Reso QDOS Q-PUK User manual
CompanyConfidential ResoLtdT/AQDOS
IssueN°116thJune2014
USERMANUAL
QDOSQ‐PUK
BluetoothWaterproofSpeaker
CompanyConfidential ResoLtdT/AQDOS
IssueN°116thJune2014
Welcome
Congratulationsonyourpurchase.YourQDOSQ‐PUKBluetoothWaterproofSpeakerfor
allBluetoothcompatibleiProducts,smartphones,tablets,PCsandotherdevicescapable
ofstreamingBluetoothaudioisdesignedtodeliverasuperioraudioexperienceasanultra
light‐weightminiportablespeakersystem.Thiscompact,ruggedspeakerbuiltfor
outdooruseeasilyconnectswirelesslytoyourmusicdevice,inseconds…nocables,no
hassles!Robustanddurablewithitsuniqueprotective,waterproofsiliconeskin,itwill
providehoursofcrystalclearaudioonthego.
Wehopeyouwilltakefewmomentstoreadthismanualandfollowalluserinstructionsto
gettoknowyourproduct.
System Specifications of the QDOS Q-PUK Bluetooth Waterproof
Speaker
ProductSpecifications
oDimensions: 85mm x 87mm x 34mm
oRated Power: DC power
oWeight : 130gms
oInterface : Micro-USB
oCommunication : NFC, Bluetooth 4.0
oApprovals: CE, FCC, RoHS (attached in Appendix B)
oWaterproof : IPX67 rated, up to 1m depth
oLED : LED light indicates power on
SpeakerDriverSpecifications
oDimensions: 50mm
oChannel Mono channel
oSpeaker rated power:4Ω3W
oRMS: 1.5W*1
oTHD: ≤10%
oFrequency 200Hz-20KHz
oS/N Ratio: ≥75dB
BluetoothSpecifications
oVersion 4.0
oOperation frequency: 2.402 -2.48GHz
oReceiving Sensitivity: -91dBm @ 0.1% BER
oOperation range: up to 10m
BatterySpecifications
oSpecification: built-in Polymer battery
oCapacity: 500mAh, 3.7v
oCharging standard: DC 5V, 500mA
MiscellaneousSpecifications
oMusic playback time: 6-8 hours at 70% volume
oCharging time: 1 ½ to 2 hours
oAuto off: device will shut down after 5 minutes of inactivity
CompanyConfidential ResoLtdT/AQDOS
IssueN°116thJune2014
Features & Functions
①Carabiner
•Convenientcarrysolutionforfixingtobackpack,beltetc..
②+VolumeUp/Nextsong
•shortpressfornextsong
•longpressforvolumeup
③NFC:approachanyNFC‐enabledmobilephonetothispositionandthespeakerand
mobilewillpairautomatically
④‐VolumeDown/Previoussong
•shortpressforprevioussong
•longpressforvolumedown
⑤LEDindicator–built‐inbatterystatus
•BlueLEDflashing‐pairing.Afterpairingsuccessfully,itwillremainblue
•BlueLEDon‐playing
•RedLEDon‐charging,whenchargingisfinished,itwillturnoff
⑥PowerswitchOn/Off
•Pressfor3secondstopoweron/off
•Theunitwillturnoffautomaticallyafter5minutesifnoaudiodevicesare
paired
⑦Pause/Playbutton
•Pressforpause,pressagainforplaymusicunderBluetoothplayingmode.
⑧ MicroUSBchargingportunderneathawaterproofanddustproofcover
⑨ Siliconeband
•85mmlength.Soft,lightweightandwaterproof,idealforhangingthe
QDOSQ‐PUKonyourwristorevenaroundyourneck.
CompanyConfidential ResoLtdT/AQDOS
IssueN°116thJune2014
Operation
First,turnontheQDOSQ‐PUKBluetoothWaterproofspeakerusingtheOn/Offbuttonon
thesideofthedevice⑥.Pressthebuttonfor3secondstopoweronorpoweroff.
