Renesas RTKA211650DE0000BU User manual

Evaluation Board Manual
R16UH0014EU0101 Rev.1.1 Page 1
May 6, 2021 © 2021 Renesas Electronics
The RAA211650 is an integrated 60V, 5A
synchronous buck regulator with adjustable switching
frequency from 200kHz up to 2.5MHz. It supports a
wide input voltage range from 4.5V to 60V and
adjustable output voltage. The RAA211650 is offered
in a 28Ld QFN package. The
RTKA211650DE0000BU evaluation board provides a
quick and comprehensive platform for evaluating the
high-performance features of RAA211650 buck
regulator.
The RTKA211650DE0000BU evaluation board
operates from a supply voltage of 4.5V to 60VDC with
the capability of delivering continuous load of 5A.
Features
▪Switch selectable EN or option to drive it by
external signal
▪Internal and external compensation options
▪Internal and external RT options
▪Internal and external soft-start options
▪Frequency synchronization and spread spectrum
options
▪Adjustable delay time options
▪Options to connect EBIAS to VOUT or drive by
external source
▪Output voltage programmable with external
feedback resistors
▪Options to use internal feedback resistors for 3.3V
VOUT
▪Connectors and test points for easy probing and
data acquisition
Specifications
This board is configured and optimized for the
following operating conditions:
▪Input voltage range:4.5V to 60V
▪Output voltage: 3.3V
▪Up to 5A output current capability
▪Internal set switching frequency of 500kHz
▪Internal compensation
▪Internal soft-start of 2ms
▪Start-up/shutdown delay of 2ms
▪EBIAS is connected to VOUT
▪Operating temperature range: -40°C to +125°C
Figure 1. RTKA211650DE0000BU Block Diagram
C
OUT
C
BOOT
C
IN
PGND
PHASE
BOOT
PVIN
COMP
AVCC
PVIN
V
OUT
(3.3V)
EN
EBIAS
PG
AGND
PVCC
SS
C
AVCC
C
PVCC
L
SET
C
DL Y
RAA211650
R
SET
R
AVCC
R
PG
V3_DLY
MODE/SYNC
EN
SW1
RT C
EBIAS
FB
R
FB1
R
FB2
RTKA211650DE0000BU

R16UH0014EU0101 Rev.1.1 Page 2
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
Contents
1. Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Operating Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Recommended Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Quick Start Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.4 Connectors, Test Points, Selection Switches, and Jumper Descriptions . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.1 Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.2 Soft-Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.3 Delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4.4 Switching Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4.5 Compensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4.6 Spread Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4.7 EXT CLK Synchronization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4.8 3.3V VOUT with Internal Feedback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4.9 Other Output Voltages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4.10 EBIAS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2. Board Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 Layout Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Bill of Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. Typical Performance Graphs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4. Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5. Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

R16UH0014EU0101 Rev.1.1 Page 3
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
1. Functional Description
The RTKA211650DE0000BU provides a comprehensive and versatile platform for you to evaluate functionality
and prototype an application of the integrated 60V, 5A synchronous buck regulator RAA211650. This evaluation
board includes the options to evaluate most of the features of RAA211650. Either a toggle switch, jumper or 0Ω
jumper resistors have been used to evaluate the features.
1.1 Operating Range
The RTKA211650DE0000BU evaluation board evaluates RAA211650 with PVIN from 4.5V to 60V and continuous
load of 5A. For proper functioning of the evaluation board, Renesas recommends operating the board within the
specifications.
The inductance and capacitance value of the regulator is chosen for 3.3V VOUT and 500kHz switching frequency.
You can replace these components with different values if a different operating condition is required.
Also, you can change the EBIAS to an external source(<12V), soft-start time, start-up delay, compensation,
switching frequency, enable spread spectrum, or synchronize to external clock. See the RAA211650 datasheet
and design spreadsheet to calculate the components for a required setting.
Updates on the output inductor, capacitors, and R9 may be required with changes on the operating VOUT, load,
and switching frequency.
1.2 Recommended Equipment
▪Power supply that can deliver 5V or higher with at least 5A source current capability
▪Electronic load capable of sinking at least 5A current
▪4-channel oscilloscope with voltage and current probes
1.3 Quick Start Guide
Use the following Quick Setup Guide to configure and power-up the board for proper operation.
1. Set the power supply voltage to 12V and turn off the power supply. Connect the positive output of the power
supply to J1 (PVIN) and the negative output to J2 (GND).
2. Connect an electronic load to J5 (VOUT) for the positive connection and J4 (GND) for the negative connection.
3. Place scope probes to VOUT (J3), PHASE (J6), and/or other test points of interest.
4. Toggle the selection switch SW1 to ON position.
5. Set the load current to 0.1A and turn on the power supply. The output voltage should be in regulation with
nominal 3.3V output.
6. Slowly increase the load up to 5A. The output voltage should remain in regulation with nominal 3.3V output.
7. Slowly sweep PVIN from 4.5V to 60V. The output voltage should remain in regulation with nominal 3.3V output.
8. Decrease the input voltage to 0V to shut down the regulator.

