User Manual
BM1
Baby Monitor
The information in this manual is subject to change without notice.
Rexing All Rights Reserved
www.rexingusa.com
We hope you love your new products as much as we do. If you need assistance, or
have any suggestions to improve it, please contact us.
Our support team will respond you as soon as possible.
Always a surprise in Rexing.
•https://www.facebook.com/rexingusa/
•https://www.instagram.com/rexingdashcam/
•https://www.rexingusa.com/support/registration/
Overview
Thank you for choosing REXING!
Check us out here.
Facebook Instagram Site Product Support
(877) 740-8004
1
What’s in the box?
1 3
46
57
2
2
1. Baby Camera
2. Parents Unit
3. Parent unit power adapter
4. USB Cable
5. Baby camera power cable
6. User Manual
7. Safety Guide
User Manual
BM1
Baby Monitor
Theinformation in this manual is subject to change without notice.
RexingAll Rights Reserved
www.rexingusa.com
Safety Guide
www.rexingusa.com
安全ガイド
Safety Instructions
•Adult assembly is required. Keep small parts away from children when assembling.
•This product is not a toy. Do not allow children to play with it.
•This Baby Monitor is not a substitute for responsible adult supervision.
•Keep this User’s Guide for future reference.
•Do not place the Baby Unit or cords in the crib or within reach of the baby (the unit
and cords should be more than 3 feet away)
•Keep the cords out of reach of children.
•Do not cover the Baby Monitor with a towel or blanket.
•Never use extension cords with power adapters. Only use the power adapters
provided.
•Test this monitor and all its functions so that you are familiar with it prior to actual
use.
•Do not use the Baby Monitor near water.
•Do not place the Baby Monitor near a heat source.
•Only use the chargers and power adapters provided. Do not use other
chargers or power adapters as this may damage the device and battery pack.
•Do not touch the plug contacts with sharp or metal objects.
Warning
3
Strangulation Hazard: Children have STRANGLED in cords. Keep this cord out of
the reach of children (more than 3 feet away). Never use extension cords with AC
Adapters. Only use the AC Adapters provided.
The BM1 Baby Monitor is compliant with all relevant standards regarding
electromagnetic fields and is, when handled as described in the User's Guide, safe
to use. Therefore, always read the instructions in this User's Guide carefully before
using the device.
•Risk of explosion if battery is replaced by an unapproved battery type.
•Dispose of used batteries according to their instructions.
•The Unit should be set up and used so that parts of the user's body other than the
hands are maintained at a distance of approximately 8 inches (20 cm) or more.
CAUTION
4
The Parent Unit includes a built-in, lithium-ion rechargeable battery pack, which is
not a user-accessible item. If you think the battery needs replacing, please contact
the helpline. Do not try to replace it yourself.
Our parent unit has come with a screen protector which is to protect the monitor.
Please peel the screen protector off before using the unit.
Parents Unit Console Overview
1. Parents Unit Console Overview
Home Button
Left Key
Reset
Antenna
Power Button
Intercom Key
Bracket
Speaker
Micro USB Input (5V/2A)
Move the camera verticaly/Increase Brightness/Volume+/Up Key
Right Key
Move the camera horizontally/Reduced Brightness/Volume-/Down Key
Start/Stop video recording
Product Overiew
5
2. Parents Unit Status Bar Icon
Signal Level (5 Levels)
No Signal
Camera 1
Camera 2 Optional, Sold Separately
Camera Swtich
Lullaby Switch
Volume Level (Level 6)
Night Vision Mode
Cry Detection (High, Medium and Low, 3 Modes)
Baby Room Temperature Display
System Time
Battery Power
Intercom Mode
Recording Mode
75
6
3. Menu Options
Volume Level Setting
Feed Reminder Time Setting
(Can Set Five Alarms)
Lullaby Selection (8 Lullabies)
System Time Setting
Temperature Mode Setting
(Celsius / Fahrenheit)
Camera Settings
(Add/Delete/Switch)
VOX Sound Detection Settings
Display Brightness Setting
OFF 0:30 1:00
2:00 3:00 4:00
OFF
23 : 40 : 58
C F
OFF LOW MED HIGH
7
8
4. Baby Camera Overview
Antena
Temperature Sensor
Micro USB Input (5V/1A)
Power Indicator
Lens
Micro SD Card Slot
Pairing Button
MIC
IR Sensor
Getting Started
Connect the Micro USB cord of the power adapter to the camera and the other
end to a power outlet (110 220V AC Outlet).
