Operating Manual
C151 - Laser Diode Controller
250mA, Type-1 Pin Conguration

Operating manual
Laser Controller
C151

2
www.redwavelabs.com
Laser Controller C151
Contents
Introduction ................................................................................................................................ 3
Absolute Maximum Ratings .......................................................................................................... 4
Mechanical Information ................................................................................................................ 4
Pin Layout .................................................................................................................................. 4
Electrical Characteristics ............................................................................................................... 5
Power Connector J6 ..................................................................................................................... 7
Control and Monitor Connector J4 ................................................................................................. 7
Control and Monitor Connector J5 (SMB) ....................................................................................... 8
Test Connector J1 ........................................................................................................................ 8
DIP SwitchS1 .............................................................................................................................. 9
Status LED ............................................................................................................................... 10
Temperature Set Point .............................................................................................................. 10
Temperature Measurements ...................................................................................................... 10
PI Control ................................................................................................................................ 11
Integral heat sink ...................................................................................................................... 11
Power dissipation ..................................................................................................................... 11
External connections and cables ................................................................................................. 12
Installation ............................................................................................................................... 12
Certification .............................................................................................................................. 12
Warranty and returns ................................................................................................................ 12
Return procedure ...................................................................................................................... 12
Revisions ................................................................................................................................. 12

3
www.redwavelabs.com
Laser Controller C151
Introduction
Redwave Labs Laser Controller C151 comes with integrated temperature
driver and laser driver in one package. Temperature control is fully linear
and has capability to use separate power supply for laser TEC. TEC control
can be done via built-in PI loop or external signal. Laser driver has analog
bandwidth of 250 kHz and separate fast TTL compatible switching
provided via SMB connector. Laser current has a hardware limit of 250
mA which cannot be exceeded in any case.
Features
Laser Controller C151 provides full control for semiconductor laser including laser diode
control and integrated temperature control.
Applications
Spectroscopy, Laser, Precision Instrument, OEM applications
Specifications
Parameter
Value
Power
Dual
Option 1: +12 V, 2 A or +12 V/0.5A
Option 2: +5V/1.5A; -12 V, 0.5 A
Laser Current Control
Laser current
0 - 250 mA. Hardware limit. Can be modified for
customized versions
Compliance voltage
> 4.0 V
Setting accuracy
2 % fs
Noise (RMS)
< 2µA
Drift
< 20 µA
Temperature coefficient
50 ppm/C
Current limit
250 mA
Setting accuracy of current limit
2 % fs
Laser External Control
Voltage range
0 --> 10 V
Input impedance
10 kOhm
Modulation coefficient ( I const )
20 mA/V
3dB Bandwidth
DC … 250 kHz
TTL modulation, rise / fall-time
250 ns
Interlock
Yes
TEC control
TEC current
0 … +- 1.0 A /1.5A
TEC voltage
> 8.0 V
Max output power
12 W
Current limit
1A or 1.5 A
Input sensor
Thermistor 10 kOhm or 100 kOhm at 25 C
PID control
Internal PI control or External direct TEC current
control
Connectors
Laser
Integrated Azimuth Electronics 14 pin connector
with heat sink. NEL DFB laser pinout. Can be
replaced with optional DB15 connector.
Power
Molex MicroFit 8 pin.
Control
Molex MicroFit 12 pin.
Dimensions (WxHxD)
120 x 92 x 30 mm
Weight
350 g
Storage Temp
-55 to 100 C
Operating Temp
-40 to 85 C
RedWave Labs Ltd keeps improving its products and therefore some specifications can vary.

