REO REOTRON SMP CP Series User manual

SMP CP-M_ANL_EN_rev04
05.01.2017
REOTRON
SMP CP
SMP CP/M
DC-Power supply

REOTRON SMP CP - CP/M
Instruction manual
2
Technical Information for the User
This description contains the necessary information for the correct application of the product described
below. It is intended for use by technically qualified personnel.
Qualified personnel are persons who, because of their training, experience and position as well as their
knowledge of appropriate standards, regulations, health and safety requirements and working conditions,
are authorised to be responsible for the safety of the equipment, at all times, whilst carrying out their nor-
mal duties and are therefore aware of, and can report, possible hazards (Definition of specialist according
to IEC 364).
Safety Instructions
The following instructions are provided for the personal safety of operators and also for the protection of
the described product and connected equipment.
Warning!
Hazardous Voltage
Failure to observe can kill, cause serious injury or damage
Isolate from mains before installation or dismantling work, as well as for fuse changes or post
installation modifications.
Observe the prescribed accident prevention and safety rules for the specific application.
Before putting into operation check if the rated voltage for the unit conforms with the local
supply voltage.
Emergency stop devices must be provided for all applications. Operation of the emergency
stop must inhibit any further uncontrolled operation.
Electrical connections must be covered
Earth bonding must be tested prior to operation
Prescribed Use
The units described herein are electrically powered for use in industrial applications and are not suitable
for domestic use
Declaration of conformity
We declare that these products conform with the following standards and directives:
Directives: Standards:
- 2014/30/EU EMC - EN 61000-6-4:2007 +A1:2011; EN 61000-6-2:2005
- 2014/35/EU LVD - EN 50178:1997
- 2011/65/EU RoHs
REO AG, D - 42657 Solingen
!
RoHS
COMPLAINT

REOTRON SMP CP - CP/M
Instruction manual
3
Contents
Technical Information for the User ............................................................................................................... 2
1.0 General................................................................................................................................................... 4
2.0 Functions................................................................................................................................................ 5
3.0 Technical Data........................................................................................................................................ 6
4.0 User controls .......................................................................................................................................... 7
4.1 Controls............................................................................................................................................... 7
4.2 Adjustment:......................................................................................................................................... 7
4.3 Adjustment procedure......................................................................................................................... 7
4.4 Display messages............................................................................................................................... 8
4.4.1 Operating modes ............................................................................................................................. 8
4.4.2 Fault messages................................................................................................................................ 8
4.5 Possible settings................................................................................................................................. 9
5.0 Set up ................................................................................................................................................... 10
5.1 Configuration..................................................................................................................................... 10
5.2 Minimum and maximum values........................................................................................................ 11
5.3 Reset error message ........................................................................................................................ 12
5.4 Save user parameters....................................................................................................................... 12
5.5 Recall saved settings........................................................................................................................ 12
5.6 Hide/show user menus ..................................................................................................................... 12
5.7 Service menu.................................................................................................................................... 13
6.0 Connections.......................................................................................................................................... 14
7.0 Dimensions........................................................................................................................................... 15

REOTRON SMP CP - CP/M
Instruction manual
4
1.0 General
Switch mode power supply for cathodic corrosion protection applications
The REOTRON SMP range of DC Power units are primary-switched power supplies with galvanic isolat-
ed output voltage. The units can be used voltage controller or current controller, or as a combined unit to
control both voltage and current. The units can be operated locally from a control panel or (switchable)
from external control signals.
Set point inputs for current and voltage are provided for external control. The set point signals may be a
control voltage 0…+10 V, DC or a control current 4…20 mA. In addition it is possible to switch ON and
OFF the output electronically (without galvanic separation) by the means of an inhibiting input. This inhib-
iting input can be operated with a potential-free contact or a control voltage +24 V, DC.
To monitor the protective current the effective actual values of current and voltage are generated by one
each 4…20 mA control signal and are available on terminals.
With an interface option can be communicated via Fieldbus (Profibus-DP, DeviceNet, CAN-Bus or Ether-
CAT) connection.
The units are built into compact aluminium enclosures for the assembly into a switching cabinet.
SMP-CP/M
To monitor the protection current, the actual values of current and voltage also displayed by analog
measuring instruments

