Regency Greenfire GF1500NG Quick start guide

920-353b
Greenfire®GF1500L
Gas Fireplace
02.28.22
www.regency-fire.com.au
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
LISTINGS AND CODE APPROVALS
These gas appliances were tested in accordance
with AS/NZS 5263.0 & AS/NZS 5263.1.3/ and
certified by the Australian Gas Association for
installation and operation as described in these
instructions. Must be installed as per AS/NZS
5601.
Your unit should be serviced annually by an
authorised service person.
Owners &
Installation Manual
MODELS: GF1500NG Natural Gas GF1500LLP-2 GF1500LULPG-2 Propane
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch: do not use any phone in your building. Leave the building immediately.
• Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Warning
Fire or explosion Hazard
failure to follow safety warnings exactly could result in serious
injury, death, or property damage.

owner's information
To the New Owner:
Congratulations!
You are the owner of a state-of-the-art gas fireplace by REGENCY®. The GF1500L has been designed to provide you with all
the warmth and charm of a wood fireplace at the flick of a switch. The GF1500L was approved by AGA for both safety and
efficiency. As it also bears our own mark, it will provide you with economy, comfort, and security for many trouble-free years to
come. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency® Fireplace.
PAIRING YOUR REMOTE CONTROL
The control box will only learn the Remote ID codes during the first 30 seconds after power is applied
and will ignore this special command from the Remote after the first 30 seconds.
To match the control box to the remote, follow the steps below :
1. Remove a battery from the remote handset.
2. Remove main power to the control box by turning off the isolation switch or switch on the GPO to
the heater.
3. Wait 30 seconds (approx.).
4. Reconnect main power to the control box.
5. Immediately put the battery back in the remote & point the remote in the direction of the heater.
6. Press and hold the PROG and FAN buttons simultaneously. The
letters “LC” will appear on the display indicating the ID codes have
been transmitted.
7. Release both buttons.
8. The display will revert back to the normal off mode display. The
heater should light – spark, burner, etc even though the remote
screen says the heater is off.
9. Press the Off button on the remote. The heater should turn off.
10. Wait approx. 30 seconds turn the on again & check all the functions
work – fan speed can be adjusted, flame height can be adjusted, etc.
Note: To view a step-by-step pairing video please visit
regency-fire.com.au/Customer-Care/Fireplace-Care-Videos
Note: The Remote Control Handset has a set of unique ID codes that is
pre-programmed into its memory. This set of ID codes helps to differen-
tiate one Remote Control Handset from another so that only the control
box with a matching ID code will respond to the appropriate Remote
Control Handset.
regency.com.au
Pairing Your Remote Control
The control box will only learn the remote ID codes during the first 30 seconds after power is
applied. After the first 30 seconds, the control box will ignore this special command.
The remote control handset has a set of unique ID codes that are pre-programmed into its
memory. This set of ID codes helps differentiate one remote control handset from another.
Only the control box with a matching ID code will respond to the appropriate remote control
handset.
To match the control box, follow these steps:
1. Ensure the remote is siwtched off.
2. Remove the main power to the control box.
3. Reconnect the main power to the control box.
4. Press and hold the PROG and FAN buttons simultaneously. The temperature display will
show the letters "LC", indicating the ID codes were transmitted, then revert to the normal
off mode display.
5. Release the PROG and FAN buttons.
The control box will only learn the remote ID codes during the first 30 seconds after power is
applied and will ignore this special command from the remote afterward.
Fan Operation
The fan must be on while the unit is in operation. This model offers a two-speed fan.
NOTES
• The heater turns off when the room temperature reaches 1 C over the set temperature and turns
back on when the room temperature reaches 0.50 C under the set temperature when in AUTO mode.
• The pairing process can be carried out by anyone.
• Please visit www.regency-fire.com.au to see the pairing video.

Greenfire® GF1500L-2 Gas Fireplace | 3
WARNING
DO NOT turn your fireplace on via any means or allow it to be turned on unless you have conducted a thourough inspection of the area surrounding the
fireplace immediately prior to its use, and you have satisfied yourself that there are no materials or other items in proximity to the fireplace which could
present a fire risk.
DO NOT turn your fireplace on via any means or allow to be turned on if there are any unsupervised children, infirm persons, or pets in the area surround-
ing the fireplace.
DO NOT use this fireplace unless you have read this manual, and strictly adhere to the user requirements and warnings set out in this manual.
RELEASE
Without limiting any other acknowledgement, release or indemnity given by you, or limitation of liability, in favour of Fireplace Products Pty Ltd (''Company''),
you irrevocably and unconditionally acknowledge and agree that failure to comply with, or strictly adhere to, the requirements and warnings set out in this
Manual (''User Requirements'') may result in:
1. damage to the fireplace;
2. damage to property;
3. a house fire;
4. severe burns or other personal injury; and/or
5. death.
Subject to any remedy, guarantee, term, condition, warranty, undertaking, inducement or representation, implied or imposed by any legislation which cannot
lawfully be excluded or limited, and to the maximum extent permitted by law:
1. the Company will not be liable for any damage, personal injury or death arising out of or in connection with your failure to comply with any User Require-
ment; and
2. you release the Company from all claims, actions, proceedings, liabilities, losses and damages in relation to death, any personal injury or property dam-
age arising out of or in connection with your failure to comply with any User Requirement.