4
www.redwavelabs.com
Laser Controller C151
Absolute Maximum Ratings
Symbol
Parameter
Ratings
Unit
Vdd1
Supply positive voltage / Laser driver and TEC
+12±10%
V
Vdd2
Supply positive voltage / Separate TEC rail
+5;+10%;-0%
V
Vee
Supply negative voltage / Laser driver and
TEC
-12±10%
V
Top
Operational Temperature
-40 to 85
Deg C
Tst
Storage Temperature
-55 to 100
Deg C
Mechanical Information
Parameter
Value
Unit
Length
4.75 (120.65)
Inch (mm)
Width
3.65 (92.7)
Inch (mm)
Height
1.01 (25.1)
Inch (mm)
Weight
350
gram
Pin Layout
1
TEC+
14
TEC-
2
TH+
13
Ground
3
Not in use
12
Not in use
4
Not in use
11
LD-
5
TH-
10
LD+
6
Not in use
9
Not in use
7
Not in use
8
Not in use
TEMP SET
P GAIN
I GAIN
PI GAIN TP

5
www.redwavelabs.com
Laser Controller C151
Electrical Characteristics
Parameter
Comments
Value
Unit
POWER
Supply positive voltage
Vdd1 / Laser driver and
TEC
Positive supply voltage for laser driver, all
control circuits and TEC. 2 A minimum is
required for single positive power supply
12+/-10%
V
Supply positive voltage
Vdd2 / Separate TEC
Power
Positive supply voltage for TEC only.
2 A minimum capabilities is required.
Designed to use 5 V rail to minimize
overall power consumption and heat
dissipation
5 V; +10%;-
0%
V
Negative supply voltage
Vee
Negative supply voltage for laser driver, all
control circuits and TEC
-12 +/- 10 %
V
LASER DIODE CONTROL AND MONITOR
Laser current Ild limit
Hardware laser limit. Can be modified for
customized versions
250
mA
Laser Compliance
voltage Vcomp
Minimum voltage across laser diode. Can
be change for customized versions.
4
V
Noise (RMS)
Integrated noise (DC-250kHz)
2
µA
Laser current drift
Laser current drift at constant temperature
20
µA
Laser current
temperature coefficient
Temperature drift of the reference
50
Ppm / deg C
Laser current range
Laser current maximum current
250 ( for
custom version
can be less;
mentioned in
the part
number C154-
70 – 70 mA,
for example)
mA
Laser current setting
accuracy
Set by components tolerance
2
% of full
scale
Laser current set voltage
External transfer function ranges
0-10 (for
custom version
less than 10V
depending on
the version)
V
Laser current set voltage
impedance
10
kOhm
Laser current
modulation coefficient
Transfer function for laser current
modulation
20
mA/V

6
www.redwavelabs.com
Laser Controller C151
Parameter
Comments
Value
Unit
Laser current
modulation bandwidth
-3 dB
250
kHz
Laser current TTL
modulation rise/fall time
Additional modulation capabilities on top
of the analog modulation. Fast ON/OFF
switches
250
nS
Laser current monitor
Monitor averaged laser current
0-10 (for
custom version
less than 10V
depending on
the version)
V
Laser current interlock
Available laser interlock. Can be
overridden with DIP-switch
TEC CONTROL AND MONITOR
TEC control type
Linear bipolar
TEC current range
Maximum range can be change with DIP
switch S1
0…±1;
0…±1.4
Amp
TEC power supply
TEC power supply can be selected from
+12V and +5V. +5V allow to improve
power efficiency for TEC with 1 Ohm and
maximum current of 1.5 A.
+5 ; +12
V
TEC compliance voltage
Voltage across TEC element
Vdd-3
V
Maximum TEC power
Maximum power for 12 V power supply
12
W
TEC current limit
Selected with DIP switch S1
1 of 1.4
Amp
Input sensor
TEC input sensor. Selected with S1 DIP
switch. Configured in bridge mode.
100 or 10
kOhm
PI control
PI analog control loop (internal mode) or
external loop though J2 connector (pin
3).Selected with S1 DIP-switch.
External or
Internal
TEC current external
transfer function
Direct control of TEC. Input range –10
to+10 V
200
mA/V
TEC current monitor
Independent TEC current monitor at pin 4
of J4 connector
5.0
V/A
TEC disable
TEC current disable function: DIP-Switch
S1.
CONNECTORS
Power J6
Molex 8 pin Micro Fit connector p/n
43045-0800
Control and monitors J4
Molex 12 pin Micro Fit connector p/n
43045-1200