REOTRON SMP CP - CP/M
Instruction manual
5
2.0 Functions
Inputs:
Terminals
Set-point 1
Voltage set-point:
or power set-point:
0...10 V, DC, 0(4)...20 mA or Potentiometer 10 k
11(-), 13(+), 14(+10Vref.)
11(-), 12 (+) with 4...20 mA
Set-point 2
Current set-point:
0...10 V, DC, 0(4)...20 mA or Potentiometer 10 k
15(-), 17(+),
18(+10Vref.)
15(-), 16(+) with 4...20 mA
Inhibit
(SMP CP & CP/M
48-10 /-20)
Contacts or 24 V, DC signal voltage
42(-), 43(+),
41 (-0Vref.), 44(+24Vref.)
Inhibit
(SMP CP & CP/M
24-5)
Contacts or 24 V, DC signal voltage
42(+),
41 (–ref.), 43 (+ref.)
Outputs:
Effective value 1
Effective output voltage 4…20 mA
31(-), 32(+)
Effective value 2
Effective output current 4…20 mA
33(-), 34(+)
Status relay
(SMP CP & CP/M
48-10 /-20)
Status ON / OFF (output), change over contact
51, 52, 53
Inhibit (SMP CP & CP/M 48-10 /-20):
Potential free input via optocoupler to terminals 42 and 43.
External contact across terminals 43 and 44 and a link between 41 and 42 or external 24 V, DC signal on
terminals 42(-) and 43(+).
Inhibit (SMP CP & CP/M 24-5):
External contact across terminals 42 and 43 or external 24 V, DC signal on terminals 41(-) and 42(+).
Voltage regulation (set-point 1)
Link set-point 2 (current) to +10V reference (terminals 17 and 18).
Set-point power to 100% or nominal value. (Menu C 020, P. =100%)
Connect voltage set-point to terminals 11 –14 (see connection diagram).
The current limit can be set in Menu “C. 020”.
Current regulation (set-point 2)
Link set-point 1 (voltage) to +10 V reference (terminals 13 und 14).
Set-point power to 100% or nominal value. (Menu C 020, P. =100%)
Connect current set-point to terminals 15 –18 (see connection diagram).
The maximum output voltage can be set in Menu “C. 020”.
Power regulation (set-point 1) Switching to power regulation: set in Menu C 003: E.F.P. = I
Link set-point 2 (current) to +10V reference (terminals 17 and 18).
Set-point voltage to 100% or nominal value. (Menu C 020, P. =100%)
Connect power set-point to terminals 11 –14 (see connection diagram).
The current limit can be set in Menu “C. 020”.

REOTRON SMP CP - CP/M
Instruction manual
6
3.0 Technical Data
REOTRON SMP
CP & CP/M 24-5
REOTRON SMP CP
& CP/M 48-10
REOTRON SMP CP
& CP/M 48-20
Input
Input voltage
110VAC/230VAC,
+/- 10%
110VAC/230VAC,
+/- 10%
110VAC,
+/- 10%
230VAC
+/- 10%
Input frequency range
50 / 60 Hz
Inrush current Typ.)
60 A / 230 VAC / 15 ms
Efficiency (Typ.)
> 85 %
Power factor
0,95
Earth leakage current
< 5 mA
Output
Output voltage
0,8 ... 24 V
0,8 … 48 V
0,8 … 48 V
Output Rated current
5 A
10 A
20 A
Output current range
0,2 ... 5 A
0,2 ... 10 A
0,2 ... 20 A
Unit output power
120 W
580 W
768W
*(PR)
960 W
Ripple & Noise
+/- 200 mVp-p
Voltage tolerance
+/- 1 %
Current tolerance
+/- 1 %
Output rise time
50 ms at full load
Output hold time
35 ms at full load
Control
Set point input
voltage / current
0... +10 VDC, 0(4)...20 mA/DC Potentiometer 10 kOhm
Feedback output
Actual voltage / actual
current
4…20 mA
Inhibit input
(Remote control)
12 / 24 VDC, 3300 Ohm
or volt free contact
Status signal
Relay, change over contact
1 A, 250 VAC
1A, 60 VDC
Environment
Working temperature
-10...+45 °C
Working Humidity
20 ~ 90 % RH non-condensing
Storage temperature
-40...+85 °C
Storage Humidity
10 … 95 % RH
Safety & EMC
Standards
EN 50178, EN61000-6-2, EN61000-6-4
Protection
IP 20
Weight
2,5 Kg (CP/M)
7,7 Kg (CP/M)
Interface
(Option)
Fieldbus
Profibus-DP
Fieldbus
CAN-Bus
Fieldbus
DeviceNe
Fieldbus
EtherCAT
Fieldbus
EtherNet-IP
Fieldbus
PROFINET
*PR = Powerranging

