REITEL STEAMY PR 1 User manual

Operating Instructions
LABORATORY EQUIPMENT IN
STAINLESS STEEL
STEAMY PR
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone.: [phone] | Fax: [phone]
www.reitel.com | [email protected]

II
Dear Customer!
The STEAMY PR is the perfect tool or paper restorators to remove glue from old and
precious paper documents with finely dosed steam, providing for optimum temperature and
humidity level.
Any other use or use beyond this is deemed improper. For resulting damage the
user/operator of this device is solely responsible.
Prior to installation of the device operating instructions and especially the safety instructions
must be read and followed by all personnel who use this device.
After having unpacked the device, please check carefully whether transportation damages of
any kind have occurred. If that is the case, the carrier or manufacturer must be notified within
3 days. The company will not be responsible for any damages found after that.
These operating instructions must be read and followed by all personnel who use this device.
To ensure quick access we recommend to keep it at a safe place near the device. In case of
loss it can be ordered at a nominal fee from the manufacturer.
This document is protected by the copyright law. Passing on or duplication of this document
or extracts thereof, evaluation and communication of its contents are not authorised. In case
of loss it can be ordered from the manufacturer.

III
INDEX
TECHNICAL DESCRIPTION......................................................................................... 4
BASIC EQUIPMENT....................................................................................................... 4
SPECIAL ACCESSORIES................................................................................................ 4
OPERATING ELEMENTS................................................................................................ 4
VERSION WITH FINE NOZZLE FOR PAPER RESTORATION.................................................. 6
VERSION WITH FLAT NOZZLE......................................................................................... 6
TECHNICAL DATA......................................................................................................... 6
SAFETY NOTES........................................................................................................... 7
GENERAL SAFETY NOTES ............................................................................................ 7
SPECIFIC SAFETY NOTES............................................................................................. 8
INSTALLATION............................................................................................................ 9
OPERATION................................................................................................................. 9
CHRONOLOGICAL RUN OF OPERATION........................................................................... 9
DECALCIFYING THE DEVICE WHEN NOT USING DISTILLED WATER ....................................10
TROUBLESHOOTING .................................................................................................11
MAINTENANCE...........................................................................................................12
WARRANTY.................................................................................................................13
DISPOSAL REGULATIONS ........................................................................................16
SPARE PARTS LIST ...................................................................................................17
EU DIRECTIVE ............................................................................................................19

4
Technical Description
Basic Equipment
•Steam cleaner STEAMY PR
Special Accessories
•Order-No.: 20107000 Wall-mounted shelf
•Order-No.: 10106000 BIOSTEAM CENTER with suction
•Order-No.: 10205000 Water softening device DELIMER COMFORT
Operating Elements
1 Steam valve
2 POWER switch
3 Swith to activate hose heating HEATING
4 Indicator lamp „low water level“
5 Heating control
6 Tank cap
7 Steam gun
8 Pistol clip (holder)
9 Steam gun hose
10 Pressure gauge
11 Temperature limiter
12 Device’s fuse
13 Safety valve with deflector plate
14 Transformer

5
Device view
Backside
1
13
11
5
4
6
7
3
9
10
2
12
14
8

6
Version with fine nozzle for paper restoration
Fine nozzle
Version with flat nozzle
Flat nozzle
Technical Data
Line voltage
230 V/50–60 Hz
Current consumption
2.300 W
Height / width / depth
420 / 300 / 350 mm
Weight
14 kg
Pressure
4 bar
Temperature
150 °C
Volume
5 l
Steam level
1
Filling
manual
Sound level
≤70 dB(A)
Housing
Stainless steel
Made in Germany (subject to modifications)

7
Safety Notes
General Safety Notes
•All equipment undergoes final inspection and testing before leaving our factory. However,
if equipment is damaged during shipping or through any other circumstances, it must not
be used in service. Please check the device regularly for damages. Damaged parts
should be replaced immediately.
•All power/air/water/gas sources should be rated for the demands of the device as listed in
the technical data sheets. Maximum ratings must not be exceeded. All VDE (Verein
Deutscher Elektro-Ingenieure) standards should be followed. Equipment should be
grounded according to standards.
•Adherence to valid regulations regarding necessary checks (e.g. according to Accident
Prevention & Insurance or electrical equipment) is exclusively taken over by the
buyer/user of this product.
•This device has been designated to be used only for its intended purpose. All other
applications must be prohibited for safety reasons as otherwise the manufacturer’s
warranty expires.
•The device should be set-up in a clean, well-ventilated room, if necessary under a hood.
•Supporting surfaces should be straight, flat and adequately stable.
•Don’t place anything on top of the machine.
•To avoid injury, appropriate protection should be worn (e.g. gloves, safety glasses, safety
shoes, hearing protection etc.)
•If the machine is defective or working improperly it must be taken out of service. In case
of further use of the machine the owner will be held responsible for any consequential
damage.
•To prevent accidents from water, fire or explosion, all power/air/water/gas sources should
be turned off after working hours and during breaks, and secured against unauthorized
access.
•When carrying out maintenance works or repairs or when opening the device always turn
off the main power switch and unplug the whole unit.
•Repairs should be carried out only by the manufacturer or by qualified and certified
personnel appointed according to chapter 7 –warranty.
•In case of leaking water out of housing or tank shut down device and call service.
•Check all hose joints for tightness, if necessary fasten clamps.

8
Specific Safety Notes
Note:
•Keep a safe distance of at least 100 cm from the safety valve (Back oft he device) to
circulation areas or workplaces –Danger of scalding.
•Ground yourself by laying your flat hand on the steam cleaner’s housing. (Gases or
fluids glowing through pipes generate static electricity. For safety reasons static
electricity is discharged during evaporation by the contact screw at the steam gun’s
handle. If the user gets an electric shock when touching the device or the steam gun,
the person was exposed to static electricity before. The combination of floor covering
and shoe soles is often the reason, falling outside the sphere of influence of the steam
cleaner’s manufacturer.)
•We recommend to fill the device only with decalcified or distilled water (damage due to
limescale deposits is not covered by warranty). Decalcification is depending on water
hardness: every one or two weeks. Verwenden Sie hierfür handelsübliche
Entkalkungsmittel und beachten Sie die Herstellerangaben und Vorschriften. It’s not
necessary when always using distilled water (we recommend to use our water softening
device DELIMER COMFORT –see “special accessories”).
•The steam jet is only to be aimed at objects to be cleaned, never at living beings.
•Only clean appropriate objects ggf. an Muster oder auf unauffälliger Stelle testen.
•The tank cap (6) may only be onpened when the device isn’t under pressure
•The device must not be filled under full heating power and empty tank (danger of
scaling).
•The device should be filled up every morning when it’s in a cold state, protecting the heat
aggregates as well as the gaskets. An unwanted interruption of operation is also avoided.
•In case of leaking water out of the housing or tank further use of the device is prohibited
(see chapter 5 troubleshooting).

9
Installation
The equipment delivered is ready for immediate use. The sealed plug can be connected
directly to the mains supply 230 V/16 A. For installation please refer to chapter 2.
Operation
Chronological run of operation
1. Operate the device only when it’s filled with water. (Pay attention to safety notes in
chapter 2) In order to avoid an unwanted dry-run, a daily filling in the morning is
recommended. Turn the heating controller (5) completely to the left (if necessary ventilate
tank by activating steam gun). Note: Fill the device only in a cold state. Open the tank
cap (6) and fill in distilled or decalcified water up to the edge (a filling funnel is
recommended). Close the tank cap (6) and hand-tighten it.
2. Turn the device on with the switch POWER (2). Set heating control (5) to max. If you
don’t set heating controller to max., the “low water level“indicator lamp lights up (4)
despite a filled tank. However the device is ready for operation, but at a low temperature.
The heating starts automatically. After approx.18 min., pressure has been achieved and
the indicator lamp goues out if the heating controller was is set to max..
3. Start the hose heating with the switch HEATING (3) ein.
4. The maximum steam pressure can be modified with the heating controller (5). (Pressure
is only built up in the upper quadrant of the controller range. Pressure is built up with
delay.)
5. Open the steam valve to take out dry steam (1).
6. Device needs refilling: indicator lamp (4) lights up. For refilling please adhere to chapter 4
Notes for the User, item 1. If the control lamp does not turn off automatically after filling,
please press the temperature limiter (11).

