resideo ADEMCO TS300 User manual

ADEMCO TS300
Dual Temperature Sensor
Installation an Operating Instructions
INTRODUCTION
The TS300 is a hardwired temperature monitor able to accurately detect variations in temperature. It can monitor the
temperature at the unit and at a remote location (using a T280R) simultaneously. Alarm annunciations include a local
piezo sounder and two programmable NO/NC outputs which activate when the mapped high or the low limit(s) is
exceeded, protecting equipment, property, and perishable items. The NO/NC alarm outputs may be delayed by
increments of one minute to allow for expected momentary temperature variations such as during a refrigeration unit's
defrost cycle. The audible alert, if programmed, sounds when the temperature limit is violated and can be silenced with
the press of a button for a programmed duration. The TS300 can accurately monitor any temperature within the range
from 32
°
F to 140
°
F (0
°
C to 60
°
C). A T280R Remote Temperature Probe may be used to monitor temperature within the
range from -40
°
F to 140
°
F (-40
°
C to 60
°
C) or to monitor temperature in a harsh environment.
INSTALLATION
Mount the unit on a wall at a convenient viewing height. For accurate temperature sensing at the unit, do not mount the
TS300 near any heat or cooling source. If the unit does not trip the panel, insure that the contact configuration (NO/NC)
as defined in the Setup Procedure agrees with that of the zone to which it is connected.
TO THE INSTALLER
Regular maintenance by the installer and frequent testing by the user are vital to continuous satisfactory operation of any
alarm system. The TS300 and the T280R should be tested periodically, at least once a month, depending on conditions.
The installer should assume the responsibility of developing and offering a regular maintenance program to the user as
well as acquainting the user with the proper operation and limitations of the alarm system and its component parts.
Recommendations must be included for a specific program of frequent testing to ensure the system's proper operation at
all times.
Illustration A
SETUP PROCEDURE
Remove the front cover from the TS300. With power applied to the unit, press the SETUP MODE switch (see Illustration
A). Press the Left button to lower a numeric limit by a value of one (press and hold to decrement by tens); Press the right
button in raise a numeric limit by a value of one (press and hold to increment by tens). Pressing either button will toggle
the either/or choices. When your preferred setting is displayed, press the setup button to accept and move to the next
parameter
.
Note that, when setting High/Low limits in Centigrade mode, incrementing/decrementing will raise/lower the limit by the
equivalent of 1
°
Fahrenheit (or 10
°
F, if button is pressed and held).
Table 1. Programmable Parameters
Parameter
Display
Default
Min
Max
Fahrenheit or Centigrade
F-C
F
F
C
Remote Probe Enable
rEN
NO
NO
YES
Display Local or Remote
temperature
DSP
LCL
LCL
RPR
Set Local Sensor Low Limit
LLO
40
32
I40
Set Local Sensor High Limit
LHI
I40
32
I40
Set Remote Probe Low Limit
RLO
40
-
40
I40
Set Remote Probe High Limit
RHI
I40
-
40
I40
Select Output Mode (both
relays)
1
Out
NC
NC
NO
Set Output Map for Output 1
2
OuI
I
I
I
Set Output Map for Output 2
2
Ou2
2
2
2
Set Alarm Delay for Output 1
DLI
0
0
255
Set Alarm Delay for Output 2
dL2
0
0
255
Enable Alarm Audible
Annunciator
AUD
YES
NO
YES
Audible Alarm Silence
Timeout
SIL
0
0
255
Hysteresis
3
Degrees of
HYS
0
0
I0
NOTES:
1
If programmed for Normally Closed (NC) it is supervised, if Normally Open (NO) it is unsupervised.
2
The Output map is a graphical representation of the possible choices.
The left character indicates which relay you are mapping, 1 or 2.
The middle character is the local sensor map and the right character is the remote probe map. See Table 2 for
map designations.
3
Hysteresis provides a buffer so that temperature that is shifting back and forth around the alarm limit point will
not create multiple alarms. You set the # of degrees that the temperature will have to rise above the
temperature low limit set point or drop below the high limit set point for the alarm to turn off. For example, if
you set the HYS at 3 degrees and your low limit is 40 degrees, you will go into an alarm condition when the
temperature reaches 39 degrees and restore from alarm would not occur until the temperature rose to 43
degrees. Hysteresis is limited to ½ the difference in degrees between the low temperature limit and high
temperature limit or the programmed HYS setting (max of 10Ε) whichever is least.
4
The setup will NOT be lost in the event that power is lost at the panel.
5
Options that relate to the remote probe will only appear is you have enabled the remote probe in selection 2
of the table parameters.
6
High/Low limits shown in table are degrees Fahrenheit. Equivalent Centigrade temperatures apply when
Centigrade has been selected.
7
Hysteresis is always programmed in degrees Fahrenheit, even if Centigrade has been selected to set limits.
-2-
Table 2. Output Map Designations
I
II
I
Output 1 - not used
I
II
I
Output 1 - Local and Remote Low
Alarms
I
II
I
Output 1 - Local Low Alarm
I
II
I
Output 1 - Local Low and Remote
High Alarms
I
II
I
Output 1 - Local High Alarm
I
II
I
Output 1 - Local Low and Remote
Low and High Alarms
I
II
I
Output 1 - Local Low and High
Alarms
I
II
I
Output 1 - Local High and Remote
Low Alarms
I
II
I
Output 1 - Remote Low Alarm
I
II
I
Output 1 - Local and Remote High
Alarms
I
II
I
Output 1 - Remote High Alarm
I
II
I
Output 1 - Local High and Remote
Low and High Alarms
I
II
I
Output 1 - Remote Low and
High Alarms
I
II
I
Output 1 - All Alarms; Local Low