REOTRON SMP CP - CP/M
Instruction manual
7
4.0 User controls
4.1 Controls
The six buttons and a LED display found in the front-
panel are used for operating and setting up the unit.
All operating methods and adjustable parameters can
be set up through this panel.
The “I” and “O” buttons are used for switching the unit
ON and OFF, however, this does not provide
mains isolation, it simply inhibits the power semi-
conductors.
The “P”, “F” and “Cursor Buttons” are used for pa-
rameter adjustment. Parameters are set by using
menu controls which are called up by entering opera-
tor codes. A capital letter is used to indicate the se-
lected function.
4.2 Adjustment:
The display value can be increased or decreased by units, or tenths of units, by a short press of either
cursor button. Holding a button down will cause the display to change in units of ten.
To prevent accidental or unauthorized adjustment the adjustment parameters, in the user menus, are
protected. A code must be entered to open the user menus. There are different pass codes for each func-
tion group.
Setting adjustments are automatically saved upon leaving the programming mode or if no button
is pressed for a period of 100 seconds.
4.3 Adjustment procedure
All setting routines are commenced by pressing the programming button “P”. The following diagram
should clarify the sequence in which keys are pressed:
1. Press the “P” key.
2. Select the code number with the cursor keys.
3. Press the “P” key. This displays the first menu point. The required menu point can be found by re-
peatedly pressing the “P” key (scrolling).
4. The value in the menu point can be changed with the cursor keys.
5. Scroll to the next menu point or to the end of the menu, which returns the display to the set point val-
ue, by pressing the “P” key. To exit the menu and return back to the normal display quickly, depress
the “P” key for 5 seconds.
6. To return back to the previous position in the menu, press the “F” key
P
F
P
P
P
P
P
I
0
P
FON
OFF
DISPLAY
PROGRAMMING
MODE / ENTER
UP
DOWN
BACK

REOTRON SMP CP - CP/M
Instruction manual
8
4.4 Display messages
During normal running mode ‘run’ is shown in the LED display. In the programming mode an abbreviation
for the corresponding parameter (see setting up instructions) and its set value, are displayed. Setting
changes are stored upon leaving the programming mode or if a key is not touched for a period of 100
seconds.
4.4.1 Operating modes
Initialisation Phase. When the supply voltage is connected (Left decimal point blinks)
Normal operation
Unit not enabled
Switched-off using “0 – key”
Left-hand decimal point in display illuminated. Current regulation mode; maximum
unit current or the set-point value for current regulation has been reached.
Under Voltage, input voltage to too low.
4.4.2 Fault messages
Over-temperature
Short circuit (internal)
Overvoltage, input voltage too high, output is inhibited
Use `C009` to reset
Unspecified error message, please contact the manufacturer.
When there is a fault an "Error" message is displayed and the unit switches off internally. The unit can be
reset using the green "I" button on the display or in menu "C 009".