R16UH0014EU0101 Rev.1.1 Page 4
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
1.4 Connectors, Test Points, Selection Switches, and Jumper Descriptions
The RTKA211650DE0000BU evaluation board includes I/O connectors, test points, selection switch, and jumpers
to provide a comprehensive and versatile platform for evaluation of RAA211650.Table 1 shows the description of
them.
1.4.1 Enable
Switch SW1 enables and disables RAA211650. SW1 in position ON ties EN to PVIN through R1,R2 divider on
PVIN. The EN threshold can be changed by changing the values of R1 and R2. With SW1 in OFF position, EN
can be driven by external source as well.
1.4.2 Soft-Start
The RTKA211650DE0000BU is set for an internal soft-start of 2ms. To change the soft-start time, remove R10 and
update C6 to get the required soft-start time using Equation 1.
where tss is the soft-start time in milliseconds.
1.4.3 Delay
The RTKA211650DE0000BU is set for start-up delay of 2ms. To change the delay time, change C8 using
Equation 2.
where tDELAY is the delay time in milliseconds.
Note: If no delay is required, mount 0Ωresistor for R14.
Table 1. Connectors, Test Points, Selection Switches, and Jumper Descriptions
Ref DES Description
J1 Input voltage positive connection
J2 Input voltage return connection
J3 VOUT/GND test points
J4 Output voltage return connection
J5 Output voltage positive connection
J6 PHASE/GND test points
J7 EXT CLK/GND connections
PVIN_1 PVIN test point
GND_2,GND_3,GND_5 GND test points
EN ENABLE test point
V3_DLY DELAY test point
EBIAS EBIAS positive connection
PG Power-good output test point
SW1 Toggle switch to ENABLE regulator with PVIN
(EQ. 1)
(EQ. 2)
C6nF 6.25tSS ms=
C8nF 4.17tDELAY ms=

R16UH0014EU0101 Rev.1.1 Page 5
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
1.4.4 Switching Frequency
The RTKA211650DE0000BU is set for an internal default switching frequency of 500kHz. To change the switching
frequency, remove R7 and mount R6 using equation 3.
1.4.5 Compensation
The RTKA211650DE0000BU is set for internal compensation. To change to external compensation, remove R12
and update R15, C9, and C7. Verify the compensation using the design spreadsheet.
1.4.6 Spread Spectrum
To disable the spread spectrum, use a 0Ωresistor for R5 or short the jumper J7. To enable the spread spectrum,
use a 0Ωresistor for R4, keep jumper J7 open, and do not put a resistor on R5.
1.4.7 EXT CLK Synchronization
The RAA211650 can be synchronized to an external clock by connecting it to J7. The external clock signal is
divided internally to half and PWM clock synchronizes only if the divided external clock frequency is greater than
110% of the frequency set by RT. The external clock should meet the specifications described in the RAA211650
datasheet.
1.4.8 3.3V VOUT with Internal Feedback
The RAA211650 has an internal feedback for a 3.3V VOUT setting. To use this feature, remove R22, C20, R23,
and R21, and use a 0Ωresistor for R24.
1.4.9 Other Output Voltages
RTKA211650DE0000BU is set for 3.3V VOUT using R21 and R23. Other output voltages are programmable by
updating the values for these resistors. Renesas recommends keeping R21 as 20kΩand change the value for
R23 using Equation 4.
With the change on VOUT, update the output inductor, capacitors, and R9 using the design spreadsheet.
1.4.10 EBIAS
EBIAS improves efficiency for the internal bias supply. The default setting on the board uses VOUT as source of
EBIAS. Limit the EBIAS source to 12V. If VOUT is more than 12V, remove R19 and an external EBIAS source
(within EBIAS specification) can be used by connecting the source to EBIAS and GND_3 test points. If EBIAS is
not used, remove R19 and install a 0Ωresistor for R20.
(EQ. 3)
(EQ. 4)
R6k 120258
fSW
1.044 kHz
----------------------------------------=
R23 R21
VOUT
0.8
----------------1–


