Revox Re:connect RS232 Splitter User manual

of
Dominating Entertainment.
Revox of Switzerland.
E 2.02
Re:connect
RS232 Splitter

RS232 Splitter Re:connect
1

RS232 Splitter Re:connect
2
Contents
RS232 Splitter
Connections
M37-2 Cabling
M37-4 Cabling
Server Setup
M208 Synchronsiation
Technical Data
Guarantee
Scope of Delivery
3
4-5
6
7
8-9
9
10
10
10

RS232 Splitter Re:connect
3
RS232 Splitter
The RS232 Splitter separates the
serial control of an M37 Music
Server (MK1 or MK2) into two
areas. In this way, with a large
Multiroom project and the 4 zone
server, it is possible to operate
two Multiroom systems at the
same time (zones 1-4 + zones 5-
8) independently of each other,
each with 2 zones (12 + 34 and
56 + 78). This has the
considerable advantage that only
one M37 Music Server has to be
maintained and there is no need
to synchronise two servers.
This advantage is achieved by
halving the independent M37
audio outputs in the
corresponding Multiroom systems
as now, in the case of an M37
with 4 audio outputs, the first
Multiroom system is supplied from
server outputs 1 and 2 and the
second Multiroom system, from
server outputs 3 and 4.
Of course, the separation of the
M37 audio outputs doesn't just
work with a 4 zone server but with
a 2 zone server as well.
The separation of the audio signal
results from the modified cabling
of the cinch cables.
There is an overview of the zone
separation on pages 8 and 9.
Note
The RS232 Splitter works
without a micro-processor and
therefore doesn't require a
software update.
Software pre-requirement for the
Server communication module:
M57+2 2.02 or higher

RS232 Splitter Re:connect
4
Connections
Connection:
Splitter with M37 RS232.
Socket: RS232 IN
Serial connection (1:1 plug -
socket) between splitter and the
M37 Music Server (MK1/2).
The cable length should not be
longer than 10 metres.
Connections
Connection:
Splitter with M37 USB socket
Socket: USB Power
5V power supply through the M37
USB interface (USB-A). The
required USB cable (USB A-B) is
supplied with the Splitter.
Connection to the M37-4 / M37-2 Music Server
Power supply through the M37 USB interface
Communication Module Server - No. 2: Zone 5-8
Communication Module Server - No. 1: Zone 1-4
Status- (on/off) and activity display (Out 1/2)

RS232 Splitter Re:connect
5
Connection:
Splitter with Server MR-
System Communication
Module c
Socket: RS232 OUT-1
Serial connection (1:1 plug-
socket) between splitter and the
Server Communication module
of the Multiroom System No. c
(Re:system M10/ M51).
The cable length should not be
longer than 10 metres.
Zones 1-4 are operated through
this communication module. The
audio signal is split by the audio
matrix in the Communication
module and is defined through
its Setup, depending on the
model version (M37-2 or M37-4).
See pages 8/9
Connection:
Splitter with Server MR-
System Communication
Module d
Socket: RS232 OUT-2
Serial connection (1:1 plug-
socket) between splitter and the
Server Communication module
of the Multiroom System No. d
(Re:system M10/ M51).
The cable length should not be
longer than 10 metres.
Zones 5-8 are operated through
this communication module. The
audio signal is split by the audio
matrix in the Communication
module and is defined through
its Setup, depending on the
model version (M37-2 or M37-4).
See pages 8/9

RS232 Splitter Re:connect
6
M37-2 Cabling
Splitter installation with M37 Music Server – 2 zones

RS232 Splitter Re:connect
7
M37-4 Cabling
Splitter installation with M37 Music Server – 4 zones

RS232 Splitter Re:connect
8
Server Setup
This part of the manual only
describes the Communication
module server setup settings in
combination with an RS232
splitter. Please refer to the
Re:source Communication
Module Server manual for the
setup configuration without
RS232 splitter.
Select the source Server from the
Source menu (M10/M51) and
press and hold the Setup key for
approx. 2 seconds. Then select
the Source softkey. Using the
Zone softkey, the Communication
module server is assigned the
zone that it has to supply.
Fig. 1 - Server setup for a 2-zone M37 server
Ö

RS232 Splitter Re:connect
9
Figures 1 + 2 (pages 8 + 9),
show the configuration of a 2 or
4 zone server with the setup
settings that are to be used. The
suffix SP in the setup stands for
splitter and may only be used if
an RS232 splitter is being used.
M208 Synchronisation
The M208 remote control is
synchronised in the same way
as with server operation without
a splitter. The M208 is
connected and synchronised
with the corresponding
Multiroom central unit (M10 /
M51) using the M208 Link box.
The server library for both
Multiroom systems is identical.
Fig. 2 - Server setup for a 4-zone M37 server

RS232 Splitter Re:connect
10
Technical data
Warranty
Warranty covers a period of 24
months from the purchasing
date.
Your dealer should be your first
contact if you need service. If he
can't give you the help you need,
send the RS232 Splitter, carriage
free and without any accessories
to your national Sales Office.
Please supply a complete
description of the fault together
with your address.
Scope of delivery
RS232 Splitter
USB cable (USB A ÆB)
Serial 1:1 cable / 2m
(plug-socket)
Operating manual
Dimensions: 140 x 27 x 65 mm (W x H x D)
Weight: 250 g
Max. cable length: 10 m (per serial cable)
Cable type: Serial 1:1 cable, Plug-Socket
E&OE.