4 | Greenfire® GF1500L-2 Gas Fireplace
table of contents
Pairing Your Remote Control ...............................................................2
WARNING ........................................................................................... 3
RELEASE ............................................................................................ 3
Copy of Data Badge ............................................................................ 5
Unit Dimensions .................................................................................. 6
Important Message ............................................................................ 7
General Safety Information .................................................................. 7
Installation Checklist ............................................................................ 8
Locating Your Gas Fireplace ................................................................ 8
Clearances .......................................................................................... 9
Framing Dimensions .......................................................................... 10
Combustible Finishing Unit Assembly/ Finishing/ Mantel
Clearances + Mantel Leg Clearances ............................................. 11
Framing & Finishing (Combustible).................................................... 12
Combustible Requirements ............................................................... 12
Clearances for Combustible Finishing with Mantel ............................ 13
Combustible Mantel Leg Clearances ................................................. 13
Non Combustible Flush Finishing - Unit Assembly/Finishing/Mantel
Clearances + Mantel Leg Clearances ............................................. 14
Installation of Access Panel ............................................................... 14
Remove 8 standoffs ........................................................................... 14
Clearances For Non Combustible Flush Finishing with Mantel ......... 15
Non Combustible Mantel Leg Clearances ......................................... 15
Flushed Finishing & Framing with Non Combustible Material ........... 16
Non Combustible Requirements ........................................................ 16
Installing a TV / Artwork Flush with the Unit ...................................... 17
TV Recess with 45 Degree Elbow ..................................................... 18
TV Recess with Vertical Venting ........................................................18
Optional Framing Kit .......................................................................... 19
Non Combustible Facing Installation ................................................. 20
Framing & Finishing (Clean Finish Installations Only) ...................... 21
Exterior Flue Termination Locations .................................................. 22
Exterior Flue Termination Locations - Clearances ............................. 23
127 mm x 203 mm Rigid Pipe - Cross Reference Chart Only .......... 24
Flue Restrictor Settings ..................................................................... 26
Flueing Introduction ........................................................................... 27
Flueing Arrangement for Horizontal Terminations ............................. 27
Rigid Pipe Flueing Systems - Basic Horizontal & Vertical
Terminations .................................................................................... 28
Flueing Arrangements - Horizontal Termination (Flex) - Regency®
Direct Vent System ......................................................................... 29
Horizontal Venting with Two 90o Elbows ............................................ 30
Horizontal Venting with Three 90o Elbows .........................................30
Unit Installation with Horizontal Termination (Rigid Flue Systems)....31
Unit Installation With Horizontal Termination Flex System ................. 32
Flueing Arrangement for Vertical Terminations - Vertical Flue with
Two 90o Elbows (1 - 90o = 2 - 45o) ................................................... 33
Vertical Venting with Three 900 Elbows ..............................................34
Direct Flue Zero Clearance Top Exit Vertical Flue Kit Installation
Instructions ...................................................................................... 35
Unit Installation with Vertical Termination (Rigid Systems) ................ 36
Vertical Termination - 127 mmx 203 mm Flueing - Vertical Flex Kit
(Part 946-772) ................................................................................. 37
Vertical Flue Extension Kit (Approved) (Part # 946-769) ................... 39
Ceiling Firestop / Firestop Spacer (Part 946-770) ............................. 39
High Elevation .................................................................................... 40
Gas Line Installation .......................................................................... 40
Pilot Adjustment ................................................................................. 40
Gas Pipe Pressure Testing ................................................................40
Wiring Diagram (NG Only) ................................................................. 41
845 S.I.T. Valve Description ............................................................... 41
Aeration Adjustment .......................................................................... 41
Conversion Kit from NG to propane/ULPG Using SIT 845 NOVA
Gas Valve ........................................................................................ 42
Optional WIFI App (Part #946-767) - WIFI Dongle Installation .......... 45
Optional Fan Ducting Kit Installation .................................................. 46
Log Set Installation ............................................................................ 49
Front Trim Removal/Installation .........................................................51
Inner Panel Removal/Installation ....................................................... 51
Faceplate and Deflector Installation .................................................. 52
Verona Faceplate Shown .................................................................. 52
Screen & Inner Door Frame Installation ............................................ 53
Optional Finishing Trim Installation .................................................... 54
Operating Instructions ...................................................................... 55
Lighting Instructions........................................................................... 55
Shutdown Instructions ....................................................................... 55
First Fire ............................................................................................ 55
Remote Control ................................................................................ 55
Summary of Controls ........................................................................ 55
Fan Operation .................................................................................... 55
Copy of Lighting Plate Instructions .................................................... 56
Normal Operating Sounds of Gas Appliances ................................... 56
Resetting the Unit .............................................................................. 56
Fan Service ....................................................................................... 57
Maintenance Instructions................................................................... 58
General Flue Maintenance ................................................................ 58
Glass Gasket ..................................................................................... 58
Glass Door ......................................................................................... 58
Glass Door Installation ...................................................................... 59
Valve Tray Replacement ....................................................................60
Troubleshooting Guide ....................................................................... 61
Troubleshooting Guide ....................................................................... 62
Gas Maintenance - Recommended Annual Routine ......................... 63
Electronic Components Parts List ..................................................... 64
Main Assembly .................................................................................. 65
Accessories ....................................................................................... 67
Warranty ............................................................................................ 68
Owner's information
Installer's information
Installation
Maintenance
Parts List
Operating Instructions