and High and Remote Low and
High
Map designations:
Low Limit High Limit Both Low
& High Limits
Examples: (The same choices can be used for relay 2)
OPERATION
Display - The TS300 displays the selected temperature (local [ambient] or remote) in either Fahrenheit or
Centigrade as programmed. To check the temperature at a sensor, press the left button for the local sensor or
the right button for the remote probe. The temperature you have requested will flash 5 times and then return to
displaying the temperature of the sensor you have chosen to display.
Alarm - If the temperature at an enabled sensor varies outside either of its mapped limits, the audible
annunciator will sound, if programmed, and the mapped output will switch to its alarm state, but only after the
selected delay time has expired. If the delay time is set to 0 the alarm will be immediate. The maximum delay
time is 255 minutes (4 hours, 15 minutes). The output will remain in its alarm state until the temperature
returns to within the selected limits as buffered by the programmed degrees of hysteresis. As long as the
temperature remains outside the selected temperature limits, the display will cycle between the desired display
temperature and the name of the limit(s) exceeded.
Silence - The Audible alarm is silenced by pressing either of the buttons. It will remain silenced until the
silence timeout time expires and then it will become audible again. In addition, when the output delay time is in
the final 60 seconds the audible will switch to a fast beep (250mS pulsed), if it has been enabled.
High and Low Temp limits and Alarm Memory - To display the programmed high and low temperature
limits, press and hold both buttons momentarily. The unit will show the programmed limits followed by any
alarms in alarm memory. The TS300 stores the last 8 alarm events. An alarm event is one where the relay
output was activated. If delays are used, and the temperature restored before the delay time expired, it is not
considered an alarm and will not be stored in alarm memory. Alarms are displayed as the limit that was
violated. For example LLO for local low limit. The alarms are displayed most recent to oldest. Alarm memory is
cleared when you enter set-up mode or when power is cycled to the unit.
-3-
TS300 SPECIFICATIONS
TS300 SPECIFICATIONS
Temperature Range / Accuracy (Local Sensor)
32
°
F to 140
°
F (0
°
C to 60
°
C) ∀3
°
F (∀1.7
°
C)
Temperature Range / Accuracy (Remote Probe)
-40
°
F to 140
°
F (-40
°
C to 60
°
C) ∀4
°
F (∀2.2
°
C)
Minimum Span between Hi and Low Limits
4
°
F (2.2
°
C)
Alarm Delay 0 - 255 minutes in 1 min increments
Alarm Output Type (2) Form A reed relays
Alarm Output Resistance 25 ohms maximum
Alarm Output Rating 50 mA max. @ 30 VDC
Audible Alarm 4 kHz, 75 dB @ 10 cm pulsed 750 mS on/off
Audible Alarm Silencing 0 - 255 minutes in 1 min increments
Input Voltage 7 to 16 VDC
Input Current 25 mA (max.)
Case Dimensions 4" x 2.6" x 0.9" (10.2 cm x 6.6 cm x 2.3 cm
T280R REMOTE TEMPERATURE PROBE
(purchased separately)
The T280R is a Remote Temperature Probe for use with the TS300. The Remote Probe is a sealed temperature sensor
with 15 feet of two conductor, 24 AWG stranded cable. The cable should be connected to the two terminals labeled
REMOTE. (Polarity need not be considered.)
Caution: Excessive force applied to the probe may damage the device.
T280R Remote Probe Specifications
Chemical Properties
Non-corrosive Water Resistant
Max. Compression Force Applied to Probe
10 lb. force
Max. Tensile Force Applied Between Probe and Cable
5 lb. force
Max. Cable Length 300 feet*
•The T280R may be extended from 15' up to 300' using shielded 24 AWG cable. Insure the shield is grounded for noise immunity.
CE compliance logo.
This product is in
conformity with the
relevant European
union harmonization
legislation
Logo de conformité CE.
Ce produit est
conforme
à la législation
d’harmonisation dans
l’Union européenne
pertinente
CE
‐
ichtlinien
‐
Logo.
Dieses Produkt
stimmt mit den
relevanten
Harmonisierungsges
etzen der EU überein
Logotipo de
cumplimiento de CE.
Este producto cumple
con la legislación de
uniformidad de la
Unión Europea
pertinente
Logo conformità CE.
Questo prodotto è
conforme alla
legislazione
armonizzata
pertinente
dell'Unione Europea
CE logo shody.
Tento výrobek je v
souladu s
příslušnými právními
předpisy Evropské
unie pro harmonizaci
CE uygunluk logosu.
Bu ürün, ilgili Avrupa
Birliği uyumlaştırma
mevzuatına
uygundur
Symbol zgodności
CE. Produkt jest
zgodny z właściwymi
przepisami unijnego
prawodawstwa
harmonizacyjnego
The WEEE symbol. It
indicates this product
is to be recycling
and not been thrown
away in a dustbin.
Le symbole DEEE. Il
indique que ce
produit doit être
recyclé et qu’il ne
doit pas être jeté à la
poubelle.
Das WEEE
‐
Symbol.
Es bedeutet, dass
dieses Produkt
recyclebar ist und
nicht in den
Hausmüll gehört
Símbolo WEEE
Indica que este
producto es para
reciclar y que no se
debe arrojar al cubo
de basura
Simbolo AEE.
Indica che questo
prodotto deve essere
riciclato e non può
essere gettato nel
secchio della
spazzatura
Symbol WEEE. To
označuje, že tento
výrobek má být
recyklován a ne být
vyhozen do
popelnice.
WEEE sembolü. Bu
ürüne geri dönüşüm
yapılması gerektiğini
ve çöp kutusuna
atılmaması
gerektiğini belirtir.
Symbol WEEE.
Oznacza, że produkt
należy poddać
recyklingowi i nie
można wyrzucać go
do pojemników na
śmieci.
For the latest documentation and online support information please go to:
www.resideo.com
For the latest warranty information, please go to:
www.resideo.com
2 Corporate Center Drive, Suite 100
P.O. Box 9040, Melville, NY 11747
2019 Resideo Technologies, Inc.
www.resideo.com
ÊN3114-1C\Š
N8188-2V3C 11/08 Rev. C