=

R16UH0014EU0101 Rev.1.1 Page 6
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
2. Board Design
Figure 2. RTKA211650DE0000BU Evaluation Board (Top)
Figure 3. RTKA211650DE0000BU Evaluation Board (Bottom)

R16UH0014EU0101 Rev.1.1 Page 7
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
2.1 Layout Guidelines
The printed circuit board (PCB) layout is critical for proper operation of the RAA211650. The following guidelines
are recommended to achieve good performance.
1. Use multilayer PCB structure to achieve optimized performance. Renesas recommends using a four layer PCB
with 2oz copper on outer and 1oz copper in inner layers.
2. Use the combination of a bulk capacitor and smaller ceramic capacitors with low ESL for input capacitors and
place them as close as possible to the IC. Place the ceramic input capacitor on the same PCB surface layer.
3. Place the ceramic AVCC capacitor on the same PCB surface layer as the regulator and as close as possible
to the AVCC and AGND pins. Use a 1µF ceramic capacitor for AVCC and use 1Ωresistor to connect AVCC to
PVCC.
4. Place the ceramic PVCC capacitor on the same PCB surface layer as the regulator and as close as possible
to the PVCC and PGND pins.
5. Add plenty of thermal vias under the exposed pad of the regulator for better heat dissipation. Connect the vias
to GND planes underneath.
6. Route the output voltage feedback signal away from BOOST and PHASE. Place feedback resistors close to
FB pin of the regulator.
7. Place bootstrap capacitor close to the IC between BOOT and PHASE pins on same PCB layer as the regulator.
Renesas recommends using a 0.1µF ceramic capacitor.
8. The copper area of the PHASE NODE should not be more than needed. Place the inductor close to regulator.
9. Place an output capacitor close to the inductor.
10. Keep SET resistor close to the SET pin. Avoid running other analog signals close to the SET pin or SET resistor.

R16UH0014EU0101 Rev.1.1 Page 8 May 6, 2021 RTKA211650DE0000BU Evaluation Board Manual
2.2 Schematic Diagram
Figure 4. RTKA211650DE0000BU Schematic
60V
BLACK
RED
GND
VOUT (3.3V, 5A)
DNP CAPS AT THE BACKSIDE OF BOARD
BLACK
GND PHASE
GND
GND
RED
SYNC_MD
OUT
IN
R2
100K
C13
2.2UF
R22
20
8200PF
C8
J2
SW1
1
2
3
Default
EBIAS
12
J3
R1
100K
C15
10UF
DNP
R6
10UF C22
J1
PG
0.1UF
C29
C19
10UF
C6
8200PF
J4
C5
10UF
C23
10UF
C9
OPEN
100K
R18
Default
EN
C20
22PF
R10
0
J5
C17
10UF
GND_5
Default
R24
DNP
R15
DNP
C1 68UF
1
R17
C21
10UF
12
J6
0.1UF
C14
DNP
R20
R7
0
10UF C24
C2
10UF
GND_2
Default
BOOT
PHASE PHASE PHASE PHASE
PHASE
PGND
PVIN
EP
V3_DLY PG
AGND
EBIAS
PVCC
PVIN
PGND
PGND
EN
PGND
SS\ST
COMP
FB
PGND
AVCC
PVIN
PVIN
SYNC\MODE
RT
SET
RAA211650
U1
1
2
3
4
5
6
7
8
9
10 11 12 13 14
15
16
17
18
19
20
21
22
23 24 25 26 27 28
29
R19
0
PVIN_1
Default
DNP
C25
R14
DNP
C3
10UF
3.3UH
744325330
L1
1 2
20K R21
OPEN
C7
10K
R3
10UF C18
DNP
C26
1UF
C10
10UF
C4
C12
2.2UF
DNP
R5
R12
0
R9
30.1K
DNP
C27
V3_DL
Default
DNP
R4
R23 62K
0.1UF
C11
12
J7
GND_3
Default
C28
DNP
AVCC
AVCC AVCC
AVCC
AVCC
AVCC
AVCC
AVCC
AVCC
BOOT
COMP
EBIAS
EN
FB
PG
PHASE
PVCC
PVIN
PVIN
PVIN
RT
SET
SS/ST
SYNC/MODE
UNNAMED_3_GTSERI ES_I834_NC
UNNAMED_3_GTSERIES_I834_NO
UNNAMED_3_SMCAP_I730_A
UNNAMED_3_SMCAP_I733_A
V3_DLY
VOUT