Whenpoweredon,theblueLEDlightwillflashandyouwillhearasound.YourQDOSQ‐
PUKBluetoothspeakerisreadyforuse.WhenyouarereadytoturnofftheQ‐PUK
speaker,simplyholdthepowerbuttondownfor3seconds.Youwillhearasoundandthe
blueLEDlightwillturnoff.
NB‐topreservebatterypowerandensureuninterruptedfunwhenoutandabout,the
QDOSQ‐PUKisdesignedtoturnoffafter5minuteswhennotinuse,orwhennodevice
ispaired!
ConnectingyourQDOSQ‐PUKwaterproofspeakerforplaybackviaBluetooth
ActivatetheBluetoothfunctionofyourdevice(smartphone,PCor
tablet)
MakesuretheQDOSQ‐PUKisturnedon
SearchforQDOS
FindQDOSPairing
SelectQDOStoconnectandplay
WhenfinishedplayingdoremembertoturnofftheQDOSQ‐PUKusing
thepowerbutton
ConnectingyourQDOSQ‐PUKwaterproofspeakerforplaybackviaNFC*
Searchyourmobiledeviceand,ifapplicable,turnon/selecttheoption
‘allowdataexchangewhenclosetootherdevices’
MakesuretheQDOSQ‐PUKisturnedon
BringthemobilephoneclosetotheNFCzoneontheQ‐PUKfor3
seconds
YouwillhearapromptvoicewhichmeanstheNFCconnectionhasbeen
successful
YoumaydisconnectwithNFCbysimplybringingthephoneclosetothe
NFCzonewhenyouarefinishedusingthedevicebutdorememberto
turnofftheQDOSQ‐PUKusingthepowerbutton
*whenchoosingthismethod,pleaseensureyourmobilephonesupportstheNFCfunction
NB–Ifyouareunabletoconnectwithyourdevicebyeithermethod,youmayneedto
deleteotherBluetoothdevicesfromyourdevicelist.SeeTROUBLESHOOTINGformore
information.
CompanyConfidential ResoLtdT/AQDOS
IssueN°116thJune2014
UsingyourQDOSQ‐PUKdevice
Nowthatyouareconnectedandreadyforplay,youcancontrolthe
volumeeitherdirectlyontheQDOSQ‐PUKusingthevolumebuttons②
④, orviathevolumecontrolonyourpaireddevice
Whenmakingorreceivingacall,theaudiowillpauseduringthecalland
restartwhenthecallhasended
NB‐soundperformancecanbeaffectedbytransmittingdistance,poorsignalandother
factors.SeeTROUBLESHOOTINGformoreinformation.
WaterproofdetailsforyourQDOSQ‐PUKBluetoothspeaker
YourQDOSQ‐PUKistestedandcertifiedsubmersibleupto1metre
Pleasenotethatplaybackmaybemomentarilyaffectedduetowater
pressureandinterference
Itisrecommendedtoshakeoffanyexcesssurfacewateranddryyour
QDOSQ‐PUKbeforere‐usetogetbacktooptimalperformance
NB‐theQDOSQ‐PUKisawaterproofspeakerandisprotectedagainstaccidentalwater
ingressforaruggedoutdoororindooruse.Itisnotdesignedforuseasanunderwater
speaker.
ChargingyourQDOSQ‐PUKdevice
Whenthebatteryislow,theQDOSQ‐PUKwillemitwarningbeepsto
remindyoutore‐chargeit
TurnoffyourQDOSQ‐PUK
Connectthemicro‐USBendoftheUSBchargingcablewiththeunit⑧
andconnecttheotherendtoyourPC,powerbankorothercharger
devicewhoseoutputisDC5V,0.5A‐2A
TheredLEDlightwillremainonwhilstcharging
YourQDOSQ‐PUKwillbefullychargedinunder2hours
NB–iftheQDOSQ‐PUKiscompletelyoutofpoweryouwillnothearthebeepingsounds
andtherewillbenovisibleLEDlight.SeeTROUBLESHOOTINGformoreinformation.
Troubleshooting
Bluetoothisabi‐directionaltransmittingprotocol;transmittingdistanceandperformanceisrelatedto
anddependentontheaudioplayer.
