Redline Communications RedMAX 4C REM3500M User manual

70-00121-01-00 Proprietary Redline Communications © 2009 Page 1 of 34 October 20, 2009
Outdoor Wireless Access
Subscriber Modem
REM Series
User Manual

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 2 of 34 October 20, 2009
Copyright Information
All rights reserved October 20, 2009. The information in this document is proprietary to
Redline Communications Inc. This document may not in whole or in part be copied,
reproduced, or reduced to any medium without prior consent, in writing, from Redline
Communications Incorporated.
Contact Information:
Redline Communications Inc.
302 Town Centre Blvd. Suite 100
Markham, ON
Canada L3R 0E8
Web site: http://www.redlinecommunications.com
Sales Inquiries:
North American [e-mail]
Toll-free sales 1-866-633-6669
International [e-mail]
Support: www.redlinecommunications.com/support/support_portal.html
Document Control:
70-00121-01-00-4C_SS_Outdoor_REM_UserManual-20090914a.doc
Disclaimer
The statements, configurations, technical data, and recommendations in this document
are believed to be accurate and reliable, but are presented without express or implied
warranty. Additionally, Redline makes no representations or warranties, either expressed
or implied, regarding the contents of this product. Redline Communications shall not be
liable for any misuse regarding this product. The information in this document is subject
to change without notice.

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 3 of 34 October 20, 2009
TABLE OF CONTENTS
1Important Safety Notices.......................................................................5
1.1 Safety Recommendations........................................................................ 5
1.2 Important Warning Symbols..................................................................... 5
1.3 RF Exposure Warnings............................................................................ 5
1.4 Safety Advisories .....................................................................................6
1.5 Electrical Safety.......................................................................................6
1.6 FCC Interference Statement ....................................................................7
1.7 Europe –EU Declaration of Conformity ...................................................8
1.8 Security Features................................................................................... 10
1.9 WEEE Product Return Process.............................................................. 10
2Overview...............................................................................................11
2.1 IEEE 802.16e / WiMAX Compliance ...................................................... 11
2.2 PHY Specification .................................................................................. 11
2.3 OFDMA.................................................................................................. 11
2.4 Convolutional Turbo Codes and Coding Rates ...................................... 11
2.5 Privacy................................................................................................... 11
2.6 Time Division Duplexing (TDD).............................................................. 12
2.7 Modulation ............................................................................................. 12
2.8 Channelization....................................................................................... 12
2.9 Service Flows ........................................................................................ 12
3Unit Features........................................................................................13
3.1.1 Ethernet Port (and Cable) .................................................................. 14
3.1.2 Grounding Connection ....................................................................... 15
3.1.3 PoE (Power over Ethernet) Power Adaptor........................................ 15
4CLI Commands.....................................................................................16
4.1 Local Ethernet Port IP............................................................................ 16
4.2 Telnet Access ........................................................................................ 16
4.2.1 Login.................................................................................................. 16
4.2.2 Logout................................................................................................ 16
4.3 Modes and Commands.......................................................................... 16
4.3.1 bsidtable - Base Station ID Table....................................................... 18
4.3.2 buzzer - Antenna alignment Tool........................................................ 19
4.3.3 collectradio - Radio Statistics ............................................................. 19
4.3.4 ethtag - Ethernet Tagging................................................................... 20
4.3.5 interface - Ethernet Port and Wireless Settings.................................. 21
4.3.6 loadImage - Download and Activate Software Image ......................... 23
4.3.7 realm - Domain Reference for Locating AAA Server .......................... 23
4.3.8 rfConfig - Configure RF Settings ........................................................ 24
4.3.9 statistics - Display Statistics ............................................................... 26
4.3.10 status - Display Status Information..................................................... 28
4.3.11 system - Subscriber General Configuration........................................ 29
4.3.12 tr069 - Auto Configuration Servers Support........................................ 30
5Appendices ..........................................................................................31
5.1 System Technical Specifications............................................................ 31
5.2 Subscriber Upgrade Procedure.............................................................. 32

