RFS BD1500W Series User manual

100518834 – Rev. B
BD1500W Series Air Dryers
User’s Guide
Models covered:
BD1500W BD1500WLP BD1502W BD1502WLP

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 3 of 98 100518834 – Rev. B
1. Welcome & Congratulations
Congratulations on your purchase of a new RFS BD1500W Series Air Dryer! We here at
RFS are very proud of our products and we are committed to providing you with the best
value and service possible.
We are sure that you will be satisfied with your new air dryer and would like to thank you
for choosing RFS for your air dryer requirements. We also hope that you will continue to
choose us for your future air pressure and related product purchases.
For information about this and other RFS products, please visit us on the web at:
www.rfsworld.com
2. Introduction
PLEASE READ THIS USER’S GUIDE THOROUGHLY AND SAVE FOR
FUTURE REFERENCE.
This User’s Guide is provided for the benefit of our customers and contains information
and direction specific to the RFS BD1500W Series Air Dryers. Models covered include
BD1500W, BD1500WLP, BD1502W, and BD1502WLP. This guide covers topics
including safety, specifications, installation, registration, operation, testing, maintenance,
replacement parts, service, and troubleshooting issues. Observation and compliance with
this User’s Guide will ensure the maximum life and efficiency of your air dryer.
This User’s Guide should be read thoroughly prior to installing, operating, or servicing
the air dryer in order to become familiar with the recommended procedures. This will
minimize the possibility of personal injury or damage to the unit due to improper
operation or handling.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 4 of 98 100518834 – Rev. B
3. Table of Contents
1. Welcome & Congratulations .......................3
2. Introduction..................................................3
3. Table of Contents..........................................4
4. Safety & Warning Information...................6
5. Overview & Specifications...........................8
5.1 Product Description.................................8
5.2 Key Features............................................8
5.3 BD1500W Series Air Dryer Models........8
5.4 Technical Specifications..........................9
5.5 Dryer Function Overview......................10
6. Installing Your Dryer.................................11
6.1 Safety & Warning Information..............11
6.2 Before You Begin..................................12
6.3 Included Contents..................................13
6.4 Required Tools and Materials................13
6.5 Installation Steps....................................14
6.6 Installation Checklist.............................22
7. Registering Your Dryer..............................23
8. Operating Your Dryer ...............................24
8.1 Safety & Warning Information..............24
8.2 Front Panel Display ...............................25
8.3 Identifying Dryer Alarms ......................26
8.4 Adjusting & Resetting Dryer Set Points 29
8.5 Open Front Panel...................................40
8.6 Depressurizing the Dryer.......................41
8.7 Connecting to Common Alarm Terminals
.....................................................................41
8.8 Connecting to Power Fail Alarm
Terminals.....................................................42
8.9 Connecting via Web Browser................42
8.10 Using the Status Screen .......................43
8.11 Using the Configuration Screen...........46
8.12 Using the Event/Alarm Screen.............49
8.13 Using the Firmware Screen..................50
8.14 Connecting via SNMP.........................52
9. Testing Your Dryer ....................................53
9.1 Safety & Warning Information..............53
9.2 Measuring Compressor Amp Draw .......54
9.3 Measuring Compressor Voltage ............55
9.4 Measuring Incoming Voltage ................56
9.5 Measuring Voltages at Solid State Relay
.....................................................................57
9.6 Testing Consistent Heatless Dryer
Cycling.........................................................59
9.7 Testing Unloader Valve.........................61
9.8 Measuring Heatless Dryer Solenoid
Voltage.........................................................62
9.9 Testing Air Dryer Fan............................63
9.10 Testing Safety Relief Valve.................63
9.11 Testing Compressor ON/OFF Cycling 64
9.12 Testing High Compressor Last Run
Time Alarm..................................................65
9.13 Testing Humidity Alarm and System
Shutdown.....................................................66
9.14 Testing High Outlet Pressure Alarm....68
9.15 Testing Low Outlet Pressure Alarm.....69
9.16 Testing Air Fittings & Hoses for Leaks
.....................................................................71
10. Maintaining Your Dryer..........................72
10.1 Safety & Warning Information............73
10.2 Six Month Maintenance.......................75
10.3 8,000 Hour Maintenance......................76
11. Replacement Parts & Accessories ...........77
11.1 Dryer Parts...........................................77

