Redexim Speed-Clean 1000 User manual

User manual
SPEED-CLEAN 1000-1700
Translation of the original user manual
2201 English 947.120.214 EN
Kwekerijweg 8 | 3709JA | Zeist | The Netherlands |
T: [phone]
E: [e-mail]
W: www.redexim.com

2
EU –DECLARATION OF CONFORMITY
We,
Redexim Handel- en Exploitatie Maatschappij B.V.
Kwekerijweg 8
3709 JA Zeist, The Netherlands
declare that this “EU - DECLARATION OF CONFORMITY” is issued under our sole responsibility
and belongs to the following product:
SPEED-CLEAN WITH MACHINE NUMBER AS INDICATED ON THE MACHINE AND IN THIS
MANUAL,
to which this declaration refers, complies with stipulation of:
2006/42/EC Machinery Directive
and with the standards:
•ISO 12100-1:2010 Safety of machinery - General principles for design - Risk assessment and risk
reduction
•ISO 13857:2019 Safety of machinery - Safety distances to prevent hazard zones being reached
by upper and lower limbs
•ISO 4254-1:2015 Agricultural machinery - Safety - Part 1: General requirements
Zeist, 03-01-2022
C.H.G. de Bree
Redexim Handel- en Exploitatie Maatschappij B.V.

3
UK –DECLARATION OF CONFORMITY
We,
Redexim Handel- en Exploitatie Maatschappij B.V.
Kwekerijweg 8
3709 JA Zeist, The Netherlands
declare that this “UK - DECLARATION OF CONFORMITY” is issued under our sole responsibility
and belongs to the following product:
SPEED-CLEAN WITH MACHINE NUMBER AS INDICATED ON THE MACHINE AND IN THIS
MANUAL,
to which this declaration refers, complies with stipulation of:
S.I. 2008 No. 1597 HEALTH AND SAFETY The Supply of Machinery (Safety) Regulations 2008
and with the standards:
•ISO 12100-1:2010 Safety of machinery - General principles for design - Risk assessment and risk
reduction
•ISO 13857:2019 Safety of machinery - Safety distances to prevent hazard zones being reached
by upper and lower limbs
•ISO 4254-1:2015 Agricultural machinery - Safety - Part 1: General requirements
Zeist, 03-01-2022
C.H.G. de Bree
Redexim Handel- en Exploitatie Maatschappij B.V.

4
FOREWORD
Congratulations on your Speed-Clean purchase. For safe and long-lasting operation of this
Speed-Clean it is necessary to read and understand this user’s manual.
Without full knowledge of the contents it is impossible to work with this machine safely.
The following page deals with the general safety instructions first. Every user must know these
and use them. After this a registration card is entered that needs to be returned in order to be
able to deal with later claims.
In this users’ manual many instructions are given, which are numbered in order. You should act
according to this order. If a is used, this points to safety instructions. If a is used, this
means a tip and/or note.
All information and technical specifications provided at the moment that this document is
published are the most recent ones. Design specifications may be changed without prior notice.
This document is a translation of the original operating instructions.
Upon request, the original operating instructions are available in Dutch.
WARRANTY PROVISIONS
THIS SPEED-CLEAN IS SUPPLIED WITH A WARRANTY AGAINST DEFECTS IN MATERIALS.
THIS WARRANTY IS VALID FOR A PERIOD OF 12 MONTHS FROM THE PURCHASE DATE.
SPEED-CLEAN WARANTEES ARE SUBJECT TO THE “GENERAL CONDITIONS FOR SUPPLY OF
PLANT AND MACHINERY FOR EXPORT, NUMBER 188”, PUBLISHED UNDER THE AUSPICES OF
THE UNITED NATIONS ECONOMIC COMMISSION FOR EUROPE.
REGISTRATION CARD
For your own information, complete the table below:
Serial number machine
Dealer name
Purchase date
Remarks

5
! SAFETY INSTRUCTIONS !
Fig. 1
Speed-Clean has been designed to be used
safely. This can only be done if the safety
instructions described in this manual are followed
fully.
Read and understand (Fig. 1) the manual before
you start using the Speed-Clean.
If the machine is not used as described in the
manual there is the risk of injury and/or damage to
the Speed-Clean.
(1) When using the machine the operator must be competent and must have
competently adjusted the machine to the surface to be treated.
With incompetent usage and damage resulting from it the manufacturer will not
accept any responsibility; all risks associated with this are the sole responsibility of
the user.
Incompetent usage also includes not following the manufacturer’s directions for use,
maintenance or repairs.
Before using the Speed-Clean, first inspect the area to be treated.
Remove loose obstacles and avoid irregularities.
(2) The Speed-Clean has been manufactured according to the latest technical insights
and is safe for use.
Should the machine be used, maintained or repaired by inexpert persons, then there
is a risk of injury to both the user and third parties. This must be avoided!
(3) All persons that have been designated by the owner to operate, maintain or repair the
Speed-Clean, must have read and fully understood the user’s manual and especially
the chapter Safety instructions.
The operator is responsible for the safe usage of the Speed-Clean.
(4) The operator is required to check for visible damage and defects before he/she
starts using the Speed-Clean. Alterations to the Speed-Clean (including its operation)
that influence the safety negatively must be remedied immediately.
Making alterations or additions to the Speed-Clean (excluding those approved by the
manufacturer) are not permitted, in principle, for safety reasons.
If modifications to the Speed-Clean have been made, then the current CE mark is
cancelled and whoever made these modifications must apply for a new CE mark
himself.

6
Check the Speed-Clean for loose bolts/ nuts/ parts every time before using it.
If present, check the hydraulic hoses regularly and replace them if they are damaged
or show signs of ageing. The replacement hoses should comply with the technical
demands of the manufacturer.
If present, before work is done to it, the pressure should always be taken off the
hydraulic installation.
In the absence of protective covers and safety stickers the Speed-Clean must
NEVER be used.
NEVER crawl under the Speed-Clean.
Turn the Speed-Clean over if necessary.
When performing maintenance, adjustments or repairs it is necessary to block the
Speed-Clean from sagging/moving/sliding away.
When performing maintenance, adjustments or repairs always turn off the tractor’s
engine and remove the tractor’s key from the ignition. (Fig.2)
Fig. 2
For maintenance and repairs only use original Speed-Clean parts for safety of
machine and operator.
Repairs of the Speed-Clean may only be performed by authorised technical
personnel.
Keep an account of repairs.
(5) Besides the instructions in this user’s manual, the generally safety and instructions
should be followed.
When using the public highway the applicable traffic regulations also apply.
Transporting people is not permitted!
Do not use the Speed-Clean in the darkness, during heavy rainfall/ storms or on
slopes with an angle over 20 degrees.

7
(6) Before commencing the work, all persons who will operate the Speed-Clean must be
familiar with all its functions and operational elements.
On the sides of the Speed-Clean safety stickers (Fig. 5) are applied with an identical
meaning. These safety stickers must be properly visible and legible at all times, and
be replaced when damaged.
During operation NO persons without the proper personal protective equipment
are permitted in the danger area of the Speed-Clean, because there is danger of
physical injury there from spurting materials (Fig. 3).
Fig. 3
Fig. 4
Bystanders without personal protective equipment must keep a minimum
distance of four metres (4 metres)! (Fig. 4)
Wear functional clothes. Wear heavy shoes with steel toecaps, long trousers, long
hair done up and no loose-fitting clothes.
Use the proper personal protective equipment according to the applicable safety
instructions.
Fig. 5
(7) Position of safety stickers. (Fig. 5)