10
Decalcifying the device when not using distilled water
1. Turn switch POWER (2) off.
2. Let the device cool itself down and empty the tank.
3. Fill the tank with decalcifier according to manufacturer’s instructions!
4. Close tank cap (6).
5. Turn switch POWER (2) on. As soon as the pressure starts building up turn down heating
controller (5).
6. Let the device cool down. Release pressure and empty the tank.

11
Troubleshooting
Device cannot be switched on.
a. Check fuse of the building.
b. Check device’s fuse
Safety valve (10) opens or water leaks out.
a. Turn the control unit (5) down and call
customer service. ATTENTION: If
used, do not remove cover and do
not close opening.
b. Tank is overfilled →drain off some
water.
Control lamp (7) shines although there’s
enough water in the tank.
Temperature limiter (11) or control unit (5)
might be released →Set control unit to
max and push temperature limiter back in
again after cooling down - for this purpose
remove black protective cap
Tank cap (6) can hardly be opened.
Ventilate tank by activating steam gun
switch „hot water“ (18)
Tank cap (6) untight.
→Replace cap or seal.
No steam.
a. Cold water was refilled and device is
heating up.
b. Device is calcified, blocked valve,
switches or valves defective →Call
customer services.
No steam pressure.
1. Regulator (5) was not set to max.
Pistol drips.
Device might be calcified or the valve
blocked →
Decalcify or use distilled water.
Electric shocks when using the steam gun
Touch the contact screw (15) on steam
gun while jetting (see chapter 2.2
Specific Safety Notes).
High wear of seals.
→Prior to heating up ventilate tank by
activating steam gun switch „hot water“
(18).
Device doesn’t work after turning it on,
main switch (2) doesn’t shine.
No power at the socket →check fuse for
the building.
Device’s fuse has blown.
→Press overcurrent protection
knob/device’s fuse knob (12) in.
Short circuit
Water in housing: shut down the device and
call customer service.
Attention: Water temperature might be up
to 160°C –Danger of scalding!

12
Maintenance
•Regularly check the device’s state. Pay attention to visible damage to housing or power
cord.
•When using hard water we recommend regular decalcification (chapter 4: Notes for the
user, 4.2 Decalcifying the device when not using distilled water).
•Clean the housing regularly with a moist cloth.
Note
Clean and protect your device regularly with the REITEL stainless steel care spray
(Order-No.: 90405000) to remove lime plaster and dust as well as other contaminants
from the surface of equipment and to prevent corrosion. The spray creates a lasting,
water repellent protective film which helps keep the equipment clean.

13
Warranty
We, REITEL Feinwerktechnik GmbH, offer a 1 year’s warranty beginning from the proven
date of purchase. This warranty covers all defects traceable to materials, design or
workmanship. The following warranty regulations are applicable:
Within the warranty period Reitel Feinwerktechnik GmbH or an authorized distributor agrees
at its sole option, to perform repair or replace this product at no charge covering all defects
traceable to materials, design or workmanship. Warranty only applies to appropriate use and
regular maintenance of this product according to the operating instructions. Claims under
warranty are restricted to complementary performance. Additional claims, especially claims
for indemnifications, are not covered by this warranty.
1.
Warranty claims have to be addressed to the distributor the product was purchased from or
directly to our service department.
Contact:
REITEL Feinwerktechnik GmbH
Senfdamm 20
49152 Bad Essen
Germany
Phone: [phone] (Service Department)
Phone: [phone] (Reception)
Fax-No: [phone]
2.
In case of warranty claim application the sales receipt or your purchase invoice showing the
date of purchase of the product and the serial number must be furnished. Securely pack and
ship the device, freight charges prepaid, at your own risk to us, along with a report describing
the defect. We reserve the right to decline warranty if this information has been removed or
modified after purchase of the product or if they are not included in case of warranty claims.
3.
Warranty repairs have to performed by REITEL Feinwerktechnik GmbH or by authorised
distributors. Repairs performed by non-authorised companies will void the claim for refund
since damages to the product resulting hereof are not covered by warranty.
4.

