Introduction
FP2-V2 HMI series is suitable for simple applications. Available screen sizes are 4.3” WQVGA
and 7" WVGA Color TFT. These HMIs are powered by FlexiSoft® programming software. These
products also support the IEC61131-3 logic programming environment which gives a unique edge
to these products.
All the products are compliant to EMC directive 2014/30/EU and LVD directive 2014/35/EU and
suitable for installation in hazardous locations because they are listed for UL Class I Div. 2.
This user manual gives detailed information regarding the hardware specifications, operating
conditions, installation, mounting, and wiring. All the information published in this manual is
produced and governed by RENU Electronics Pvt. Ltd. and is protected by Indian Copyright Act.
Before you start
FlexiPanels®FP2-V2 series products are general-purpose human machine interface
devices, suitable for a variety of simple applications across various industries. However,
RENU Electronics is not responsible or liable for any indirect or consequential damage
resulting from the use of this product.
The user should check and confirm the suitability of the product before using it in any
specific application.
The diagrams and examples in this manual are included for illustration purposes only.
RENU Electronics assumes no responsibility or liability regarding actual use based on
these diagrams or examples.
Reproduction of the contents of this manual, in any form (in part or whole), is strictly
prohibited.
Following table shows various symbols that may be used in this manual to provide
information regarding safety, precautions, and usage of the product:
WARNING: Indicates circumstances that may cause an explosion in a hazardous environment,
which may lead to injury or death, damage or economic loss
CAUTION: Indicates specific precautions to be taken by the user during installation, operation
and maintenance of the product
ATTENTION
ATTENTION: Indicates important information regarding the application and functions of the
product

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 5of 20
Safety Precautions
This section of the manual provides information that is critical regarding safety and therefore the
user is advised to go through the information in detail before installing the product. Users may
contact RENU Electronics technical support team at [email protected] for any
specific question(s) related to safety.
WARNING: EXPLOSION HAZARD
Do not disconnect equipment unless power has been removed or the area is known
to be nonhazardous.
The substitution of any component may impair suitability for Class I, Division 2.
Secure any external connections that mate to this equipment by using screws, sliding
latches, threaded connectors, or any other means provided with this product.
If this product contains batteries, it must only be changed in an area known to be
nonhazardous.
CAUTION: GENERAL PRECAUTIONS
Do not use this product for an emergency stop. A separate physical switch, outside
the product, must be used for any emergency stop operations.
Do not use the external power supply source that does not comply with the specified
power requirements of the product, it may cause malfunction or permanent damage
to the product.
Do not attempt to open, dismantle, or modify the product, doing so will void the
warranty.
This product is supplied as open-type equipment and it must be mounted within an
enclosure, suitably designed for specific environmental conditions.
When used in Class I, Division 2 hazardous location, the product must be mounted
in a suitable enclosure with a proper wiring method that complies with the governing
electrical codes.
The USB port is intended for temporary local programming purposes only and not
intended for permanent connection. If you connect or disconnect the USB cable with
power applied to this product or any other device on the USB network, an electrical
arc can occur, which could cause an explosion in hazardous location installations.
Make sure that connectors are securely tightened to properly seal the connections
against leaks.
Do not place the product in direct sunlight. Prolonged exposure to sunlight may
degrade the LCD and housing.

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 6of 20
Product Overview
This section of the manual provides an overview of FP2-V2 series products, its front and back
view, installation details, dimensional details, mounting method, and details.
Installing FP2-V2 products
FP2-V2 series products are designed for front panel mounting. Before installing the products,
the user should review the panel guidelines, panel cutout dimensions, product dimensions, and
minimum clearances.
Panel Guidelines
The panel must be at least 2mm (12gauges) so that it can provide the required support and
proper sealing against water and dust. The panel surface must be flat, without any imperfection,
to maintain the adequate seal and IP rating.
The maximum panel thickness allowed is 6mm (±0.2mm).
Panel Cutout Dimensions
The panel must be at least 2mm (12gauges) so that it can provide the required support and
proper sealing against.
Model
Height (mm)
Width (mm)
FP2043T-V2
80
111
FP2043TN-V2
80
111
FP2070T-V2
127
175
FP2070TN-V2
127
175
ATTENTION
ATTENTION: Panel cutout
Before making a panel cutout, disconnect all electrical power from the panel.
Make sure that area surrounding the panel cutout is clear.
Make sure that metal cutting does not enter any component already installed in the
panel.