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 4 of 34 October 20, 2009
LIST OF FIGURES
Figure 1: Subscriber System Features............................................................... 13
Figure 2: 90 Degree Universal Mounting Bracket .............................................. 14
Figure 3: Outdoor Ethernet Cable - Cable Connection....................................... 14
Figure 4: Optional Redline-Supplied PoE Power Adaptor.................................. 15
LIST OF TABLES
Table 1: Notices - R&TTE Community Language CE Declarations......................8
Table 2: Overview - Subscriber Service Class Types ........................................ 12
Table 3: Subscriber Installation Parts ................................................................ 13
Table 4: System - PoE Ports ............................................................................. 15
Table 5: System - Ethernet Data Port Link/Act LEDs......................................... 15
Table 6: CLI - Generic Commands .................................................................... 17
Table 7: CLI - Modes and Commands............................................................... 17
Table 8: CLI - bsIdTable - Base Station ID Table Commands............................ 18
Table 9: CLI - buzzer - Antenna Alignment Tool Commands ............................. 19
Table 10: CLI - collectradio - Radio Statistics .................................................... 19
Table 11: CLI - ethTag - Ethernet Tagging Commands ..................................... 20
Table 12: CLI - interface - Ethernet and Wireless Configuration Commands ..... 21
Table 13: CLI - loadImage - Upgrade CPE Software Commands ...................... 23
Table 14: CLI - realm - For Locating AAA Server Commands............................ 23
Table 15: CLI - rfConfig - RF Configuration Commands .................................... 24
Table 16: CLI - statistics - Statistics Commands................................................ 26
Table 17: CLI - status - Status Commands........................................................ 28
Table 18: CLI - system - System Commands..................................................... 29
Table 19: CLI - tr069 - Auto Configuration Servers Support Commands............ 30
Table 20: Specifications - Indoor Wireless Subscriber Modem .......................... 31

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 5 of 34 October 20, 2009
Chapter
1
1
1 I Im mp po or rt ta an nt t S Sa af fe et ty y N No ot ti ic ce es s
1.1 Safety Recommendations
It is strongly recommended that end-users of the equipment observe all warnings and
cautions during operation, installation, and maintenance of the system.
Failure to comply with these warnings and cautions, or with specific warnings and
cautions elsewhere in the manuals, or displayed directly on system equipment, violates
the safety standards incorporated into the design, manufacture, and intended use of the
system equipment.
Redline Communications assumes no liability for the customer’s failure to comply with
these requirements.
1.2 Important Warning Symbols
The following symbols may be encountered during installation or troubleshooting. These
warning symbols mean danger. Bodily injury may result if you are not aware of the safety
hazards involved in working with electrical equipment and radio transmitters. Familiarize
yourself with standard safety practices before continuing.
Electro-Magnetic Radiation
Important Safety Notice
High Voltage
1.3 RF Exposure Warnings
To satisfy RF exposure requirements (EN 50385)
for RF transmitting devices, where an externally mounted antenna is employed in point-
to-multipoint applications, each antenna must be separated from all persons by a
distance of at least 50 centimeters. To ensure compliance, operations at closer than this
distance is not recommended. The antenna used for this transmitter must not be
collocated in conjunction with any other antenna or transmitter.

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 6 of 34 October 20, 2009
1.4 Safety Advisories
1. Read this manual and follow all operating and safety
instructions.
2. Installation of the system must be contracted to a professional installer.
3. Read this user manual and follow all operating and safety instructions.
4. PoE (Power over Ethernet) power adaptor caution:
PoE Power Adapter Caution
Warning to Service Personnel: 48 VDC
Standard Ethernet equipment may be damaged if connected directly to
the 'Data + Power Output' port of a PoE power adaptor.
5. The power requirements are indicated on the product-marking label. Do not exceed
the described limits.
6. Disconnect the power before cleaning.
7. Disconnect power when unit is stored for long periods.
8. The outdoor unit must not be located near power lines or other electrical power
circuits.
9. The system must be properly grounded to protect against power surges and
accumulated static electricity. It is the user’s responsibility to install this device in
accordance with the local electrical codes: correct installation procedures for
grounding of the outdoor unit, mast, lead-in wire and discharge unit, location of
discharge unit, size of grounding conductors and connection requirements for
grounding electrodes.
10. Keep all product information for future reference.
1.5 Electrical Safety
1. To minimize shock hazard, the equipment chassis and enclosure must be connected
to an electrical ground. All power outlets and plugs must meet International
Electrotechnical Commission (IEC) safety standards.
2. Do not operate the system equipment in the presence of flammable gases or fumes.
Operation of any electrical equipment in such an environment constitutes a definite
safety hazard.
3. Only qualified maintenance personnel may remove equipment covers to replace
internal subassemblies, components, or perform internal adjustments.

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 7 of 34 October 20, 2009
1.6 FCC Interference Statement
Important: The following statements apply only to the REM2500M 2.5 GHz model.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the Federal Communication Commission (FCC) Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
IMPORTANT NOTE: Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
40 cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The availability of some specific channels and/or operational frequency bands are
country dependent and are firmware programmed at the factory to match the intended
destination. The firmware setting is not accessible by the end user.
Due to the essential high output power natural of WiMAX device, use of this device with
other transmitter at the same time may exceed the FCC RF exposure limit and such
usage must be prohibited (unless such co-transmission has been approved by FCC in
the future).

