RF-Lambda REMC27G32GD User manual

RF-LAMBDA
The power beyond expectations
RF-LAMBDA INC. www.rflambda.com
Sales: [email protected] Technical : s[email protected]
REMC27G32GD
71W Wide Band Solid State EMC-Benchtop Power Amplifier 27-31GHz
71W Solid State EMC Benchtop Power Amplifier
27GHz~31GHz
Features
•Automatic Calibration
•Built in Temperature Compensation
•Adjustable Attenuation:
31.5dB Range, 0.5dB Step Size
•Supply Voltage: 110V/220V AC
Typical Applications
•Aerospace and military applications
•Test and Measurement.
•Research and Development.
Parameter
Min.
Typ.
Max.
Units
Frequency Range
27 - 31
GHz
Gain
50
dB
Gain Variation Over Temperature
(-45 ~ +85)
-
dB
Input Return Loss
-
dB
Output Return Loss
-
dB
Saturated Output Power (Psat)
48.5
dBm
Output Third Order Intercept (IP3)
-
dBm
Isolation S12
-
dB
Input Max Power (No Damage)
Psat –Gain
dBm
Weight
35
lbs
Impedance
50
Ohms
Power Supply Connector
D-SUB COMBO 3POS
Input / Output Connectors
Input: 2.9mm female, Output: 2.92mm female or WR28
Material
Aluminum / Copper
Electrical Specifications, TA=25
℃

RF-LAMBDA
The power beyond expectations
RF-LAMBDA INC. www.rflambda.com
Sales: [email protected] Technical : s[email protected]
REMC27G32GD
71W Wide Band Solid State EMC-Benchtop Power Amplifier 27-31GHz
Absolute Maximum Ratings
Supply Voltage
110V 220v ac
RF Input Power (RFIN)
Pin_max = Psat - Gainsat
Psat –Gain
Storage Temperature (°C)
-50 to +125
Note: Maximum RF input power is set to assure safety of
amplifier. Input power may be increased at own risk to
achieve full power of amplifier. Please reference gain and
power curves
Note: The operating temperature for the unit is specified at the package base. It is the user’s responsibility to ensure the part is in an
environment capable of maintaining the temperature within the specified limits
Biasing Up Procedure
Step 1
Connect input and output with 50 Ohm
source/load. ( in band VSWR<1.9:1 or >10dB
return loss)
Step 2
Turn on AC power.
Step 3
Enable RF output
Power OFF Procedure
Step 1
Turn off RF output power
Step 2
Turn Off AC power
Step 3
Disconnect input and output
Parameter Standard Description
Operational Temperature
MIL-STD-39016
-45℃~+85℃
Storage Temperature -55℃~+125℃
Thermal Shock 1 Hour@ -45℃1 Hour @ +85℃(5 Cycles)
Random Vibration Acceleration Spectral Density 6 (m/s)
Total 92.6 RMS
Electrical & Temperature
Burn In Temperature +85℃for 72 Hours
Shock
1. Weight >20g, 50g half sine wave for 11ms, Speed variation 3.44m/s
2. Weight <=20g, 100g Half sine wave for 6ms, Speed variation
3.75m/s
3. Total 18 times (6 directions, 3 repetitions per direction).
Altitude Standard: 30,000 Ft (Epoxy Sealed Controlled Environment)
Optional: Hermetically Sealed (60,000 ft. 1.0 PSI min)
Hermetically Sealed
(Optional) MIL-STD-883 MIL-STD-883 (For Hermetically Sealed Units)
Environmental Specifications and Test Standards

