PUETZ GOLF WHL-603 User manual
STEAMCLEANER
USERGUIDE
PUETZ
GOLF
Catalog
FAQ......................................................
QuickStartGuide.................................
TechnicalSpecification.........................
Accessory Installation..........................
WindowWiperInstallation.....................
Warranty...............................................
2-3
4-5
6
7-8
9
10
Question1：What's the highest temperature that this steam cleaner can achieve?
Question2：If I want to add water again after use, why can't the safety cap be opened?
Question3：How to add water?
1. Fill clean water into the measurement cup up to the marking no more than 250ML.
2. Fill in the water into the boiler with the funnel without exceeding 250ML of water.
3. Plug the safety cap firmly by clockwise rotating
The internal temperature of our steam cleaner can reach 230°F (110℃) and the steam
comes out at a temperature of 212°F-221°F (100-105℃). For the sake of safety, the
designed temperature of the steam cleaner can only reach 230°F (110℃) to avoid
damage in high temperature. Deep cleaning is not recommended because the
cleaning at the designed temperature of 230°F (110℃) can secure personal safety
when eliminating the stains. It is recommended that the cleaner is always plugged in.
FAQ
1 2
Unplug First Add water into the
steam cleaner
Open the lidFully discharge the
residual steam and
wait red spot sinks down
Keep pressing down
Question4: How to use the safety steam button?
As shown in the following pictures (Left: LOCKED—Right: UNLOCKED)
Question5：Who could I to contact in case of my accessory damage?
1 . Unplug the safety cap;
2 . Add about 250ML of water with a
funnel and measuring cup;
3 . Plug the safety cap;
4 . Install the accessories;
QuickStartGuide
01
04
03
02
CAUTION:
For the sake of safety, you shall
wait for 3-5 minutes for the safety
cap to cool down and then you
can unplug the safety cap.
!
3 4
5.Plug the power cord and wait 3-4
minutes to warm up;
6.When the red LED has changed to
disappear, you can use the steam
cleaner after driving the safety lock;
7.You can use to clean places where
necessary.
05
06
07
Model:
Voltage/Frequency:
Rated Power:
Water Tank Capacity:
TechnicalSpecification
WHL-603 Heating Time: 3-4 minutes
AC 110-120V, 50/60 Hz Usage Time: 8-12 minutes
900-1050W Flow Rate: 28 g/min
350ML Steam Pressure: 0.26-0.32 Mpa
Safety Cap
Indicator Light
Cable
ON/OFF Button
Measuring
Cup
Funnel
Towel Sleeve
Nozzle
Accessory
Nozzle
Window/Door
Brush Plate
Faric Steamer
Tool
Extension
Hose Brush Head Bend Spray
Cup
5 6
Accessory Installation
Attach Faric Steamer Tool/Use to Clean Faric & Clothes or Other Places
Attach Window/Door Cleaning Tool/Use to Clean Windows or Other Places
Attach Spray Cup with Round/Use to Clean Sofa, Bed or Other Places
Attach Long Spray Nozzle/Use to Clean Kitchen Furniture or Other Places
Attach Bent Nozzle/Use to Clean Toilet or Other Places
Attach Extended Connecting Spray/Use to Clean Floor
Gap & Wall Cracks or Other Places
1
2
3
4
5
6
7 8
WindowWiperInstallation
The window wiper can be used to clean windows,flat and smooth flooring.
Installation: First, hook the lower mounting clips of the window wiper (A)
onto the lower edge of the steam iron and then clip the upper mounting
clip (B) into the upper edge of the steam iron.
Removal: Push the upper window wiper clip (B) forwards and pull the
wiper away from the steam iron. Unfasten the lower clips (A) and remove
the window wiper.
B
B
A
A
A
A
Complete
Iron Brush
Window Wiper
12
9
PUETZ
GOLF
Warranty・PuetzGolfSteamCleaner
LimitedOneYearWarranty
The warranty offers you specific legal rights.And you also have other
rights which may vary from state to state. If you need additional instruction
regarding this warranty or have any questions regarding what it may cover,
please contact Puetz Golf Consumer Services by E-mail, as described below.
Subject to the EXCEPTIONS AND EXCLUSIONS identified below, upon
receipt of the product Puetz Golf will repair or replace (with new re-
manufactured components or products), at Puetz Golf's option, free of
charge from the date of purchase of the original purchaser.
We offer a Warranty of one year for any defective or malfunctioning part.
See information below on If your Puetz Golf product should require service.
This warranty does not apply to fans or routine maintenance components
such as filers, belts, or brushes. Damage or malfunction caused by
negligence, abuse, neglect, unauthorized repair, or any other use not in
accordance with the User's Guide is not covered.
If you need infonnation about repairs or replacement parts, or if you have
questions about you warranty, contact Puetz Golf Consumer Services.
WebsiteandE-mail
https://www.puetzgolf.com
