OB1203 Certification Preparation
, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 1
© 2021 Renesas Electronics
Overview
SpO2 measurements are affected by two variations in the human body. The first is skin color. The second is the
blood perfusion, which causes optical modulation and varies based on the person’s temperature and health.
Changes in these variants affect SpO2 measurements.
In this pre-calibration test procedure, both of these variables are simulated and the oximeter output is monitored.
Renesas provides test stimuli simulating various conditions that represent the majority of the human population.
Therefore, a successful execution in the actual human subject testing certification testing can be assumed.
Contents
1. Test Purpose.................................................................................................................................................. 2
2. Required Equipment...................................................................................................................................... 2
3. Preparation of Test Equipment .................................................................................................................... 2
3.1 WhaleTeq AECG100 Hardware and Software Setup............................................................................ 2
3.2 Opto-mechanical Test Fixture ............................................................................................................... 3
3.2.1. Preparing the Opto-mechanical Test Adapter......................................................................... 3
3.2.2. Mounting the Reference Board and Opto-mechanical Test Adapter...................................... 5
4. Reference Board Setup and Preparation .................................................................................................... 6
5. Test Setup Calibration using the Reference Board ................................................................................... 9
5.1 Initial Setup of the AECG100 Tester................................................................................................... 10
5.1.1. Calibration of Opto-mechanical Test Fixture......................................................................... 10
6. DUT Determination and Correction of Sp02 Errors Induced by External Optical Crosstalk ............... 11
6.1 Background.......................................................................................................................................... 11
6.2 Methods............................................................................................................................................... 11
6.3 Crosstalk Correction Validation........................................................................................................... 13
7. DUT – Dark Skin Sensitivity and Low Perfusion Limit Determination ................................................... 14
7.1 Dark Skin Sensitivity Test.................................................................................................................... 14
7.2Determination of the Minimum Signal Strength Threshold.................................................................. 15
7.3 SP02 Saturation Value Test before Calibration................................................................................... 16
7.4 Sp02 Saturation Validation.................................................................................................................. 17
7.5 Test Report Generation....................................................................................................................... 17
8. Human Calibration Test .............................................................................................................................. 17
9. Revision History .......................................................................................................................................... 18

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 2
1. Test Purpose
Customers who desire to obtain regulatory certification for their product equipped with Renesas’ OB1203 will
need to perform human subject testing. Since these tests are time consuming and complex, it is best to prepare
by performing pre-setup and pre-tests dry runs.
This document describes the following required steps for a successful completion:
1. Collecting the required equipment
2. Preparation of measurement
3. Test setup calibration
4. Test data collection
5. R-curve generation based on data collected
6. Validation test using the test setup
7. Creation of measurement threshold
2. Required Equipment
■WhaleTeq AECG100 with 940nm test head
●WhaleTeq AECG100 GUI installed
■OB1203SD-RL-EVK Heart Rate, SpO2, and Respiration Rate Evaluation kit (reference board).
●With installed calibration software
●Renesas E2 or E2 Lite programmer including programming software
●Renesas E2 or E2 Lite to OB1203SD-RL-EVK programming adapter board
■Renesas opto-mechanical test adapter with inserted Aluminum reflector cone
■The device under test – DUT
3. Preparation of Test Equipment
3.1 WhaleTeq AECG100 Hardware and Software Setup
Follow the WhaleTeq documentation to complete the setup and proceed to the next step.
Figure 1. SP02 Test Setup with WhaleTeq AECG100

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 3
Figure 2. WhaleTeq AECG100 Tester with PPG Module Attached
Figure 3. Mechanical Drawing of Fixture Base PPG-2R
3.2 Opto-mechanical Test Fixture
3.2.1. Preparing the Opto-mechanical Test Adapter
In order to optically and mechanically couple the OB1203SD-RL-EVK reference board and the DUT to the
WhaleTeq test head, it is required to provide a stable, reliable, and repeatable adapter. This adapter ensures
that the test procedure can be followed successfully and to achieve repeatable test results that support the
requirements of this procedure. Renesas has created a universal test adapter that can be machined or 3D
printed. For more details, please see below.