RF-LAMBDA
The power beyond expectations
RF-LAMBDA INC. www.rflambda.com
Sales: [email protected] Technical : s[email protected]
REMC27G32GD
71W Wide Band Solid State EMC-Benchtop Power Amplifier 27-31GHz
Ensure that the amplifier input and output ports are safely terminated into a proper 50 ohm load before turning on the power.
Never operate the amplifier without a load. A proper 50 ohm load is defined as a load with impedance less than 1.9:1 or return
loss larger than 10dB relative to 50 Ohm within the specified operating band width.
Power Supply Requirements
Power supply must be able to provide adequate current for the amplifier. Power supply should be able to provide 1.5 times the
typical current or 1.2 times the maximum current (whichever is greater).
In most cases, RF - Lambda amplifiers will withstand severe mismatches without damage. However, operation with poor loads
is discouraged. If prolonged operation with poor or unknown loads is expected, an external device such as an isolator or
circulator should be used to protect the amplifier.
Ensure that the power is off when connecting or disconnecting the input or output of the amp.
Prevent overdriving the amplifier. Do not exceed the recommended input power level.
Adequate heat-sinking required for RF amplifier modules. Please inquire.
Amplifiers do not contain Thermal protection, Reverse DC polarity or Over voltage protection with the exception of afew
models. Please inquire.
Proper electrostatic discharge (ESD) precautions are recommended to avoid performance degradation or loss of functionality.
What is not covered with warranty?
Each RF - Lambda amplifier will go through power and temperature stress testing.
Since the die, ICs or MMICs are fragile, these are not covered by warranty. Any damage to these will NOT be free to repair.
Amplifier Use
Ordering Information
Part No. Description
REMC27G32GD 27GHz~31GHz
Power Amplifier

RF-LAMBDA
The power beyond expectations
RF-LAMBDA INC. www.rflambda.com
Sales: [email protected] Technical : s[email protected]
REMC27G32GD
71W Wide Band Solid State EMC-Benchtop Power Amplifier 27-31GHz
ALARM
POWER
RF INPUT
ON
RF OUTPUT
WR 28
ADJUST
PN:REMC27G34GB
Freq:27-34GHz THE LEADER OF RF BROADBAND SOLUTIONS
OFF
9
87
6
54
32
1
0.BACK-
SPACE
RESET
MENU
?
ENTER ??
?
436.8 [17.197]
447 [17.598]
57.2 [2.252] 3.5 [0.138]
7.5 [0.295]
506.94 [19.958]
14.5 [0.571]
448.8 [17.669]
133.2 [5.244]
147.2 [5.795]
482.6 [19.000]
22.17 [0.873]
133.2 [5.244]
491.44 [19.348]
436.8 [17.197]
109.2 [4.299]
412.8 [16.252]
Important Notice
Outline Drawing:
All Dimensions in mm [inches]
The information contained herein is believed to be reliable. RF-Lambda makes no warranties regarding the information contained herein.
RF-Lambda assumes no responsibility or liability whatsoever for any of the information contained herein. RF-Lambda assumes no responsibility
or liability whatsoever for the use of the information contained herein. The information contained herein is provided "AS IS, WHERE IS" and
with all faults, and the entire risk associated with such information is entirely with the user. All information contained herein is subject to
change without notice. Customers should obtain and verify the latest relevant information before placing orders for RF-Lambda products. The
information contained herein or any use of such information does not grant, explicitly or implicitly, to any party any patent rights, licenses, or
any other intellectual property rights, whether with regard to such information itself or anything described by such information.
RF-Lambda products are not warranted or authorized for use as critical components in medical, life-saving, or life sustaining applications, or
other applications where a failure would reasonably be expected to cause severe personal injury or death.

RF-LAMBDA
The power beyond expectations
RF-LAMBDA INC. www.rflambda.com
Sales: [email protected] Technical : s[email protected]
REMC27G32GD
71W Wide Band Solid State EMC-Benchtop Power Amplifier 27-31GHz
Power Indicator
Gain Adjustment Knob
ON/OFF switch
Instrument AC power supply switch
USER CONTROL, D-SUB Connector
low-voltage (3.3V) TTL control signals.
See page below for more information.
Front Panel
Rear Panel
RF Output
RF Input
Alarm Indicator
Keypad
Fuse Holder
USB Port (upon request)
LAN Port (upon request)
Main AC connector
GND connector
EMC Equipment User Manual

