
to activate press and hold button for two seconds and back light will turn on, to
turn off press and hold same button for two seconds.
• Low Battery is indicated by a battery symbol appearing on the bottom left of the
LCD display.

REDBACK LASERS WARRANTY
Durationofwarrantyisxedandautomatic,whenweadvertise5yearsonaparticularmodel,
itsveyears.Nodropdowntoalessertimeifyouforgettoregister,registrationisNOT
required just proof of purchase showing date.
Although the duration of our warranties are for a particular period it does not mean we will
charge you for a genuine warranty failure a month or two outside that warranty period, we
believe in a fair go.
Even though a product shows signs of accidental damage, scratches and the like, we will not
automatically fail the warranty claim, if the fault is NOT caused by a drop or misuse and is a
genuine warranty failure then we will cover it.
Calibration is not covered by warranty much the same as the wheel balance on your car is not
covered by warranty, we do however offer a one off free re-calibration service during the period
of warranty, conditions and details below.
RedBack LasersTM distributed by CMI Industries Pty Ltd
P.O. Box 7324 - Geelong West - Victoria - 3218 - Australia
CMI Industries Pty Ltd provides consumers with a warranty to our products, this is in addition to requirements of any
relevantlegislationsuchastheCompetitionandConsumerAct2010.Denitions:
“CMI”, “We” or “Our” refers to CMI Industries Pty Ltd (ABN 29 102 713 922) of 18b Tarkin Crt, Bell Park, Victoria 3215
ph 1800 769 858
“You” or “Consumer” refers to the initial purchaser of the product.
“Product” refers to goods manufactured by or for CMI Industries Pty Ltd under the brands of RedBack Lasers,
Level1Laser and CMI Lasers.
“Material” refers to material or component used in the construction and manufacture of the product.
“Workmanship” refers to handling, assembly and manufacturing processes done by or for CMI Industries Pty Ltd in
order to manufacture the products.
“Warranty Period” For the DGL1010VS is Five Years. Warranty period is from original purchase date, no extension is
made in the event of warranty replacement products supplied or time spent being repaired.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
CMI warrants that our products will be free from defects in material and workmanship for the warranty period.
CMI promises to repair or replace, free of charge, the product or part of product if found to be faulty due to defective
workmanship or materials within the duration of the warranty as long as the following terms and conditions are met;
•Productmustnothavebeenmisusedorabused,mustnothaveincurredaccidentaldamageorhadun-authorised
repair or tampering that has caused or contributed to its fault or failure.
•YoumustcontactCMIbyphone,mailoremailimmediatelywhenafaultordefecthasbecomeapparentandwithin
the warranty period.
•ProductmustbereturnedtostoreofpurchaseordirectlytoCMI,wewillcovercostofpostageonlywhensentby
our reply paid Australia Post service (Australian Main land and Tasmania only) details will be provided upon phone, post
or email communications with us.
•CMIwillcovercostoffreightbackofrepairedorreplacedproducttooriginalpurchasestoreoryoudirectly
(depending on how it was sent Australian Main Land and Tasmania only).
•CMIwilldeterminewhethertorepairorreplacetheproductorpartofproductonacasebycasebasis.
•Furtherexclusionsinthiswarrantyincludedamageordefectcausedbyuseofnon-originalaccessoriesorparts,
damage in transportation, normal wear and tear, damage through moisture, damage due to electric surge, failure due
to neglect or damaged caused by adjustments not outlined in CMI’s instructions.
Subject to the requirements of all applicable Australian Acts or legislation and to the extent permitted by law, CMI
accepts no liability (whether expressed or implied) of any nature whatsoever for any loss of earnings, hiring of
replacement equipment, Inaccurate work carried out by the consumer or agent, damage or injury arising as a result of
any fault in the product. It is the consumers responsibility to maintain good working practices and regularly test their
tools for accuracy and serviceability.
Calibration of the product is not covered by warranty subject to the requirement of all applicable Australian Acts or
legislation and to the extent permitted by law, CMI does however offer a free re-calibration service (once within the
period of the warranty) you are liable for the cost to send the product to us then we will recalibrate and return the
product to you free of charge. Note this offer is invalid if the product shows signs of misuse or accidental damage that
has caused it to go out of calibration.
A CMI product returned that fails to fall within the terms and conditions of this warranty will be quoted for repair.
Table of contents
Other RedBack Lasers Measuring Instrument manuals
Popular Measuring Instrument manuals by other brands

Chatillon
Chatillon DFS II-R-ND user manual

Elbro AG
Elbro AG SMSB482 quick reference

Roche
Roche cobas Urisys 1100 Operator's manual

Environmental Express
Environmental Express CL 200 instruction manual

Amptec Research
Amptec Research 620LK Installation, operation and maintenance manual

SATO
SATO SK-950A instruction manual

TSI Instruments
TSI Instruments PORTACOUNT 8020 Addendum

York Survey Supply
York Survey Supply 346010 operating instructions

Union
Union INCA1021 Translation of the original operating instructions

Kanomax
Kanomax ANEMOMASTER LITE 6006 user manual

CloudMinds
CloudMinds XI MR-5S user guide

AST
AST TI-1800 user manual