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 4
Figure 4. Top View of the OB1203
to WhaleTeq Test Adapter
Figure 5. Side View of OB1203 to
WhaleTeq Test Adapter
Figure 6. Perspective View of
OB1203 to WhaleTeq Test Adapter
The 3D stl file can be printed on a 3D printer (see OB1203SD-RL-EVK webpage for file).
It is also required to apply (at least on one side of the test adapter) a reflective insert ensuring acceptable optical
performance, and at the same time, eliminating uncertainty from the print quality and/or material properties. It
has been determined that aluminum foil is a good material for this purpose, and Renesas has provided an
applicator to insert the foil properly. This applicator can also be 3D printed.
Procedure to Insert the Aluminum Foil Using the Applicator
1. Use an appropriately sized piece of Aluminum foil and wrap it around the
pointed end of the applicator in a single ply.
2. Insert the Aluminum foil into one cavity of the adapter making sure the
applicator fits snuggly into the cavity – use firm but light pressure.
3. Remove the applicator and the Aluminum foil from the cavity.
4. Use a sharp knife and cut off the excess of the Aluminum foil just above the
cone – there should be a small cutting groove to assist a straight cut (see Figure 8
image on top left).
5. Apply a thin layer of glue to the outside of the Aluminum foil and re-insert the
Aluminum foil using the applicator tool.
6. This time, remove the applicator leaving the Aluminum foil behind in the cavity.
It should be held in place by the glue.
7. Using a small tool, clear the optical opening at the tip of the adapter of the
Aluminum foil and 3D print material ensuring an un-obstructed path for the optical
signal.
Note: The cavity with the Aluminum foil should be used on the Photo Detector
receiver side of the DUT and the LED side of the WhaleTeq test head to collect
the maximum light possible and funnel it into the DUT receiver.
DUT OB1203
DUT OB1203
DUT OB1203
Renesas Test
adapter
WhaleTeq
Test head
Figure 7. Illustration of
Applicator Inserted into Test
Adapter
Figure 8. Illustration of
Cutting Groove

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 5
3.2.2. Mounting the Reference Board and Opto-mechanical Test Adapter
The fixture is machined or printed as required to fit the case of the DUT, aligning the cross bar in the fixture with
the center of the OB1203, and not blocking the LEDs or detector. The fit must exclude external light. The DUT
must be mechanically aligned and securely mounted to the fixture.
3.2.2.1. Opto-Mechanical Test Head Stack Up
1. Top: OB1203 Device Under Test.
The DUT must be mechanically attached and stable so that it cannot move.
Figure 9. Test Stack Up with Aluminum Foil Insert on the Receive Side of the DUT
2. Renesas Test Adapter.
The DUT must be aligned optically so that the light is un-obstructed in both directions. Pay special attention
to the alignment of the optical divider inside the cone because it must be in the correct orientation separating
the light between LEDs and Photo detectors with minimal crosstalk.
3. The Renesas test adapter should have at least one side of the cone covered with a reflective material such
as a layer of Aluminum foil. Please use the provided applicator and follow the instructions on inserting the
reflective layer into the cone. The reflective side of the cone should be on the sensor side of the DUT.
4. WhaleTeq Test Head.
The test head also has an optical divider eliminating crosstalk between the LED and photo detector. Please
ensure that the all dividers are aligned properly.
Figure 10. WhaleTeq Test Head with Optical Divider

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 6
4. Reference Board Setup and Preparation
To simplify this step, it is recommended to use an OB1203SD-RL-EVK board from Renesas. Please contact
Renesas support to request.
Each OB1203SD-RL-EVK is equipped with test mode software. In order to switch between “normal mode” and
“test mode”, push the wake button again until “Run mode change” appears on the display. The test software
supports printing test values on the display for easy post-processing.
This OB1203 test software is identical to the Renesas provided version running on the DUT except for the
following:
Parameter in Header
File OB1203.h
SpO2 / HR
Algorithm
Test Software
Comment
Light level ADC
THRESH_COUNT
196 k
32 k
Required threshold of light
coming from the WhaleTeq to
start algorithm
PS_THRESHOLD_HI to
start algorithm
15 k
200
Required threshold of light
coming from the WhaleTeq to
start algorithm
BIO_THRESHOLD
8 k
2 k
Display
SpO2 / HR
SpO2 / HR
ADC counts for IR and Red

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 7
LED current
Software version
MAX_LOW_SAMPLES
30
500
to allow routine to continue while changing GUI
parameters for 10 s
Keeps the algorithm awake
preventing battery conserving
time out
SpO2 display
70 to 100%
45 to 110%
Range limit in Display
In order to re-flash the DUT
1. Download the Renesas Flash Programmer.
2. Create a new project as described in the Renesas Flash Programmer Manual (please see the manual on the
Flash Programmer webpage) which is downloaded with the Flash Programmer software.
3. In the Programmer setup, use as controller the RL78 group, R5F100BG as device, and the .mot file as the
programming file.
a. Buy a Flash Programmer like the Renesas E2 lite.

