Shark S2901UKCO User manual

S2901UKCO
OWNER’S GUIDE

1 2FREEPHONE 0800 862 0453 www.sharkclean.eu
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WHEN USING YOUR SHARK®STEAM MOP,
BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED, INCLUDING THE
FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING
YOUR SHARK® MULTI-FUNCTION STEAM
POCKET MOP LITE.
DANGER OF SCALDING.
Please use caution when using the steam
mop. The steam emitted from the steam
mop is very hot.
IMPORTANT:
This appliance is not intended for use
by persons with reduced physical,
sensory or mental capabilities, or lack
of experience and knowledge, unless
they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
Children shall not use or play with this
appliance. Close supervision is necessary
to keep appliance out of reach of children
during use and cooling.
26. Keep your work area well lit.
27. Store steam mop indoors in a cool, dry place.
28. To avoid circuit overload, do not operate another
appliance on the same socket (circuit) as the
steam cleaner.
29. If an extension cord is absolutely necessary, an
extension cord rated a minimum of 15 ampere,
2.08mm2(14 AWG) cord should be used.
Cords rated for less amperage may overheat.
Care should be taken to arrange cord so that it
cannot be pulled or tripped over.
30. DO NOT leave unattended when the system is
connected to a power supply or electrical outlet.
Turn off all controls before unplugging the unit.
31. DO NOT store unit with damp or wet cleaning
pocket attached. Never leave the steam mop in
one spot on any surface for any period of time
with a damp or wet cleaning pocket attached as
this will damage your floors.
32. Always unplug and allow the steam mop to cool
before removing or changing mop heads.
33. Make sure that the water tank door is closed
when using the appliance.
WARNING: Your steam mop is
designed to clean hard floor surfaces that
will withstand high heat. Do not use on
unsealed wood or unglazed ceramic floors.
On surfaces that have been treated with
wax or some no wax floors, the sheen may
be removed by the heat and steam action.
It is always recommended to test an
isolated area of the surface to be cleaned
before proceeding. We also recommend
that you check the use and care
instructions from the floor manufacturer.
SAVE THESE
INSTRUCTIONS
14. DO NOT put any objects into openings. Do not
use with any opening that is blocked.
15. DO NOT put hands or feet under the steam
mop. Unit gets very hot.
16. Use ONLY on flat, horizontal surfaces when using in
steam mop mode. Do not use on walls, counters or
windows when using in steam mop mode.
17. DO NOT use on leather, wax polished furniture
or floors, synthetic fabrics, velvet or other
delicate, steam sensitive materials.
18. Liquid or steam must not be directed towards
equipment containing electrical components,
such as the interior of ovens.
19. DO NOT add cleaning solutions, scented
perfumes, oils or any other chemicals to
the water used in this appliance as this may
damage the unit or make it unsafe for use. If
you live in a hard water area, we recommend
using distilled water in your steam mop.
20. When in use, NEVER turn the appliance
over or on its side. NEVER DIRECT STEAM
TOWARDS PEOPLE, ANIMALS OR PLANTS.
21. NEVER LEAVE THE STEAM MOP IN ONE
SPOT ON ANY SURFACE FOR ANY PERIOD
OF TIME WHEN THE CLEANING POCKET IS
ATTACHED AS THIS WILL DAMAGE YOUR
FLOORS.
22. Carefully remove the cleaning pocket
immediately after you have unplugged and
allowed the steam mop to cool.
23. When cleaning the steam mop, unplug the power
cord from the electrical outlet and clean with
a dry or damp cloth. Do not pour water or use
alcohol, benzene or paint thinner on the unit.
24. Extreme caution should be exercised when
using this appliance to clean stairs.
25. Never use steam mop without the cleaning
pocket attached.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
1. Use the system only for its intended use.
2. DO NOT use outdoors.
3. DO NOT leave the appliance unattended when
plugged in. Always unplug the power cord from the
electrical outlet when not in use and before servicing.
4. DO NOT allow the appliance to be used by
children. Close attention is necessary when
used near children, pets or plants.
5. Use only as described in this manual.
6 .
Use only manufacturer’s recommended accessories.
7. DO NOT use with damaged cord or plug.
8. DO NOT USE if the appliance is not working,
has been dropped, dropped into water,
damaged or left outdoors.
9. NO SERVICEABLE PARTS. Incorrect re-
assembly or repair can cause a risk of electrical
shock or injury to persons when the appliance
is used. Contact Customer Service.
10. To protect against a risk of electric shock, DO
NOT immerse the steam mop into water or any
other liquids.
11. DO NOT handle plug or steam mop with wet
hands or operate appliance without shoes.
12.
DO NOT pull or carry by power cord, use power
cord as handle, close a door on the power cord, or
pull the power cord around sharp edges or corners.
Keep power cord away from heated surfaces.
13. DO NOT unplug by pulling on power cord. To
unplug, grasp the plug not the power cord.
Do not use extension cords or outlets with
inadequate current carrying capacity.