RF-LAMBDA
The power beyond expectations
RF-LAMBDA INC. www.rflambda.com
Sales: [email protected] Technical : s[email protected]
REMC27G32GD
71W Wide Band Solid State EMC-Benchtop Power Amplifier 27-31GHz
Self Calibration Screen
Instrument Protection Alarms
The front panel LCD screen will display the error code or error message when instrument self protection is
triggered. Front panel alarm indicator will light up.
To eliminate the error code, press “RESET” on front panel keypad to reboot the instrument and clear the alarms.
If error code can not be eliminated after reboot, please contact [e-mail]
Calibration is may be recommended
“[1] Calibrate” to execute instrument self calibration
process.
“[2] Reset” to reboot the instrument.
*Please turn OFF RF input power, and terminate the RF
output port while applying calibration function
Switching On Instrument
Please follow the instructions on the front panel LCD screen after switching on the power.
Press “1” on keypad to continue.
Front Panel LCD Screen Display

RF-LAMBDA
The power beyond expectations
RF-LAMBDA INC. www.rflambda.com
Sales: [email protected] Technical : s[email protected]
REMC27G32GD
71W Wide Band Solid State EMC-Benchtop Power Amplifier 27-31GHz
Instrument temperature
RF output attenuation (change with adjustment knob)
RF input signal center frequency
Instrument RF output power
Switches On or Off for instrument RF output port
Indicates instrument RF output status. It will display:
Output is Ready to Turn on or RF Output is ON
Press “Menu” on keypad to enter instrument functions
selection menu
Instrument Function Selection Page
Instrument Status Display Page
To enter this function selection page, press “Menu” on front
panel keypad while the instrument is showing the status page.
Press the corresponding number on front panel keypad to
select:
“[1] Calibrate”calibrates the instruments.
“[2] Frequency” enters RF input signal center frequency.
“[3] RF ON/OFF” switches the RF output port on or off.
“[4] Reset” Restarts the instrument (Turns RF output off)
“[5] Status” enters instrument status display page.
“[6] Product Info” displays product part number and serial
number
All action functions will ask for confirming execution when selected from function selection menu.
User can set a constant gain for the unit. Equipment will
automatically adjust the gain at certain frequency

RF-LAMBDA
The power beyond expectations
RF-LAMBDA INC. www.rflambda.com
Sales: [email protected] Technical : s[email protected]
REMC27G32GD
71W Wide Band Solid State EMC-Benchtop Power Amplifier 27-31GHz
Pin #
Name
Function
Initial State
Description
Applied
1
Reset
Control
Resets PA when logic LOW is applied and released
Yes
2
Driver Disable
Control
LOW
Appling logic HIGH disables driver of amplifiers
Yes
3
Drain Disable
Control
LOW
Applying logic HIGH disables drain of amplifiers
Yes
4
RF IN Over
Indicator
LOW
Pin will be latched to logic HIGH when input signal is
over limit
No
5
Temp Over
Indicator
LOW
Pin will be latched to logic HIGH when amplifier is
driven over temperature
Yes
6
Current Over
Indicator
LOW
Pin will be latched to logic HIGH when drain current
limit is reached
Yes
7
ID Imbalance
Indicator
LOW
Pin will be latched to logic HIGH when an imbalance
in the drain current of the combining branches occurs
Yes
8
PA input
power
Indicator
PA input power is represented by voltage
No
9
PA output
power
Indicator
PA output power is represented by voltage
No
10
PA output
reflection
power
Indicator
PA output reflection power is represented by voltage
No
11
VSWR
Indicator
LOW
Pin will be latched to logic HIGH when output
reflection is over limit
No
13
+5V
Power Supply
+5V
+5V DC is supplied for reference
Yes
14
GND
Ground
GND
Ground
Yes
15
GND
Ground
GND
Ground
Yes
User Control Connector on Rear Panel
HIGH/LOW voltages are standard TTL signals:
0.0V-0.8V = LOW
2V-5V = HIGH