Someterminalaudioplayersmanageautomaticswitchingbetweensongsdifferentlyandyoumay
experiencesomePOPnoiseintheintervalbetweensongsfromtimetotime.
IfyouexperienceissuesconnectingtheBluetoothdevice,pleasedeletetheotherBluetoothdevices
fromthelist,re‐activatetheQDOSQ‐PUKBluetoothspeakerstand,re‐searchitandre‐pairit.
EnsurethatotherdevicesinthevicinitywithBluetoothswitchedonhavealsodeletedtheQDOSQ‐
PUKfromtheirlistssothatyourdevicecanpairwithit.
Poorsignalenvironmentswillaffectsoundplaybackperformancebutmovingtoabettersignalarea
willrestoreperformance.
CompanyConfidential ResoLtdT/AQDOS
IssueN°116thJune2014
Lowbatterycapacitymayalsoaffectplaybackperformance.Re‐chargethedeviceusingthecable
providedtorestoreperformance.
Itisrecommendedalwaystoturnoffyourdevicewhenchargingandtounplugbeforeuse.
WHATSINTHEBOX
QDOSQ‐PUKBluetoothspeaker
Carabinerandsiliconeband
USBtoMicro‐USBchargingcable
Usermanual
CAREANDMAINTENANCE
Alwaysturnofftheunitandunplugthepowercablefirstbeforeperformingany
generalcleaning
Onlycleanwithadrycloth.Donotuseliquids,aerosols,chemicals,cleaningsolvents
orstrongdetergents
Toavoiddamagealwaysstorethespeakerinaclean,dryanddust‐freeenvironment
anddonotplaceanyheavyobjectsontopoftheunit
Avoidextremehighandlowtemperatures,directsunlight,dustandhumidity.
Maintainventilationduringuseanddonotplaceanythingonoraroundyourproduct
duringoperation
DisposingofyourQDOSQ‐PUKBluetoothspeaker
1. TheuseoftheWEEEsymbolindicatesthatthisproductmaynotbetreatedas
householdwaste.Byensuringthisproductisdisposedofcorrectly,youwillhelp
protecttheenvironment.Formoredetailedinformationabouttherecyclingof
thisproduct,pleasecontactyourlocalauthority,yourhouseholdwastedisposal
serviceproviderortheshopwhereyoupurchasedtheproduct.
2. Donotincinerateordisposeofyourproductinafireormicrowave
For Your Safety
Failuretoreadandfollowthesesafetywarningscouldresultinfire,explosion,
electricalshockorotherhazard,causingseriousand/orfatalinjuryand/or
propertydamage
Followalloperatingandusageinstructions
Beforeusealwayscheckfordamageanduseonlythecablesprovided
Donotblockanyopeningsinthespeakercabinetnorpushobjectsintothespeaker
ventsorslots.
Donotattempttoopenordismantletheunitandneverdisassembleormodifythe
componentsoftheQDOSQ‐PUKBluetoothspeaker
KEEPAWAYFROMFIRE.Avoidthrowingthespeakerintofireorstoringneartoany
heatingsource
Keepawayfromcorrosivematerials
TheQDOSQ‐PUKistestedandqualifiedaswaterprooftoanIPratingof7which
indicatesthelevelofprotectionagainstharmfulingressofwater‐ingressofwaterin
CompanyConfidential ResoLtdT/AQDOS
IssueN°116thJune2014
aharmfulquantityshallnotbepossiblewhentheenclosureisimmersedinwater
(immersionupto1m)
DonotsubmergeorusetheQDOSQ‐PUKBluetoothspeakerinwaterdeeperthan1
metre.TheQDOSQ‐PUKwilllikelybedamagedbywaterpressurebelowthatdepth.