Popular Temperature Controllers manuals by other brands

alre RTBSB-001 Series manual

alre

alre RTBSB-001 Series manual

alre ITR 79 quick start guide

alre

alre ITR 79 quick start guide

Meade TS33F-M user manual

Meade

Meade TS33F-M user manual

esera automation 11130 user guide

esera automation

esera automation 11130 user guide

Eurotherm 2108i Installing and operating instructions

Eurotherm

Eurotherm 2108i Installing and operating instructions

Temptime EDGE M-300 user guide

Temptime

Temptime EDGE M-300 user guide

Elotech R 1100 Description and operating manual

Elotech

Elotech R 1100 Description and operating manual

Uni-Ubi Uface 5-Temp Product Booklet

Uni-Ubi

Uni-Ubi Uface 5-Temp Product Booklet

Arico TC5E user manual

Arico

Arico TC5E user manual

TREND T/PC installation instructions

TREND

TREND T/PC installation instructions

AMX VST-TSF Dimensional drawing

AMX

AMX VST-TSF Dimensional drawing

Okolab H201-T-UNIT-BL manual

Okolab

Okolab H201-T-UNIT-BL manual

Instant Transmission TX40U-IT instruction manual

Instant Transmission

Instant Transmission TX40U-IT instruction manual

Omron E5DC manual

Omron

Omron E5DC manual

Elko iNELS RF Control RFTC-150/G manual

Elko

Elko iNELS RF Control RFTC-150/G manual

SIKA IO-Link IOB operating manual

SIKA

SIKA IO-Link IOB operating manual

Lennox V0STAT54P-3 Installation & operation instructions

Lennox

Lennox V0STAT54P-3 Installation & operation instructions

dixell XR02CX operating manual

dixell

dixell XR02CX operating manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
