Relax-A-Lounger EVANDER User manual

8 of 8 Rev.10132016
EVANDER WITH ROLL ARM
TOLL FREE 1-877-693-8866 LIFESTYLE SOLUTIONS
R

PARTS AND HARDWARE
Avoid using sharp objects such as a knife to cut open packing as you may accidentally damage the upholstery.
7 of 82 of 8
M8 x 30mm
Bolt
x 2
M8 x 40mm
bolt
x 6
M8
Nut
x 2
M8 x 22mm
Washer
x 6
Seat Body
x 1
Backrest
x 1
Back Cushion
x 2
Pillow
x 2
Wood Leg
x 4
Arm
x 1 Pair
14mm
Spanner
x 1
M5
Allen key
x 1

3 of 8
ASSEMBLY INSTRUCTIONS
CAUTION: At least two adults are required to safely perform this task.
Other lifting attempts may risk back injury due to large and heavy part(s).
Carefully place arms and wood legs as shown below, secure the legs by screwing
into pre-drilled holes on the bottom of arm by hand. Please avoid overtightening.
Assemble the backrest onto the frame legs with short bolts, and nuts by provided
allen key and spanner.
6 of 8

Align arms and metal frame , secure with a long bolt and washer at the
pre-drilled holes on the arms with provided allen key.
3
Place both back cushions and pillows on assembled sofa body.
4
5 of 8
4 of 8
Converting to bed
OPERATING YOUR UNIT
Remove the back cushions and pillows first,standing at the front of the unit (from sofa
position), lift the seat cushion pull out until it can not move.
Push over the backrest on to metal frame. Adjust the gap between the seat cushion and
backrest . Then place your back cushions and pillows.
