Rellorus HCF003 User manual

Automatic Pet Feeder
Model: HCF003
User Manual
Manufacturer: Shenzhen Yilan Network Technology Co., Ltd.
Address: Room 501-R21, Building 1, TOD Technology Center, No. 7, Lipu
Street, Dafapu Community, Bantian Street, Longgang District, Shenzhen
Made in China Rev_1.0
Questions or Concerns?
?
!
https://www.rellorushome.com
suppo@rellorushome.com

EN
DE
FR
ES
IT
01
17
33
49
65

SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE AND SAVE FOR FUTURE REFERENCE
When using an electrical appliance, especially when children are present, basic safety
precautions should always be followed, including the following:
INTENDED USE
Close supeision is necessa when any appliance is used by or near children. Children
should be supeised to ensure that they do not play with, in or around the appliance.
Intended for use with dogs or cats only. Do not use this pet feeder with puppies, kittens,
dogs or cats not able to reach the food tray or with any physical disability.
Use the appliance only for intended household purposes as described in this User Manual.
ELECTRICITY SAFETY
DO NOT operate the appliance if it has a damaged power cord or plug, or if it is
malfunctioning or has been damaged in any manner.
DO NOT immerse power cord, plugs, or the device base in water or other liquid or
allow moisture to come into contact with these pas.
To reduce the risk of electrical shock, do not place or store an appliance where it can
fall or be pulled into a tub or sink.
Always unplug the appliance when not in use, before putting on or taking o pas and
before cleaning. Never unplug by pulling on power cord.
Use ONLY the provided power adapter and charging cable.
If the supply cord is damaged, it must be replaced by the manufacturer, its seice
agent or similarly qualied persons in order to avoid a hazard.
RELATED TO USE
DO NOT attempt to disassemble, repair, modify or replace any pa of your product. All
seicing should be peormed by qualied personnel only. No user seiceable pas inside.
DO NOT allow pets to chew on or swallow any pas. Cover or hide the power cord
with care to prevent pets from biting.
DO NOT lift the pet feeder by lid, hopper, bowl or bowl holder. Lift and car feeder
using both hands and hopper base, while keeping unit in upright position.
Install or store pet feeder on a level suace against wall or in a corner to avoid tripping.
For d food use only. Do not use wet, canned, moist food or pet food with special
shapes, holes or diameter above 12mm/0.47 inch.
Install 3 alkaline D batteries (not included) for back-up power in case of a power outage.
Before leaving for extended time, always replace batteries with new batteries. Check
operation frequently to be sure the pet feeder is dispensing properly.
Dispose of all packaging materials properly. Keep away from children and pets.
Desiccant Box
Lid Lock Buckle
Food Tank
Tank Base
Tank Lock
Batte Compament
Power Po
Speaker
Lid
LED Display
Control Panel
Food Outlet
Stainless Steel
Bowl
Bowl Holder
Splitter
Exploring Your Pet Feeder
1 x Power Adapter
1 x USB to DC Cable
1 x Desiccant Bag
(* Replace eve 30 days)
0201
Other Accessories
Specications
Capacity
Applicable Kibble
5L / 1.32 Gal
0.07-0.47 inch / 2-12 mm d food
DC 5V Power Adapter
3 x Alkaline D Batte (not included) for backup
Power Supply
IMPORTANT SAFETY INSTRUCTIONS
EN

0403
Assembling Your Pet Feeder
1
2
Press lock buckle to open lid. Take out all accessories and remove all packing materials.
1
Align the notches and snap the right holder into the left one.
4
Place bowls in bowl holders. Lift feeder and attach the bowls to the notch underneath
the base.
5
Take desiccant bag out from packaging, open desiccant box and place it in. Put the lid
back on.
6
Plug in DC cable. Install 3 D batteries (not included) for back-up power in case of a
power outage.
2
Align the notches and snap splitter into the left bowl holder.
3
12
1
2
X2

0605
LED Display Control Panel
Time (24-Hour) /
Poion (P: 1-48) Locked / Unlocked Recording
Back-up Batte Status Meal Plan: 1-6 Food Stuck / Error
Unlocked Status:
•Hold for 2s until a beep is heard to sta recording (Max. 10s) and release
to stop.
•Double tap to play.
•Triple tap (within 1s) to turn on/o recording function.
Recording
•Tap once to dispense one poion of food. Tap repeatedly to dispense more
poions.
Manual Feeding
Unlocked Status:
•Tap to increase number.
•Hold and for 7s to restore to facto settings.
Locked Status:
•Tap to check feeding plan.
Increase
Unlocked Status:
•Tap to decrease number.
Locked Status:
•Tap to check feeding plan.
Decrease
Unlocked Status:
•Hold for 2s to set current time.
•Tap once to set meal plan.
•During setting, hold for 2s to conrm and exit.
Settings
•Hold for 3s to lock or unlock the control panel.
•Auto lock if no operation is done in 60s.
•During setting, tap to return to the previous step.
Lock / Unlock / Return
Unlocked Status:

Hold for 2s to enter current
time setting. Tap or to
adjust the hour.
0807
Using Your Pet Feeder
Fill food tank with d pet food
(0.07-0.47 inch). Cap the lid
back and press to snap in place.
1
Hold for 3s to unlock the
control panel. If no operation
is done in 60s, it will be locked
again.
1
Plug in the included power
adapter. The LED display will
light up indicating the feeder
is on.
2
With the feeder unlocked,
tap once to feed 1
poion manually. You can
also set automatic feeding
plan as follows.
3
Manual Feeding
Scheduling Feeding Plan
Step 1 - Setting Current Time
OR
Manual Feeding
Automatic
Feeding Plan
•Make sure that pet feeder is properly installed before lling the food tank.
•Unlock rst (hold for 3s) before using the control panel.
If no feeding plan is set, the feeder will car out the default feeding plan as
follows.
mm 02 1
1 inch
12mm/0.47 inch
X1
Meal
Time
Poion
1
8:00
8
2
12:00
8
3
18:00
8
2
Tap once to save and move
to minute setting. Tap or
to adjust, then tap to save
and exit.
3
3S
2S
X1
X1

In the unlocked status, hold
and simultaneously for 7s until
a beep is heard to restore to
facto settings.
The recording will not be cleared.
To update the meal call, hold
to record a new one.
1009
Step 2 - Setting Feeding Time & Poion
Recording a Meal Call
Additional Features
Tap once to enter feeding
time setting (for MEAL 1). Tap
or to adjust the hour.
1
Tap once to save and move
to minute setting. Tap or
to the minute.
2
In the unlocked status, hold
for 2s until a beep is heard. Keep
holding to record your voice (Max.
10s). Release to end or record for
10s.
The recording plays automatically.
You can also tap twice to play
manually.
To turn on/o recording function,
tap three times within 1s.
1
2
3
2S
Tap once to save and move
to poion setting. Tap or
to adjust the poion (Max. 48)
for meal 1.
3
Tap once to save and repeat
for the rest meals (2~ 6). Or
you can hold for 2s to save
the current meal and exit.
4
2S
OR
Repeat for Meal 2~6 Save and Exit
Clearing All Settings
1
2
7S
7S
X1
X1
X1
X1

1211
1
2
Care and Cleaning
•Always d all pas thoroughly before reassembling for next use.
•It is recommended to clean the feeder regularly for the health of your pets.
Lift the feeder and remove the bowl holder.
1
Rinse clean and air d thoroughly.
2
Cleaning Bowls & Holders
In the unlocked status, hold and simultaneously for 3s until a beep is heard to
unlock the food slider.
1
Cleaning Lid, Tank & Tank Base
1
2
Press the lock buckle to open the lid. Take out the desiccant bag.
2
Slide the lock latches on both sides to position to remove the tank and tank base.
3
3S
3S
34

1413
Rotate the four lock latches to unlocked position, then take out the food slider.
4
Rinse clean the lid, tank, tank base and food slider. D thoroughly before reassembling.
5
Wipe the base with a soft and damp cloth. Do not rinse or immerse in water.
6
Hold the food slider and place it back to the base. Rotate the lock latches to lock the
slider in place.
7
Align the grooves on both sides and install the tank base, tank and lid back.
8

1615
The troubleshooting guide addresses the most common problems. If problems persist,
feel free to contact the Customer Suppo at suppo@rellorushome.com
Troubleshooting
Q: LED display OFF.
A: •Check if the pet feeder is properly connected to a powered electrical outlet
with the included cable and power adapter.
•If no operation is done in 60s, the screen will be locked (only on). Hold
for 3s to unlock and wake up the screen.
Q: Food does not come out.
A: •Be sure to add d food with size of 0.07-0.47 inch (2-12mm) in diameter.
•Remove the food tank to check if the tank base is properly installed.
•Check if the food is stuck or food outlet is blocked.
•Check if the pet feeder is properly connected to a powered electrical outlet or
if outage occurs with no back-up batteries installed.
Q: Cannot hear any voice when feeding.
A: Make sure you have recorded successfully. Unlock the control panel, double tap
to play. If no sound is heard, you may need to record again as instructed in
Recording a Meal Call.
Q: Control buttons are not responsive.
A: Make sure the control panel is not locked. Unlock rst (hold for 3s) before using
the control panel.
- Accident, misuse, or repairs peormed by unauthorized personnel.
- Any unit that has been tampered with or used for commercial purpose.
- Normal wear and tear of wearable pas.
- Use of force, damage caused by external inuences.
- Damage caused by non-obseance of the User Manual, e.g. connection to an
unsuitable mains supply or non-compliance with the instructions.
- Paially or completely dismantled appliances.
- Defects caused by or resulting from damages from shipping or from repairs, seice, or
alteration to the product or any of its pas that have been peormed by a repair
person not authorized.
Warranty and Seice
Thank you for choosing Rellorus Automatic Pet Feeder. This product is covered with
Rellorus product and labor warranty for 12 months from the date of its original purchase.
We can only provide after sales seice for products that are sold by Rellorus or Rellorus
authorized retailers and distributors. If you have purchased your unit from a dierent
place, please contact your seller for return and warranty issues.
* Please have your invoice and order ID ready before contacting Customer Suppo.
The warranty will not apply in cases of:
