Response CWD3 User manual

Digital Wireless Colour Camera
Recordable CCTV Kit CWD3
Installation and Operating Instructions
YOUR HELPLINE 0844 736 9149
www.friedland.co.uk
Lines open Monday to Friday 9.00am to 5.00pm. Calls charged at local rates.
These instructions should be retained in a safe place for future reference.

2
CONTENTS
1. INTRODUCTION—3
2. KIT CONTENTS—6
3. INSTALLATION—8
3.1 Contents and Connections 8
3.2 Powering up the system 9
3.3 Setting the Camera Channel (Optional) 10
3.4 Pairing the Camera to Receiver (Optional) 10
3.5 Camera Installation 11
4. MONITOR PANEL INTRODUCTION—12
5. SYSTEM INTRODUCTION—13
5.1 Icon Functions 13
5.2 System Menu 14
6. System Operation —16
6.1 Camera Setup 16
6.2 Recorder Setup 19
6.3 Event List 21
6.4 System Setup 23
6.5 Alarm Buzzer 26
6.6 Pan Tilt Zoom 27
6.7 Memory Card Overwrite 28
7.PC PLAYBACK SOFTWARE—29
7.1 Sec24 Media Player Introduction 29
7.2 Installation 30
7.3 Playback recorded le(s) 33
7.4 Channel Disable / Enable Select 35
8. System Conguration—36
9.Product Specication—37
10.Total Recording Time for Memory Cards (32GB max.)—37
11.Battery used in the 7" LCD monitor—37

3
1. INTRODUCTION
The Digital Wireless Colour Camera Recordable CCTV Kit is a wireless security system
designed to view and capture video clips of any motion viewed by the wireless camera
and store them in on a micro SD memory card. The wireless camera supplied is colour,
weatherproof and suitable for day/night use for the protection of your home or ofce, etc.
Please read before you start:
Always use discretion when installing CCTV survillance equipment especially
when there is perceived policy. Enquire regarding local regulations applicable
to the lawful installation of video recording/surveillance. Third party consent
may be required.
WIRELESS DEVICES OPERATING RANGE:
Ensure the signal reception viewed from the wireless camera is the best
possible reception (i.e. no interference lines viewed on the TV) between the
camera and receiver. If necessary reduce the distance between the camera
and receiver to improve overall system performance.
The Wireless Colour Camera Recordable CCTV Kit operating on a secure
digital 2.4GHz frequency can greatly reduce interference from products such
as wireless routers, cordless phones, microwave ovens, concrete walls, large
scale metal objects, and furniture.
YOUR HELPLINE 0844 736 9149
www.friedland.co.uk
If you have any problems installing this CCTV system please refer to the
Trouble Shooting sections on page 9 which should help solve any common
problems, or call the Customer Helpline, available Monday to Friday 9.00am
to 5.00pm.
Calls are charged at local rates. Network charges for mobiles may
vary depending on your network and call plan.

4
Camera 2
Camera 1
Front Door
cable hole
(to allow camera
cable and connector
to pass through)
Receiver
TV/Monitor
Ensure the distance from camera to power
outlet does not exceed the length of the
camera power adapter cable
PLANNING YOUR LAYOUT:
SAFETY AND INSTALLATION TIPS:
7" LCD DVR Receiver
• keep away from heat sources and high temperature places
• Avoid direct sunlight
• Avoid humid places
• Avoid vibration
• Install in a ventilated environment
• The supplied 2GB micro SD memory card can be replaced with up to a 32GB
capacity one if required.
• Do not use in wet conditions if operated on battery power
YOUR HELPLINE 0844 736 9149
www.friedland.co.uk
Lines open Monday to Friday 9.00am to 5.00pm. Calls charged at local rates.
NOTE:
The camera has an open eld RF operating range of up to 150m.
7" LCD DVR
20mm diameter

