REMET CNC RT-630 Guide

USER MANUAL
WARRANTY CARD
EXCHANGE PARTS CATALOG
To the chippers: RT-630
eRRead all instructions carefully before working
with the device, become familiar with all control
elements. In case of doubt, contact the man-
ufaturer.
Keep the manual in a safe place in order to obtain
all necessary information at any times.
REMET CNC TECHNOLOGY
Limited Liability Company
36-053 Kamień, Łowisko 320A
VAT No PL5170374653
Original instruction

REMET CNC TECHNOLOGY SP. Z O.O.
Page 2 z 22
Manufacturer of machinery and equipment, CNC machining service
Table of Contents
1. GENERAL SCHEME ........................................................................................................................... 3
2. PRPOPOSE AND GENERAL DESCRYPTION OF THE DEVICE .................................................................. 4
3. DEVICE SPECIFICATION.................................................................................................................... 5
4. SAFETY ADVICES .............................................................................................................................. 6
Generl remars:................................................................................................................................. 6
Activities after finishing work........................................................................................................ 11
5. PROHIBITED ACTIONS.................................................................................................................... 13
Comments and first aid........................................................................................................ 14
6. TRANSPORT AND STORAGE OF DEVICES....................................................................................... 14
7. CHOOSING POWER SHAFT............................................................................................................. 15
8. REPLACING AND ALIGINIG THE BLADE AXIS.................................................................................. 16
9. REPLACEABLE PARTS AND INSTALLATION..................................................................................... 17
10. MAINTENANCE AND CLEANING ............................................................................................... 20
Safety instructions for maintenance.. ........................................................................................... 20
General maintenance and cleaning activities ............................................................................... 20
11. DISPOSAL AND ENVIRONMENT PROTECTION .......................................................................... 20
12. SOLUTIONS FOR SAMPLE PROBLEMS........................................................................................ 20
13. WARRANTY CARD ...................................................................................................................... 21
GUARANTEE PROCEDURES: ............................................................................................... 21

REMET CNC TECHNOLOGY SP. Z O.O.
Page 3 z 22
Manufacturer of machinery and equipment, CNC machining service
1. GENERAL SCHEME

REMET CNC TECHNOLOGY SP. Z O.O.
Page 4 z 22
Manufacturer of machinery and equipment, CNC machining service
2. PRPOPOSE AND GENERAL DESCRYPTION OF THE DEVICE
The device is designed for shredding woody and fibrous garden waste, such as
cuttings from tree branches and branches.
Warning:
It is forbidden to insert stones, glass, metal, bone, plastic, textiles and other ma-
terials into the feed mechanism of the chopper mechanism. Any use other than
approved in this operating manual may damage the device and cause a serious
threat to the operator. The operator or user bears all responsibility for injury and
damage caused to third parties and their property. The manufacturer accepts no
liability for damages and unfortunate events caused by improper use and operation
of the device, including any changes and modifications made by users and opera-
tors which also lead to immediate loss of warranty.
The chipper is equipped with a cutting disc system (hardened high-speed steel
knives). The cut material is pulled in by gravity. The chipper has metal (open)
covers for the inlet and outlet feeder and a cutting disc to ensure safe operation.
Solid construction equipped with a 3-point hitch system ensures durability and
stability of the device.
INCORRECT OPERATION OF THE MACHINE MAY
CAUSE INJURY OR DEATH. BEFORE USING THE
MACHINE, IT IS NECESSARY TO READ THE IN-
STRUCTIONS.
Warning:
This symbol is used in these instructions if there is a
danger to the user or bystanders.
This symbol is also used when there is a threat to the
environment or property.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 5 z 22
Manufacturer of machinery and equipment, CNC machining service
3. DEVICE SPECIFICATION
Technical specifications:
Typ RT-630
MINIMUM / RECOMMENDED POWER
* [HP] 25/50*
RECOMMENDED ROTATION PTO
SHAFT (RIGHT SIDE) [rpm]
750-1000
CUTTER DIAMETER [mm] 620
NUMBER OF KNIVES 4 + 1 przeciw ostrze
Material of CUTTING KNIVES Stal HARDOX typ 500
Recommended overload clutch [Nm]
** 900-1700
LOAD FEEDER [mm] 480x480
FIXING SYSTEM three-point system
Max. cutting diameter of fresh soft
wood [mm] * 120
Max. cutting diameter of fresh hard
wood [mm] * 100
Max. cutting diameter of dry hard
wood [mm] * 80
CHIPER DIMENSIONS WITH FOLDED
CHARGE FUNCTION L x W x H
85 / 85 / 150
PIVOTING ANGLE OF THE EQUIP-
MENT PIPE
360˚
HEIGHT OF EXTRUSING PIPE [cm] 160
Weight [kg] 200
* The maximum diameter of shredded branches depends on the type of wood and
the conditions when cutting the material. For hardwood (e.g. oak / beech), the
maximum cutting diameter will be smaller than softwood (e.g. pine, spruce). For
dry or knotty wood, the maximum cutting diameter will also be reduced.
** Clutch selection parameter should be corrected with max. the PTO torque on
the tractor