R16UH0014EU0101 Rev.1.1 Page 9
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
2.3 Bill of Materials
Qty Reference Designator Description Manufacturer
Manufacturer
Part Number
1 SW1 SWITCH-TOGGLE, TH, 5PIN, SPDT, 2POS,
On-None-On, ROHS
C&K GT11MCBE
3 EN, EBIAS, PVIN_1 CONN-Miniature Red Test Point, Vertical,
ROHS
Keystone 5000
3 GND_2, GND_3,
GND_5
CONN-Miniature Black Test Point, Vertical,
ROHS
Keystone 5001
2 PG, V3_DLY CONN-Miniature White Test Point, Vertical,
ROHS
Keystone 5002
4 J1, J2, J4, J5 CONN-SOLDER MOUNT BANANA PLUG Keystone 575-4
3 J3, J6, J7 CONN-HEADER, 2 Pin, BLK, 2.54mm Pitch,
ROHS
Samtec TSW-102-07-G-S
1 L1 COIL-INDUCTOR, SMD,10.2mmx10.5mm,
3.3µH, 12A, 20%, ROHS
Wurth
Elektronik
744325330
1 R23 RES, SMD, 0603, 62k, 1/10W, 1%, TF, ROHS Panasonic ERJ-2RKF6202X
0 R4, R5, R6, R14, R15,
R20, R24
RES, SMD, 0603, DNP-Place Holder, ROHS
1 R22 RES, SMD, 0603, 20Ω, 1/16W, 1%, TF, ROHS Generic Various
3 R10, R12, R19 RES, SMD, 0603, 0Ω, 1/10W, 1%, TF, ROHS Generic Various
2 R3, R7 RES, SMD, 0603, 010k, 1/10W, 1%, TF, ROHS Generic Various
3 R1, R2, R18 RES, SMD, 0603, 100k, 1/10W, 1%, TF, ROHS Generic Various
1 R21 RES, SMD, 0603, 20k, 1/10W, 1%, TF, ROHS Generic Various
1 R9 RES, SMD, 0603, 30.1k, 1/16W, 1%, TF, ROHS Generic Various
1 R17 RES, SMD, 0603, 1Ω, 1/10W, 1%, TF, ROHS Vishay RCA06031R00FKEA
0 C25-C28 CAP, SMD, 3x4, DNP-Place Holder, ROHS
1 C10 CAP, SMD, 0603, 1µF, 10V, 10%, X7R, ROHS Murata GRM188R71A105KA61D
3 C11, C14, C29 CAP, SMD, 0603, 0.1µF, 100V, 10%, X7R,
ROHS
Murata GRM188R72A104KA35J
12 C2-C5, C15, C17-C19,
C21-C24
CAP, SMD, 1210, 10µF, 100V, 10%, X7S,
ROHS
Murata GRM32EC72A106KE05L
1 C20 CAP, SMD, 0603, 22pF, 50V, 5%, C0G, ROHS Generic Various
2 C6, C8 CAP, SMD, 0603, 8.2nF, 25V, 5%, X7R, ROHS Generic Various
0 C7, C9 CAP, SMD, 0603, DNP-Place Holder, ROHS Generic Various
2 C12, C13 CAP, SMD, 0603, 2.2µF, 10V, 10%, X7R, ROHS Taiyo Yuden LMK107B7225KA-T
1 C1 CAP, SMD,10mm(dia)x12mm(H), ALUM, 68µF,
20%, 80V, ROHS
Vishay MAL214699705E3
1 U1 IC-BUCK Regulator, 28P, QFN, 4x5, ROHS Renesas RAA211650
1 PCB PWB-PCB, RAA211650, REVC, ROHS Imagineering
Inc
RTKA211650DE0000BU_REVC