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 8 of 34 October 20, 2009
1.7 Europe –EU Declaration of Conformity
This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. The
following test methods have been applied in order to prove presumption of conformity with the
essential requirements of the R&TTE Directive 1999/5/EC:
IEC 60950-1: 2001 (1st edition)
Safety of Information Technology Equipment
EN50385
Product standard to demonstrate the compliance of radio base stations and fixed terminal
stations for wireless telecommunication systems with the basic restrictions or the reference
levels related to human exposure to radio frequency electromagnetic fields (110 MHz - 40
GHz) - General public
EN 301 489-1
Electromagnetic compatibility and Radio Spectrum Matters (ERM); Electromagnetic
Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical
requirements
EN 301 489-4
Electromagnetic compatibility and radio spectrum matters (ERM); Electromagnetic
compatibility (EMC) standard for radio equipment and services; Part 4: Specific conditions for
fixed radio links and ancillary equipment and services
EN 302 544-1 (REM2500M 2.5 GHz Systems Only)
Broadband Data Transmission Systems operating in the 2 500 MHz to 2 690 MHz frequency
band; Part 1: TDD Base Stations; Harmonized EN covering the essential requirements of
article 3.2 of the R&TTE Directive
EN 302 326-2 (REM3500M 3.5 GHz systems Only)
Fixed Radio Systems; Multipoint Equipment and Antennas; Part 2: Harmonized EN covering
the essential requirements of article 3.2 of the R&TTE Directive for Digital Multipoint Radio
Equipment
0678
Table 1:Notices - R&TTE Community Language CE Declarations
Country
Notice
Česky
[Czech]
[Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se
základními požadavky a dalšími příslušnými ustanoveními směrnice
1999/5/ES.
Dansk
[Danish]
Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr
[udstyrets typebetegnelse] overholder de væsentlige krav og øvrige relevante
krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme
tüüp = type of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja
nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
English
Hereby, [name of manufacturer], declares that this [type of equipment] is in
compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 9 of 34 October 20, 2009
Table 1:Notices - R&TTE Community Language CE Declarations
Country
Notice
Español
[Spanish]
Por medio de la presente [nombre del fabricante] declara que el [clase de
equipo] cumple con los requisitos esenciales y cualesquiera otras
disposiciones aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΣΗΝ ΠΑΡΟΤ΢Α [name of manufacturer] ΔΗΛΩΝΕΙ ΟΣΙ [type of equipment]
΢ΤΜΜΟΡΦΩΝΕΣΑΙ ΠΡΟ΢ ΣΙ΢ ΟΤ΢ΙΩΔΕΙ΢ ΑΠΑΙΣΗ΢ΕΙ΢ ΚΑΙ ΣΙ΢ ΛΟΙΠΕ΢
΢ΥΕΣΙΚΕ΢ ΔΙΑΣΑΞΕΙ΢ ΣΗ΢ ΟΔΗΓΙΑ΢ 1999/5/ΕΚ.
Français
[French]
Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est
conforme aux exigences essentielles et aux autres dispositions pertinentes de
la directive 1999/5/CE.
Italiano
[Italian]
Con la presente [nome del costruttore] dichiara che questo [tipo di
apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of
equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un
citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka
esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in
overeenstemming is met de essentiële eisen en de andere relevante
bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott]
jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm
fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z
zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami
Dyrektywy 1999/5/EC.
Português
[Portuguese]
[Nome do fabricante] declara que este [tipo de equipamento] está conforme
com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami
in ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
[Meno výrobcu] týmto vyhlasuje, že [typ zariadenia] spĺňa základné požiadavky
a všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
[Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen
tyyppimerkintä] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten
ja sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som
framgår av direktiv 1999/5/EG.

User
REM Outdoor Subscriber Manual
70-00121-01-00 Proprietary Redline Communications © 2009 Page 10 of 34 October 20, 2009
1.8 Security Features
Redline Communications wireless systems and provide security setting that can be adjusted by
the operator to meet specific applications. Redline recommends these parameters be set
according to industry recognized security practices. Considerations include confidentiality,
integrity, and availability of information. Implementation of these recommendations and the final
responsibility for the system security is the responsibility of the system administrator and
operators.
1.9 WEEE Product Return Process
In EU countries, dispose of equipment in accordance with the WEEE (Waste from Electrical and
Electronic Equipment) directive, 2002/96/EC, Redline Communications equipment is marked with
the logo shown above. The WEEE directive seeks to increase recycling and re-use of electrical
and electronic equipment. This symbol indicates that this product should not be disposed of as
part of the local municipal waste program. Contact your local sales representative for additional
information. In non-EU countries, dispose of equipment in accordance with national and regional
regulations.