Greenfire® GF1500L-2 Gas Fireplace | 5
safety decal
This is a copy of the data badge that accompanies each GF1500L Direct Vent Gas Fireplace. We have printed a copy of the contents here for your review.
Copy of Data Badge
Part #: 920-354
Colour: Black on Grey
Size: 100% 7" W x 2.7" H
Nov 12/20: Created Decal
Serial
Number
Regency Gas Fireplace
551
Distributed by:
Western Australia:
Air Group Australia
28 Division St
Welshpool, WA 6106
Eastern Australia
Fireplace Products
Australia Pty. Ltd.
99 Colmans Road
Dandenong, VIC 3175
New Zealand:
Aber Holdings
17 Main Street Place
Te Rapa, HA 3200
To be installed by an authorised person in
accordance with installation instructions provided
with the appliance.
Electrical: 240V 50 Hz
920-354
Gas Type NG Propane ULPG
Model GF1500LNG-2 GF1500LLP-2 GF1500LULPG-2
Gas Consumption High
Manifold Pressure High
1.13 kPa 2.75 kPa 2.75 kPa
Injector Size 1 x #29 1 x #47 1 x #49
3.40 mm 1.99 mm 1.85 mm
Model
Approval No. AGA
AS / NZS 5263.0 & AS / NZS 5263.1.3
8240 G
Gas Consumption Low
Minimum Supply Pressure
Manifold Pressure Low
36.9 MJ/h 37.9 MJ/h 33.7 MJ/h
0.87 kPa 2.49 kPa 2.49 kPa
0.40 kPa 1.60 kPa 1.60 kPa
50 MJ/h 49 MJ/h 44 MJ/h
NOTE
• Regency® units are constantly being improved. Check the badge on the unit and if there is a
difference, the badge on the unit is the correct one.

6 | Greenfire® GF1500L-2 Gas Fireplace
dimensions
Unit Dimensions
1151mm
344mm
1263mm
633mm
249mm
117mm
37mm
159mm
459mm
13mm
737mm
824mm
945mm
560mm
523mm

