The Renogy Cable Entry Housing (MTS-CE) is a UV-resistant, waterproof, and ABS plastic
membrane designed to provide the solution for cable entry through roofs. With its dual cable entry,
the MTS-CE easily passes solar cables and can be conveniently mounted on virtually any roof
surface.
Key Features
 100% recyclable and UV resistant
 Drill-free mounting
 Waterproof rated cable entry glands
 Designated for virtually any aluminum framed solar panels
 Easier and more flexible installation
 Compatible with all Renogy solar panels
Identification of Components
Installation
NOTE: The following instructions are to serve as a simple guideline.
Recommended tools to have before installation:
 Assembly Adhesive (Sikaflex-252)
 Caulking gun
 Masking Tape
 Hand Pads (Scotchbrite Pads)
 Spirit Level
 Tape Measure
Cable
Membrane
Gasket
Sealing Cable
Glands

5
WARNING: Assembly adhesives contain hazardous chemicals that can be
detrimental to one’s health. Make sure to abide by the manufacturer’s handling and care
when using assembly adhesives.
1. Set Up Mounting Area
a. On the flat surface, mark the area by which the wire will feed through
b. Drill a small hole at the chosen spot that is suitable enough for wire feeding
c. Smooth out any rough edges
d. Pass cable through the MTS-CB and into the roof
NOTE: Cables with MC4 ends will need to go through the MTS-CB before going through
the roof

6

7
2. Apply Adhesive to the cable entry gland and install on flat surface
NOTE: Always mark out where the component will be located on the flat surface before
proceeding to apply adhesive
a. Clean the surface that will be bonded to ensure maximum bonding potential
b. Apply adhesive to the bottom side of the membrane where they will make contact with
the flat mounting surface
c. Apply pressure to ensure proper contact.
NOTE: A correct bond should have the adhesive seeping from the bracket onto the flat
surface.
NOTE: Adhere to adhesive manufacturer specifications for application and time to dry

8
3. Tighten cable gland at desired wire length
a. Upon desired wire length, tighten individual cable glands by rotating clockwise
b. Rotate until wire feed is no longer mobile through the gland.
c. Repeat for the other cable gland

9
Technical Specifications
Parameter
Specification
Material UV-resistant ABS Plastic
Weight
(each component)
7.9
oz.
Dimensions (l x w x h)
4.7 x 3.9 x 2.0
in
Recommended Adhesive Sikaflex 252 or alike
Cable
Gland
Diameter Range
6mm
–
12m
m
Dimensions
Note: The following drawings utilize inches as their dimension units.