3 4FREEPHONE 0800 862 0453 www.sharkclean.eu
Getting Started
When assembling your steam mop there may be a little water in or around the water tank. This is because we test all
our steam mops 100% before you buy them, so you get a quality Shark® Multi-Function Steam Pocket®Mop Lite.
aMop Handle
bCord Clip
cWater Tank Cap
dHandheld Steamer
ePower Button
fRelease Button
gRectangle Mop Head
hCleaning Pocket for Rectangle Head (x4) (P151WEUK )
iCarpet Glider (XCG3501)
n
jAccessory Hose (3010FO2901)
kWindow Squeegee (1078SO)
lConcentrator Nozzle (3011FO2901)
mGrout Scrubber Brush (1081SO)
nFilling Flask (1039SO)
l
m
k
j
a
c
d
i
e
g
h
b
f
Contents
Getting Started ............................................................................................... 4
Assembling Your Steam Mop ........................................................................... 5
Using Your Steam Mop .................................................................................... 6
Using Your Carpet Glider.................................................................................. 7
Using Your Handheld Steamer.......................................................................... 8
Using Your Removable Handheld Steamer with Different Accessories.................. 9
Care of Your Steam Mop................................................................................ 12
Troubleshooting Guide................................................................................... 14
Thank you for
purchasing
the Shark®
Multi-Function
Steam Pocket®
Mop Lite.
This appliance complies with the WEEE-Directive 2012/19/EU on the disposal of electrical and electronic
equipment (WEEE).
This appliance complies with the European directives for electromagnetic compatibility (EMC) 2004/108/EC and its
revisions, as well as Low Voltage Directive (LVD) 2006/95/EC and its revisions.
This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material sources. To return your used device,
please use the return and collection systems or contact the retailer where this product was purchased.
They can take this product for environmental safe recycling.
Disconnect the plug from mains after use.
Although the product is not provided with standby mode, it still fulfills the requirements of 1275/2008/EC - the
directive for Eco-Design requirements since according to technical justification, it is considered as inappropriate
to provide standby and off modes when connecting to mains. To reduce energy consumption be sure to unplug the
unit after use.
Guarantee: This product is unconditionally guaranteed for one year against all defects of workmanship and
materials. This guarantee does not affect your statutory rights. If this product proves unsatisfactory please contact
our customer service department on freephone 0800 862 0453 or by e-mail [e-mail].
IPX4
THIS MANUAL COVERS MODEL NUMBER:
S2901UKCO 11
TECHNICAL SPECIFICATIONS
Voltage: 220-240V~, 50/60Hz
Power: 1250 Watts
Water Capacity: 350 ml

5 6FREEPHONE 0800 862 0453 www.sharkclean.eu
NOTE: To prolong the life of your Steam Mop, we
recommend using distilled water.
NOTE: Sweep or vacuum your floors prior to cleaning
with your Steam Mop.
3Pull and twist the quick release cord holder to
unwrap the power cord completely. Plug into an
electrical outlet. (fig. 5)
4Press the power button to turn the unit on. (fig. 6)
5Clean your floors with a forward and backward
motion.
1Turn the water tank cap counter clockwise and
remove from the tank. (fig. 3)
2Use the filling flask and pour water into the tank. Do
not overfill. Replace the cap on the water tank.
(fig. 4)
IMPORTANT: Do not use on unsealed wood or
unglazed ceramic floors. On surfaces that have
been treated with wax or some no wax floors,
the sheen may be removed by the heat and
steam action. It is always recommended to test
an isolated area of the surface to be cleaned
before proceeding. We recommend that you
check the use and care instructions from the
floor manufacturer.
IMPORTANT: Make sure you do not use the
mop without attaching a cleaning pocket and
adding water to the tank first. When you are
using the mop for the first time, it might take
longer than the normal 30 seconds to start
steaming.
Using Your Steam Mop
fig. 3
fig. 4
fig. 5
fig. 6
IMPORTANT: Always make sure the mop is
UNPLUGGED from the wall when not in use.
Never fill the mop, attach the mop head,
change or remove the cleaning pocket when
the mop is plugged into the wall. To prolong
the life of your Shark®Multi-Function Steam
Pocket®Mop Lite we recommend using
distilled water. Make sure you only add water
to the tank. Chemicals or cleaning solution
may damage the appliance and could be
unsafe for you and your family.
Assembling Your Steam Mop
fig. 1 fig. 2
STEAM MOP ASSEMBLY
1Insert the Mop Handle end with the “ “ facing the
front of the unit into the handheld steamer. Push the
mop handle in until you hear it click into place. (fig. 1)
2Select the Rectangle or Triangle mop head and the
desired cleaning pocket. Fit one side of the pocket
onto the head first, then using the loop, pull the
pocket over the head. Attach the quick fasteners on
the top of the pocket to secure in place.
3Snap the mop head into the mop body by lining up
the groove on the back of the mop body with the
groove on the back of the mop head. Push until you
hear it latch into place. Press the release button to
remove or change the mop head. (fig. 2)

7 8FREEPHONE 0800 862 0453 www.sharkclean.eu
Your Shark®Multi-Function Steam Pocket®Mop
Lite is designed to clean surfaces that will withstand high
heat and moisture. Do not use on unsealed wood surfaces
(especially wooden antique furniture), unglazed ceramic
tile, painted surfaces or surfaces that have been treated
with wax, oils, varnishes, or shellac. The sheen may be
removed by the heat, steam, and friction of the cleaning
tools. Lacquer and polyurethane coatings provide a hard
durable protective finish that withstands moisture, but it
is always recommended to test an isolated area of the
surface to be cleaned before proceeding.
We also recommend you check the use and care
instructions from the surface manufacturer.
When cleaning finished wood surfaces, use broad,
continuous cleaning strokes. To prevent surface damage,
avoid focusing steam or allowing the cleaning tools to sit
in one spot for any amount of time.
Using Your Handheld Steamer
1To remove the Handheld Steamer, press and hold
down the Handle Release Button while pulling out
the handle. (fig. 10)
2To remove the mop head, press the mop head
release button and pull the mop head off. (fig. 10)
fig. 10
6Use the shaggy side of the cleaning pockets to lift
up and lock away all the dirt and debris and the
scrubbing side to break up the tough stains. (fig. 7)
7When the water tank is empty, the Steam Mop will
stop producing steam. You can refill the water tank
at any time as long as the mop is unplugged from
the outlet. Follow the instructions from page 8. This
applies to switching the mop head or cleaning pocket
as well.
NOTE: Please wait 2-3 minutes for the Steam Mop
to cool off before switching the mop head or the
cleaning pocket. Never leave the Steam Mop with a
damp/wet cleaning pocket on any floor.
8When you are done, press the power button to turn
the steam mop off.
Using Your Carpet Glider
THE CARPET GLIDER
1The Carpet Glider can be used with the Rectangular
Head to lightly steam your carpet and area rugs.
Just place the mop head with cleaning pocket
attached into the glider. (fig. 8)
2Move the Steam Mop back and forth across a
section of the carpet. (fig. 9)
fig. 7
fig. 8 fig. 9
The Steam Mop will not clean your
carpeting or area rugs. However, it is
great for grooming and freshening.