R16UH0014EU0101 Rev.1.1 Page 10
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
2.4 Board Layout
Figure 5. Silkscreen Top Layer Figure 6. Top Layer
Figure 7. Layer 2 Figure 8. Layer 3
Figure 9. Bottom Layer Figure 10. Silkscreen Bottom Layer

R16UH0014EU0101 Rev.1.1 Page 11
May 6, 2021
RTKA211650DE0000BU Evaluation Board Manual
3. Typical Performance Graphs
4. Ordering Information
5. Revision History
PVIN = 24V, VOUT = 3.3V, fSW = 500kHz, L = 3.3µH, COUT = 80µF, RSET = 30.1kΩ, TA= +25°C, internal compensation, internal soft-
start unless otherwise stated.
Figure 11. Efficiency vs Load Current (VOUT = 3.3V) Figure 12. Steady-State Operation IOUT = 5A
Figure 13. Start-Up through EN, IOUT = 5A Figure 14. Shutdown through EN, IOUT = 0A
Part Number Description
RTKA211650DE0000BU RAA211650 28Ld QFN evaluation board
Rev. Date Description
1.1 May 6, 2021 Changed file number from X0116913 to Renesas format.
Applied new template.
Removed soft-stop information.
Updated Figures 1, 4, and 14.
1.0 Feb 12, 2021 Initial release
20
30
40
50
60
70
80
90
100
01234
5
Efficiency (%)
Load Current (A)
Vin at 5V Vin at 24V
Vin at 36V Vin at 60V
VOUT 2V/Div
1µs/Div
IL2A/Div
PHASE 10V/Div
VOUT 2V/Div
1ms/Div
IL5A/Div
ENABLE 10V/Div
PHASE 20V/Div
VOUT 2V/Div
5s/Div
IL2A/Div
ENABLE 10V/Div
PHASE 20V/Div

Corporate Headquarters
TOYOSU FORESIA, 3-2-24 Toyosu,
Koto-ku, Tokyo 135-0061, Japan
www.renesas.com
Contact Information
For further information on a product, technology, the most
up-to-date version of a document, or your nearest sales
office, please visit:
www.renesas.com/contact/
Trademarks
Renesas and the Renesas logo are trademarks of Renesas
Electronics Corporation. All trademarks and registered
trademarks are the property of their respective owners.
IMPORTANT NOTICE AND DISCLAIMER
RENESAS ELECTRONICS CORPORATION AND ITS SUBSIDIARIES (“RENESAS”) PROVIDES TECHNICAL
SPECIFICATIONS AND RELIABILITY DATA (INCLUDING DATASHEETS), DESIGN RESOURCES (INCLUDING
REFERENCE DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND
OTHER RESOURCES “AS IS” AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, WITHOUT LIMITATION, ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR NON-INFRINGEMENT OF THIRD PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for developers skilled in the art designing with Renesas products. You are solely responsible
for (1) selecting the appropriate products for your application, (2) designing, validating, and testing your application, and (3)
ensuring your application meets applicable standards, and any other safety, security, or other requirements. These
resources are subject to change without notice. Renesas grants you permission to use these resources only for
development of an application that uses Renesas products. Other reproduction or use of these resources is strictly
prohibited. No license is granted to any other Renesas intellectual property or to any third party intellectual property.
Renesas disclaims responsibility for, and you will fully indemnify Renesas and its representatives against, any claims,
damages, costs, losses, or liabilities arising out of your use of these resources. Renesas' products are provided only subject
to Renesas' Terms and Conditions of Sale or other applicable terms agreed to in writing. No use of any Renesas resources
expands or otherwise alters any applicable warranties or warranty disclaimers for these products.
(Rev.1.0 Mar 2020)