REMET CNC TECHNOLOGY SP. Z O.O.
Page 6 z 22
Manufacturer of machinery and equipment, CNC machining service
4. SAFETY ADVICES
Generl remars:
1. The use of wood chippers is forbidden by:
•Unauthorized persons, untrained, unfamiliar with the instructions for use or
under the influence of alcohol or narcotics and psychotropic substances
(drugs) and drugs that weaken their ability to react,
•Children (below the minimum age of the operator as defined by local regu-
lations),
•Pregnant women,
•People with limited mental capabilities.
2. Before using the device for the first time, the operator should read the op-
erating instructions issued by the device manufacturer and make sure he
knows how to operate all the controllers.
3. In addition, the staff operating the chipper must be qualified and receive
appropriate EH&S training in order to learn the principles of safe and proper
service.
4. To work with the chipper, two trained persons are required: the chipper
operator and the tractor operator.
5. Operators must provide sufficient space and harden and a non-slip ground
to work with the device.
6. Operators performing work with a chipper should constantly observe the
area of work and should never allow bystanders or animals to stay in the
working area of the machine.
7. Chipper operators are responsible for the safety of bystanders or animals
that may be in the zone of the machine.
8. Work using a wood chipper may only be carried out by adults who have
been trained by the employer.
9. An employee performing work with a chipper must be in good physical con-
dition.
10. It is forbidden to work during rain and bad weather. It is required to operate
only in daylight or in good artificial light.
11. Do not overload the device.
12. Work wisely and take regular breaks.
13. Ensure that the chipper's knives are always sharp.
Incorrect use of the device can cause serious injury.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 7 z 22
Manufacturer of machinery and equipment, CNC machining service
Personal protective equipment and pictograms
During working with a wood chipper, use:
•protective glasses or a face mask
•ear protectors
•protective gloves
•protective footwear
•protective clothing, tight fitting to the body, without loose straps or sleeves.
Oznacznie Opis Oznacznie Opis
Use hand protection
No unauthorized person! No unauthorized
person!
Wear foot protection
Prohibition of putting hands into the oil
feeder, Keep a safe distance from the inlet
hole and discharge area
Wear safety glasses
Warning! Danger of injury from rotating cut-
ting rollers. Keep hands and feet away from
the openings during machine operation.
Wear ear protection
Attention, it is possible to cut your fingers /
hands!
Read the user's manual
Attention, danger of intercepting / drawing
in / entangling!
Spinning elements!
Obligation to lubricate the gear
transmission
Warning, danger!
Recommended propeller shaft
speed: 540-1000 rpm
Attention rotating blades, danger of cutting
your fingers!
Do not walk on the surface of
the feed funnel!
Don't come in, don't stand up!
Warning! High oil pressure!
Use personal protective equipment.
Attention, fine parts falling out at high speed use personal
protection equipment (full face mask).
Warning! Rotating parts, danger of being caught.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 8 z 22
Manufacturer of machinery and equipment, CNC machining service

