Royalcraft Santorini Set User manual

Santorini Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 1 / 6

www.ro
y
alcraft.co.uk
Product size:
Table: L180*H75 cm
Bench: L180*H75 cm
Stool: L180*H75 cm
This product is for Domestic Use only!
IMPORTANT, RETAIN FOR FUTURE REFERENCE
READ CAREFULLY

Santorini Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 2 / 6

www.ro
y
alcraft.co.uk
Before you start
Warnings
IMPORTANT, RETAIN FOR FUTURE REFERENCE
READ CAREFULLY
See enclosed instructions for assembly, safety and care
information.
Failure to follow the warnings could result in serious injury.
Handle heavy parts with care.
Ensure that this product is fully assembled as illustrated before
use.
This product should only be used on firm, level ground.
Keep small parts out of reach of children.
Do not stand or climb onto this product.
This product is intended for domestic use only.
Furniture can be dangerous if incorrectly used. No liability will be
accepted for damage or injury caused by incorrect use of this
product.
Dos
When you are ready to start, make sure that you have the right
tools, plenty of space and a clean, dry area for assembly.
Remove all packaging and banding and place the components
carefully on suitable surfaces to prevent damaging or scratching
them.
Check the pack and make sure you have all of the parts listed.
Check all screws and bolts are tightened and inspect regularly.
This product is suitable for all year outdoor use, but we
recommend that a furniture cover be used to add additional
protection to your product when not in use.
PLEASE NOTE - All cushions should be stored indoors after use.
The cushions are not waterproof.
During severe weather conditions and in the winter months we
recommend moving your furniture inside into a cool, dry place.
Before storage, ensure that the product is clean and dry.
To clean, wipe down with a sponge and warm soapy water and
wipe with a clean, dry cloth.
Cushions should be cleaned following the care instruction on the
label.
Don’ts
Do not use scourers, abrasives, washing powders, chemical cleaners
or any other substances containing abrasives since these substances
can damage the product.
Never tilt the product during use.
Do not place very hot or very cold items on the table surface
unless adequately thick table-mats are used to prevent such
items from coming into contact with the glass.
Do not use the table as a chopping surface. Do not strike table top
with hard or pointed items.
Do not use power tools to construct this product.
Do not use this product if parts are missing, damaged or worn.
Do not sit or lean on the table.
Do not stand or climb onto the product and do not use it as a ladder,
as this could lead to it unbalancing and overturning.
Never drag furniture when moving it, always lift it.
Number of people required for assembly
Two people
Time to assemble
20 Minutes
Tools required


Tips:
Do NOT fully tighten bolts before
all components are connected.
Only fully tighten once you are
satisfied with the alignment of all
components.
Do not overtighten bolts.

Santorini Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 3 / 6

www.ro
y
alcraft.co.uk
This dining set includes below parts.
The Table is KD which needs assembly.
Combination
Part No. Diagram Name Qty.
1
Table
(assembly
required)
1 PC
2
Bench 2 PCS
3
Stool 2 PCS

Santorini Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 4 / 6

www.ro
y
alcraft.co.uk
Components, fixtures & fittings (not actual size)
Table Parts List
Part
No. Diagram Qty. Part No. Diagram Qty.
A
Table Top Frame
1 PC B
Leg
4 PCS
C
Connecting Ring
1 PC D
Base
1 PC
E
Glass Top
1 PC S1
Spanner
1 PC
F2
Bolt Head Cap
20 PCS W20
M6*20mm Bolt
8 PCS
W35
M6*35mm Bolt
12 PCS F3
Washer
20 PCS



Santorini Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 5 / 6

www.ro
y
alcraft.co.uk
Step by step assembly instructions
Step One
Open the packaging with the glass face down
on a flat surface. Leave the glass on the carton
until the rest of the table is fully assembled.
With the help of another person,
place the Table Top Frame (A) upside down
on a flat, non-abrasive surface to
avoid scratching the table surface or rim.
Step Two
Place the Table Legs (B) onto
the Table Top Frame (A),
aligning all holes in each part.
Loosely attach the Table Legs
to the Table Top Frame using
Washers (F3) and Bolts (W20).
Loosely attach the Connecting Ring (C) onto The Table Legs (B), aligning all holes in
each part, using Washers (F3) and Bolts (W20).
Only tighten the bolts when all bolts and washers are in place and turn freely. Once you are
satisfied with the alignment of the components carefully tighten all bolts using Spanner (S1).
Do not over-tighten.
Cover each bolt with Bolt Head Cap (F2).

Santorini Set
Assembly Instructions
ProducedinChinaforA.Mir&Co.,Ltd.
© A. Mir & Co., Ltd. 6 / 6

www.ro
y
alcraft.co.uk
Step Three
Loosely attach the Base (D) onto
The Table Legs (B), aligning all parts
and fastening by Washers (F3) and Bolts (W35).
Only tighten the bolts when all bolts
and washers are in place and
turn freely. Once you are satisfied
with the alignment of the
components carefully
tighten all bolts using Spanner (S1).
Do not over-tighten.
Cover each bolt with Bolt Head Cap (F2).
Step Four
With the help of another person,
carefully turn the table in the
upright position.
Note: There are adjustable feet screws
under the base, adjust the feet screws
to ensure the table is evenly placed
on the level ground.
Don’t place the glass until the table is even
and stable.
Carefully place the Glass Top (E)
onto the Table Top Frame (A).
Your table is now ready for use.
Never tilt the product during use.
Ensure the product is always placed firmly on the ground.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
Adjustable Foot Screw