8
TABLE OF CONTENTS
EU –DECLARATION OF CONFORMITY................................................................................... 1
UK –DECLARATION OF CONFORMITY................................................................................... 3
FOREWORD.............................................................................................................................. 4
WARRANTY PROVISIONS........................................................................................................ 4
REGISTRATION CARD.............................................................................................................. 4
! SAFETY INSTRUCTIONS ! .............................................................................................. 5
1.0 TECHNICAL DATA .......................................................................................................... 9
2.0 GENERAL DESCRIPTION............................................................................................... 9
3.0 FIRST INSTALLATION ...................................................................................................10
4.0 COUPLING / DISCONNECTING.....................................................................................11
5.0 WORKING DEPTH ADJUSTMENT OF BRUSH..............................................................12
5.1 ADJUSTABEL RAKE / REAR BRUSH ............................................................................13
6.0 TRANSPORT OF THE SPEED-CLEAN..........................................................................14
7.0 THE DRIVING SPEED....................................................................................................14
8.0 THE USE OF THE SPEED-CLEAN.................................................................................14
9.0 START/STOP PROCEDURE..........................................................................................14
10.0 EMPTYING OF THE DIRT RECEIVING BIN...................................................................15
11.0 PROBLEM ANALYSIS....................................................................................................16
12.0 MAINTENANCE..............................................................................................................17
12.1 ADJUSTABLE GUARD PLATE ADJUSTMENT ..............................................................18
12.2 CHANGING OF THE VIBRATION SIEVE .......................................................................19
12.3 GREASE POINTS...........................................................................................................20
13.0 OPTION: MAGNETIC BROOM.......................................................................................21

9
1.0 TECHNICAL DATA
Model
Speed-Clean 1000
Speed-Clean 1700
Working width
970mm (65.7”)
1670mm (65.7”)
Working depth (With brush not worn out)
0mm -10mm (0”-0.4”)
0mm -10mm (0”-0.4”)
Driving speed
Max. 12km/h (7.4mph)
Depending on ground
conditions.
Max. 12km/h (7.4mph)
depending on the conditions of
the surface.
Weight
165 Kg ( 365 lbs)
220 kg ( 485 lbs)
3-points connection
Cat. 1 small
Cat. 1
Minimal lift capacity at the lift
eyes
200 Kg (440 Ibs)
250 Kg (550 Ibs)
Contents receiving bin
25ltr. (1525 cu. inch.)
2x 20ltr. (2x1220 cu. inch.)
Maximum capacity
(Theoretical with speed; 10 Km/h (6.2mph))
9700 m2/h (104410 ft2/h)
16700 m2/h (179750 ft2/h)
Drainage vibrating sieve
(Standard delivered)
5mm x 5mm (0,2 “ x 0,2”)
5mm x 5mm (0.2 “ x 0.2”)
Shipping dimensions
L x B x H
1720 x 1200 x 728 mm
67,7" x 47.2" x 68"
L x W x H
1720 x 1900 x 728 mm
67,7" x 74.8" x 68"
Standard parts
- Removable dirt receiving bin.
- Ground-hugging dragging brush.
- Easily changeable sieve.
- Manual cylinder with manual and tool set.
- Rake section
Options
- Sieve elements with various drainage dimensions.
2.0 GENERAL DESCRIPTION
The Speed-Clean is a surface cleaning machine for cleaning artificial turf.

10
3.0 FIRST INSTALLATION
Fig. 6
The machine is delivered on a pallet in transport position. To take the machine off the pallet and
place it horizontally, act as follows: (Fig. 6).
!! NEVER CRAWL UNDER THE MACHINE !!
1. Attach a cable to the lifting points on both sides of the machine, and to the top of the 3-
point hitch on the front.
2. Lift the machine about 50 mm (2”) off the ground.
3. Remove the pallet by removing the bottom 3-point pins (1) and (2).
4. Pull the pallet from under the machine.
5. Slowly rotate the machine horizontally.
6. Lower the machine in a controlled and slow fashion until it is fully on the ground.
Make sure the cable/crane/lift has the capacity to lift at least 500 kg (1000 lbs).
