Dear customer,
Congratulations on purchasing the new RETIGO VISION combi steamer. The Retigo Company appreciates
your decision and believes that you will always achieve great results turning your ideas into reality in your everyday
work by using this equipment. By using your new combi steamer you will attain the highest quality of prepared food
and your guests will like revisiting to your establishment.
Your new RETIGO VISION combi steamer combines long-term experience of the best chefs together with the
latest scientic and modern technologies. Due to its intuitive operation, preset program options and the unique
“Easy cooking” function, you will instantly achieve optimal cooking performance without needing to study the
technologies and procedures of food preparation.
It is also possible to create your own programs with an unlimited number of steps which you can store and sort
according to your routines and requirements. The well arranged menu offers the choice of your favorite recipes, as
well as your most frequently used cooking programs.
The advanced cooking system of the RETIGO VISION oven allows you to make changes to the cooking
program even after you have started the cooking process. The new “Learn and Remember function”allows you to
store the program so that you can use it again with all the changes you have made.
RETIGO s.r.o. believes that the new combi steamer RETIGO VISION will bring you maximum comfort during
everyday work and present new possibilities of food preparation. This is also supported by the warranty period,
stated in the service log and the certicate of warranty. Please insist that the company installing your new combi-
oven to validates your certicate of warranty. The warranty does not cover damage and faulty operation caused by
the incorrect operation, non-compliance with this operating manual, the use of aggressive chemical cleaning
agents or the improper cleaning of the device. The warranty also excludes damages resulting from incorrect
installation, which is not in accordance with the manufacturer’s instructions; technically faulty connections, as well
as faults caused by unauthorized personnel or an act of God.
In order for you to achieve great results with your new combi steamer RETIGO VISION right from the beginning,
we would like to provide you with the help of this manual with all the necessary information and useful advice for
trouble-free work. To be able to take full advantage of all the possibilities of your new combi steamer RETIGO
VISION we recommend that you carefully study the manual before using the combi steamer.
RETIGO s.r.o. wishes you lots of cooking pleasure in using your new combi steamer RETIGO VISION.

OPERATING MANUAL FOR RETIGO BLUE VISION COMBI STEAMERS
3
ver. EN04/06/12
CONTENT
1. Introduction 3
1.1 Safe use of the equipment 3
2. Safety notices 4
2.1 General notices 4
3. General Information 5
4. General description of the equipment 8
5. Equipment characteristics 9
6. Description of the control panel 10
6.1 Basic description of the control panel 10
6.2 Description of the control panel buttons 11
6.3 Icons on the touch screen 12
7. Manual mode 14
7.1 Basic use of Manual mode 14
7.2 Further setting options in the manual mode 17
7.3 Ending the cooking process 19
8. Recipes 20
8.1 Using the “Recipes” section 20
8.2 Further options in the “Recipes” section 24
8.3 Pictograms 30
8.4 Vision Chef Virtual Cookbook 33
9. Easy Cooking 34
9.1 Using Easy Cooking 34
10. Automatic cleaning 36
10.1 Automatic cleaning powder “RETIGO Active Cleaner” 36
10.2 Using the “Cleaning” programs 36
10.3 Cancelling the cleaning process prematurely 38
10.4 Manual Cleaning 38
10.5 Cooking chamber descaling 38
11. Extras 39
11.1 “Low temperature cooking” option (LTC) 39
11.2 “Overnight cooking” option (OC) 41
11.3 “Rack timing” option (RT) 41
11.4 “Cool down“ option 43
11.5 “Golden Touch” (GT) option 44
11.6 “HACCP” option 44
11.7 “USB” option 44
11.8 “Stand by” option 46
12. Settings 46
12.1 “User settings” option 46
12.2 “Info“ 49
12.3 “Service“ 50
13. Help 51
13.1 “Manual” option 51
13.2 “Hot-line chef”, “Hot-line service” and “Contact” options 51
14. VISION AGENT 52
15. Gas combi steamers 53
15.1 Gas burner ignition 53
15.2 SAFETY INSTRUCTIONS for gas combi steamer service 53
16. Maintenance 54
16.1 General instructions 54
16.2 Daily cleaning (maintenance) 54
16.3 Monthly cleaning (maintenance) 55
16.4 Quarterly cleaning (maintenance) 56
16.5 Annual maintenance 57
17. RETIGO Combi steamer lifetime 58
18. Error code table 59

