1
TOLUCA FIRE TABLES
MODELS 42100167, 42100171, 42100189 & 42100190
OWNER’S MANUAL

TOLUCA FIRE TABLE OWNER’S MANUAL 3
CONTENTS
Toluca Fire Tables are manufactured under license by Eldorado Stone.
®
For repair and replacement parts, contact Eldorado Stone at 800-925-1491.
Burners comply with:
ANSI Z21.97/CSA 2.41-2014 Outdoor Decorative Gas Appliances
Tested by RADCO, an independent third party testing laboratory, and certified by ICC-ES®, an accredited certification body.
The burners in this fire bowl have been evaluated and certified for both Canadian and USA Markets (CSA Standards). The
following information regarding safe operation and maintenance of this appliance is a result of the tests performed by
RADCO and certified by ICC-ES.
SAFETY INSTRUCTIONS .......................................................................... 4
GAS REQUIREMENTS..................................................................................7
LIQUID PROPANE............................................................................................... 7
NATURAL GAS .................................................................................................... 7
SET-UP.............................................................................................................. 8
PLACE FIRE TABLE IN DESIRED LOCATION................................................8
CONNECT A GAS LINE .....................................................................................9
CONNECTION FOR LIQUID PROPANE ..........................................................9
CONNECTION FOR NATURAL GAS.............................................................. 10
PERFORM A LEAK TEST................................................................................. 10
PLACE DECORATIVE STONE IN FIRE TABLE ..............................................11
OPERATING THE FIRE TABLE .............................................................. 12
TROUBLESHOOTING................................................................................. 13
CLEANING, MAINTENANCE & STORAGE ........................................ 14
WARRANTY ................................................................................................... 15
TOLUCA FIRE TABLE
MODEL 42100167 (LP) & 42100171 (NG) ....................................... 16
DIMENSIONS ......................................................................................................16
PARTS LIST.........................................................................................................17
TOLUCA FIRE TABLE
MODEL 42100190 (LP) & 42100189 (NG)...................................... 18
DIMENSIONS ......................................................................................................18
PARTS LIST.........................................................................................................19

TOLUCA FIRE TABLE OWNER’S MANUAL 5
AVERTISSEMENTWARNING
Do not store or use gasoline, or other flammable
vapors and liquids, in the vicinity of this or any other
appliance.
An LP-cylinder not connected for use shall not be
stored in the vicinity of this or any other appliance.
Ne pas entreposer ne utiliser de l’essence ni d’autres
vapeurs ou liquides inflammables dans le voisinage
de l’appareil, ne de tout autre appareil. Une bouteille
de propane qui n’est pas raccordée en vue de son
utilisation, ne doit pas être entreposée dans le
voisinage de cet appareil ou de tout autre appareil.
AVERTISSEMENTDANGER
AVERTISSEMENTWARNING
If you smell gas:
• Shut o gas to the appliance.
• Extinguish any open flame.
• If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
S’il y a une odeur de gaz:
• Coupez l’admission de gaz de l’appareil.
• Éteindre toute flamme nue.
• Si l’odeur persiste, éloignez-vous de l’appareil
et appelez immédiatement le fournisseur de
gaz ou le service d’indcendie.
FOR OUTDOOR USE ONLY. POUR USAGE À L’EXTÉRIEUR SEULEMENT.
AVERTISSEMENTDANGER
MONOXYDE DE CARBONE
Cette appareil peut produire du monoxyde de
carbone, un gaz inodore.
L’utilisation de cet appareil dan des
espaces clos peut entrainer la mort.
Ne jamais utiliser cet appareil dans un
espace clos comme un véhicule
de camping, une tente, une automobile
ou une maison.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor. Using it in an enclosed
space can kill you.
Never use this appliance in an enclosed
space such as a camper, tent, car or
home.
AVERTISSEMENTWARNING
Improper installation, adjustment, alteration, service
or maintenance can cause injury or property
damage. Read all the installation, operating and
maintenance instructions thoroughly before
installing or servicing this equipment.
Une installation, un ajustement, une modification,
une réparation ou un entretien inapproprié peuvent
être la cause de blessure ou de dommages. Veulliez
lire attentivement les instructions d’installation,
d’utilisation et d’entretien avant d’installer ou de
réparer ce matériel.
WARNING
Failure to follow all instructions exactly may result in fire or explosion causing property damage, personal
injury or loss of life.
We recommend installation is completed by professionals that are locally licensed by the authority having
jurisdiction in gas piping. Follow all local codes.
We suggest that our products be serviced annually by a professional certified in the US by the National
Fireplace Institute (NFI) as NFI Gas Specialist.
