Air Cooling Jacket for AS2100 Laser Sensor
Manual
V1.1
03/29/22

2 | P a g e
Table of Contents
1 General Information..................................................................................................................................3
2Specification .........................................................................................................................................3
3 Assembly....................................................................................................................................................3
4 Base Alignment..........................................................................................................................................5
5 Mounting Air Line......................................................................................................................................6
5.1 LED Status...........................................................................................................................................6
6 Pictures ......................................................................................................................................................7
7 Air Cooling Jacket Structure......................................................................................................................7
7.1 Air Cooling ..........................................................................................................................................8
8 Drawing......................................................................................................................................................9

3 | P a g e
1 General Information
•This Air-Cooling Jacket can be used with our AS2100 standard interface. The sensor
extensions Ethernet/IP can't be used with this Air-Cooling Jacket.
•The AS2100 Laser Sensor, Air-cleaner, Air-dryer, Air-filter, Pressure reduction and air
regulator are not included.
2Specification
3 Assembly
Outer Tube Diameter: 8mm
Air nipple size: PT 1/8”
Cable Gland: M16
Mounting: Mounting slots for M5/M4 screws
Size: width: 85mm x length: 235mm x height: 158mm
Weight approx..: 1.264kg
Material Housing body: Aluminum Hard anodizing
Not included: AS2100 laser sensor, air-cleaner, air-dryer, air-filter,
pressure reduction & air regulator are not included
Compatible to: AS2100 with standard interfaces, not Ethernet/IP
First, insert the cables into the cable glad of the jacket.
Then connect the cable to the sensor before you
assemble the laser sensor into the air-cooling jacket.

4 | P a g e
Remove the four
hexagonal socket set
screws. You need these
tapped holes to mount
the sensor into the jacket.
Slide the sensor into the
air jacket.
Set the four screws and
attach the sensor to the
housing. The screws are
provided.

5 | P a g e
4 Base Alignment
When you close the rear cover of the air-
cooling jacket, installation is easier
without bending the cable inside the
enclosure.
Set the four screws and attach the rear
cover.
Finally, tighten the metallic cable gland.
The tilting can be adjusted with the four
screws on the two sides of the air jacket.
We recommend manually supporting the
housing for alignment to prevent
damaging of the product because the
laser’s position in the housing is
positioned towards the front.
The rotation can be adjusted with the
main fixing screws.

6 | P a g e
5 Mounting Air Line
5.1 LED Status
Connect the 8mm tube into the quick coupling
Remove the tube from quick coupling.
The user can see the sensor’s operating status through the clear glasses on the housing top
without pulling the laser sensor out. This makes it convenient to do maintenance or monitoring
device on site.

7 | P a g e
6 Pictures
7 Air Cooling Jacket Structure

8 | P a g e
7.1 Air Cooling
Generally, the air provided must be clean, oil- and moisture free. Please use all the necessary
equipment.
The air guide block has a jaw trough which oil and moisture are discharged through drainage channels.
Only fresh air is left inside the housing in order to perform both cooling and air purging functions.

9 | P a g e
8 Drawing
Dimensions in mm
Weight: 1.264 kg