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 5 of 98 100518834 – Rev. B
11.2 Dryer Parts cont...................................78
11.3 Dryer Parts Cont. (Circuit Board
Selection).....................................................79
11.4 Dryer Parts Cont. (Humidity Sensor
Selection).....................................................79
11.5 Heatless Dryer Assembly Parts............80
11.6 Accessories for Your Dryer.................81
11.7 Ordering Parts from RFS.....................81
12. Service & Repair.......................................82
12.1 Services Offered ..................................82
12.2 Initiating a Service Transaction...........82
13. Troubleshooting Your Dryer...................83
13.1 Before You Call Altec AIR .................83
13.2 Safety & Warning Information............83
13.3 Air Dryer Won’t Power ON.................84
13.4 Display Screen Not Functioning..........85
13.5 High Outlet Pressure Alarm.................85
13.6 Can’t Create a High-Pressure Alarm ...85
13.7 Low Outlet Pressure Alarm .................86
13.8 Can’t Create a Low-Pressure Alarm....86
13.9 High Humidity.....................................87
13.10 Can’t Create a High Humidity Alarm /
Shutdown.....................................................88
13.11 High Flow Rate Alarm.......................88
13.12 High Cabinet Temperature Alarm .....88
13.13 Inconsistent Heatless Dryer Cycling..89
13.14 Compressor Doesn’t Operate.............89
13.15 Compressor Won’t Build Pressure.....89
13.16 Compressor Excessive AMP Draw....90
13.17 High Compressor Last Run Time
Alarm...........................................................90
13.18 Can’t Create a High Compressor Last
Run Time Alarm..........................................91
13.19 Compressor Rapid ON/OFF Cycling.91
13.20 Contacting Altec AIR Technical
Support.........................................................92
14. Appendix ...................................................93
14.1 Wiring Diagram...................................93
14.2 Set Point Limits and Defaults ..............94
14.3 SNMP Parameters................................95
15. Limited Warranty Agreement.................96
Registration Reminder.................................96
16. Contacting RFS.........................................97
16.1 General / Sales.....................................97
16.2 Service .................................................97
16.3 Technical Support................................97
17. Notes...........................................................98

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 6 of 98 100518834 – Rev. B
4. Safety & Warning Information
This section contains general information about safety and warning points to consider and
adhere to during installation, operation, and maintenance of your air dryer. PLEASE
READ THIS SECTION BEFORE PERFORMING ANY OPERATION OR
PROCEDURE ON YOUR AIR DRYER.
Additional warnings specific to an operation or procedure will also be presented
throughout the following sections. These will include the symbol as well as a label of
“WARNING!”, “CAUTION!”, or “IMPORTANT!” Please be sure to pay close
attention for these warnings and read them as you encounter them.
WARNING!
For your safety, all the information in this User’s Guide must be
followed to minimize the risk of electrical shock and prevent
property damage or personal injury.
WARNING!
Extreme care should be exercised to avoid contact with live
electrical circuits. Many procedures performed during installation,
operation, testing, and maintenance of this air dryer require the
equipment to be running, creating a situation for potential electrical
shock. It is highly recommended that you remove all jewelry before
performing any procedures.
WARNING!
Internal surfaces may be hot. Use care when coming into contact
with internal components as there is a potential for some of these
components to become hot when in operation or standby.
WARNING!
High Noise. RFS air dryers are meant to be installed in an unattended
area.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 7 of 98 100518834 – Rev. B
CAUTION!
Depressurizing the air dryer may be necessary before performing
certain procedures. NEVER remove pressure sensing tubes from the
Control Board without depressurizing the air dryer first, or damage to
the Control Board will occur.
IMPORTANT!
Performing procedures not described in this User’s Guide or installing
components not supplied by RFS is NOT RECOMMENDED AND
MAY VOID THE WARRANTY.
IMPORTANT!
Performing routine maintenance as outlined in the Maintaining Your
Dryer section will ensure optimal performance over the lifecycle of
your air dryer.
CAUTION!
Incoming power to dryer must be:
15-amp service recommended
110 - 125 VAC, 50/60 Hz for BD1500W & BD1500WLP
models
208 - 230 VAC, 50/60 Hz, 1 Phase for BD1502W &
BD1502WLP models
CAUTION!
This Air Dryer does not contain an internal Surge Protection Device
(SPD). If an SPD is required, it must be supplied by the user.
IMPORTANT!
Installation of RFS air dryers are intended for network
telecommunication facilities (non-customer premises) only.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 8 of 98 100518834 – Rev. B
5. Overview & Specifications
5.1 Product Description
The BD1500W Series Air Dryers from RFS are designed to intake wet ambient air
and remove the moisture for delivery to applications requiring a constant, on-demand
source of dry, pressurized air. This process is fully automatic and will remain
consistent with minimal required periodic maintenance. These dryers are designed
specifically for indoor use. The BD1500W Series Air Dryers employ a fully digital
operating platform offering the most accurate readings of dryer variables, removable
access panel allowing easier access for adjustment and maintenance, and ultra-quiet
Compressor with an industry leading maintenance interval of 8,000 hours.
5.2 Key Features
LCD display of all operating parameters
Solid state microprocessor-based circuitry eliminates costly maintenance
Accurate humidity sensing within 0.1% RH
Quietest dryer on the market - less than 50 dBA
Oil-less Compressors with 8,000-hour maintenance interval
5.3 BD1500W Series Air Dryer Models
Model Description
BD15
00W
110 - 125 VAC, Standard Pressure 2 - 15 PSI (13.8 - 103.4 KPa)
BD15
00WLP
110 - 125 VAC, Low Pressure 0.30 - 7.50 PSI (2.1 - 51.7 KPa)
BD15
02W
208 - 230 VAC, Standard Pressure 2 - 15 PSI (13.8 - 103.4 KPa)
BD15
02WLP
208 - 230 VAC, Low Pressure 0.30 - 7.50 PSI (2.1 - 51.7 KPa)

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 9 of 98 100518834 – Rev. B
5.4 Technical Specifications
BD1500W
BD1500WLP BD1502W BD1502WLP
Output
Capacity * Normal: Up to 1200 SCFD (34 SCMD) continuous *
Maximum: 1500 SCFD (42.5 SCMD) emergency *
Power
Requirements
110 - 125 VAC,
50/60 Hz, 7.0 Amps
208 – 230 VAC, 1 Phase,
50/60 Hz, 3.5 Amps
Outlet
Pressure
Range
2 - 15 PSI
(13.8-103.4
KPa)
0.30 - 7.50 PSI
(2.1-52.7 KPa)
2 - 15 PSI
(13.8-103.4 KPa)
0.30 - 7.50 PSI
(2.1-52.7 KPa)
Outlet Air
Humidity Less than 2% RH
Compressor
Type Two-cylinder, 3/4 HP, oil-less type
Drying
Method Heatless Desiccant
Operating
Temperature
Range
40° to 85°F (optimal)
(4° to 29°C)
Noise Level 48 dBA at 10’ (3m)
Alarms Standard alarms – complete readings of all critical measurement points,
individual alarm indication display
Outlet
Connections 3/8” O.D. tube fitting
Dimensions 12” D x 17.25” W x 27” H
(30.48cm D x 43.8cm W x 68cm H)
Net Weight 80 lbs. (36.3 Kg)
* NOTE: The Flow measurement will display **** for flows over 1000 SCFD
(28.3 SCMD) for the & models.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 10 of 98 100518834 – Rev. B
5.5 Dryer Function Overview
Component Description
1
Compressor
Compresses drawn in ambient air.
2
Unloader Valve
Relieves excess C
ompressor head pressure.
3
Unloader Valve
Exhaust
Exhausts the air from the Unloader Valve
.
4
In
-
Line
Cooler
Cools compressed air
prior to drying function.
5
Heatless Dryer
Removes moisture from compressed air.
6 Capacity Control Valve Regulates System Pressure and prevents air from
bleeding back through the H
eatless
D
ryer.
7
Humidity Sensor
Measures the H
umidity of the
compressed air.
8
Air Tank
Stores dry compressed air.
9 Static Pressure Regulator Regulates the Static Pressure
(17 PSI (117.2 KPa) for W & WLP, 60 PSI (413.7
KPa) for WHP). Maintains constant pressure on the
F
low
B
lock for accurate
F
low measuring.
10
Flow Block
Measures the F
low
R
ate
of compressed air.
11
Outlet Pressure Regulator
Regulates the Outlet P
ressure.
12 Pressure Outlet Outputs the pressure set by the Outlet Pressure
Regulator.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 11 of 98 100518834 – Rev. B
6. Installing Your Dryer
6.1 Safety & Warning Information
WARNING!
Extreme care should be exercised to avoid contact with live
electrical circuits. Many procedures performed during installation,
operation, testing, and maintenance of this air dryer require the
equipment to be running, creating a situation for potential electrical
shock. It is highly recommended that you remove all jewelry before
performing any procedures.
WARNING!
Internal surfaces may be hot. Use care when coming into contact
with internal components as there is a potential for some of these
components to become hot when in operation or standby.
CAUTION!
Proper Installation & Maintenance as outlined in this User’s Guide is
extremely important to ensure the reliability and longevity of the
equipment as well as prevent damage or personal injury.
CAUTION!
Incoming power to dryer must be:
15-amp service recommended
110 - 125 VAC, 50/60 Hz for BD1500W & BD1500WLP
models
208 - 230 VAC, 50/60 Hz, 1 Phase for BD1502W &
BD1502WLP models