OPERATING MANUAL FOR RETIGO BLUE VISION COMBI STEAMERS
4
ver. EN04/06/12
1. Introduction
1.1 Safe use of the equipment
Combi steamers RETIGO VISION have been
designed and produced to meet all applicable
international safety standards. Installation deviating
from the installation instructions, incorrect operation,
settings, servicing, as well as improper cleaning or any
modications made to the combi steamer, which are not
authorized by the manufacturer, may cause injury or
possibly death.
CAREFULLY READ the operating manual before
you begin using the equipment. Keep this manual in
a safe place for use by all users of the equipment and
for further reference in the future.
Make sure the electrical connection, water
connection as well as the waste water pipe connections
are correct and in accordance with the manufacturer’s
directions stated in chapter “Transport and Installation”
of the combi steamers technical documentation. Should
you have any doubts or questions regarding the
installation, operation or safety of the equipment, please
consult your supplier.
Do not remove any compact covers – danger of
electricity-related injuries.
Do not leave the equipment running without
supervision unless specically stated in the manual.
Do not continue running the device if have any
doubts about its trouble-free operation, or if it is
damaged in any way, turn it off immediately, disconnect
the electrical connection, stop the water supply and
consult your supplier.
Never let unauthorized personnel operate this
equipment or handle it, clean it or carry out other
activities in conict with its designed use. Such
unauthorized use may cause injuries or possible
depreciation of the equipment.
Always comply with the principles of working with
electric devices.
This symbol means that RETIGO s.r.o. is
entitled, according to statute 477/2001 Codex,
(94/62/ES) to use the trademark Green Point
(Zeleny bod), meaning that the price of the
equipment includes costs related to the disposal of
packaging materials.
Sell the metal parts to an organisation specializing in
metal processing; place the glass parts in waste
containers designated for glass. The heat insulation
and electrical components should be handed over to
a facility authorized to handle such waste.

OPERATING MANUAL FOR RETIGO BLUE VISION COMBI STEAMERS
5
ver. EN04/06/12
2. Safety notices
Study this operating manual carefully
Only qualied and trained personnel are allowed
to use this device
Provide regular training to operation personnel.
In this way you will prevent possible work-
related injuries and damage to the equipment.
The equipment is to be used only for food
preparation and in accordance with the manual.
Any alternative use is against its designation
and is considered dangerous.
Before use check the cooking cabinet of the
combi steamer. Left over food as well as
cleaning materials or other left over items are to
be removed and the cooking cabinet should be
thoroughly cleaned using the manual shower.
Never shower left over food into the drain –
remove it from the cooking cabinet.
Cleaning agents and decalcifying agents are to
be used only according to the description in this
manual and following the instructions on each of
the agents.
The buttons on the control panel are to be
pressed only using ngers. The use of sharp,
pointed or other objects causes the warranty to
become void.
Do not block the ventilation openings of the
combi steamer by placing items in front of them,
namely do not place GN containers on the
ovens, fabric or other objects.
Ensure a clear steam exhaust through the
ventilation openings above the combi-oven.
Make sure water doesn’t drip or spray onto the
combi-oven, do not place water-lled dishes on
the combi-oven.
Do not place sources of re on the equipment
or in its vicinity.
For safety reasons do not remove the compact
cover and do not attempt to reach inside the
equipment. The device does not include any
parts the user can adjust. Repairs not described
in this manual should be carried out by qualied
service technicians.
2.1 General notices
Do not install any heat sources (deep-fryers,
grills, burners, cooking plates …) in the vicinity
of the combi steamers.
The temperature of the exterior glass of the door
can exceed 60˚C.
Switch off the water and electricity supplies
when not using the combi-oven for an extended
period of time.
Leave the combi steamer door open when
nished working, e.g. overnight
Should the GN containers be lled with liquids
by more than two thirds – special attention
should be paid when handling and removing
them. Place such lled GN containers only to
the racks where you can see. Pay extra attention
when extracting any hot GN containers with
some content!
Attention! When working with the combi steamer
bear in mind that the GN containers, cooking
mats and trays may be hot – danger of burn
injuries!
Attention! When in operation the combi steamer
produces hot steam – danger of scalding!
Accident hazard!!! Be careful when using with
gastro containers in the combi steamer where
the upper tray is 160 cm and more above the
oor. Risk of injury by hot GN content.