Greenfire® GF1500L-2 Gas Fireplace | 7
installer's information
11. Under no circumstances should this appliance
be modified. Parts that have to be removed for
servicing should be replaced prior to operating
this appliance.
12. Installation and any repairs to this appliance
should be done by an authorized service per-
son. A professional service person should be
called to inspect this appliance annually. Make
it a practice to have all of your gas appliances
checked annually.
13. Do not slam shut or strike the glass door.
14. Under no circumstances should any solid fuels
(wood, paper, cardboard, coal, etc.) be used
in this appliance.
15. The appliance area must be kept clear and
free of combustible materials, (gases and other
flammable vapours and liquids).
General Safety Information
1. The appliance installation must conform with
local codes or, in the absence of local codes,
with the current Installation and Building Codes.
2. The appliance when installed, must be electri-
cally grounded in accordance with local codes.
3. See general construction and assembly in-
structions. The appliance and flue should be
enclosed.
4. This appliance must be connected to the speci-
fied flue and termination cap to the outside of
the building envelope. Never vent to another
room or inside a building. Make sure that the
flue is fitted as per Flue instructions.
5. Inspect the flue system annually for blockage
and any signs of deterioration.
6. Flue terminals shall not be recessed into a wall
or siding.
7. Any safety glass removed for servicing must
be replaced prior to operating the appliance.
8. To prevent injury, do not allow anyone who is
unfamiliar with the operation to use the fireplace.
9. Wear gloves and safety glasses for protection
while doing required maintenance.
10. Be aware of electrical wiring locations in walls
and ceilings when cutting holes for termination.
"THIS UNIT MUST ALWAYS
TERMINATE / FLUE
DIRECTLY TO THE OUTDOORS."
Important Message
SAVE THESE INSTRUCTIONS
The GF1500L™ direct vent fireplace must be
installed in accordance with these instructions.
Carefully read all the instructions in this manual
first. Consult the "authority having jurisdiction" to
determine the need for a permit prior to starting the
installation. It is the responsibility of the installer to
ensure this fireplace is installed in compliance with
manufacturers instructions and all applicable codes
and complies with a AS/NZS 5601.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED
ON OR NEAR THE APPLIANCE.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURES, ESPE-
CIALLY THE FIREPLACE GLASS, AND
SHOULD STAY AWAYTO AVOID BURNS
OR CLOTHING IGNITION.
INSTALLATION AND REPAIR SHOULD
BE DONE BY AN AUTHORIZED
SERVICE PERSON. THE APPLIANCE
SHOULD BE INSPECTED BEFORE
USE AND AT LEAST ANNUALLY BY A
PROFESSIONAL SERVICE PERSON.
MORE FREQUENT CLEANING MAY
BE REQUIRED DUE TO EXCESSIVE
LINT FROM CARPETING, BEDDING
MATERIAL, ETC.IT IS IMPERATIVETHAT
CONTROL COMPARTMENTS, BURNERS
AND CIRCULATING AIR PASSAGEWAYS
OF THE APPLIANCE BE KEPT CLEAN.
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED
OUT OF TRAFFIC AND AWAY FROM
FURNITURE AND DRAPERIES.
WARNING: FAILURE TO INSTALL THIS
APPLIANCE CORRECTLY WILL VOID
YOUR WARRANTY AND MAY CAUSE A
SERIOUS HOUSE FIRE.
YOUNG CHILDREN SHOULD BE CARE-
FULLY SUPERVISED WHEN THEY ARE
IN THE SAME AREA AS THE APPLI-
ANCE. TODDLERS,YOUNG CHILDREN
AND OTHERS MAY BE SUSCEPTIBLE
TO ACCIDENTAL CONTACT BURNS. A
PHYSICAL BARRIERS IS RECOMMEND-
ED IFTHERE ARE AT RISK INDIVIDUAL
INTHE HOUSE. TO RESTRICT ACCESS
TO A FIREPLACE OR STOVE, INSTALL
AN ADJUSTABLE SAFETY GATE TO
KEEP TODDLERS, YOUNG CHILDREN
AND OTHER AT RISK INDIVIDUALS OUT
OFTHE ROOM AND AWAY FROM HOT
SURFACES.
The gas appliance connected to the electrcity
supply shall be provided with the means
of double pole electrical isolation that is
adjacent to the appliance location and ac-
cessible with the appliance installed.Per AS/
NZS 5601-2013.

8 | Greenfire® GF1500L-2 Gas Fireplace
installer's information
This includes:
1. Clocking the appliance to ensure the correct
firing rate (noted on label) after burning
appliance for 15 minutes.
2. If required, adjusting the primary air to ensure
that the flame does not carbon. First allow the
unit to burn for 15-20 min. to stabilize.
Locating Your Gas Fireplace
1. When selecting a location for your fireplace,
ensure that the clearances are met.
Diagram 1
2. The appliance must be installed on a flat, solid,
continuous surface. For example, a wood, metal,
or concrete floor or in a raised (on the wall)
application. The appliance must be installed on
a metal or wood panel extending the full width
and depth of the appliance.
3. The GF1500L Direct Vent Gas Fireplace can be
installed in a recessed position or framed out
into the room as in A, B, C and D. See diagram
1.
8. Test Gas Pressure (Refer to "Gas Pipe Pressure
Testing" section).
9. Install standard and optional features. Refer to
the following sections:
a) Log Install
b) Faceplate / Door Frame Overlay
c) Remote Control
10. Final check.
Before leaving this unit with the customer, the
installer must ensure that the appliance is firing
correctly and its operation fully explained to
customer.
Installation Checklist
1. Locate the appliance:
a) Room location (Refer to "Locating Your Gas
fireplace" section)
b) Clearances to Combustibles (Refer to
"Clearances" section)
c) Mantle Clearances (Refer to "Mantel
Clearances" section)
d) Framing & Finishing Requirements (Refer
to "Framing & Finishing" section)
e) Flueing Requirements (Refer to "Flue"
section)
2. Assemble the standoffs and nailing strips (refer
to "Unit Assembly Prior to Installation").
3. Slide unit into place.
4. Install flue (Refer to "Flue Arrangement"
sections).
5. Make gas connections (Refer to "Gas Line
Installation section).
6. Pair up Remote Control (Refer to "Pairing up
Remote Handset" section)
7. Test the pilot (Refer to "Pilot Adjustment"
section).
4. The GF1500L Direct Vent Gas Fireplace
is approved for alcove installations, see
"Clearances" section for details.
5. We recommend that you plan your installation on
paper, using exact measurements for clearances
and floor protection, before actually installing
this appliance. Have an authorized inspector,
dealer, or installer review your plans before
installation.
PACKAGING:
The unit and its contents are packaged to
prevent damage during transport.
After unboxing,remove the plastic wrap then
the screws that secure the unit to the pallet.
Before commissioning of the unit, unwrap
each log and set aside. Before installation
of the logs, removal of the sheet metal cover
that protects the burner is required.
Refer to subsequent instructions on proper
set up and safety check before placing unit
into commission.
NOTE
• Not intended for use as a fireplace insert.
Do not install in a fireplace.
NOTE
• For flue terminations refer to "Exterior Flue
Termination Locations" section.
A) Flat on wall
B) Flat on wall corner
C) Recessed into wall/alcove
D) Corner
CAUTION
• Any alteration to the product that causes
sooting or carboning that results in damage
is not the responsibility of the manufacturer.