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 8
b. Set up as described in the manual.
Table 1. Required Pins
Function
Pinout at Programming Tool
Ground
Pin 2, 12 and 14 (connect all)
Vcc
Pin 8
Reset
Pin 10 and 13 (connect both)
Tool0
Pin 5

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 9
c. Connect the Flash programmer to the adapter board and the adapter board to the four pin E1 connector
on the RL78 evaluation board. The pinout of the connector is listed on the evaluation board. The pins
are:
○Vcc (3.3 VDC)
○Tool0
○Reset
○Ground
d. Flash the *.mot file on the RL78
5. Test Setup Calibration using the Reference Board
Run the calibration software on the OB1203SD-RL-EVK Reference board. It scrolls through four screens that
illustrate calibration values necessary for this process.
SpO2 / HR
LED current
ADC counts for IR and Red
Software version
Figure 11. Calibration Software Screens

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 10
5.1 Initial Setup of the AECG100 Tester
5.1.1. Calibration of Opto-mechanical Test Fixture
This test calibrates the optical parameters of the test fixture and ensures that the DUT receives sufficient signal
to continue with this test. To assure a consistent reference, this step is performed with the OB1203SD-RL-EVK
reference board as described in the previous steps.
5.1.1.1. WhaleTeq AECG100 Setup
1. Set the AECG100 SpO2 settings to the following parameters in the GUI.
Figure 12. WhaleTeq AECG100 GUI Screenshot for Initial Test Fixture Setup
■In the Sp02 Tab:
●In the RED Parameter block:
○Check Lock DC box
○Red AC of 18.70 mV
○Red DC of 2000 mV
■In the IR Parameter block:
○Check Lock DC box
○IR AC of 15.00 mV
○IR DC of 1000 mV
For this test, all other settings can be left to default.
2. Push “Play” and observe the IR and Red ADC counts on the calibration reference devices’ OLED display
running the OB1203 calibration software.
Adjust the IR DC and Red DC values in the WhaleTeq GUI so that the DUT Display reads 60.000 (counts)
for IR and 40.000 (counts) for Red.

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 11
If the DUT screen stays in “Adjust to 50” (50 is the normalized ADC count for both, red, and IR in test mode),
the WhaleTeq LED(s) is producing too much light output for the DUT to reach its nominal operating range.
In this case, reduce the IR DC and Red DC values in the WhaleTeq GUI until the DUT leaves the “Adjust to
50” screen. Then adjust the IR and Red DC values so that the DUT Display reads 60.000 for IR and 40.000
for Red.
Table 2. Test Results and Calculation of Fixture Factor
Color
Standard
ADC Counts
Fixture Factor FF = Standard / Measured
IR
60.000
<calculate FFIR>
FFIR = IR DC Level [mV] / 1000 mV
Red
40.000
<calculate FFRed>
FFRed = Red DC Level [mV] / 2000 mV
Note: The FFIR and FFRed fixture factors should be applied to all of the AECG100 Red and IR settings
moving forward in the procedure.
3. Proceed to next step.
6. DUT Determination and Correction of Sp02 Errors Induced by
External Optical Crosstalk
6.1 Background
The OB1203 is designed to be used either in direct contact with skin or with a secondary cover window.
If the final DUT implementation uses an additional cover window, it may provide a path for additional optical
crosstalk between the LEDs and the detector. Because this cross-coupled light can induce Sp02 measurement
errors, Renesas recommends that it to be determined and compensated for. The following procedure describes
how to determine the amount of crosstalk and how it can be eliminated at the DUT system level.
6.2 Methods
1. Simulator testing is used to predict the impact of a secondary cover window on the Sp02 performance of the
DUT.
2. A software correction factor is developed to compensate for crosstalk effects of the cover window.
3. The effectiveness of the correction factor is verified on the simulator.
The following figure shows the various light paths possible between the emitters and detector on a typical
reflectance oximeter.

