RFS DBUX6-W6074ADB User manual

N -20-1316-00MT
6/8GHz for 6ft
Installa on Instruc onti ti
RF Interface dual-band
/ 71
Feed DB 6/8 GHz
X1
OMT DB 6/8 GHz
X1
x1
Grease
x4
Hm6 x 25
x4
W6
x4
Feed Clamp
x4
A5
x4
M5 x 30
x4
W5
1
Diplexer 6-8 GHz
X2
Feed Assembly
x4
A5
x4
M5 x 30
x4
W5
O Ring
Ketp in place
5 .N m
GREASE
x8
M5 x 16
x8
W5
x8
A5
N -20-1316-00MT
6/8GHz for 6ft
Installa on Instruc onti ti
RF Interface dual-band
2 / 7
Beware, according to antenna orientation
the OMT & Diplexer have different position
Offset Right
Offset Left

3
2
3 / 7
x4
Hm6 x 25
x4
W6
x4
Feed Clamp
8 .N m
GREASE
N -20-1316-00MT
6/8GHz for 6ft
Installa on Instruc onti ti
RF Interface dual-band
Offset left configuration from there
4
O Ring
Ketp in place
4 / 7
5
Polarization Adjustment
Loosen off
Tune
Tighten
8 .N m
N -20-1316-00MT
6/8GHz for 6ft
Installa on Instruc onti ti
RF Interface dual-band
±5° ±5°
x8
M5 x 16
x8
W5
x8
A5
5 .N m
GREASE

5 / 7
N -20-1316-00MT
6/8GHz for 6ft
Installa on Instruc onti ti
RF Interface dual-band
x4
M4 x 10
x4
Hm5 x 10
x4
W4
x1
Plate cover 6 GHz
x1
Plate cover 8 GHz
Optional blanking plate installation for PDR70 & PBR84
7
6
V Polar
H Polar
6 GHz 8 GHz
6 GHz 8 GHz
6 / 7
N -20-1316-00MT
6/8GHz for 6ft
Installa on Instruc onti ti
RF Interface dual-band
Optional adapter for PDR84
x2
Adapter PDR84
x8
W4
x8
M4 x 12
x2
Joint R84
x4
M4 x 10
x4
Hm5 x 10
x4
W4
x1
Plate cover 6 GHz
x1
Plate cover 8 GHz
Optional blanking plate installation
8

x1
Plate cover 6 GHz
x1
Plate cover 8 GHz x4
M4 x 10
x4
Hm5 x 10
x4
W4
x1
Flat Joint 6 GHz
x1
Flat Jiont 8 GHz
7 / 7
N -20-1316-00MT
6/8GHz for 6ft
Installa on Instruc onti ti
RF Interface dual-band
Optional for UDR70 & UBR84
O Ring
Ketp in place
O Ring
Ketp in place
x1
Shim 6 GHz
x1
Shim 8 GHz
Optional blanking plate installation
9