Greenfire® GF1500L-2 Gas Fireplace | 9
Clearances
The clearances listed below are minimum distances unless otherwise stated.
A major cause of chimney-related fires is failure to maintain required clearances (air space) to combustible materials. It is of the greatest importance that this
fireplace and flue system be installed only in accordance with these instructions.
Clearance: Dimension Measured From:
A: Mantel Height (min.) 254 mm Top of fireplace opening/hot air outlet
B: Sidewall (on one side) 152 mm Side of fireplace opening/hot air outlet
C: Ceiling (room and/or alcove) 1162 mm Top of fireplace opening/hot air outlet
D: Mantel Depth (max.) 305 mm 730 mm above fireplace opening/hot air
outlet
E: Alcove Width 1524 mm Sidewall to sidewall (minimum)
F: Alcove Depth 914 mm Front to back wall (maximum)
G: From Floor 617 mm Top of fireplace opening/hot air outlet
Note: O No hearth required
Installed close
to ceiling.
Flue Clearances to Combustibles
Horizontal - Top 76mm
Horizontal - Side 51mm
Horizontal - Bottom 51mm
Vertical 51mm
Alcove
E
F
E
D
A
B
Installed Close
to Floor
G
F
installation
CAUTION
• The top, back and sides of the fireplace are defined by
standoffs. The metal ends of the standoff may NOT be
recessed into combustible construction.
WARNING
Fire hazard is an extreme risk
• If these clearances (air space) to combustible
materials are not adhered to. It is of greatest
importance that this fireplace and flue system be
installed only in accordance with these instructions.

10 | Greenfire® GF1500L-2 Gas Fireplace
installation
Framing Dimensions
Dimensions Description GF1500
A Framing Height 945 mm combustible finish
A¹Framing Height -Steel Stud 846 mm non combustible steel stud
B Framing Width 1394 mm
C Framing Depth 568 mm
D Minimum Height to Combustibles 1225 mm
E Corner Wall Depth 1460 mm
F Corner Facing Wall Width 2065 mm
G Vent Centerline Height 1016 mm
H* Non-combustible facing height *see non-combustible facing height in this manual
I Gas Connection Opening Height 38 mm
J Gas Connection Height 67 mm
K Gas Connection Inset 44 mm
L Gas Connection Opening Width 89 mm
D
G
H
Non-Combustible
Facing
Header
F
E
I
J
KL
Flex or Rigid Pipe
Drywall or
other facing
C
C
A
B
C
Timber
Studs
Finished Floor
A
B
C
Timber
Studs
Finished Floor
A
1
Steel Stud
on edge
Combustible flush finishing framing
IMPORTANT
• This unit can be finished with combustible facing material of 10-19mm thickness or non com-
bustible facing material a minimum of 12 mm thick.
NOTES
• A minimum thickness of 12mm non combustible facing board compliant with AS1530-1 and AS1530-3 is required
when using the non-combustible flush finishing option. A minimum thickness of 10mm-19mm combustible facing
board and a 13 mm air gap is required when choosing the combustible flush finishing option.
• Do not place timber studs below those already in place. Steel studs must be added as shown when choosing the non
combustible flush finishing option, and installed after unit is in place, prior to installation of non- combustible finishing.
• If raising the unit, the minimum framing height measurement (A) must be adhered to.
* For example: unit raised 300mm then A+ 300mm = 1240 mm.
D
G
H
Non-Combustible
Facing
Header
F
E
I
J
KL
Flex or Rigid Pipe
Drywall or
other facing
C
C
A
B
C
Timber
Studs
Finished Floor
A
B
C
Timber
Studs
Finished Floor
A
1
Steel Stud
on edge
Non-combustible flush finishing framing
D
G
H
Non-Combustible
Facing
Header
F
E
I
J
KL
Flex or Rigid Pipe
Drywall or
other facing
C
C
A
B
C
Timber
Studs
Finished Floor
A
B
C
Timber
Studs
Finished Floor
A
1
Steel Stud
on edge
D
G
H
Non-Combustible
Facing
Header
F
E
I
J
KL
Flex or Rigid Pipe
Drywall or
other facing
C
C
A
B
C
Timber
Studs
Finished Floor
A
B
C
Timber
Studs
Finished Floor
A
1
Steel Stud
on edge
D
G
H
Non-Combustible
Facing
Header
F
E
I
J
KL
Flex or Rigid Pipe
Drywall or
other facing
C
C
A
B
C
Timber
Studs
Finished Floor
A
B
C
Timber
Studs
Finished Floor
A
1
Steel Stud
on edge
D
G
H
Non-Combustible
Facing
Header
F
E
I
J
KL
Flex or Rigid Pipe
Drywall or
other facing
C
C
A
B
C
Timber
Studs
Finished Floor
A
B
C
Timber
Studs
Finished Floor
A
1
Steel Stud
on edge

Greenfire® GF1500L-2 Gas Fireplace | 11
installation
Unit Assembly Prior To installation
The nailing strips must be correctly positioned and attached before unit is
slid into position.
Nailing Strips-Combustible Finishing
The nailing strips come attached to the unit. There is one plate on each side
and one on the top. The top and side nailing strips are secured to the framing.
Installing Access Panel
The unit is equipped with a removable access panel for pre-finish installation
of optional components. This panel is located on the lower front face. Access
to the gas connection is easier with the panel removed.
1. Remove four screws to remove access panel.
2. Install any optional components with access panel removed.
3. To reinstall the access panel, line up the two upper tabs and secure with
four screws.
Combustible Finishing Unit Assembly/ Finishing/ Mantel Clearances + Mantel Leg Clearances
Nailing Strips
(DO NOT REMOVE NAILING STRIPS
WHEN USING COMBUSTIBLE FINISHING)
4 screws
IMPORTANT
• The framing depth measurement is noted with the nailing
strips set as far forward on the firebox as possible. The
nailing strips can be adjusted up to 38 mm to allow for vary-
ing thickness of non combustible material & wall finishes.
NOTE
• The access panel is no longer usable/accessible once facing material
is installed.

12 | Greenfire® GF1500L-2 Gas Fireplace
installation
Combustible Requirements
Framing & Finishing (Combustible)
148mm
482 mm
1288 mm
630 mm
Finished Material
10mm-19mm thick-
ness using combus-
tible finishing
Note: must maintain
13mm air gap all
around
(see diagrams below
and on next page)
1st slot
Unit
13mm
gap
NOTES
• The appliance must be installed on a flat, solid,
continuous surface For example a wood, metal
or concrete floor. In a raised (on the wall) ap-
plication the appliance must be installed on a
metal or wood panel extending the full width
and depth of the appliance.
• Do not remove the standoffs located around
the perimeter of this unit These act as a guide
for placing the combustible material.
NOTES
• *The finishing trim or one of the fascias must
be used with combustible finishing.
• 10 mm to 19 mm combustible finishing can be
used if the 13 mm air gap around the front fac-
ing of the unit is maintained. Finishing material
cannot be thicker than 19 mm and must be flush
with the front edge of the flange.
• The siding nailing strips are factory set at 10
mm. The top nailing strip is fixed during transit
to the rear of the appliance.
• Do not place any reinforcement in front of the
header and behind the finishing material.
• The nailing strip must be used. It is fixed during
transit to the rear of the unit.
• Depending on the material used for finishing,
the nailing strips must be set accordingly so
that the finished material is always flush with
the edge of the flange.
• If finishing with material that has a combined
thickness greater than 19 mm, non combustible
material must be used.
NOTE
• Maintain a 13 mm gap all around. A
minimum of 10 mm to maximum 19 mm
material thickness is required.

Greenfire® GF1500L-2 Gas Fireplace | 13
installation
Clearances for Combustible Finishing with Mantel
Combustible Mantel Leg Clearances
Mantel leg & combustible finishing clearances are shown in the diagram below.
Combustible Material
(152mm)
(305mm)
(0)
(630 mm)
To unit base
(322 mm)
Top of
Fireplace
Opening
(576 mm)
(305mm)
(470 mm)
(241mm)
Combustible Stud
(On Edge)
Nailing Flange
Combustible facing
(min. 10mm- max. 19mm)
(297 mm)
(200mm)
(100mm)
(372 mm)
Allowable mantel
leg projection
181mm
254mm
330mm
38mm
MANTEL LEG
102mm
178mm
Allowable mantel
leg projection
181mm
254mm
330mm
38mm
MANTEL LEG
102mm
178mm
Allowable mantel
leg projection
181mm
254mm
330mm
38mm
MANTEL LEG
102mm
178mm
13mm Gap 13mm Gap
Combustible Combustible
Important:
Due to the extreme heat this fireplace emits, the mantel clearances are
critical.
Combustible finishing and mantel clearances are shown in the diagram on the
right. Finishing trim must be used with combustible finishing.
NOTES
• Maximum combustible finishing material thickness is 19 mm, mea-
sured from the front of the fireplace opening. If total finishing material
is greater than 19 mm, non combustible material must be used.
• Use high quality paint on the mantel and facing, or the paint may
discolour.
• Combustible mantel starts at 796 mm (618 mm + 178 mm) from
the unit's base.