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 12
Estimate the impact of the cover window of the DUT:
1. Remove the cover window from the DUT and apply it to the reference board prepared in the previous
section.
2. Apply black carbon tape on top of the cover window.
3. Start the DUT and let the ADC readout stabilize. In order to achieve better resolution, the LED current
automatically increases to a preset or until the crosstalk reaches 7000 ADC counts. Read the IR and red AC
counts (average the numbers displayed) and the LED currents in mA. Add the values in the following table.
4. To verify the influence of the black tape, repeat the measurement without cover window on the DUT by
applying the black tape directly onto the OB1203.
Black tape applied directly to OB1203:
Note ADC counts per mA red
Note ADC counts per mA IR
Black tape applied to cover window
Note ADC counts per mA red
Note ADC counts per mA IR
Next, enter the ADC and mA values of the DUT with cover glass in the header file OB1203.h, as cross_ir_adc,
cross_ir_mA, cross_r_adc, cross_r_mA. In the following example, the IR current was 170mA and the IR ADC
count 600. Compile and load the program.
#define cross_ir_adc 600
#define cross_ir_mA 170
#define cross_r_adc 400
#define cross_r_mA 127
This sets the crosstalk cancellation in the software.
If you want to repeat the procedure, set the cross_r_mA and cross_ir_mA value to zero.
When the crosstalk cancellation is set by following the above process, the ADC values become small and
comparable to the noise that causes some changes in the ADC counts.

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 13
6.3 Crosstalk Correction Validation
A Whaleteq AECG100 simulator was used to validate Sp02 measurement performance.
The following graph shows that the cover window induces significant inaccuracy while the cross-coupling
correction factor corrected the measurement.
Figure 13. Before and After Correction
The results in the graph show that while cross-coupling through a cover window can have a large effect on
accuracy, the OB1203 software can successfully correct for any particular cover window inducing cross-
coupling.

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 14
7. DUT – Dark Skin Sensitivity and Low Perfusion Limit
Determination
7.1 Dark Skin Sensitivity Test
This procedure tests the performance of the DUT at the “corner” of dark skin sensitivity and low perfusion. It
represents the worst-case condition in a human subject test case ensuring that the DUT is likely to perform to
the required certification standard levels.
Complete the following instructions:
1. Run the test mode on the DUT.
2. Set up the DUT on the WhaleTeq AECG100 test fixture using the adapter used in the reference calibration
step before. It is likely that you have to make some opto-mechanical adjustments – this is acceptable and
within reasonable limits.
3. Set the following AECG100 settings in the GUI.
a. Set the default calibration curve of the DUT’s OB1203 algorithm. These are the values wanted to
evaluate and adjust using this procedure.
SpO2 = 107.36 - 10.29 * R - 28.15 * R2
b. Set the AC and DC settings per line 1 of Table 3. Check the “lock DC” boxes for both red and IR.
c. Click the radio button for PI(R).
d. Set the SpO2 value to 90%. This will automatically adjust the Red AC to simulate 90%.

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 15
Table 3. Adjust IR AC Counts to Find 90% Sp02 Limits for Various Skin Types
1. Adjust IR AC to the minimum necessary to get a correct DUT SP02 Reading of 90%
4. Push Play and observe the SpO2 value on the DUT OLED display.
5. Increase the setting of the IR AC in small steps until the level is found where the value is within 3.5% of the
set value of 90%. Record the PI AND AC values in the IR box necessary to achieve a 90% Sp02 value. If the
PI is too low the reading can either be incorrect or not shown in the display. It is necessary that the DUT
does not display an incorrect value; therefore, the threshold must be determined and added to the software.
Note that the perfusion index can be increased by warming your finger.
6. Repeat this test for lines 2 and 3 of the table.
7.2 Determination of the Minimum Signal Strength Threshold
To calculate the threshold values for IR and Red, do the following:
1. Red AC Threshold ADC count = Red DC ADC count (from the DUT display) * PI (Red)
2. IR AC Threshold ADC count = IR DC ADC count (from the DUT display) * PI (IR)
Red DC [mV] IR DC [mV] IR AC [mV] [1] GUI Red PI GUI IR PI GUI IR AC mV
DUT
SP02
Reading
Pass/Fail
86.5% to
93.5%
Dark skin
900[1] <FFRed> mV
See Table 2
350[1]<FFIR> mV
See Table 2
0.86[1]<FFIR> mV
Darker skin 450[1] <FFRed> mV
See Table 2 175[1]<FFIR> mV
See Table 2 1.7[1]<FFRIR> mV
Darkest skin
225[1] <FFRed> mV
See Table 2
100[1]<FFIR> mV
See Table 2
3.5[1]<FFIR> mV

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 16
7.3 SP02 Saturation Value Test before Calibration
This procedure tests whether the DUT is properly reporting values from 100% to 70%. This will establish the
correction values (R-curve) for the DUT on the simulated test. It does not check the actual accuracy on human
test subjects.
Set the AECG100:
a. Set the default calibration curve of the OB1203.
SpO2 = 107.36 - 10.29 * R - 28.15 * R2(default calibration curve)
b. Set the AECG100 SpO2 settings to:
oRed DC of 2000mV
oIR DC of 1000mV
oClick both Lock DC boxes
oRed AC of 15mV
oIR AC of 18.7mV
c. Click the radio button for PI(R).

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 17
d. Adjust the R-curve: Set the SpO2 value to each of the values in the Excel spreadsheet (see the following
figure and Recalculation of R-curve XLS located on the OB1203SD-RL-EVK webpage). This will
automatically adjust the Red AC to simulate the set value in the GUI.
Document the readings in the Excel spreadsheet.
The R-curve is a second degree function of the R value. It uses three coefficients, a factor for R2, one for R, and
a constant. The default coefficients in the software are listed at the top of the spreadsheet: -28.149 is the factor
for R2, -10.293 for R, and 107.36 is the constant. The numbers for corrected R-curve are shown in green.
Adjustment of the R-curve in the software: Write the new numbers in SpO2.h as shown below; re-compile the
program, and re-load it on the MCU.
// R - curve: SpO2 = Rsquare * R * R + Rlinear * R + Rconstant
#define Rsquare -28.149 // coefficient for R square
#define Rlinear -10.293 // coefficient for R
#define Rconstant 107.36 // constant
7.4 Sp02 Saturation Validation
Repeat the measurements as shown in the Excel spreadsheet’s validation step to validate that the DUT is now
measuring correctly.
7.5 Test Report Generation
With the values from the validation step, the “Report” tap generates a test report.
8. Human Calibration Test
This test is performed in an outside test lab. For calibration, typically five subjects are tested. Based on passing
the previous test, we expect to get data from all five subjects. The result we get is a table for each subject of 24
paired reference and DUT readings. Note that these values are derived from 30-second periods where the SpO2
of the test subject is stabilized. This is difficult to do so the exact reference values do not repeat subject to
subject. The result is a “cloud” of data over all of the readings of the reference device and the DUT.
1Default starting point
Default R-curve as set in the GUI SpO2 (DUT) used = -28.149 R^2 + -10.293 R + 107.36
2Run the test procedure - enter measured SP02 values in the yellow field
Obtain the new DUT R-curve Preset Measured Calculated
SpO2 WhaleTeq SpO2 DUT R DUT
100 98 0.42210 Measured SP02 values
95 94 0.52994
90 87 0.68707
85 83 0.76523
80 78 0.85469
75 74 0.92105
68 65 1.057442
3Use new R-Curve values before running the validation test
Type in the reference and measured SpO2 values SpO2 (DUT) new = -25.326 R^2 + -13.432 R + 110.01 New R-Curve Values

OB1203 Certification Preparation, Setup, and Test Procedure
X0119984 Rev.1.0
Mar 11, 2021
Page 18
9. Revision History
Revision
Date
Description
1.0
Mar 11, 2021
Initial release.

Corporate Headquarters
TOYOSU FORESIA, 3-2-24 Toyosu,
Koto-ku, Tokyo 135-0061, Japan
www.renesas.com
Contact Information
For further information on a product, technology, the most
up-to-date version of a document, or your nearest sales
office, please visit:
www.renesas.com/contact/
Trademarks
Renesas and the Renesas logo are trademarks of Renesas
Electronics Corporation. All trademarks and registered
trademarks are the property of their respective owners.
IMPORTANT NOTICE AND DISCLAIMER
RENESAS ELECTRONICS CORPORATION AND ITS SUBSIDIARIES (“RENESAS”) PROVIDES TECHNICAL
SPECIFICATIONS AND RELIABILITY DATA (INCLUDING DATASHEETS), DESIGN RESOURCES (INCLUDING
REFERENCE DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND
OTHER RESOURCES “AS IS” AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF THIRD PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for developers skilled in the art designing with Renesas products. You are solely responsible
for (1) selecting the appropriate products for your application, (2) designing, validating, and testing your application, and (3)
ensuring your application meets applicable standards, and any other safety, security, or other requirements. These
resources are subject to change without notice. Renesas grants you permission to use these resources only for
development of an application that uses Renesas products. Other reproduction or use of these resources is strictly
prohibited. No license is granted to any other Renesas intellectual property or to any third party intellectual property.
Renesas disclaims responsibility for, and you will fully indemnify Renesas and its representatives against, any claims,
damages, costs, losses, or liabilities arising out of your use of these resources. Renesas' products are provided only subject
to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing. No use of any Renesas resources
expands or otherwise alters any applicable warranties or warranty disclaimers for these products.
(Rev.1.0 Mar 2020)
© 2021 Renesas Electronics Corporation. All rights reserved.