The burner must be replaced prior to the appliance being put into operation if there is evidence of the burner
being damaged. A replacement burner should only be used from the original manufacturer.
Failure to position the parts in accordance with diagrams or failure to use only parts specially approved with
this appliance may result in property damage or personal injury.
Only use gas/fuel type specified for fire bowl. Verify correct gas/fuel type and pressure by checking label on
back side of burner assembly pan. Never use an alternative fuel to include bio-fuel, ethanol, lighter fluid or any
other fuel.
CAUTION
Do not remove the metal data plates attached to the underside of the fire table burner. These plates contain
important information.
Do not use charcoal or other solid fuel in gas burning appliances.
Do not use your fire table for cooking. Do not heat any unopened glass or metal container of food in the fire
table. Pressure may build up and cause the container to burst, possibly resulting in serious personal injury or
damage to the fire table.
Never use the fire table in windy conditions. If used in a consistently windy area a windbreak will be required.
Always adhere to the specified clearances listed in this manual.
Never allow clothing or other flammable materials come in contact with any hot surface until it has fully
cooled. Never wear loose fitting or hanging garments while using your fire table. Fabric may ignite and result
in personal injury.
When handling propane gas line and connectors, do not allow them to come in contact with any metal
surfaces. Do not drop propane connectors.
CALIFORNIA PROPOSITION 65 WARNING:
Chemicals known to the State of California to cause cancer, birth defects or other reproductive harm are
found in and/or created by the combustion of natural gas, propane, butane and other fuels. Always operate
this unit as described in the owner’s manual and in well ventilated areas.
SAFETY INSTRUCTIONS

TOLUCA FIRE TABLE OWNER’S MANUAL 7
In the event that a burner goes out, turn burner knobs to the full OFF position and let it air out. Do not
attempt to use the fire table until the gas has had time to dissipate.
Propane gas source to the fire table must be regulated. Do not operate if regulator has been removed.
Fire or explosion can occur.
GAS SAFETY
While the fire table is operating, the outside surface may reach high temperatures which may cause burns.
Never leave children unattended in the area where the fire table is being used. Close supervision of children
is necessary when any appliance is used near children. Never leave the fire table unattended when in use.
When using the fire table, do not touch the rock, fire screen, or immediate surroundings, as these areas
become extremely hot and could cause burns.
Do not reach over your fire table when hot or in use.
Do not store items of interest to children around or below the fire table.
Never allow children to sit or stand on any part of the fire table.
BURN HAZARD
SAFETY
Keep all electrical supply cords away from the heated areas of the fire table.
Clothing or any other flammable materials should not be hung from the appliance, or placed on or near
the appliance.
Installation and repair should be done by a qualified service person. The appliance should be inspected before
use and at least annually by a qualified service person. More frequent cleaning may be required as necessary.
It is imperative that the control compartment, burner and circulating air passageways of the appliance be
kept clean.
It is the installer’s responsibility to ensure a safe installation and to educate the end user as to proper operation
of the burner unit. Installer must leave the owner’s manual, metal plate with operating instructions, and valve
key with the end user.
Read this section before installation. It explains what you need to know about liquid propane and natural gas
prior to setting up your fire table.
LIQUID PROPANE
Your fire table is not provided with a propane tank.
You will need to provide one. Use the following
specifications for purchasing your propane tank.
SPECIFICATIONS
The 2 lb. propane gas supply cylinder is constructed
and marked in accordance with the specifications
for propane gas cylinders as required by the U.S.
Department of Transportation (DOT), Specifications
for LP-Gas Cylinders or the Standard for Cylinders,
Spheres and Tubes for Transportation of Dangerous
Goods and Commission, CAN/CSA B339, as
applicable.
Manifold Pressure: For plumbed-in liquid propane
installation, use a regulator.
Supply Pressure: Maximum line pressure for
plumbed-in propane is 14" W.C. psi (3.5 kPa).
Minimum line pressure for propane is 11" W.C.
Pressure Regulator: The unit must be used
with the supplied gas pressure regulator and hose
assembly. The regulator will control and maintain
a uniform gas pressure in the manifold. The burner
orifice has been sized for the gas pressure delivered
by the regulator. Replacement pressure regulator
and hose assemblies must be those specified in
this manual.
Cylinder Specification: Any propane gas
supply cylinder used with this fire table must be
approximately 12" in diameter and 18" high. The
maximum fuel capacity is 20 lbs. of propane,
or 5 gallons. Full cylinder weight should be
approximately 38 lbs. (43.7 lbs. nominal water
capacity.) Always use the cylinder dust cap on
the cylinder valve outlet during transport and
when the cylinder is not connected to the fire
table. The 20 lb. propane gas cylinder used must
include a collar to protect the cylinder valve.