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 12 of 98 100518834 – Rev. B
6.2 Before You Begin
6.2.1 Carefully inspect the unit, including the shipping box as well as the air
dryer, for ANY DAMAGE CAUSED BY SHIPPING. If any shipping
damage is detected, it is important to file a claim with the shipping
company prior to continuing the installation procedures.
6.2.2 Read the entire Installing Your Dryer section to familiarize yourself with
the components and procedures before performing the air dryer installation.
6.2.3 Verify the installation location of the air dryer:
6.2.3.1 Well ventilated and free from abrasive dust or chemicals.
6.2.3.2 Ambient temperature is between 40° and 85°F (4.4° and 29.4°C)
(optimal).
NOTE: Higher temperatures will decrease component lifespan.
6.2.3.3 Meets the following power requirements:
15-amp service recommended
110 - 125 VAC, 50/60 Hz for BD1500W & BD1500WLP models
208 - 230 VAC, 50/60 Hz, 1 Phase for BD1502W & BD1502WLP models
6.2.4 Notify the alarm center of the installation and potential for alarms during
the process (as necessary).
IMPORTANT!
Performing procedures not described in this User’s Guide or installing
components not supplied by RFS is NOT RECOMMENDED AND
MAY VOID THE WARRANTY.
WARNING!
High Noise. RFS air dryers are meant to be installed in an unattended
area.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 13 of 98 100518834 – Rev. B
6.3 Included Contents
(1) BD1500W Series Air Dryer
(1) Installation Guide (not shown)
Package located inside the dryer:
(1) 120 VAC Power Cord (for BD1500W & BD1500WLP models)
(1) 220 VAC Power Cord (for BD1502W & BD1502WLP models)
(1) Precision Bleed Orifice Fitting
(1) User’s Guide (not shown)
6.4 Required Tools and Materials
9/16” wrench
Cup of soapy water
1-inch paint brush (recommended)
Box cutter