REMET CNC TECHNOLOGY SP. Z O.O.
Page 9 z 22
Manufacturer of machinery and equipment, CNC machining service
Security signs:
1. Safety signs must be kept clean at all times and legible.
2. Immediately replace security signs that are missing or have become illegible.
3. The replaced parts which had the safety mark (s) should also be given a valid
mark.
4. Safety signs are available from an authorized distributor or in the sales / service
department of the factory.
Installation of safety signs:
1. The place of installation should be degreased and wiped dry.
2. Apply warning signs when the temperature is more than 10˚C (50˚F).
3. Before removing the protective paper, determine the appropriate application
site.
4. When tearing off the protective paper of the adhesive layer, apply a warning
sign and then smooth with protective paper.
To do before starting work
Before starting work:
1. Inspect the wood chipper before each use. Check that the safety and pro-
pulsion system functions correctly. If not, the system should be repaired
before starting the chipper.
2. Before starting work, it is necessary to make sure that all covers are
properly fastened (check tightness of screws).
3. The machine should be placed on an even, hard, non-slippery surface with
extreme caution.
4. Before commencing shredding, make sure that there are no bystanders or
animals near the machine.
5. Before starting the engine on the tractor, check the attachment of the chip-
per.
6. Wear a helmet or other headgear that covers the hair, safety glasses, ear
protectors, and protective clothing. The person operating the machine
should not wear a scarf, tie, too loose clothing (close-fitting clothing recom-
mended) and gloves intended for other work (e.g. welding leather).
7. Damaged or illegible stickers must be replaced.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 10 z 22
Manufacturer of machinery and equipment, CNC machining service
Aggregating with a tractor:
1. Observe the recommended minimum tractor front load in order to maintain
stability.
2. Be extremely careful when coupling the shredder with the tractor and when
disconnecting it.
3. Each time before starting work, check the correct operation of all safety
switches.
4. It is strictly forbidden to stay between the chipper and the tractor and in close
proximity when performing activities with the lever for operating the hydraulic
system.
5. It is forbidden for anyone to stand between the tractor and the chipper during
work.
6. Use only PTO shaft with cover. Working with a shaft without a guard or with a
damaged guard is strictly prohibited.
7. The shaft cover must be secured against rotation, e.g. by means of a chain.
8. Operation without WPM (power take-off shaft in the machine) and PTO (power
take-off shaft on the tractor) guards is prohibited.
9. The power take-off must be of sufficient length
Rules for the safe performance of work
1.Before starting work, make sure that the inlet and outlet are empty.
2. During operation and immediately after switching off do not touch the insertion
channel, do not put your hands deep into the feeder inlet (the device works for a
short while even after switching off).
3. When working with a tractor that does not have an emergency switch, two
people are required to operate the device, the operator of the tractor driving the
chipper and the operator of the chipper.
4. Operators must provide sufficient space and solid and a non-slip surface to work
with the device. Operator have to work only in daylight or very good artificial light-
ing.
5. Operators must also ensure a good balance and stability. Do not lean forward
and do not stand above the device when throwing material.
6. Keep your head, hair and body away from the insertion hole and use safety
goggles, ear protection and protective clothing.
7. Operators performing work with a chipper should constantly observe the area
of work and immediately stop work in the event of the appearance of bystanders
or animals in the machinery working area.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 11 z 22
Manufacturer of machinery and equipment, CNC machining service
8.Before inserting the material to be cut into the inlet funnel, pay attention that
the material does not contain any foreign elements harder than wood, such as
stones, wires, ropes, nails, rivets, chains, etc., which may damage the knives,
cutting mechanism or the whole machine co as a consequence, it may lead to
a dangerous accident endangering the life and health of the operator and other
bystanders.
9. In the event of blockage of the chopping mechanism, stop the tractor engine
driving the chipper immediately.
10. If branches of the operator are caught on the clothes and pulled towards the
inlet of the chipper feeder, the tractor operator must immediately bring the tractor
to a halt.
11. To prevent accidental starting of the tractor engine driving the chipper, remove
the key from the ignition or disconnect the battery by removing the clamp from
the clamp.
12. During each break in work, the chipper drive must be switched off.
13. When the cutting system is working transportation, handling and lifting are
prohibited.
14. To avoid jams, insert limp and thin material alternately with larger branches.
15. Switch off the machine when all the material has passed through the shredder.
Otherwise, the device may jam.
16. Keep a safe distance from the machine during work, because long branches
can be thrown out during pulling.
Activities after finishing work.
1. After switching off the drive, wait a short while, as the rotating parts of the
mechanism run for some time after switching off the drive.
2. Make sure the machine is completely stopped and then perform the cleaning
and maintenance of the machine.
3. Park the machine and secure it in a parking place.
4. Inspection of the technical condition, adjustment and performance of ad hoc
repairs and maintenance works as well as cleaning of parts and working assemblies
may be carried out only when the chipper has the drive off.5. Periodically you
should check that all bolts and nuts are tight. Replace damaged ones.
6. When replacing a damaged chipper knife, always tighten or unscrew the knife
with protective gloves and in accordance with the instructions in section 9.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 12 z 22
Manufacturer of machinery and equipment, CNC machining service
Rules of conduct in emergency situations posing a threat to employees' life or
health.
1. After finding defects, damage or improper operation of the machine or its copo-
nents, the wood chipper shall be immediately turned off and immobilized and the
superior should be notified. Resumption of work without removing the damage or
the cause of the failure is not allowed.
2. If it is necessary to leave the chipper unattended during work, switch off the
tractor and secure the machine.
3. In the event of any doubts as to the observance of safety conditions at work,
the employee has the right to stop work and contact his supervisor to clarify the
situation and make a decision.
4. In the event of an accident at work, turn off the tractor driving the machine,
report the accident to your supervisor, call an ambulance if necessary. Leave the
workplace in the condition in which the accident happened.
5. If there is any doubt as to how the work should be carried out, the work should
be stopped and the manager asked for guidance.
6. In case of fire of the tractor driving the chipper. Follow the instructions
with instructions in the event of fire.
7. A faulty or damaged or remaining in-service chipper should be withdrawn from
use, and clearly marked with information boards and secured in a way preventing
its activation.
Startup of the machine:
1. Despite the lack of operational restrictions regarding the first start-up of the
wood shredder, it is recommended to make the following checks:
2. After working 1 hour:
• Check tightness of all screws,
• Check the condition of the rotor bearings,
• Check the condition of the cutting disc and cutting blades. Adjust or re-
place as necessary.
• Grease all kalamitami.
After working each subsequent 10 hours:
Repeat the steps listed above.
PROHIBITED ACTIONS