14
If the unit sent in for repair or replacement is still under the original warranty then warranty is
to the end of the original 1 year warranty.
5.
If the unit is destined to be operated in another country than originally intended and
manufactured for, modifications to the product might be necessary to comply to special
technical and /or safety standards of that specific country. Such modifications are no defects
traceable to materials, design or workmanship. and are therefore expressly excluded from
warranty claims.
Modification costs or damages arising from operation of the product under deviating
conditions are not covered by warranty.
6.
Exclusions from warranty:
−Service and maintenance work as well as repair and replacement of consumables
according to our consumables‘ list
−Transportation cost of the machine or installation and dismounting expenses incurred
−Damages due to use of the product other than for its intended purpose
−Damages due to faulty installation or insufficient maintenance of the product (e.g.
decalcification)
−Damages due to natural disaster e.g. lightning, water, fire, act of nature beyond
control, war, inadequate line voltage, insufficient ventilation, no decalcification,
insufficient care and cleaning or non-adherence to operation and maintenance
instructions according to the accompanying operation guide.
−Damage due to use of the product other than in accordance with the instructions
provided by REITEL Feinwerktechnik GmH;
−The warranty does not cover the cost of removal and replacement of parts and
accessories, unless supplied as original equipment by REITEL Feinwerktechnik
GmbH
−All kind of damages occurred not directly at the device as well as consequential
damages (e.g. damages to furniture due to a lack of water, downtime of the machine,
material, lost working hours, wages and other consequential damages).
This warranty shall be rendered null and void if:
−the product has been subject to any modification, repair or replacement other than as
authorised by REITEL Feinwerktechnik GmbH
−the product is continued to be operated despite a functional defect

15
7.
The warranty is device specific and may be claimed, within the warranty period, by any
person who has legally acquired the device.
8.
Consumables are excluded from warranty. Spare parts are subject to a warranty coverage of
6 months against all defects traceable to materials, design or workmanship according to
these warranty regulations.
9.
Legal default claims on the part of the purchaser remain unaffected by this warranty.
10.
We reserve the right to charge a fee if repair of the device is rejected and the device is
destined to be sent back unrepaired.
11.
Please note:
Upon repair or replacement of this unit, personal data and settings might get lost or
damaged. We don’t accept liability for all kind of data loss. The customer is advised to
backup essential programs and data before sending for service.
12.
This warranty shall be interpreted in accordance with German law to the exclusion of UN
sales law. Place of jurisdiction is our business location.
13.
If any provisions of this warranty are judged to be illegal or unenforceable, the continuation in
full force and effect of the remaining provisions will not be prejudiced. The provisions of this
warranty judged to be illegal or unenforceable shall be construed so as to give effect to the
intent manifested by the provision held invalid, illegal or unenforceable and to give effect to
section 13 hereof.
14.
Should you need to borrow a device while your device is being repaired, please contact
Messrs. REITEL or your distributor. These loans are a service for which availability cannot
necessarily be guaranteed. After the warranty period, a free may be charged for loan
equipment as well as for shipping and packaging.

16
Disposal Regulations
According to valid laws our devices are disposed of according to B2B –
Regulations for proper disposal. Please contact your local dealer for additional
information.