IfyourQDOSQ‐PUKBluetoothspeakerdoesfallintodeeperwater,donotresume
usewithouttheadviceofaqualifiedtechnician
Topreventshortcircuitorotherpotentialhazards,keepsmallelectricallyconductive
partsawayfromtheQDOSQ‐PUKBluetoothspeakeranditsconnectingsockets
DonotallowsmallchildrentoplaywiththeQDOSQ‐PUKBluetoothspeaker
unsupervised
Intheunlikelyeventofover‐heatingorifyounoticeanyunusualsmells,distortions,
discoloringorotherabnormalphenomena,pleasestopusingtheQDOSQ‐PUK
Bluetoothspeakerimmediatelyandseektheadviceofaqualifiedelectronic
technician
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgeneratesusesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,
may cause harmfulinterferencetoradiocommunications.However,thereisnoguaranteethatinterference
willnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisen-
couragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
‐‐Reorientorrelocatethereceivingantenna.
‐‐Increasetheseparationbetweentheequipmentandreceiver.
‐‐
Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconn
ected.
‐‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Changesormodificationsnotexpresslyapprovedbythepartyresponsibleforcompliancecouldvoidthe
user'sauthoritytooperatetheequipment.
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwoconditions:
(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,
includinginterferencethatmaycauseundesiredoperation.
For Help and More Information
www.qdossound.com
Werecommendyoukeepthisdocumentandtheoriginalpackagingforfuture
reference
Allrightsreserved.Reproductioninwholeorinpartisprohibited.QDOSisatrade‐
markofResoLtd.Allothertrademarksarethepropertyoftheirrespectiveowners.
Specificationsaresubjecttochangewithoutnotice.Actualcolourandcontentsmay
differslightlyfromthosepictured.
MadeinChina.
QDOSwarrantsthisproducttobefreefromdefectsinmaterialsandworkmanshipin
thecourseofnormaluseforaperiodoftwoyearsfromthedateofpurchase.This
guaranteecoversbreakdownsduetomanufacturingordesignfaults;itdoesnot
CompanyConfidential ResoLtdT/AQDOS
IssueN°116thJune2014
applyincasessuchasaccidentaldamage,howevercaused,wearandtear,
negligence,adjustment,modificationorrepairnotauthorisedbyus.
Shouldyouhaveaproblemwithyourunitpleasecontactyoursupplierorcontact
QDOSsupportat[email protected]
DISCLAIMER OF WARRANTY
EXCEPT FOR THE LIMITED WARRANTY PROVIDED HEREIN, TO THE EXTENT
PERMITTED BY LAW, RESO LTD DISCLAIMS ALL WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING ALL WARRANTIES OF MERCHANTABILITY AND/OR FITNESS
FOR A PARTICULAR PURPOSE. TO THE EXTENT THAT ANY IMPLIED WARRANTIES
MAY NONETHELESS EXIST BY OPERATION OF LAW, ANY SUCH WARRANTIES ARE
LIMITED TO THE DURATION OF THIS WARRANTY. SOME STATES/PROVINCES DO
NOT ALLOW LIMITATIONS OF HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
LIMITATION OF LIABILITY
REPAIR OR REPLACEMENT OF THIS PRODUCT, AS PROVIDED HEREIN, IS YOUR
EXCLUSIVE REMEDY. RESO LTD SHALL NOT BE LIABLE FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT LIMITED TO,
LOST REVENUES, LOST PROFITS, LOSS OF USE OF SOFTWARE, LOSS OF
RECOVERY OF DATA, RENTAL OF REPLACEMENT EQUIPMENT, DOWN-TIME,
DAMAGE TO PROPERTY AND THIRD-PARTY CLAIMS ARISING OUT OF ANY THEORY
OR RECOVERY, INCLUDING WARRANTY, CONTRACT, STATUTORY OR TORT.
NOTWITHSTANDING THE TERM OF ANY LIMITED WARRANTY OR ANY WARRANTY
IMPLIED BY LAW, OR IN THE EVENT THAT ANY LIMITED WARRANTY FAILS OF ITS
ESSENTIAL PURPOSE, IN NO EVENT WILL RESO LTD’S ENTIRE LIABILITY EXCEED
THE PURCHASE PRICE OF THIS PRODUCT. SOME STATES/PROVINCES DO DOT
ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL
DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE
OTHER RIGHTS.
QDOS is the trading brand of Reso Ltd, a UK company,
MountManorHouse
16,TheMount
Guildford
SurreyGU24HN
UnitedKingdom
www.qdossound.com
Table of contents