5
Camera(s) and DVR
NIGHT VISION:
Do not attempt to open the units with the power adaptor plug connected to avoid any risk
of personal injury.
When installing CCTV camera(s), always follow manufacturer's advice when using power
tools, steps, ladders, etc. and wear suitable protective equipment (e.g. safety goggles)
when drilling holes. Before drilling holes through walls check for hidden electricity cables
and water pipes. The use of cable/pipe detector is advisable.
It is also advisable to avoid exposing any cameras to extreme weather conditions (e.g,
under a gutter which is prone to any water leaks). When installing any cameras with this
unit, it is advisable to use cable conduit to protect any video/power extension cables
from being exposed externally and to prevent/reduce the chances of the cables being
tampered with. After drilling any hole though an external wall for a cable, ensure the hole
is sealed up around the cable using a sealant to prevent drafts.
To prevent a re or electrical shock hazard, do not attempt to open the housing while
the unit is exposed to rain, water or wet conditions. There are no user serviceable
parts inside. Refer servicing to qualified service personnel. Avoid pointing the
camera(s) directly at the sun or any bushes, tree branches or moving objects that might
unnecessary cause the DVR to record due to winds for example. The system also
provides "Masking" function, and the user may screen out motion detection area in parts
of the picture which motion detection is not required.
The camera has built-in infra-red LEDs to allow you to view at night for 24hrs
surveillance. The LEDs will automatically activate at night and the picture viewed will turn
to black and white. The night viewing range is up to 5-8m.

6
A
1 x 7" LCD Monitor (Receiver)
2 x Digital Wireless Cameras
B
C
3 x 5V/1A Power Adapter for Camera and Receiver
D
2 x Camera Stands
E
2 x Fixings Pack
F
1 x Video Playback PC Software(CD-ROM)
G
1 x AV Cable for TV Output
H
I
J
K
L
2 x Power Supply Adaptor Extension Cable for Cameras (1.8m)
2 x Camera Antennas
1 x 2 GB Micro SD Memory Card and adaptor
1 x Manual
1 x Window Sticker
2. KIT CONTENTS
YOUR HELPLINE
0844 736 9149
www.friedland.co.uk
Trouble Shooting page 9 or call the
Customer Helpline available Monday to
Friday 9.00 am to 5.00pm.
If any parts are missing contact your helpline 0844 7369149
Tools Required:
Memory card reader for a PC if using playback software (only if your PC has no built
in memory card reader) Safety Glasses Hammer Bradawl Electric drill
No. 2 Philips screwdriver 5mm masonry drill bit 20mm masonry drill bit

7
AB
Digital Wireless Camera
C
5V/1A Power Adapter for
Camera and Receiver
D
H
Camera Stand
Power Supply Extension
Cable for Cameras (1.8m)
Fixings Pack Video Playback PC
Software (CD-ROM)
Window Sticker
E
J
F
L
G
AV Cable
I
K
Camera Antenna
Manual
YOUR HELPLINE 0844 736 9149
www.friedland.co.uk
Lines open Monday to Friday 9.00am to 5.00pm. Calls charged at local rates.
Digital Wireless Receiver
Digital Wireless Colour Camera
Recordable CCTV Kit CWD3
Installation and Operating Instructions
YOUR HELPLINE 0844 736 9149
www.friedland.co.uk
Lines open Monday to Friday 9.00am to 5.00pm. Calls charged at local rates.
These instructions should be retained in a safe place for future reference.
CCTV
2GB Micro SD Memory
Card and Adaptor

8
3. INSTALLATION
3.1 Contents and Connections
NOTE:
"If the wireless camera is located within 1m to 1.5m from the wireless receiver and the
camera's volume on the receiver is turned on , then you may hear a whistling noise on
the monitor which if feedback picked up by the microphone. In this case please locate
the camera further away from the receiver to prevent this noise."
"If the power connection to the camera is kept outdoors, ensure the connection is
suitably protected."
TV / MONITOR
Receiver
Power Supply
Adaptor
WIRELESS CAMERA
Camera Power
Supply Adaptor
WIRELESS
RECEIVER
Turn power
on here
Video Signal
to RCA Input
Connect to
DC 5V/1A port
on Wireless
Receiver
to Wireless Cammera
WIRELESS CAMERA
Camera Power
Screw the Camera Bracket
Screw the Camera Antenna
clockwise on to the back of the Camera
clockwise on to the lower
body of the Camera
Screw the Camera Bracket
Screw the Camera Antenna
clockwise on to the back of
the Camera
clockwise on to the lower
body of the Camera
to Wireless Cammera
Connect to
3.5mm Phone
Jack on Wireless
Receiver
Wireless
Receiver
Connector Cable
(Optional for 7”
LCD DVR receiver)
Connect to Audio Input on TV
Yellow = Video
White = Audio
YOUR HELPLINE
0844 736 9149
www.friedland.co.uk
Trouble Shooting page 9 or call the Customer Helpline
available Monday to Friday 9.00 am to 5.00pm.