REMET CNC TECHNOLOGY SP. Z O.O.
Page 13 z 22
Manufacturer of machinery and equipment, CNC machining service
5. PROHIBITED ACTIONS
1. It is forbidden to work with a chopper after consuming alcohol or narcotic
drugs and psychotropic substances (drugs) and drugs that weaken the ability to
react.
2. It is forbidden to use the chipper by:
• Unauthorized persons, untrained, unfamiliar with the operating instructions,
• Children (below the minimum age of the operator as defined by local regula-
tions),
• Pregnant women,
• People with limited mental capabilities.
3. It is forbidden to start work with a chipper without checking the technical
condition of the device.
4. Operators are prohibited from leaving the running machine unattended.
The engine of the tractor should be always switched off.
5. It is forbidden to make any adjustments to the chipper or make repairs
while the chipper is coupled to the tractor.
6. It is forbidden to use the machine with removed or damaged protections
such as covers and covers, drop and ejection funnels and missing warning de-
cals.
7. It is forbidden to use the device for other purposes than the ones it is in-
tended for.
8. It is forbidden touse the device while the driving tractor is moving.
9. It is prohibited to make any changes or modifications to the device, making
changes or modifications results in immediate loss of warranty. In addition, the
manufacturer shall not be liable for any resulting damage to property and per-
sonal injury, death of the operator) resulting from changes or modifications to
the device.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 14 z 22
Manufacturer of machinery and equipment, CNC machining service
Comments and first aid
1. Report any accident at work to your supervisor, and leave the workplace in
the condition in which the accident occurred.
2. Always be prepared to get the following equipment:
•Completely equipped first aid kit easily accessible to the operator and by-
standers.
•Clean towels and cloths to stop bleeding.
•A cell phone or other device that allows you to call for help quickly.
•Do not work alone! There should be a person who knows the first aid prin-
ciples nearby. The assistant must be at a safe distance from the work
area, but should always pay attention to the operator. Use the device only
in places where you can quickly call an ambulance! If an injury occurs,
first aid should be given and, if necessary, further medical assistance
should be sought.
6. TRANSPORT AND STORAGE OF DEVICES
The device should be transported after coupling with the tractor or on a platform
suitable for this type, before moving or transporting, the loading funnel must be
folded and secured. Never allow anyone to sit or stand on the machine.The de-
vice should be stored out of reach of children in a dry place at 0ºC to + 40ºC.
Before storage, please proceed as follows:
1. Remove all residual material from the machine.
2. Wash the machine thoroughly with pressurized water to remove any
dirt, sludge or sand.
3. Check all rotating parts, remove entangled material if necessary.
4. Run the machine for a few minutes to dry the machine from inside.
5. Lift and lock the drop funnel.
6. Make touch-up patches for scratches and notches to protect against
corrosion.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 15 z 22
Manufacturer of machinery and equipment, CNC machining service
7. CHOOSING POWER SHAFT
To ensure compatibility with a diverse group of 3-point mounting systems, the
power transmission shaft may be too long or too short. It is particularly important
that the transmission through the telescopic shaft is carried out freely, but without
tapping to limit the operating range. Too long a shaft can cause bearing dam-
age (including bearing housing cracks) in both the shredder and the trac-
tor.
A. Length determination:
•Bystanders and animals should be removed from the device area.
•Connect the chopper to the tractor, without the power transmission shaft.
•Raise the chopper to level the PTO shafts.
•Measure the dimension between the retaining grooves between the PTO
shaft on the tractor and PTO shaft in the shredder.
•Measure the same dimensions on the compressed drive system (power
shaft)
•In case the power transmission shaft exceeds the measured dimension from
step 4, shorten the shaft.
B. Cutting the telescopic power shaft:
•Cut off the machine dimension (A) to the size of the notched drive system
(B) or (B-A). This dimension determines if the drive system is too long.
•Add an additional inch (25mm) to this dimension so that the system does
not touch the working dimension, set the cut-off dimension (C).
•Cut the dimension (C) at both ends with a metal saw. Plastic sleeves should
also be cut.
•Blind the resulting sharp edges.
•Assemble the shaft.
•Check whether the PTO shaft connection is hassle-free.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 16 z 22
Manufacturer of machinery and equipment, CNC machining service
8. REPLACING AND ALIGINIG THE BLADE AXIS
Before adjusting the position of the knives or replacing them, disconnect the
device from the power source and place it on a stable, level and non-slippery sur-
face.
Knife adjustment scheme:
1. Adjust the blades by loosening the M12 lock screws (2) and the M8 lock nuts
(3) and partially unscrew the M8 screw (4).
2. Then loosen the M10 screws (1) locking the counter-blade (A) and slide the
counter-blade (A) inside the cutting chamber from 3 mm to obtain the finest
chips, or up to 14 mm to obtain the thickest chips, after determining the position
of the counter blade, tighten the screw -by (1).
3. We start to set the cutting knives, use the M8 adjusting screws (4) to set the
clearance from 1 mm to 2.5 mm in relation to the counter-blade (A) and then
tighten the blade using M12 allen screws. We adjust the adjusting screws (4).
Note: Each blade (B) relative to the counter blade must be set separately with
the same clearance.
1 - M10 screw, 2 - M12 screw (blade), 3 - M8 counter nut, 4 - M8 screw, A - Counter-blade, B - Blade

