Regalo Easy Diner 2662 User manual

Easy Diner
Hook-on High Chair
MODEL NO: 2662 & 2772
Owner’s Manual
READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE
OF GATE. KEEP INSTRUCTIONS FOR FUTURE USE.
Regalo International, LLC.
3200 Corporate Center Drive, Suite 100
Burnsville, MN 55306-9803, USA
Toll Free: 866-272-5274
Made in China
...........................................................................
www.regalo-baby.com

Assembly and Installation Instructions
READ ALL INSTRUCTIONS BEFORE ASSEMBLY AND USE OF CHAIR
KEEP INSTRUCTIONS FOR FUTURE USE
Contact Regalo for questions.
If in doubt about the use of your product, call our customer care line 866-272-5274.
Regalo International, LLC.
3200 Corporate Center Drive, Suite 100
Burnsville, MN 55306-9803, USA
Made in China

1
- Failure to follow all warnings or instructions could result in
serious injury or death.
- Always secure child with the restraints.
- Never leave child unattended. Always keep child in view while
in hook-on chair.
- Do not use on a glass table top, loose tabletop, single pedestal
table, card table, table leaf or with table cloths or place mats.
- Check stability of table before and after seating child.
- Recommended only for children capable of sitting upright
unassisted.
- Do not place an ordinary chair under this hook-on chair or
position this hook-on chair on counters or tables that are near
other structures which could be used by the child to push the
hook-on chair off or up from the table or counter.
- Use only for children up to 37 lbs. (16.8kg)
- Use only for tables 1-2 in thick. (25.4-50.8mm)
- Keep table and seat clean and dry to prevent slipping.
- Discontinue use if hook-on chair is broken. Contact
manufacturer immediately for replacement parts or service.
- Do not use without all tips (suction cups or other
locking/latching mechanisms) attached securely to the table
surface.
- Discontinue use if child, when seated in hook-on chair, is able
to move the hook-on chairs arms on the table top.
- Do not allow other children or animals to play near or walk
under hook-on chair while in use.
- Before removing child from hook-on chair, be sure the child’s
legs are free from chair supports.
WARNING:

2
Check that you have these contents:
A. Seat Support & Pad
B. U-Bar
C. Left Arm
D. Right Arm
E. Carry Bag
A.
B.
C. D.
E.

3
Assembling your Easy Diner
Step 1: Remove the black plastic ends from the all metal bars.
Step 2: Slide the U-Bar through the sleeve at the back of the Seat Support until the ends
are exposed on both sides.
Step 3: Slide the paddle grip of the Right Arm though the sleeve on the right side of the
Seat support. Note: Remove the detachable seat pad and inspect to ensure you have
inserted the arm through the permanently sewn arm sleeve and NOT between the
detachable seat pad and the seat support. Improper installation could result in unsafe
conditions.

4
Step 4: Attach the right arm to the right side of the U-Bar, pushing the spring pin, as you
slide the arm over the U-Bar.
Step 5: Repeat Step 3-4 for the left side.
Installing your Easy Diner
Step 1: Slide the Easy Diner onto the edge of a table making sure that they pegs are
underneath the table and that the grip pads are on top of the table.
Note: Make sure the locks are folded down so that they do not interfere with the
attachment to the table. Press in the lock release button to do this.
Note: Your Easy Diner will be noticeably angled when first placed on the table top. THIS
IS NORMAL. Proceed to Step 2.

5
Step 2: Push down on the back of the Easy Diner until the seat is almost level with the
table top.
Step 3: Pivot the locks back until they automatically lock in the vertical position.
Step 4: Continue to push down on the back of the seat while turning the locking knobs
until they are tight against the bottom of the table surface.
Note: If properly locked to the table top, you should not be able to pull your Easy Diner
off the table, even when pulling with a reasonable amount of force.

6
Harness Instructions
Step 1: To secure your child in the harness, push buckle tounges (A) into buckle housing
(B) and adjust with waist strap adjuster so that the waist strap is firmly secured around
child.
Step 2: Attach shoulder straps in position on buckle tongues (A) and adjust so that they
are secure, yet comfortable on child.
Closing the Easy Diner Chair
Before attempting to close the Easy diner Chair, remove your child.
Step 1: Loosen the table locks on the arms.
Step 2: Press in the lock release buttons and pivot the locks forward.
Step 3: Remove the Easy Diner from the table.
Step 4: Fold the arms inward to store the Easy Diner in the Carry Bag.
Adjuster
Adjuster
Strap
Clips
Buckle Housing (B)
Waist Strap
Adjuster
Waist Strap
Adjuster
Buckle
Tongue (A)
Buckle
Tongue (A)

7
Care and Maintenance
Periodically check the Easy diner for signs of damage, wear, or missing components.
Do not use if any parts are missing, worm, or damaged.
Always dry metal parts to avoid the formation of rust.
Regularly check the screws attached to the locking knobs to ensure that they are
securely tightened and tighten them when necessary.
Fabric Care
Always check the strength of the fabric and the strength of the stitching each time the
fabric is washed.
90 Days Limited Warranty:
If, during the rst 90 days after consumer purchase of this item, under reasonable and
non-commercial use and conditions of maintenance, it fails while owned by the original
purchaser because of the quality of materials or workmanship of nish and assembly,
Regalo International will replace or repair it at Regalo’s option. PROOF OF PURCHASE
REQUIRED.

8
Replacement Parts Available
In the event of any damage or breakage, the following replacement parts are available
for order by contacting Regalo Customer Service.
Contact Regalo for questions and replacement parts.
For questions about the use of your Easy Diner, call our customer care line 866-272-5274.
Regalo International, LLC.
3200 Corporate Center Drive, Suite 100
Burnsville, MN 55306-9803, USA
Made in China
Easy Diner
Rubber End Cap
(#91106)
Easy Diner
Spin Knob
(Green #97107)
(Navy #96107)
Easy Diner U-Bar
(Platinum #94108)
(Navy #96108)
Easy Diner Right Arm
(Red #99104)
(Green #97104)
Easy Diner Left Arm
(Red #99105)
(Green #97105)
Easy Diner Seat Support
(Navy #96109)
(Gray #94109)
Easy Diner Seat Pad
(Navy #96110)
(Gray #97110)

02/26/15_BL