9 10FREEPHONE 0800 862 0453 www.sharkclean.eu
fig. 13
USING THE CONCENTRATOR NOZZLE
Cleaning Tip: The Concentrator Nozzle creates direct
steam spray to clean and sanitise hard to reach nooks
& crannies and other places where germs may build
up. Use the Concentrator Nozzle to loosen and dislodge
compact dirt often found in corner and tight places where
traditional methods and cleaning tools tend to push dirt
into, making it tough to reach and clean. Spray direct
steam and wipe clean with a wet cloth or paper towel.
1Attach the Concentrator Nozzle by pressing the
nozzle onto the Accessory Hose until it clicks into
place. (fig. 13)
2Press the power button to start the steamer.
For effective cleaning, hold the steam output nozzle
1-2 inches away from the surface you’re cleaning.
CAUTION: Do not press the power button until
the Concentrator Nozzle is snapped into the
accessory hose of your Handheld Steamer.
3To remove the Concentrator Nozzle, press and hold
the accessory release button, then pull it out of the
Accessory Hose.
CAUTION: Do not press the power button while
removing the Concentrator Nozzle. Avoid
touching the tip of the Concentrator Nozzle, as
this will be very hot after steaming.
NOTE: The Handheld Steamer may continue to emit
steam for a few seconds after the power button is
pressed to turn the unit off. This is normal, and the
steaming will eventually come to a stop.
CAUTION: Do not press the power button while
attaching or removing the Accessory Hose.
CAUTION: Do not use the Accessory Hose
without cleaning tools attached.
1First attach the Accessory Hose to the Handheld
Steamer by snapping the Accessory Hose into the
main nozzle. (fig. 11)
2 Select the desired cleaning tool for use. Follow the
cleaning tool sub-assembly instructions for the
selected tool. (fig. 12)
3To remove the Accessory Hose, press and hold
down the Handheld Release Buttons. Then slide out
the Accessory Hose using the grip.
fig. 11
Release
Button
Using Your Removable Handheld Steamer
with the Different Accessories
fig. 12

11 12FREEPHONE 0800 862 0453 www.sharkclean.eu
AFTER USE AND STORAGE
1Press the power button to turn the unit off. Unplug
the cord from the outlet and place the mop into the
upright position. Let the unit cool for 2-3 minutes.
2When you have finished using the Handheld Steamer,
reattach the handle to the handheld steamer.
Care of Your Steam Mop
fig. 16
3Remove the cleaning pocket from the mop head by
releasing the quick fasteners and using the loop on
the side of the pocket, avoiding contact with the hot
pocket or dirt.
4 Empty the water tank before storage. Remove the
water tank cap and empty the tank over a sink.
Replace the water cap.
5To store the Shark®Multi-Function Steam
Pocket®Mop Lite hanging up, first remove the head
(after it has cooled and the steam has been released)
then hang on a large hook. (fig. 16)
USING THE WINDOW SQUEEGEE
Cleaning Tip: To use the window squeegee, work with
the vapor jet down using top to bottom movements. To do
this without leaving streaks, use lateral movements from
the top to the bottom of the surface.
CAUTION: Always avoid any sudden changes in
temperature to prevent breakage of cracks in
windows.
1Attach the Window Squeegee by snapping into the
handle of the Accessory Hose until it clicks into
place. (fig. 15)
2Press the power button to start steaming.
3To remove the Window Squeegee, press and hold
down the Accessory release button. Then slide out
the Window Squeegee.
CAUTION: Turn the unit off before attaching or
removing the Window Squeegee.
USING THE GROUT SCRUBBER
Cleaning Tip: The Grout Scrubber is designed for
removing stubborn messes in hard-to-reach nooks,
corners and in grout where focused scrubbing power
may be needed. It can loosen and dislodge compact dirt
often found in corners and tight places where traditional
methods and cleaning tools tend to push dirt into,
making it difficult to reach and clean. Scrub with the
Grout Scrubber and wipe clean with a cleaning cloth.
1Attach the Grout Scrubber by snapping into the handle
of the Accessory Hose until it clicks into place.
(fig. 14)
2Press the power button to start steaming.
3To remove the Grout Scrubber, press and hold
down the Accessory release button. Then slide out
the tool out.
CAUTION: Turn the unit off before attaching or
removing the Grout Scrubber.
fig. 14
fig. 15
Using Your Removable Handheld Steamer
with the Different Accessories - cont.