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 7of 20
Product Dimensions
This section of the manual provides dimensional details of FP2-V2 series products. All the dimensions
shown below are measured in mm.
FP2043-V2
FP2070-V2
Minimum Clearances
Maintain clearance from enclosure walls, wires, and other adjacent devices. Keep 2” space on all sides
for adequate ventilation. Plan for adequate space around the product and inside the enclosure for
ventilation and cabling. Take into consideration the heat produced by other devices in the enclosure. The
ambient temperature around this product must be 0° to 50°C.

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 8of 20
Mounting FP2-V2 Products
FP2-V2 series products must be installed on the front panel, using the clamp accessories shipped with
the product. Before mounting, make sure that the sealing gasket is properly positioned. This gasket forms
a compression type seal. Do not use sealing compounds. Then, place the unit in the panel cutout and
tighten the mounting screws evenly (torque 0.4Nm) to maintain water and dust resistance.
ATTENTION
ATTENTION: Mounting FP2-V2 on Panel
Do not push the LCD display when pushing the unit into the panel as it may damage
the display.
Connecting Power
FP2-V2 series requires a 24VDC isolated power supply. Follow the steps mentioned below to connect
the power:
Make sure that terminal is not connected to a power source
Secure the 24VDC power wires
Secure the functional earth ground wire to the functional earth ground terminal screw on the
terminal block
Apply 24VDC power to the terminal
Power Rating
Unit
Voltage
Current
Wattage
FP2043T-V2
24VDC
130mA
3.12W
FP2043TN-V2
24VDC
150mA
3.6W
FP2070T-V2
24VDC
200mA
4.8W
FP2070TN-V2
24VDC
230mA
5.52W
Grounding
The optimum method for grounding electronic equipment is to ground it separately from other high-power
systems and to ground more than one unit of electronic equipment with a single-point ground. Following
marked terminal is provided with the unit for grounding:

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 9of 20
Product Specifications
This section of the manual provides detailed specifications of FP2-V2 series products, ordering part
numbers, operating conditions, environment, and approvals.
Product Nomenclature / Ordering Part Number
FP2-V2 series has 2 models, depending on display size and each model has two variants, based on
Ethernet. Detail part number or ordering information is as follows:
Model
Description
FP2043T-V2
2 Serial ports#(1 RS232, 1 RS485), 1 USB Device, 1 USB Host
FP2043TN-V2
2 Serial ports#(1 RS232, 1 RS485), 1 USB Device, 1 USB Host, 1 Ethernet
FP2070T-V2
2 Serial ports (RS232 / RS485), 1 USB Device, 1 USB Host
FP2070TN-V2
2 Serial ports (RS232 / RS485), 1 USB Device, 1 USB Host, 1 Ethernet
[# Note: FP2043-V2 support one DB9 port that supports RS232 and RS485 levels on different pins. “Y” type cable
can be used for separate RS232 and RS485 levels simultaneously.]
T: Touch Screen
N: Support Ethernet
FP2 XXX Tx-V2
Display Size
043: 4.3” WQVGA (480 x 272)
070: 7” WVGA (800 x 480)
Series

FlexiPanels®Basic HMI
© Renu Electronics Pvt. Ltd.
Page 10 of 20
Display Specifications
FP2-V2 series products support high-quality color TFT display range.
Size: 4.3” WQVGA Color TFT with 4-wire analog resistive touch screen
Resolution: 480 x 272pixels
Brightness: 400cd/m2
Backlight life: 30,000Hrs.
Size: 7” WVGA Color TFT with 4-wire analog resistive touch screen
Resolution: 800 x 480pixels
Brightness: 350cd/m2
Backlight life: 30,000Hrs.
CPU, Memory and Power Supply
CPU: 32-bit RISC Processor
RAM: 16MB
User Application
8MB
Flash
16MB
Ladder Memory
2MB
Alarm Memory
1350 Alarms
Retentive Memory
8000Words
Keep Memory
1000Words
Data Log
4MB
Power supply:
24VDC(+20%, -15%)
RTC:
Built-in, Date & Time function