REOTRON SMP CP - CP/M
Instruction manual
9
4.5 Possible settings
Parameter
Code
Default
settings: (factory)
Menu
Code:
Disable external set-point
0 / I
E.S.O.
0
003
4...20 mA
0 / I
4.20
0
003
Power regulation
0 / I
E.F.P.
0
003
Minimum voltage
0...100 %
U.
0
020
Minimum current
0...100 %
I.
0
020
Minimum power
0...100 %
P.
100
020
Maximum voltage
50...100 %
u.
100
020
Maximum current
50...100 %
i.
100
020
Maximum power
50...100%
o.
100
020
Soft-start
0...60 sec.
/.
0,1
020
Soft-stop
0...60 sec.
\.
0,1
020

Internal voltage set-point (Display)
0...100 %
U.
0
002
Internal current set-point (Display)
0...100 %
I.
0
002
Internal power set-point (Display)
0...100 %
P.
100
002

Error reset
Clr.Er.
009
Save user settings
PUSH.
143
Recall factory settings
FAC.
210
Recall user settings
US.PA.
210
Hide programming menus
0 / I
Hd.C.
0
117

Display actual set-point (in %)
Voltage
u.
050
Current
i.
050
Power
P.
050

Display actual effective value (in %)
Voltage
u.
051
Current
i.
051
Power
P.
051

REOTRON SMP CP - CP/M
Instruction manual
10
5.0 Set up
Minimum values or internal set-points
P
Code 002
F
P
P
P
P
P
PP
Set point 1, Voltage [%]
Set point 2, Current [%]
Running mode
Set point 3, Power [%]
5.1 Configuration
Code 003
P P
P
P
P
PP
P
P
E.S.O. = 0 = External Set point
E.S.O. = I = Internal Set point (Keys)
4.20 = 0 = External Set point 0...20 mA / 0...10V
4.20 = I = External Set point 4...20 mA
E.F.P. = 0 = Voltage- / Current regulation
E.F.P. = I = Power regulation set point
-E.n. = 0 = Invert Enable Off
-E.n. = I = Invert Enable On
Running mode

REOTRON SMP CP - CP/M
Instruction manual
11
5.2 Minimum and maximum values
P P
P P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
P
Code 020
PP
P P
Min ouptput voltage [%]
(without external set point)
Min output current [%]
(without external set point)
Output voltage limit [%]
Umax
Start ramp time [Sec.]
Running mode
Output current limit [%]
Imax
P-Characteristic current regulation
Stop ramp time [Sec.]
Min output power [%]
(without external set point)
P-Characteristic power regulation
Output power limit [%]
Pmax
P-Characteristic voltage regulation

REOTRON SMP CP - CP/M
Instruction manual
12
5.3 Reset error message
PP
Code 009 Clear error
An error message can also be cleared by pushing the green “I”-Button in the Display.
5.4 Save user parameters
Code 143
P P
P
P
Running mode
Save current parameter settings
5.5 Recall saved settings
Code 210
PP
P
P
P
P
Restore factory settings
Restore previously saved settings
Running mode
5.6 Hide/show user menus
Code 117
P P
P
PHd.C. = 1= Hide menus
Running mode

REOTRON SMP CP - CP/M
Instruction manual
13
5.7 Service menu
Display the set-point values sent to the unit.
Display the effective values measured by the unit.
P
Code 051
P
P
P
P
P
P
P
P
Display feedback voltage [%]
Display feedback current [%]
Running mode
Display feedback power [%]
Unspecified / Reserve
Unspecified / Reserve
Unspecified / Reserve
Unspecified / Reserve
P
Code 050
P
P
P
P
Display set point voltage [%]
Display set point current [%]
Running mode
Display set point power [%]

REOTRON SMP CP - CP/M
Instruction manual
14
6.0 Connections
REOTRON SMP CP & CP/M 24-5
0V
ref. 10 V
Output
0V
ref. +10 V
0V
+24V
+
-
Enable 12 / 24 V
Mains input 230 V, 50/60 Hz
L
N
PE
1
2
11 12
13 14
15
16
17 18
41 42
43
61
62
63
4 - 20mA
0 - 10V
Set point voltage
10 kR
0V
0V
31 32
33 34
Actual voltage
Actual current
4 - 20mA
4 - 20mA
4 - 20mA
0 - 10V
Set point current 10 kR
REOTRON SMP CP & CP/M 48-10 /-20
0V ref. 10 V
Output
0V
ref. +10 V
0V +24V
+
-
Enable 12 / 24 V
Mains input 230 V, 50/60 Hz
L
N PE
1
2
11 12 13 14
15
16
17 18
41 42 43 61 62 63
4 - 20mA
0 - 10V
Set point voltage
10 kR
0V 0V
31 32 33 34
Actual voltage
Actual current
4 - 20mA
4 - 20mA
44 51 52 53
Status relay output on/off
4 - 20mA
0 - 10V
Set point current 10 kR
PE PE