Filler Valve: If you do not have an updated filler
valve on your existing propane tank, you will need
to purchase one at your local hardware store, as
you will not be allowed to refill the tank at any
filling station.
Transporting Gas Cylinder: Only one cylinder
should be transported at a time. Transport cylinder
in an upright and secure manner with control valve
turned o and the dust cap in place.
NATURAL GAS
Ensure that the service supplying the fire table is
fitted with a conveniently positioned shut o valve
with easy access. The shut-o valve MUST NOT be
inside the appliance!
REQUIREMENTS
Always check the rating plate to make sure the gas
supply you are hooking up to is the gas type the fire
table is manufactured for.
The installation of this appliance must conform
with local codes or, in the absence of local codes,
to the National Fuel Gas Code, ANSI Z223.1,
NFPA 54; National Fuel Gas Code; Natural Gas
and Propane Installation Code, CSA B149.1; or
Propane Storage and Handling Code, CSA B146.2,
as applicable. Natural gas connection must be
performed by a licensed contractor or local gas
company representative.
Ensure that the service supplying the fire table is
fitted with a conveniently positioned shut o valve
with easy access.
PRESSURE NATURALGAS LIQUIDPROPANE
MINIMUM WC "WC
NOMINAL WC "WC
MAXIMUM psi(WC) psi("WC)
PRESSURE TESTING
If this fire table is installed with a fixed fuel
piping system and equipped with an appliance
gas pressure regulator, the fire table and its
individual shut-o valve must be disconnected
from the gas supply piping system during any
pressure testing of the system at test pressures
in excess of ½ psi (3.5 kPa).
The fire table must be isolated from the gas
supply piping system by closing its individual
manual shut-o valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than ½ psi (3.5 kPa).
SAFETY INSTRUCTIONS CONTINUED GAS REQUIREMENTS

TOLUCA FIRE TABLE OWNER’S MANUAL 9
Set-up of your Toluca fire table consists of 4 easy steps:
 PlaceFireTableinDesiredLocation
 ConnectGasLine
 ConnectionforLiquidPropane
 ConnectionforNaturalGas
 PerformaLeakTest
 PlaceDecorativeStoneinFireTable
If you use natural gas, you are responsible for ensuring that a gas line is installed and safe for use. We
recommend that a licensed contractor install your fire table.
This appliance, when installed, must be electrically grounded in accordance with local codes or, in the
absence of local codes, with the National Electrical Code, ANSI/NFPA 70; or the Canadian Electrical Code,
CSA C22.1, if applicable.
TOLUCA FIRE TABLES ARE DESIGNED FOR
OUTDOOR USE ONLY.
Never locate this appliance in a building, garage
or other enclosed room, under a sealed overhead
structure, or in any enclosed area such as a shed or
breezeway. Keep clear of trees and shrubs.
Do not place fire table under or near windows or
vents that can be opened into your home.
Maintain sucient distance as to not overheat any
overhead combustible material such as a patio cover.
The area surrounding your fire table should be kept
clean and free from flammable liquids and other
combustible materials such as mops, rags or brooms,
as well as solvents, cleaning fluids, and gasoline.
Do not block the vents located near the base of your
fire table as gas may build up in case of leak and
cause serious damage.
Do not locate appliance where it can get excessively
wet. Do not use this appliance if any part has been
underwater. Immediately call a qualified service
technician to inspect the unit and to replace any
part of the control system and any gas control which
has been underwater.
Place your fire table on a flat and stable surface in
an outdoor location such as a patio deck. Maintain
the following clearances to combustible materials:
Sides & Back..........48 inches (122 cm)
measured from side
Top ...........................120 inches (305 cm)
measured from hearth
Adjustable Legs....½ inch (1.27 cm)
measured from bottom of
fire table to flooring surface
(for ventilation)
VENTILATION
Fresh air must be able to pass though installed vents
to safeguard against residual gas accumulation.
Failure to allow proper ventilation may cause fire or
explosion. Place the fire table on a solid platform
such as concrete to allow air flow through vents in
the bottom. The vents must never be allowed to be
obstructed. See the figure below.
PLACEMENT FOR NATURAL GAS
If you are planning to use natural gas, you may
choose to locate the fire table in a permanent
location in order to hide the gas line. If you bury the
gas line, you will need a gas riser about 10" above
the ground. You will also need to have a gas valve
located OUTSIDE the fire table in order to shut
o gas to the fire table. We strongly recommend
having a licensed contractor install your gas line.
