Relcom CBR-A0050A User manual

2221 Yew Street
Forest Grove, Oregon 97116 USA
[phone] or [phone]
Fax [phone]
www.relcominc.com
500-146 Rev. 0 02.12.09
Assembly
Instructions CBR-A0050A CBR-A0060A 19” Rack
Mount Kit
CBR-A0050A
Single Unit Kit Qty
ABottom Support 1
BBottom Screws 4
CFront Plate (single) 1
DFront Screws 4
ELocking Nuts 2
CBR-0060A
Dual Unit Kit Qty
ABottom Support 2
BBottom Screws 8
CFront Plate (dual) 1
DFront Screws 8
ELocking Nuts 4
Remove the front Bezel of the Repeater by
removing the two side retaining screws.
Remove the four screws that hold the
Repeater's front panel and discard them.
Place the Repeater upside down on a flat
surface and position the Bottom Support
(A) so that the end with two drilled holes
is in alignment with the front panel of the
Repeater.
Secure the Repeater to Bottom Support
(A) with the four Bottom Screws (B).

2221 Yew Street
Forest Grove, Oregon 97116 USA
[phone] or [phone]
Fax [phone]
www.relcominc.com
500-146 Rev. 0 02.12.09
Stand Repeater on its rear end and place
Front Plate (C) over the front panel of the
Repeater so that the two bolts on the back
of Front Plate (C) go through the two holes
in Bottom Support (A).
Partially insert all four Front Screws (D)
through Front Plate (C) then tighten.
Position Repeater assembly so that the
underside of Bottom Support (A) is
accessible.
Attach Locking Nuts (E) to bolts of Front
Plate (C) and tighten.
