Relaxis 09-0020-01 User manual

Patent No. 9,017,273

1
Patent No. 9,017,273

2
Patent No. 9,017,273

3
Patent No. 9,017,273
Figure 1: Relaxis system

4
Patent No. 9,017,273

5
Patent No. 9,017,273
Figure 2: Packaged system
Figure 3: Connecting the power
supply to the controller
Controller
Power
Supply

6
Patent No. 9,017,273
Figure 4: User controls
and lights
Figure 5: Lights at the
bottom of controller
Figure 6: Pad position example for
sleeping on your back
On/Off Power
Button
Line Power
Light
Increase Intensity
Button
Intensity Indicator
Lights
Decrease Intensity
Button
Fault Light
Line
Power
Light
Fault
Light

7
Patent No. 9,017,273
Figure 7: Pad position example
for sleeping on your side
Figure 8: Controls for
adjusting vibration intensity
Increase Intensity
Button
Intensity Indicator
Lights
Decrease Intensity
Button

8
Patent No. 9,017,273
Problem
1. No power (green Line Power
Light does not turn on)
2. Fault Light activated (yellow
Fault Light is on)
3. Pad continues to vibrate
after pressing the Power
Button to turn off the system
Possible Solution
1. Make sure the power supply is plugged securely
into both the controller and the wall outlet.
2.Conrmthatyouareusingthepowersupply 
provided with your Relaxis.
3.Conrmthatyouareusinga“live”outlet.
4. Push the Power Button to turn on the system.
1. Push the Power Button to turn off the system.
2. Wait for 15 minutes.
3. Push the Power Button to turn the system back on.
1. Push the Power Button again to turn off the system.
2. If the pad continues to vibrate, unplug the power
supply from the wall socket and call your distributor.

9
Patent No. 9,017,273
Problem
4. Relaxis shuts off before the
end of the 35-minute
therapy cycle
5. Cannot change the vibration
intensity
Possible Solution
1. Check that the power supply is plugged
securely into the controller and the wall outlet.
2.Conrmthatyouareusingthepowersupply
provided with your Relaxis.
3. Push the Power Button to turn on the system.
4.ConrmthatthegreenLinePowerLight
turns on.
5. Adjust the vibration intensity to the setting
that feels best for you.
1. Push the Power Button to turn off the system.
2. Push the Power Button to turn the system
back on.
3. Hold down the Increase Intensity Button until
all of the Intensity Indicator Lights turn on.
4. Adjust the vibration intensity to the setting
that feels best for you.

10
Patent No. 9,017,273

11
Patent No. 9,017,273

12
Patent No. 9,017,273
Federal (USA) law restricts
this device to sale by or on
the order of a physician.
Non-Sterile
Reference Number
Serial Number
Batch Code
Connected to power. When
the green Line Power Light on
the controller is illuminated, the
Relaxis system is receiving
power from the wall socket.
Temperature limits for
transport and storage.
Power supply ingress protection
(IP) rating. An ingress rating of
40 indicates the power supply
enclosure is protected against
ingress of solid particles with a
diameter greater than 1mm and
has no ingress protection for
water.
CSA-certiedforCanada
and U.S.
Follow instructions for use. It
is important to read all of the
Operation Manual with careful
attention to warnings and
cautions before using this
product.
Manufacturing Date
Powersupplyisclassiedas
Class II
Device has type BF applied
parts
Caution: If the yellow Fault
Light on the controller turns
on (Figures 4 and 5), refer
to Troubleshooting section.
Humidity limits for transport
and storage.
Relaxis IP rating. An ingress
rating of 22 indicates the pad
and controller enclosures are
protected against ingress of
solid particles with a diameter
of 12.5mm and ingress of
vertically falling water drops
when the enclosure is tilted
up to 15º.
Rx only
IP40 IP22
!
NON
STERILE
REF
LOT
SN
-25° C
70° C
0%
93%
C US

13