OPERATING MANUAL FOR RETIGO BLUE VISION COMBI STEAMERS
6
ver. EN04/06/12
Handling GN containers
• If GN containers are more than two thirds full of
liquid – special attention should be paid when
handling them and when taking them out. Place
such lled GN containers only on to the racks
where you can see. Pay extra attention when
extracting any hot GN containers with some
content!
Loading trolley
(applies to types 2011, 1221, 2021)
• You must secure the trolley every time you drive
it into the combi steamer.
• When operating a loaded trolley you must
always use the position locks (GN closure) of
the GN containers.
• When moving GN containers lled with liquids –
sealing covers must be used. Otherwise there is
a risk of scalding.
• In the event that the oor is uneven , the loading
trolleys are not to be used to drive into the
combi-oven.
• Never leave the handle bar of the trolley inside
a closed combi steamer – this could damage the
door.
• Never pull out the trolley without using the
approprite handle bar – not using the handle bar
could lead to burns.
• When using banquet trolleys always make sure
the plates are tted to the stands correctly.
• Always use the automatic cleaning program to
clean the trolleys.
3. General Information
Switching the combi-steamer ON/OFF
The combi steamer is designed for continuous
connection to electric power. Connect or disconnect the
power by switching off the external main switch.
The switch is to be used for switching on and off
(when putting into operation, for maintenance and
installation and also during an emergency shut down
of the device.)
Boiler preheating
(for boiler combi steamers only)
After switching the combi steamer on, the boiler
automatically lls up with water and the water is then
heated. During this process, in modes “Steam” or “Hot
air” the start of the program will be delayed until the
water is hot. After that the combi steamer will continue
automatically.
Opening/closing the door
The combi steamer door is tted with a closing
mechanism enabling opening with both the right and left
hand. By moving the handle to the sides, the latch is
released and the door can be opened by pulling the
handle. For safety reasons, the heating and ventilation
fans are switched off upon opening the door to prevent
steam from escapting out of the cooking cabinet. Open
the door slightly at rst, then open it fully after a short
while in order to prevent scalding by hot steam. Close
the door by pressing on the door handle - shut the door
(if you have a model with a loading trolley, press the
door and move the handle clockwise by 90°).
If the door remains open and the equipment is
set to “START” a warning to close the door will
appear.

OPERATING MANUAL FOR RETIGO BLUE VISION COMBI STEAMERS
7
ver. EN04/06/12
• It is forbidden to use the combi steamer without
loading the trolley for normal operation and for
cleaning!
Temperature probe
The temperature probe is used to read the
temperature inside the food being prepared and also
for managing the cooking process during gentle
method of food processing.
• Use the temperature probe only on food.
• Never inject the probe into frozen foods – danger
of breaking!
• Avoid excessively exing the cord leading into
the probe.
• Do not pull the temperature probe out by pulling
on the cord.
• Place the probe so that it does not touch the
door glass.
• The temperature probe may be hot – use
protective gloves.
• Take out the temperature probe before you take
the food out and place it in the probe holder.
• When not using the temperature probe, place it
in the probe holder.
• Never leave the temperature probe outside the
cooking cabinet – danger or shutting it in the
door and damaging it!
Cooling the cooking cabinet
For fast cooling of the cooking cabinet use the
“Cooling” function in the “Extras” section
Never use the manual shower to cool the
cooking cabinet. When the temperature is
higher than 90˚C – there is a danger of damaging
the inner door glass!
Manual shower
Use the manual shower to rinse the inside of the
cooking cabinet, to cool the cooking cabinet to a lower
temperature and for further auxiliary processes
performed in combi steamers (basting…)
The manual shower is functional only when the
combi steamer door is open
Never spray water from the manual shower onto
the hot door glass – danger of glass breakage.
Always place the manual shower on to its holder
after use.
Cleaning of the combi steamer
It is necessary to clean the combi steamer on
a regular basis (see chapter “16. Maintenance”). When
cleaning the combi steamer it is necessary to follow the
following instructions:
• use only cleaning agents recommended by the
manufacturer of the combi steamer
• follow instructions written on the cleaning agents
• never apply cleaning agents on to hot stainless
steel surfaces – danger of disturbing the surface
and subsequent discoloration. The warranty
does not cover such damage!
• always rinse the inside of the cooking cabinet
with the manual shower after cleaning – this
removes the cleaning agents used.
• never use mechanical cleaning means to clean
the combi steamer (such as steel wool, scrapers,
knives)
• do not clean the combi steamer with high-
pressure water cleaners
• leave the door open after cleaning the cooking
cabinet
Always use protective aids and recommended
working attire (gloves, goggles, mask) when
cleaning the combi steamer! You are protecting
your health!
When the combi steamer is not cleaned often
enough – left over grease builds up on the
cooking cabinet walls – it can ignite at high
temperatures. Such damage is not covered by
the warranty!