REMET CNC TECHNOLOGY SP. Z O.O.
Page 17 z 22
Manufacturer of machinery and equipment, CNC machining service
9. REPLACEABLE PARTS AND INSTALLATION
Spare parts and assembly
Spare parts can be ordered directly from the manufacturer. When ordering,
please indicate the type of device.

REMET CNC TECHNOLOGY SP. Z O.O.
Page 18 z 22
Manufacturer of machinery and equipment, CNC machining service

REMET CNC TECHNOLOGY SP. Z O.O.
Page 19 z 22
Manufacturer of machinery and equipment, CNC machining service

REMET CNC TECHNOLOGY SP. Z O.O.
Page 20 z 22
Manufacturer of machinery and equipment, CNC machining service
10. MAINTENANCE AND CLEANING
Safety instructions for maintenance..
Before performing maintenance or repair, the device must be disconnected
from the power source and stand on a stable, level and non-slippery surface. The
device should be cleaned before and after each use, and the tightening of the cover
fixing screws must be checked.
General maintenance and cleaning activities
The device should be kept clean at all times. To clean the device, use only a
brush or a cloth. Never use any solvents or cleaning agents.
Check all covers and protective elements for damage and correct positioning.
Replace if necessary. Pay special attention to loose and worn parts. Check screws
and nuts are tight.
11. DISPOSAL AND ENVIRONMENT PROTECTION
Dispose of the device, accessories and packaging in accordance with the envi-
ronmental protection requirements at specialized disposal points.
The device may not be disposed of as household waste. Save the environment.
The device should be taken to a local point of disposal. Utilization is free. Further
information can be obtained at the point of disposal. Incorrect disposal can be
punished according to local regulations.
12. SOLUTIONS FOR SAMPLE PROBLEMS
Problem
Possible cause
Solution
The device does not pull
the branch
The cutting roller is blocked
Disconnect the drive, re-
move the blocking element
if possible
Cutting rollers rotate bac-
kwards
The propeller shaft turns
anti-clockwise (to the left)
to the right
Branches are not cut cor-
rectly
Blunt cutting knives or
damaged blade edges
Sharpen or replace if nec-
essary
Incorrectly arranged cut-
ting knives Align the blades correctly
Metallic or other disturbing
sounds are heard during
work
Too much dirt inside the
mechanism or possible
bearing damage
After disconnecting the
drive source, clean the in-
side of the shredder.
If the bearing is damaged,
it must be replaced by
qualified personnel