14 | Greenfire® GF1500L-2 Gas Fireplace
installation
Installation of Access Panel
Remove top nailing strips & standoffs at side and under-
neath
1. Remove the top nailing strip/standoff by removing 4 screws in locations shown
in diagram to the right, then lift off and recycle.
Non Combustible Flush Finishing - Unit Assembly/Finishing/Mantel Clearances + Mantel Leg Clearances
2. Break off the 8 standoffs with a pair of pliers.
Remove 8 standoffs
Installation Access Panel
Tab locations on access panel
The unit is equipped with a removable access panel for pre-finish
installation of optional components - this panel is located on the
lower front face.
1. Remove 4 screws to remove access panel.
2. Easier access to gas connection with panel removed.
3. Install any optional components with access panel removed.
4. Reinstall access panel, line up 2 upper tabs and secure in place
with 4 screws.
Note: Access panel is no longer usable/accessible once facing material
installed.

Greenfire® GF1500L-2 Gas Fireplace | 15
installation
Clearances For Non Combustible Flush Finishing with Mantel
Due to the extreme heat this fireplace emits, the mantel
clearances are critical.
Combustible mantel clearances from top of front facing are shown
in the diagram on the right.
Non Combustible Mantel Leg Clearances
Mantel leg & Non-combustible finishing clearances as per diagram: (Flushed Finish)
Allowablemantel
leg projection
181mm
254mm
330mm
38mm
MANTELLEG
102mm
178mm
Allowablemantel
leg projection
181mm
254mm
330mm
38mm
MANTELLEG
102mm
178mm
Allowablemantel
leg projection
181mm
254mm
330mm
38mm
MANTELLEG
102mm
178mm
83mm
Non-combustible
83mm
Non-combustible
Combustible Material
(152 mm)
(305mm)
(0 mm)
To Uni
t
Base
(617 mm)
(335 mm)
Top of
Fireplace
Opening
(589mm)
(305 mm)
(457 mm)
(254mm)
Non-Combustible facing (min.12 mm)
Non-Combustible steel stud
846 mm to underside
of steel stud
(100mm)
(310 mm)
(200mm)
(385 mm)
NOTES
• For a flushed finish using non-combustible finishing, seven
13mm stand-off tabs around the fireplace opening must
be broken off. The top nailing flange cannot be used and a
non-combustible steel stud must be installed to support the
non-combustible facing.
• Ensure the paint that is used on the mantel and the facing
is high quality or the paint may discolour.

16 | Greenfire® GF1500L-2 Gas Fireplace
installation
Non Combustible Requirements
Flushed Finishing & Framing with Non Combustible Material
The seven fireplace opening standoffs which are located on this unit can be removed
when non combustible material is installed flush with the unit.
(see P. 13).
Non-combustible finishing material on the top and sides must also be used.
871 mm
605 mm
1432 mm
Non-combustible
Combustible
Combustible
Steel Stud
on edge
Timber Stud
Timber Stud
159 mm 446 mm
Non-Combustible
Material
Combustible
Material
Finished
Material
* diagrams shown below are
with top nailing strip removed.
12mm
25mm
38mm
Unit
Unit
Unit MINIMUM THICKNESS OF THE FINISH MATERIAL: 12MM
A minimum thickness of 12mm non-
combustible facing is required.
NOTE
• For flush finishing, the top nailing strip must be removed and a non-combustible
steel stud support added.
NOTE
• The appliance must be installed on
a flat, solid, continuous surface For
example a wood, metal or concrete
floor. In a raised (on the wall)
application the appliance must be
installed on a metal or wood panel
extending the full width and depth of
the appliance.

Greenfire® GF1500L-2 Gas Fireplace | 17
installation
Installing a TV / Artwork Flush with the Unit
Note: All wiring should stay free and clear of the vent system to avoid damage due to heat, if located directly in front of the vent system.
Ensure wiring is secured without any sag.
Heat deflector must overhang front of TV by 51mm.
Follow mantel clearance chart for install height and heat deflector depth.
Note: The TV mounting bracket can not be secured directly to the appliance. It must be secured to framing. The TV depicted in the picture may need to be
higher depending on the style of TV mounting bracket used. The mounting bracket shown is a simple single strip TV secured to framing.
L
51mm
A
B
C
13mm Air Gap
A—Depth of TV & Mounting Bracket B—Height From Base of Unit C—Distance From Top of 13mm Air Gap
127mm 981 mm 351 mm
153mm 1006 mm 376 mm
178mm 1029 mm 399 mm
203mm 1052 mm 422 mm
229mm 1077 mm 446 mm

18 | Greenfire® GF1500L-2 Gas Fireplace
installation
508.0
127.5
75 min.
358
77
TV Recess with 45 Degree Elbow TV Recess with Vertical Venting
IMPORTANT
• The clearances noted are recommended only and not a guarantee of compliance with all TV manufacturers’ maximum
allowable operating temperatures.
• It is the responsibility of the user to check the TV installation instructions to ensure that the location of the TV in relation
to the fireplace is suitable.
• Most television manufacturers instruct the user to not place the television above any heat source. Doing so may negatively
affect the longevity of the television and may negate the warranty.
• If you do place a television above the fireplace, please be aware of the large amount of heat the fireplace generates. Regency
in no way guarantees or takes responsibility for the suitability of the above installation for all homes, or any negative impacts
from placing a TV above the fireplace, including damage to the TV.
127.5 mm
max.
75 mm
min.
508 mm min. 358 mm min.
77 mm max.
51 mm
min.