Once the camera is plugged in, it will automatically turn on and the blue indicator
will be on.
• If the pairing is not successful, please refer to Pairing Instructions on page 11 to
repair the camera;
•If Pairing , you need to press the switch key to switch to view. If you
are pairing , press the switch key to display view. (Optional is
available to purchase separately.)
1. Power On Baby Camera
Plug in the USB power cable to turn on the camera.
Unplug the power cable to turn off the camera.
2. Turn On/Off Baby Camera
3. Parent Control Unit Switching On/Off
When the Baby Camera and the Parents Control Unit are turned on, live
footage from the camera is showed onto the display (If the display is not
normal, check the camera pairing connection).
4. Review Images
It takes 3-4 hours to fully charge the Parent Control Unit to use wirelessly. If the
device is connected through the USB cable to a power source then it will stay
powered.
Press and hold the power button for 3 seconds to switch on/off the parents
unit. Pull out the receiving antenna on the Parents Unit to establish a good
connection with the baby camera.
9
Once the baby camera and Parents Control Unit are both switched on, they will be
paired automatically. If not, follow the steps below:
Note:
The Parent Control Unit can only show the viewing of 1 camera at a time. You can
can connect up to 2 cameras to each Parent Control Unit ( Additional Camera
Sold Seperately)
Note:
The Recorded videos can only be viewed on a computer or seperate device.
Simply remove the SD card and use a Micro SD Card Adapter or use a card
reader. (Not included)
Format a new Micro SD Card by turning on the camera, press and hold the
Pairing button for 3 seconds. When the blue light flashes twice, the formatting
is completed and you can start recording videos.
5. Pairing
6. Formatting Micro SD Cards
•Enter Pairing mode by turning on the camera, double press the power button
until the blue light flashes quickly, release the button.
• On the Parent Control Unit, press the home button to get to the menu.
Press or to select which camera to pair and press to confirm.
• Once you choose which camera to pair, the red light in the upper left corner of the
display will flash, when successful the flashing will shop and the display will show
the video stream of the camera.
• If there is no connection for 10 seconds, the pairing mode will automatically end.
Redo the steps if not successful.
• To switch between or , press the button on the Parent Control Unit to
return to the main menu and press the button.
10
Baby Camera Operations
1. Installation
• Place the camera in a convenient position so that it can aim at the area you want
to monitor.
• Adjust the angle of the baby camera by turning the camera up, down, left or right
until a satisfactory image is obtained on the Parent Control Unit.
3. Night Vision Mode
The camera is equipped with 8 high-intensity infrared LED lights that capture
clear images in the dark. When the built-in optical sensor detects that the
ambient light is weak, the infrared LED will automatically light up, the screen of
the parents unit will show a black and white color, and the icon will be
displayed in the status bar at the top of the screen.
4. Recording Mode
• Insert a Micro SD card Via the button under the baby camera lens.
•The press and hold the button on the Parent Control Unit in order to start
recording. Press the button again in order to stop recording.
Speak to the camera, the speaker on the display should be able to hear the voice. If
not, you can press or to increase the volume (see the 4.3 volume
adjustment in the manual for details)
2. Intercom Mode
11
Parent Control Unit Operations
1. Camera Direction Adjustment
Press the or key to start the camera adjustment, adjust to the desired
position, then press key to confirm.
2. Intercom Mode
3. Volume Adjustment
To enter intercom mode, on the Parent Control Unit press the key and hold,
this will start the conversation. Releasing the key will enter hands free
intercom mode.
4. Display Brightness Adjustment
12
Press button, press in the display mode to pop up the brightness
adjustment progress bar, then press the or button to select the
appropriate screen brightness, wait for 3 seconds, the system will automatically
save the settings.
Press button, press in the display mode to increase or reduce
the camera's transmission volume. The volume has 6 levels, and you can select
the appropriate volume from the volume level of 1-6.
• Press button.
• Press the or button until is selected, and click to confirm.
• In the pop-up menu bar, press the button or button to select the
lullaby you want in the 8 lullabies, click to confirm. To play all the music in
a loop, select the icon and press the key to confirm. Press the key
to return to the previous step.
Note:
If an alarm time is selected, the parent unit will beep every 0.5 hours, 1 hour,
2 hours, 3 hours, 4 hours and the flashing flag of the feeding reminder will
be displayed on the control unit.
• Press button.
• Press the or button until is highlighted, and click to confirm.
• Press the button or button to select the alarm time for the feeding
reminder (0.5h, 1 h, 2h, 3h, 4h). To return to the previous step, press the key.