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 14 of 98 100518834 – Rev. B
6.5 Installation Steps
6.5.1 Using a box cutter remove
the Dryer from box and all
shipping materials.
NOTE: If ANY SHIPPING
DAMAGE is detected, file a
claim with the shipping
company prior to continuing
the installation procedures.
6.5.2 Open Front Panel locking
latches and remove the Front
Panel.
6.5.3 Check for loose parts,
hoses, or wiring.
NOTE: If ANY SHIPPING
DAMAGE is detected, file a
claim with the shipping
company prior to continuing
the installation procedures.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 15 of 98 100518834 – Rev. B
6.5.4 Remove the ship-loose
contents package.
6.5.5 Remove and discard the
packing foam blocks from
around the Compressor.
6.5.6 Remove the Plug from the
Outlet Port by pressing the
ferrule down then pulling the
plug upward.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 16 of 98 100518834 – Rev. B
6.5.7 Install the Plug into the
included Precision Bleed
Orifice Fitting and then into
the dryer Outlet Port.
6.5.8 Place the dryer at the
desired operating location:
Place the dryer on a leveled surface
For rack install use Universal Rack Mounting Kit P011674 (section
11.6 )
For wall install use Wall Mounting Kit P011773 (section 11.6 )
6.5.9 Verify that the dryer is powered OFF.
6.5.10 Plug AC Power Cord to
dryer.
6.5.11 Wire or plug the power
cord into:
110 - 125 VAC power
outlet for BD1500W
& BD1500WLP
models.
208 - 230 VAC, 1 phase, power outlet for BD1502W &
BD1502WLP models.
oLine – Black (Brown)
oNeutral – White (Blue)
oGround – Green (Green/Yellow)

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 17 of 98 100518834 – Rev. B
6.5.12 Power the dryer ON.
NOTE: The Compressor and
heatless dryer will start,
creating air flow through the
Outlet Port.
6.5.13 Set the System Pressure:
With Compressor running:
6.5.13.1 Pull the Capacity
Control Valve knob
out.
6.5.13.2 Turn the knob until
the reading on the
pressure gauge is:
80 PSI (551.6 KPa)
for W & WLP
NOTE: 90 PSI (620.5 KPa)
may be used on W & WLP
dryers in low flow applications
to maintain low humidity.
6.5.13.3 Push the knob in to
lock.
6.5.14 Let the dryer run until the Humidity drops below 2% (may take up to 15
minutes). Press the RESET Button if the dryer goes into SHUTDOWN
mode.
6.5.15 Power the dryer OFF.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 18 of 98 100518834 – Rev. B
6.5.16 Remove the Precision Bleed Orifice fitting from the Outlet Port by
pressing the ferrule down
then pulling the fitting
upward.
NOTE: Save this fitting for use in
low flow applications.
6.5.17 Connect the air supply
line to the Outlet Port.
NOTE: If the downstream system is pressurized prior to installation of
dryer, make reasonable attempts to install the dryer while minimizing system
depressurization. Complete depressurization may result in ambient moisture
being introduced into the system, which may require extended run time and
dryer cycling to reduce or eliminate. Ambient moisture in the downstream
system may result in high humidity alarms and shutdowns.
6.5.18 When connecting to a completely depressurized system, a high
compressor run time alarm may be triggered. This alarm will need to be
manually reset until the system is pressurized and humidity levels have
reached their defined levels.

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 19 of 98 100518834 – Rev. B
NOTE: For all dryers with minimal
FLOW:
Install the included Precision
Bleed Orifice fitting to
maintain a constant air flow.
6.5.19 Power the dryer ON.
6.5.20 Set the Static Pressure:
6.5.20.1 Pull Static Pressure
Regulator knob out.
6.5.20.2 Turn knob until the
reading on the pressure
gauge is:
17 PSI (117.2 PSI) for
W & WLP

Radio Frequency Systems BD1500W Series Air Dryers User’s Guide
Page 20 of 98 100518834 – Rev. B
6.5.20.3 Push knob in to lock.
6.5.21 Set the Outlet Pressure:
6.5.21.1 Pull the Outlet
Pressure Regulator knob
out (or loosen the
retaining nut – LP
Models).
6.5.21.2 Turn knob until
Outlet Pressure (OUTP) reading is at the desired setting.
6.5.21.3 Push knob in to lock (or tighten the retaining nut – LP Models).
6.5.22 Check for air leaks:
NOTE: This is a general procedure that can be applied to any fitting or hose
that has air pressure in it. DO NOT SOAP TEST THE HUMIDITY
SENSOR FITTING. DAMAGE TO THE SENSOR MAY OCCUR.
With Compressor NOT running:
6.5.22.1 Listen for any ‘hissing’ sounds which may indicate a fitting or hose
air leak.
With Compressor running:
6.5.22.2 Use a 1-inch paint
brush to dab soapy water
on the air fitting or hose
connection to be tested.
If air bubbles appear at the
connection, this indicates that
air is leaking from the
connection.
