RGBlink TAO 1tiny User manual
User Manual
TAO 1tiny
©Xiamen RGBlink Science & Technology Co., Ltd.
2
Overview
About TAO 1tiny
TAO 1tiny is the essential accessory for compact webcam and ePTZ camera users, enabling those
cameras to become HDMI native devices connectable almost anywhere.
This tiny inline convertor- measuring at just 9x5x3cm, provides HDMI connectivity for cameras and
similar USB-C UVC capture devices, supporting popular VESA standard resolutions up to 4K
Video transcoded to HDMI is uncompressed with full fidelity maintained for superior visual
performance.
Parts Info
01 Type C Power Port
02 USB 2.0 COM Port
03 USB Type C Input Port
04 HDMI 2.0 Output Port
Note:If the input UVC signal is 4K@30 and the HDMI OUT connecting to 4K monitor,the output resolution up to
4K@60.
©Xiamen RGBlink Science & Technology Co., Ltd.
3
Connecting TAO 1tiny
Installing TAO 1tiny
TAO 1tiny supports USB 3.0 (UVC compliance) to HDMI 2.0 output.It can work with USB camera and mini series.
1. How to Work With USB Camera
Please operate as shown in the following figure:
（1）Connecting Power Port with power supply.
（2）Connecting USB-C Input Port with USB Camera via USB-C cable.(TAO 1tiny can supply power to USB
camera:5V/1A)
（3）Connecting HDMI 2.0 Output Port with monitor via HDMI cable.
If necessary,you can plug in USB Receiver into USB 2.0 Port to control USB camera via remote control.
2. How to Work With mini Series
Please operate as shown in the following figure:
（1）Connecting Power Port of TAO 1tiny with power supply.
（2）Connecting mini-pro with USB-C Input Port via USB 3.0 to USB-C cable.
（3）Connecting HDMI 2.0 Output Port with monitor via HDMI cable.
©Xiamen RGBlink Science & Technology Co., Ltd.
4
Firmware Upgrade
TAO 1tiny can be upgraded via USB disk.The device will auto-upgrade after plugging USB disk(including the latest
upgrade firmware) to USB 2.0 port.The device will auto-restart after upgrade and you can find a file of upgrade
done in the USB disk.Besides,the HDMI monitor will show the message of “Upgrade Done” and upgrade version.
⚠Do not disconnect the device during firmware upgrade.
Content is subject to change without notice. Users can download latest Manual Book on www.rgblink.com
©Xiamen RGBlink Science & Technology Co., Ltd.
5
Warranty
All products are designed and tested to the highest quality standard and backed by 1 years parts and labor
warranty. Warranties are effective upon delivery date to customer and are non-transferable. RGBlink
warranties are only valid to the original purchase/owner. Warranty related repairs include parts and labor, but do
not include faults resulting from user negligence, special modification, lighting strikes, abuse(drop/crush),
and/or other unusual damages.Warranty is return to base.Return for repairs are accepted only where shipping
charges are prepaid.
Your complete satisfaction is our goal.
According to the after-sale service,please contact our team as soon as possible after the failure occurs to obtain
the corresponding after-sale service.
Headquarter: S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen, Fujian Province, P.R.C
●Tel: +86-592-5771197
●Fax: +86-592-5788216
●Customer Hotline: 4008-592-315
●Web:http://www.rgblink.com
●E-mail: support@rgblink.com