17
Spare Parts List
Best.-Nr.:
Ref.:
Menge
Qty.
ME
Unit
E6220810
Drehknopf / Rotary knob
1
St./pc.
E6227420
Dampfkesselbaugruppe mit SHV + Druckschalter, inkl.
E62277 / Tank with safety valve + pressure switch, incl.
E62277
1
St./pc.
E6221500
Dichtung für Flansch / Sealing for flange
1
St./pc.
E7000800
Dichtung für Tankverschluß 5/PACK / Tank cap seal 5
pcs./pack
5
Pack
E6061820
Drehknopf für Regler / Rotary knob for control
1
St./pc.
E6220600
Druckschalter / Pressure switch
1
St./pc.
E6221800
Eckregelventil / Angle valve
1
St./pc.
E6226100
Einfülltrichter inclusive Dichtring / Funnel incl. sealing
ring
1
St./pc.
24201000
Flachdüse, inkl. Montageumrüstung / Flat nozzle, incl.
Mounting
1
St./pc.
20108000
Abdampfhandstück-Halter / Steam gun holder with
stand
1
St./pc.
20101100
Abdampfschale mit Handstückhalter / Steam bowl with
steam gun holder
1
St./pc.
E6220220
Gehäuse / Housing
1
St./pc.
E6032500
Griff inclusive Scheiben / Handle incl. discs
2
St./pc.
E6060200
Gummipuffer (4 Stück) / Rubber buffer feet
1
St./pc.
E6225700
Gummiring / Rubber ring
1
St./pc.
E6227700
Heizkörper inclusive Flansch und Dichtung / Heating
element incl. flange and seal
1
St./pc.
E7327600
Isoliermatte (nicht gezeichnet) / Isolation mat (not
drawn)
1
St./pc.
E6021200
Kabelverschraubung / Cable screwing
1
St./pc.
E6060400
Klammer für Pistole inclusive Halter (bitte angeben, ob
schwarze oder blaue Pistole) / Clip for steam gun incl.
holder (pls. indicate type of steam gun (black or blue
steam gun)
1
St./pc.
E6220400
Manometer / Gauge
1
St./pc.
E6069900
Pumpe für Entkalkung, Handbetrieb / Pump for
decalcification, manual operation
1
St./pc.
E6061400
Regler / Control unit
1
St./pc.
E7411200
Relais mechanisch / Mechanic relay
1
St./pc.
E6064800
Schalter beleuchtet grün / Green illuminated switch
2
St./pc.
E6175100
Schlauchpaket, beheizt mit Handgriff / Hose package for
steam gun
1
Bgr/unit
E6065000
Schutzkappe für Schalter (2Stck.) / Protective cap for
switch (2 pcs.)
1
Satz/set
E6062300
Sicherheitsventil / Safety valve
1
St./pc.
E7431100
Sicherungsautomat 15A Supersteam ab 05.09.06 /
Automatic fuse 15A Supersteam from 05.09.06
1
St./pc.
E7413400
Signallampe rot, rund / Round red signal lamp
1
St./pc.
E6063000
Tankverschluß ohne Sicherheitsventil / Tank cap
without safety valve
1
St./pc.

18
E6062020
Temperaturbegrenzer / Temperature limiter
1
St./pc.
E6175600
Transformator für Schlauchheizung 24 V/75 W /
Transformer for hose heating 24 V/75 W
1
St./pc.
E6175500
Verschraubung UNI - VS 13 ohne DK, (030) / Screw
joint UNI - VS 13 without DK, (030)
1
St./pc.
E7090000
Verschraubungen, bitte Form angeben / Screw joint, pls.
indicate the form
1
St./pc.
E6071900
Zuleitung / Feed
1
St./pc.

19
EU DIRECTIVE

We manufacture in compliance with Quality Management ISO 13485:2016 incorporating
established standards.
REITEL Feinwerktechnik GmbH
Senfdamm 20 | 49152 Bad Essen
Phone: [phone] | Fax: [phone]
www.reitel.com | [email protected]
122021