OPERATING MANUAL FOR RETIGO BLUE VISION COMBI STEAMERS
8
ver. EN04/06/12
Repairing malfunctions
Malfunctions can be repaired only by an authorised
service, trained and certied by the manufacturer.
In the event that untrained entry or unauthorise
servicing occurs, the warrant becomes void!
Monitoring and maintenance
It is necessary to have the combi-steam oven and its
accessories inspected at least once a year by an
authorised service to ensure the trouble-free operation
of the equipment. (see chapter “16. Maintenance”).

OPERATING MANUAL FOR RETIGO BLUE VISION COMBI STEAMERS
9
ver. EN04/06/12
4. General description of the equipment
Combi steamer types 623, 611, 1011
Combi steamer types 1221, 2011, 2021
1. combi steamer door with double glass
2. door handle with an integrated latch
3. inner door glass
4. catch to secure the inner glass
5. condensate door drip tray catching
condensed water from the inner glass with
an automatic release.
6. adjustable feet
7. drain cover
8. air and dust lter
9. side cover
10. temperature probe
11. inner detachable wall in front of the
ventilation fan
12. combi steamer control panel
13. manual shower
14. ventilation shaft
15. controlled and safety valve for exhausting
surplus steam
16 racks for GN containers
17. interior light
18. loading trolley (combi steamers type
1221, 2011, 2021)
19. USB connector

OPERATING MANUAL FOR RETIGO BLUE VISION COMBI STEAMERS
10
ver. EN04/06/12
The product rating label of the combi steamer is
located on the upper right side. A copy of the rating
label is located inside the device, on the left side.
The plate contains the following information: the
manufacturer, technical data regarding the
equipment, i.e. type and model, construction number,
year of manufacture, important data regarding the
type of power supply, power input, weight and water
protection class. The label also includes CE and
ESC marks, conrming that the equipment complies
with all requirements of CSN, EN, IEC and
government ordinances.
Product rating label of combi steamer RPE0611IA
5. Equipment characteristics
RETIGO VISION is a universal device for the
preparation of meals. It enables the user to prepare a
complete menu. It is possible to carry out all kinds of
thermal processing of food in the RETIGO VISION
combi steamer, such as roasting, frying, grilling, stewing,
steaming, cooking at low temperatures, low-temperature
overnight roasting/baking. An advantages is that food
is processed with a low consumption of water and oil
and the transfer of smells between various meals is
prevented. Vitamins and minerals are preserved, while
considerable power, area and time savings are
achieved. Due to the ability to control humidity in the
cooking cabinet there are great savings in the weight of
the food processed.
It is also possible to use the combi steamer as
proong compartment, to preserve and dry fruits or
other technological processes. All such processes are
programmable and can be carried out without the need
for personnel. Use of the temperature probe is another
advantage, especially with foods sensitive to high
temperatures (roast beef).
If the equipment is used reasonably, you can save
considerable space and time, which would otherwise be
taken up by single-purpose cooking appliances.
Thermal processing of food takes place in the
cooking cabinet where hot air is circulated evenly by the
ventilation fan. Air can be humidied by the generation
of steam. Humidity is controlled automatically according
to set value and operation. During steam operation the
humidity is set to 100%, in combined operation it can be
adjusted.
All processes are automatically controlled by
a microcomputer that is integrated in the control sytem
of the combi steamer.
The cooking itself can take three different forms:
• Less experienced users can use EASY
COOKING which will recommend and set
suitable values according to the meal that is
being prepared. EASY COOKING uses
technology which has been developed by
a team of RETIGO expert chefs and includes all
kinds of food processing that can be performed
in the combi steamer.
• Another option is to use pre-set programs or
create custom programs. 1000 programs
(recipes) can be entered into the combi steamer
memory and each can contain up to 20 steps.
Each step can include different parameters and