13 14FREEPHONE 0800 862 0453 www.sharkclean.eu
Troubleshooting Guide
PROBLEM POSSIBLE REASONS & SOLUTIONS
The Shark®Multi-Function
Steam Pocket®Lite Mop
will not turn-on.
Your steam mop should be securely plugged into an electrical outlet only.
Check your fuse or breaker.
The unit will not make
steam.
Is there water in the water tank? If not, add water to your steam mop following
instructions on page 8.
When using the unit in the handheld mode, ensure that you are holding the
handheld unit horizontally to optimise the steam output. Do not hold the
handheld unit vertically as this will impede steam production. Use the hose with
your chosen accessory to reach difficult areas and above floor cleaning whilst
maintaining the horizontal position of the handheld unit.
If the unit still does not make steam, follow the instructions on page 13 to clean
the nozzle.
The Shark®Multi-Function
Steam Pocket®Lite Mop
leaves water on the floor.
Check to see if your cleaning pocket is too wet. We recommend you unplug the
steam mop and change the cleaning pocket.
Make sure the cleaning pocket is attached correctly.
The Shark®Multi-Function
Steam Pocket®Lite Mop left
a white spot on the floor.
Do not leave your steam mop on the floor with a damp or wet cleaning pocket.
If you’re using tap water, we recommend switching to distilled water.
Make sure the cap is securely on the water tank.
Floors are cloudy, streaky
or spotty after steaming.
The cleaning pocket might be dirty. Flip or change the cleaning pocket.
If you washed the cleaning pocket with powder detergent, then your pocket
could be damaged and require replacement. Replacement pockets are available
at www.sharkclean.eu.
This could also be an indication of prior soap or grease residue that has
accumulated on the floor. As our steam mops use only a small amount of
water, it may not be wet enough to rinse off the accumulation that the steam
is bringing to the surface. We suggest rinsing the floor with nothing but water,
letting it dry, and then steam mopping again with a clean pocket. One or more
rinses generally removes the residue.
A more stubborn case may require you to rinse the floor with a mix of one part
vinegar and two parts water.
The Shark®Multi-Function
Steam Pocket®Lite Mop is
hard to push.
Make sure the cleaning pocket is attached correctly.
Check to see if the cleaning pocket is excessively dirty. If so, replace the
cleaning pocket.
DECALCIFYING YOUR STEAM MOP
Calcium and mineral deposits can build up and
impact the performance of your steam mop
over time. To extend the life of your product we
recommend that you use distilled water.
CARE OF YOUR CLEANING POCKETS
1We recommend washing your cleaning pocket
separately from other fabrics to avoid picking up lint.
For optimal cleaning performance, the pockets may
need to be washed up to (3) three times. Only use
liquid detergent (no powder detergent). Do not
use any fabric softeners or bleach. Line dry. Do
not tumble dry. (fig. 17)
2If there are loose threads on the cleaning pocket,
carefully cut the thread with scissors. Do not pull on
them or cut at the base. (fig. 18)
IMPORTANT: The cleaning pocket may be
very hot from the steam. Use caution when
removing. Let the unit cool for 2-3 minutes.
fig. 17
fig. 18
fig. 19
CLEANING THE NOZZLE
NOTE: To prevent clogging, it is recommended that
you periodically clean the Direct Steam Nozzle and
the extension hose stem.
1Your Handheld Steamer should not normally require
cleaning, however, should you notice a decrease in
the steam output, it may be necessary to remove
mineral deposits built up around the nozzles.
2Unplug the cleaner from the electrical outlet.
3Use a small diameter stiff metal wire, such as a
straightened metal paperclip, and carefully insert the
end of the wire into the nozzle orifice. See illustration
above. (fig. 19)
4Move the wire back and forth several times to remove
any deposits.
5Plug in the appliance to the power outlet and test
steam output.
40°
Care of Your Steam Mop - cont.

IPX4
Euro-Pro Europe Limited
15 Mariner Court
Calder Park
Wakefield
WF4 3FL
Freephone 0800 862 0453
www.sharkclean.eu
Technical Details
Model number: S2901UKCO 11
Input: 1250 Watts
Main unit voltage: 220-240V~, 50/60Hz
COPYRIGHT© EURO-PRO OPERATING LLC 2015
Euro-Pro, Shark and Steam Pocket are registered
trademarks of Euro-Pro Operating LLC.
PRINTED IN CHINA
S2901UKCO_11_IB_E_151005_2
Illustrations may differ from actual product.