6. Lullaby
5. Feeding Reminder (Alarm Clock)
7. System Time Setting
• Press button.
• Press the or button until is selected, and click to confirm.
• Press the button or button in the pop-up menu to adjust the clock,
minute, second, AM/PM. Press the button when you complete the time
setting and go to the next step. Press the button to return to the
previous step.
13
Note:
If the temperature is above 86 F or below 68 F, the temperature reading will turn
red, and make a beeping alarm noise. The temperature icon will also flash if the
room temperature is abnormal.
VOX detection: Turn on the VOX mode by pressing the VOX key on the Parent
Control Unit, after 30 seconds, the screen will turn off.
When the volume of the baby cry or sound is louder than the set value, the
display will light up and alert you to the noise.
8. Temperature Display
•Press button.
•Press the or button until is selected, and click to confirm.
• In the pop-up menu bar, press the button or button to select or
as the temperature unit and press the key to confirm. To return to the
previous step, press the key. The screen status bar will display the
temperature, reading from the temperature sensor on the back of the camera.
9. Camera Display Selection
• Press button.
• Press the or button, to select camera 1, camera 2 or switch,
and press the button to confirm viewing.
• The display can be switched to view different lenses at the same time, you can
switched the lenses between and in mode.
• You also can press the button to quickly select , or switch mode to
watch.
CF
•Press button.
•Select modes to turn on VOX, or select to turn off VOX.
10. VOX Setting ( Voice Activated Alert / Baby Cry Alert )
14
Note:
•When the VOX is turned off, press the power button and the display screen
will turn off. You can hear the sound from the camera at all times. This mode is
suitable for when the baby is playing and the adult needs to leave for a while.
•When the VOX mode is turned on: when the ambient sound of the camera is
louder than the set value, the display screen will light up and the speaker will make
a sound alerting you to check in on the baby. This mode is best used at during
bedtime.
3. In the VOX off mode, short press the button, you can quickly enter the VOX
mode (The quick acess VOX mode will only turn off the display, but will retain the
camera’s music transmission)
15
Tip:
The microphone of the receiver and camera cannot be too close. That is the
reason why some users get confused when they operate the devices and always
get noise in the background. This phenomenon is an uncontrollable factor.
FAQ and Troubleshooting
Q: Why is the distance in the room not far enough?
A: a. Check if the receiving antenna of the parent unit terminal is turned on;
b. Due to different wall materials of different houses, the blocking of 2.4G signals
is different. When the signal is not good, simply adjust the positioning to fix.
Q: Why is the temperature not accurately showing on the screen?
A: a. There should be a difference in indoor air circulation.
b. If the temperature sensor is just placed in a new environment, there will be a
deviation time within two hours for the correct temperature to display.
Q: Why there is always some noise in the background?
A: It is impossible to eliminate all the noise. This kind of howling has always been
a problem in the audio field. Please keep your receiver and camera separate in
3.2 FT away or more.
16
Camera
Camera
Lens
Viewing
Angle
Display Battery
Capacity
Display Power
Dissipation
CAM Power
Dissipation
Operating
Temperature
Material
Display
Weight
Camera
Weight
Camera
Dimensions
1280x720P Display 4.5-lnch IPS
1/6 CMOS
2300 mAh
75 Degree
1.6W
1.5W
14°F ~149°F
PC+ABS
0.3 LB
0.5 LB
0.42x3.13x0.65
inch (HxD)
Display
Resolution
Transmission
Distance
Transmision
Method
Temperature
Alarm
Crying
Alarm
Lullabies
Feeding
Alarm
Night Vision
(Automatic)
Display
Dimensions
VGA 480x800
15 frames/sec
2.4GHz FHSS
300M (Open Space)
Support
Support
Support
Support
3.4 X 4.2 inch
Support (8 Lullabies)
Specifications
17
Warranty & Support
The Rexing BM1 Baby Monitor comes with a full 12-month warranty. If you register
your product on our official site (https://www.rexingusa.com/support/registration),
you can extend the warranty to 18 months.
Warranty
If you have any questions regarding your product, please do not hesitate to contact
answered within 12-24 hours.
Support
Rexing is firmly committed to always improving our products, services, and user
experience. If you have any thoughts on how we can do even better, we welcome
your constructive feedback and suggestions.
Your opinion matters
Thank you for choosing Rexing!
18
FCC ID: 2AYKP-ABM200
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Other manuals for BM1
1
Table of contents
Other Rexing Baby Monitor manuals