9
3.2 Powering up the system
Insert the memory card into the DVR if not already tted
Press and Hold power key for one second to power hold the power. Press and hold the power
key for two seconds to power off the system.
After system power on, adjust the camera viewing position again if necessary.
The 7" LCD monitor DVR is fitted with a rechargeable battery and
can operate for up to 4 hours (in power save mode) on battery power
once fully charged. The monitor can be carried around anywhere
within operating range of the cameras, but should be used in a dry
environment as it is not weatherproof.
ON/OFF
power button
Micro SD card slot
on 7" LCD DVR
Trouble Shooting
PROBLEM SOLUTION
No camera picture The power supply adaptor for the monitor
camera(s) is not plugged in.Camera out
of range. Locate camera closer to the
receiver.
Poor picture quality Clean the camera lens.
A white image
appears at night The camera's infra-red LEDs shine invisible light that reects of surfaces such
as glass causing white light. Place the
camera on the other side of windows to
try to improve the night vision or place in a
well lit area.
The system will
not record under
SCHEDULE/
MOTION detection setting
Ensure correct DATE AND TIME has
been set and the Record Schedule setup
correctly.
Ensure the memory card is inserted into
DVR and formatted.

10
3.3 Setting the Camera Channel (Optional)
3.4 Pairing the Camera to Receiver (Optional)
The wireless cameras will be supplied preset to channel 1 and channel 2.
The wireless monitor supports up to 4 wireless cameras. Follow the step below to set or
change the monitor channel of the camera. If you are adding another camera to link with the
supplied monitor in this kit, then ensure its channel is set to a different channel to the existing
camera(s).
Follow the steps in 6.1 Camera Setup (p.16) SETUP section to set or change the channel
of the camera. If you are adding another camera to link with the supplied receiver in this kit,
then ensure its channel is set to a different channel to the existing camera(s).
Pairing Key
YOUR HELPLINE
0844 736 9149
www.friedland.co.uk
Trouble Shooting page 9 or call the
Customer Helpline available Monday to
Friday 9.00 am to 5.00pm.

11
3.5 Camera Installation
Attach Stand to Mounting Surface
A.Secure camera stand on the wall
B. Loosen the thumb screw
C.Adjust the camera to the correct viewing position then secure the joint with
T-bolt.
C
B

12
4. MONITOR PANEL INTRODUCTION
1
2
3
4
5
6
7
8
9
10
11
12
Display Menu Playback REC Mode Other
1 Link indicator
2 Power indicator
3 Switch Channel Cursor UP Fast Forward
4 VOL Down Cursor Left VOL Down Switch
Display CH
5 Menu OK / ENTER PLAY / PAUSE
6 VOL Up Cursor Right VOL Up
Switch Display CH
7 Switch Channel Cursor Down Fast Backward
8 ESC EXIT Previous
9 REC/STOP Next STOP
10 ZOOM
11 ALARM
12 Power Button
YOUR HELPLINE
0844 736 9149
www.friedland.co.uk
Trouble Shooting page 9 or call the
Customer Helpline available Monday to
Friday 9.00 am to 5.00pm.

13
5. SYSTEM INTRODUCTION
5.1 Icon Functions
(Display Icon)
1. Signal Indicator
2. 1Channel Indicator
3. Recording Indicator
4. Audio Channel Indicator
5. Display mode
QUAD Display
Scan Display
1Single Display
6. Audio Volume (Seven volume levels)
= Full Volume
= 1/2 Volume
= Mute
7. Monitor Power Indicator
Power indicator will indicate 100% when adaptor in use or the battery is fully charged.
Power indicator will indicate much battery power power available for operation in
blocks.
Recharge will be required when Power indicator displays single block.
System will soon shut off when Power indicator displays zero block.
IIII = 100% Strength II = 50% Strength
III = 70% Strength I = 20% Strength
8. System Time
9. ZOOM Indicator
PTZ X 1 Indicator
PTZ X2 Indicator

14
5.2 System Menu
[Main Menu]
Press MENU to enter main menu.
After entering [MAIN MENU] system will highlight EVENT LIST by default. System will idle
in [MAIN MENU] for 2 minutes before exiting [MAIN MENU].
Use ▲▼◄► to select, Press MENU to conrm selection and to enter sub-menu.
CAMERA SETUP
RECORDER SETUP
Press MENU to CAMERA SETUP Sub Menu
Press MENU to RECORDER SETUP Sub Menu

15
EVENT LIST
SYSTEM SETUP
ALARM BUZZER
PAN TILT ZOOM
Press MENU to enter EVENT LIST
Press MENU to enter SYSTEM SETUP
Press MENU to turn ALARM BUZZER ON / OFF for when motion is detected
Press MENU to enter single camera PAN TILT ZOOM mode
YOUR HELPLINE
0844 736 9149
www.friedland.co.uk
Trouble Shooting page 9 or call the
Customer Helpline available Monday to
Friday 9.00 am to 5.00pm.