REOTRON SMP CP - CP/M
Instruction manual
15
7.0 Dimensions
REOTRON SMP CP 24-5

REOTRON SMP CP - CP/M
Instruction manual
16
REOTRON SMP CP/M 24-5

REOTRON SMP CP - CP/M
Instruction manual
17
REOTRON SMP CP 48-10 /-20

REOTRON SMP CP - CP/M
Instruction manual
18
REOTRON SMP CP/M 48-10 /-20

REOTRON SMP CP - CP/M
Instruction manual
19

REO AG
Brühler Straße 100 · D-42657 Solingen
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected]
Internet: www.reo.de
PRODUCTION+SALES:
China
REO Shanghai Inductive Components Co., Ltd
No. 536 ShangFeng Road · Pudong, 201201 Shanghai · China
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected] ·Internet: www.reo.cn
India
REO GPD INDUCTIVE COMPONENTS PVT. LTD
2/202 Luna Road · Village Luna · Taluka Padra
Vadodara - 391440 · India
Tel.: [phone]
E-Mail: [email protected] · Internet: www.reo-ag.in
USA
REO-USA, Inc.
8450 E. 47th St ·USA-Indianapolis, IN 46226
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected] · Internet: www.reo-usa.com
SALES:
France
REO VARIAC S.A.R.L.
ZAC Du Clos aux Pois 1 ·6/8 rue de la Closerie-LISSES·F-91048 Evry Cédex
Tel.: [phone] ·Fax: [phone]
E-Mail: reovar[email protected] · Internet: www.reo.fr
Great Britain
REO (UK) Ltd.
Units 2-4 Callow Hill Road ·Craven Arms ·Shropshire SY7 8NT · UK
Tel.: [phone] ·Fax: [phone]
E-Mail: m[email protected] · Internet: www.reo.co.uk
Italy
REO ITALIA S.r.l.
Via Treponti, 29 · I-25086 Rezzato (BS)
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected] ·Internet: www.reoitalia.it
Poland
REO CROMA Sp.zo.o
ul. Pozaryskiego 28, bud 20 ·PL-04-703 Warszawa
Tel.: [phone] ·Fax: [phone]
E-Mail: crom[email protected] · Internet: www.croma.com.pl
Spain
REO ESPAÑA 2002 S.A.
C/Manuel Ventura i Campeny 21B ·local 9 ·E-08339 Vilassar de Dalt (Barcelona)
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected] · Internet: www.reospain.com
Switzerland
REO ELEKTRONIK AG
Im Halbiacker 5a · CH-8352 Elsau
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected] ·Internet: www.reo.ch
Turkey
REOTURKEY ELEKTRONİK San. ve Tic. Ltd. Şti.
Halil Rıfatpasa Mah. · Darülceze CD Perpa Tic Merkezi
B Blok Kat 8 No:1095 ·TR-34384 Sisli –Istanbul
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected] · Internet: www.reo-turkey.com
Divisions:
REO Vibratory Feeding and Power Electronics Division
Brühler Straße 100 · D-42657 Solingen
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected]
REO Train Technologies Division
Erasmusstraße 14 · D-10553 Berlin
Tel.: [phone] · Fax: [phone]
E-Mail: [email protected]
REO Drives Division
Holzhausener Straße 52
D-16866 Kyritz
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected]
REO Medical and Current Transformer Division
Schuldholzinger Weg 7 · D-84347 Pfarrkirchen
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected]
REO Test and PowerQuality Division
Brühler Straße 100 · D-42657 Solingen
Tel.: [phone] ·Fax: [phone]
E-Mail: [email protected]