7
www.redwavelabs.com
Laser Controller C151
Parameter
Comments
Value
Unit
Laser connector
Integrated Azimuth Electronics 14 pin
connector with heat sink. NEL DFB laser
pinout. Can be replaced with optional
DB15 connector.
Test connector J1
Test connector: can be used for remote
control of the driver. Molex p/n 87831-
1620
Power Connector J6
PIN#
Abbreviation
Name
Description
1
Vdd1
Positive power
+12 V
Electrically connected to Pin 5.
2
GND Main
Ground for Vdd1
Ground for the +12/-12 power supplies
3
Vdd2
TEC Power
Positive power for separate TEC power: +5 V. Electrically
connected to pin 7
4
Vee
Negative power –
12 V
Electrically connected to Pin 8.
5
Vdd1
Positive power
+12 V
Electrically connected to Pin 1.
6
GND TEC
Ground for Vdd2
Ground for the +5 power supply. Connected to GND Main
with 1 Ohm resistor at connector.
7
Vdd2
TEC Power
Positive power for separate TEC power: +5 V. Electrically
connected to pin 3
8
Vee
Negaive power –
12 V
Electrically connected to Pin 4.
Power connector J6 (pin assignment is on left) is Molex Micro-Fit p/n 43045-0800. Mating
connector is Molex Micro-Fit p/n 43025-0800 with crimp pins Molex p/n 43030-0009. Mating
connector and necessary number of crimp pins are included with C151 Laser controller. Molex
suggested crimping tool p/n 63819-0000 which can be purchased from Digikey Inc
(www.digikey.com)
Control and Monitor Connector J4
PIN#
Abbreviation
Name
Description
1
LD_I_CTRL
Laser current Control
Control laser diode current with transfer function of 20
mA/V
2
LD_ON_OFF
TTL control of laser
current
Switches laser current ON/OFF with TTL level (5V) external
signal. Electrically connected to J5 (SMB). 0V-LD_ON; 5V
– LD_OFF.
3
TEC_I_CTRL_EXT
External control of
TEC current
Controls TEC current directly with transfer function of 200
mA/V. Switch S1-3 must be in EXT position. Bandwidth of
TEC control is limited to approximately 50 Hz.
4
TEC_I_MON
TEC current monitor
Shows current of the laser TEC with transfer function
Vmon=Itec * 5.0 V/A.
5
GND
Ground
Control and Monitor Ground connection. Must not be used
for power ground.

8
www.redwavelabs.com
Laser Controller C151
PIN#
Abbreviation
Name
Description
6
INTERLOCK-
Negative Interlock
Negative interlock connection. Connected to Ground
directly
7
T_SET_EXTERNAL
External temperature
set point
External temperature set point can be selected with switch
S1-4. Transfer function can be calculated as Rset =
(Vo+0.3119*Vset)/(Vo-0.3119*Vset) * R0 ; R0 =10K or
100K , Vo=5.000V and
1/Tset = A + B * ln(Rset) + C * (ln(Rset))3 . Typical values:
A= 1.1280e-03; B=2.3450e-04;C=8.73e-08.
8
LD_I_MON
Laser diode monitor
Monitor average laser diode current with transfer function
50 V/A and bandwidth of approximately 25 kHz.
9
LIMIT_I_FAULT
TEC current limit
error
0V – normal operation; +5V if current limit (any side) is
reached.
10
GND
Ground
Control and Monitor Ground connection. Must not be used
for power ground.
11
T_ACTUAL_MON
Actual temperature
monitor
Buffered output of the voltage across the thermistor.
12
INTERLOCK+
Positive Interlock
Positive interlock connection. Can be overridden with S1-
6.
Control and monitor connector J4 (pin assignment is on left) is Molex Micro-Fit p/n
43045-1200. Mating connector is Molex Micro-Fit p/n 43025-1200 with crimp pins
Molex p/n 43030-0009 . Mating connector and necessary number of crimp pins are
included with C151 Laser controller. Molex suggested crimping tool p/n 63819-0000
which can be purchased from Digikey Inc (www.digikey.com)
Control and Monitor Connector J5 (SMB)
PIN#
Abbreviation
Name
Description
1
LD_ON_OFF
TTL control of laser
current
Switches laser current ON/OFF with TTL (5V) level external
signal. Electrically connected to J4 Pin 2. 0V-LD_ON; 5V –
LD_OFF.
Laser On/Off connector J5 is standard SMB connector for easy direct connection of laser current fast ON/OFF signal.
Test Connector J1
PIN#
Abbreviation
Name
Description
1
LD+
Laser Diode
Positive Connection
Directly connected to the Azimuth connector
J2 Pins 11 and 13
2
LD-
Laser Diode
Positive Connection
Directly connected to the Azimuth connector J2
Pin 12
3
RESERVED
4
RESERVED
5
TEC_DISABLE
Laser TEC remote
disable
Remote control of Switch S1-1: 0V – TEC
Enable; 5V – TEC disable. Remote control
overrides S1.
6
THERMISTOR_TYPE_CONTROL
10K/100K remote
thermistor selection
Remote control of Switch S1-2: 0V – 100K;
5V – 10K. Remote control overrides S1.
7
PID_CONTROL
Remote PID control
Remote control of PID loop (S1-3): 0V –
External; 5V – Internal (Analog PI loop).
Remote control overrides S1.