16
SCAN ACTIVATED CAMERAS
MEMORY CARD OVERWRITE
Press MENU to scan activated cameras in full screen mode.
Press MENU to set memory card overwrite ON or OFF.
6. System Operation
6.1 Camera Setup
Select CAMERA SETUP, press MENU key once to enter sub-menu.

17
Camera Pairing
With PAIRING section highlighted, press MENU key once to begin camera pairing (pair
LED on camera will blink once and following with LED blinking continuously indicating
data transmission in process.
System will conrm pairing process is successful with "PAIRED" displaying on screen.
System will indicate pairing process failed with "PAIRING FAIL" displaying on screen.
Press ESC to return to main menu.
Use▼▲to select the camera to set up (1-4).
Use◄►to select [PAIRING] [BRIGHTNESS] [CAMERA ON/OFF]

18
With BRIGHTNESS section highlighted, use ▼▲ to adjust camera brightness.
Press ESC to return to main menu.
With ACTIVATION section highlighted, use ▼▲ to enable or disable camera.
Press ESC to return to main menu.
NOTE:
Ensure the cameras are paired to the receiver for SCAN or QUAD to function
properly (camera "ON" can only be selected when camera has been paired to
system.).
Camera Brightness Adjustment
Camera Activation

19
Record Schedule
6.2 Recorder Setup
Use▲▼◄► to select and press MENU to enter schedule setup.There are three different
recording options available to chose from. First highlight the time period and press MENU key
to switch between different recording mode.
M: MOTION (REC only when motion detected)
S: SCHEDULE (record between selected times for each day)
C: MANUAL (manual REC)
The system will record video from all 4 channels simultaneously with MOTION, SCHEDULE
and MANUAL record modes. One of the four channels will have audio available.
The time slot boxes in the diagram above each represent hourly slots, e.g., selecting AM10:00
means recording will occur from 10:00am to 11:00am. Also if for example boxes AM10:00
and AM11:00 are set to "S" (Schedule) recording, please note that a continuous 2 hour video
le will not be recorded but separate les depending on the recording time for each le setup,
(p21), i.e., if set to 2 minutes then 60 clips will be recorded in a 2 hour schedule recording slot.
While the system is performing MOTION recording, audio will automatically switch to the
channel triggering by motion.
Recording cannot be stopped until 30 seconds after recording has started. This mandatory
system operation is designed to prolong the overall life of memory card. To stop recording,
press REC/DEL once. To remove the memory card, please power off the system rst.
If set to SCHEDULE recording mode, the system will automatically resume recording 60
seconds after recording is stopped manually. If set to MOTION record mode, the system will
resume motion detection function 60 seconds after recording is stopped manually.
Recording must be stopped before entering the system main menu and the system will
resume QUAD mode after idling for two minutes.
NOTE:
Recording will not work if no memory card is inserted into the monitor DVR.

20
Setup Masking Area
NOTE:
If a new memory card is used then it must be formatted rst here before use.
Select RECORDER SETUP, press MENU to enter.
Use ▲▼ to select MASKING AREA section
Use ◄► to highlight camera for setup, press MENU to enter
Use ◄► ▲▼ to highlight the grid for no motion detection in this area. Use MENU
key to mask/unmask grid(s). Movements taking place inside masked area will be
ignored.Use ◄►▲▼ to select another grid for setup or press ESC to save and exit
Motion Detection Sensitivity
Format Memory Card
Select RECORDER SETUP, press MENU to enter.
Use ▲▼ to select MOTION DETECTION SENSITIVITY section
Use ◄► to highlight camera for setup
Use ▲▼ to adjust sensitivity level: OFF / LV1 / LV2 / LV3 (LV3 is most sensitive)
Press ESC to save and exit
Select RECORDER SETUP, press MENU to enter
Use ▲▼ to select FORMAT STORAGE, press MENU to enter
Press MENU again to conrm and begin formatting memory card
Press ESC to exit