Greenfire® GF1500L-2 Gas Fireplace | 19
installation
Optional Framing Kit
920-194 01/28/20
OPTIONAL FRAMING KIT
1. Construct the timber framing, ensure inside dimensions are 1095 mm H
x 1394 mm W as shown below.
NN
NN
2. Bend both side nailing strips from the side of the appliance until
positioned as shown below. Determine the overall combined thickness
of the non-combustible board + finished material being used. The
nailing strips can be adjusted up to 38mm. Remove top nailing strip and
recycle.
3. Adjust the nailing strips by loosening 2 screws on each nailing strip -
adjust and retighten screws.
NOTE: depending on the finishing material used.
4. Attach both vertical studs (607-065) to the vertical timber studs and
secure using 6 screws, as shown.
NOTE: Ensure the flat side of the steel stud is facing the timber framing.
(607-065)
Flat side out
5. Secure horizontal steel header stud (606-067) with 2 screws per side as
per diagram.
6. Slide the unit into position. Hook up gas, flueing, electrical and
conversion kit (if purchased) prior to installing the remaining steel studs.
7. Secure the upper horizontal steel stud (606-067) as shown with 2
screws per side.
8. Secure the top large horizontal stud (607-027) with 2 screws per side
as shown. Bring finishing material to the edge of the top framing lip on
large stud (607-027).
9. Install the large lower stud (607-066) with 2 screws on each side.
Header stud
(606-067)
606-067
607-065
607-027
607-066
607-065
Nailing Strips
Remove Top
Nailing Strip
Large stud
(607-027)
Large stud
(607-066)
Horizontal stud
(606-067)
tooltip
Framing Lip
Finishing with
non combustible
material
Use Top Holes
Finishing with
combustible material
Use lower holes
1
GF1500L-1

20 | Greenfire® GF1500L-2 Gas Fireplace
installation
Non Combustible Facing Installation
1. Using screws for use with non-combustible boards-secure non-combustible material around unit, framing and top nailing strip every 150mm.
2. Wipe any debris/dust from the non-combustible material and dry wall.
3. Prior to securing, it is mandatory to prime the facing and edges using a quality primer. This will ensure proper adhesion of the tape, filler and paint.
Failure to follow this procedure will result in cracked seams.
4. Tape the seams using a mesh type tape.
5. Fill seams as normal. Avoid using filler which shrinks excessively. Filler must be cured as per manufacturer's recommendations.
6. Prime wall for a second time for proper adhesion of paint.
7. Paint walls using a high quality paint which will withstand the high temperatures being emitted from this appliance.
IMPORTANT
• Regency Fireplace Products are designed, produced, tested and certified to the highest industry standards. The finishing
of the walls surrounding Regency is as critical as the installation itself. The temperatures around linear gas fireplaces are
typically higher than would be acceptable for the combustible materials.Your Regency Fireplace is no exception to this rule.
Therefore, the units are specified with non-combustible required materials to specific dimensions above and around the
units.This is due to these areas reaching higher temperature levels than required/acceptable for a combustible material. To
obtain the best, most durable finish around your fireplace, this calls for a high level of care and attention to the preparation
and finish around this appliance, using only the highest quality materials, able to withstand the temperatures produced.
• By following the installation instructions in the manual exactly, you will increase your chances for a damage free finish.
• Every precaution is taken in providing the recommendations on preparation and finish, given the variation in paint quality,
with temperature limits and workmanship applied to or used in any application surrounding the fireplace. This includes
framing as well as finishing.
• Over time natural convection from any fireplace can cause discoloration in the area directly above the appliance. Lower
quality paints, under prepared finishes, poor applications and any framing discrepancies or in the installation can cause
this discoloration process to be expedited.
• Discoloration is not the responsibility of Regency Fireplace Products, we believe careful attention to the recommendations
provided here will be result in aesthetically pleasing result free of issues outlined above.
IMPORTANT
• Prior to installation of non-combustible materials by others, check and inspect carefully for any hairline cracks and or
damage to board.The non combustible board must be a minimum of 12mm thick and comply with AS1530-1 and AS1530-3.
Material which is thinner may crack as a result due to the high temperatures this appliance emits.
• To avoid cracking the board-pre-drill holes prior to securing to unit/framing.
IMPORTANT
• To avoid cracking the board, pre-drill holes prior to securing
the unit/framing.
NOTES
• When applying 12mm minimum non-combustible board to framework it is advisable to use the same 12mm minimum non-combustible board on the
whole front face of the wall.
• When using a standard fascia cut out the clean edge trim opening plus a further 10 mm border.
• When using a 15mm finishing trim cut out the clean edge trim opening plus a further 4mm border.
• When using painted 12mm minimum non-combustible board as finished wall surface use 15mm finishing trim.
• When using clean edge trim do not seal heater to finished wall material.
• The above will allow for possible expansion and contraction.