9
www.redwavelabs.com
Laser Controller C151
PIN#
Abbreviation
Name
Description
8
T_SET_CONTROL
Remote control of
set temperature
Remote control of S1-4: 0V – Internal; 5V –
External. Remote control overrides S1.
9
TEC_I_LIMIT_CONTROL
Remote control of
TEC current limit
Remote control of S1-5: 0V – 1A; 5V – 1.4A.
Remote control overrides S1.
10
INTERLOCK_CONTROL
Remote control of
Interlock function
Remote control of S1-6: 0V – Enable; 5V –
Disable (Overridden). Remote control overrides
S1.
11
TH-
Laser package
Thermistor
Negative
connection
Directly connected to the Azimuth connector J2
Pin 2
12
TH+
Laser package
Thermistor Positive
connection
Directly connected to the Azimuth connector J2
Pin 1
13
RESERVED
14
RESERVED
15
TEC+
Laser package TEC
Positive connection
Directly connected to the Azimuth connector J2
Pin 6
16
TEC-
Laser package TEC
Negative
connection
Directly connected to the Azimuth connector J2
Pin 7
Test connector J1 (pin assignment is on left) is Molex Milli-Grid p/n 87831-1620. Mating
connector is Molex Milli-Grid p/n 87568-1694 for ribbon cable. C151 comes without
Milli-Grid mating connector. Customized connector arrangement can be used for the
remote control of the switch S1. RedWave Labs can advised on the specific applications
when required.
DIP SwitchS1
S1 can be remotely controlled through J1 except for the TEC power selection (POSITION 8 in table below). This remote
control functionality can be used for integration inside spectrometers or other instruments.
PIN#
Abbreviation
Name
Description
1
TEC_DISABLE
Laser TEC
disable
0V (0) – TEC Enable; 5V (1) – TEC disable.
2
THERMISTOR_TYPE_CONTROL
10K/100K
thermistor
selection
0V (0) – 100K; 5V (1) – 10K
3
PID_CONTROL
PID control
0V (0) – External; 5V (1) – Internal (Analog PI
loop).
4
T_SET_CONTROL
Control of set
temperature
0V (0)– Internal; 5V (1) – External
5
TEC_I_LIMIT_CONTROL
Control of TEC
current limit
0V (0)– 1A; 5V (1) – 1.4A
6
INTERLOCK_CONTROL
Control of
Interlock function
0V (0) – Enable; 5V (1) – Disable (Overridden)
7
RESERVED
8
TEC_POWER_CONTROL
Control of TEC
Power
0V (0) – 5 V Power supply; 5V (1) – 12 V Power
Supply
