RFS SC2 Series User manual

Working
on Pylon
NMT-30-1001-00
1 / 6
According to the antenna's orientation (Left or Right)
Le"
Right
(top)
2
3
Installa on Instruc on! !
SC2/SCX2 MOUNT
M12 X 2
a
M 8012x1 X 2
M12 X 4
b
A 31 X 2
Clamp Cas!ng X 1
a
a
5 mm gap
b
b
M10x40
M10
X 3
X 3
W10 X 3
A10.5 X 3
X 1
W
W
W
1
Working at ground
Lock
L
L
Plas!c Washer
W
W
W
4
5
NMT-30-1001-00
2 / 6
Installa on Instruc on! !
SC2/SCX2 MOUNT
M8x130 X 1
M8
W8
X 2
X 1
L8.4 X 1
A8.4 X 2
M8x20 X 1
X 1
M8 25x X 1
M8 X 2
W10 X 2
A8 X 1
L8.4 X 2
Ø8 X 1
Plas!c Washer
8 180x X 1
M 01 X 2
A 0.51 X 2
Clamp Cas!ng X 1
W8 X 3
V-Bolt M10 X 1

10 Kg
5 mm gap
Coïncidence
7
20 Nm
1
8 Nm
50 Nm
2
8
Working at ground
6
Working
on Pylon
NMT-30-1001-00
3 / 6
Installa on Instruc on! !
SC2/SCX2 MOUNT
Opposite
Antenna
NMT-30-1001-00
4 / 6
Installa on Instruc on! !
SC2/SCX2 MOUNT
COARSE ALIGNMENT
Once the transmission with the opposite antenna is established by moving the antenna
by hand, the screws can be hand tight.
GAP
GAP
2x M12
3x M8
3x M10
Azimuth
Elevation
9

NMT-30-1001-00
5 / 6
Installa on Instruc on! !
SC2/SCX2 MOUNT
POWER LEVEL ALIGNMENT
10
2x M12
3x M8
3x M10
Tightened without blocking (< 0.1mm)
Fine Alignment Procedure
Elevation alignment
Azimuth alignment
+15°
-15°
+20°
-20°
!
0.5°
for W800
NMT-30-1001-00
6 / 6
Installa on Instruc on! !
SC2/SCX2 MOUNT
FINAL ANTENNA TIGHTENING
11
Tightening alternatively the 2 M12
screws until specified torque while
checking the Power Level
50 Nm
First step:
Tight the screw while checking
the Power Level.
Second step:
Tight alternatively the M10 screws
and until the specified torque
while checking the Power Level.
1
1
2
3
1
2
3
12
13
35 Nm
17 Nm
8 Nm