PLACE FIRE TABLE IN DESIRED LOCATION
NEVER ALLOW VENTS
TO BE OBSTRUCTED
CONNECT A GAS LINE
LOCATION OF GAS INLET
THIS APPLIES TO BOTH LIQUID PROPANE
& NATURAL GAS INSTALLATION.
Your fire table will arrive with the burner and burner
plate set in the fire table as shown in Figure A. You
will need to lift it up to access the gas inlet.
The gas line between the burner and the gas valve
located on the side of the fire table has been
connected for your convenience. Figure B shows the
burner plate lifted up with the flex hose connected
to the burner.
Figure A
Figure B
CONNECTION FOR LIQUID PROPANE
Unless you have a permanent liquid propane gas
line installed, you will need to bring the black gas
line under the fire table through the ventilation.
See Figure C.
The flex line that runs from the gas valve to the
burner has been connected at the factory. You will
only need to connect the propane line from the gas
valve to the propane tank, as shown in Figure D.
Perform a leak test before replacing the burner
plate. (See page 10.)
Connect the black liquid propane hose to a gas
cylinder. Use a QCC-1 propane connector with a
regulator. (See page 7 for description.)
When you connect the regulator to the tank valve,
hand tighten the black QCC-1 nut clockwise. DO NOT
use a wrench to tighten.
Figure D
BLACK PROPANE LINE
WITH ½" ADAPTER
Figure C
SET-UP

TOLUCA FIRE TABLE OWNER’S MANUAL 11
CONNECTION FOR NATURAL GAS
The flex line that runs from the gas valve to the
burner has been connected at the factory. You
will only need to connect the natural gas line from
the gas valve to the gas source, as shown in the
Figure E.
Perform a leak test before you replace the burner
plate. (See below.)
Connect to the gas source.
Perform a leak test at least once a year whether the
gas supply cylinder has been disconnected or not.
In addition, whenever the gas cylinder is connected
to the regulator or whenever any part of the gas
system is disconnected or replaced, perform a
leak test.
As a safety precaution, remember to always leak
test your fire table outdoors in a well-ventilated area.
Never smoke or permit sources of ignition in the
area while doing a leak test. Do not use a flame, such
as a lighted match to test for leaks. Use a solution of
soapy water.
1. Prepare a leak testing solution of
soapy water by mixing in a spray
bottle one part liquid soap to one
part water.
2. Make sure all the control knobs are in
the OFF position.
3. Turn on the gas.
4. Apply the leak-testing solution
by spraying it on joints of the gas
delivery system. Blowing bubbles
in the soap solution indicates that a
leak is present.
5. Stop a leak by tightening the loose
joint or by replacing the faulty
part with a replacement part
recommended by the manufacturer.
Do not attempt to repair the
cylinder valve if it is damaged.
The cylinder must be replaced.
6. Turn the control knob back to the full
OFF position.
If you are unable to stop a leak:
7. Turn the control knob back to the full
OFF position.
8. Shut o the gas supply to the fire
table and release pressure in the
hose and manifold.
9. On propane systems, remove the
cylinder from the fire table.
10. Call an authorized gas appliance
service technician or an liquid
propane gas dealer.
Do not use the appliance until the leak is corrected.
PERFORM A LEAK TEST
NG FLEX LINE WITH
½" ADAPTER
After you have completed all plumbing installation,
you can fill the fire table with the decorative filler
material provided.
Type of filler placement, such as lava rock, decorative
stone or glass, is entirely your choice according to
your preferences, but it needs to be rated for use
with fire. It will not aect the operation of the fire
table in any way. You can place the filler material
on the burner, but no higher than 1" thick. Excessive
filler material may impede gas flow and cause gas
build-up and potentially cause an explosion.
PLACE DECORATIVE STONE IN FIRE TABLE
SET-UP CONTINUED

TOLUCA FIRE TABLE OWNER’S MANUAL 13
WARNING: DO NOT USE SOLID FUEL, SUCH
AS WOOD OR CHARCOAL, IN GAS FUELED
FIRE TABLES.
Upon completing the gas line connection, a small
amount of air will be in the lines. When the first
lighting the burner, it will take a few seconds for the
lines to purge themselves of this air.
Once the purging is complete, the burner will light
and operate as indicated in the instruction manual
Subsequent lighting of the appliance will not require
purging unless the gas supply has been disconnected.
Inspect the gas hose before each use of the fire
table. If the hose shows evidence of excessive
abrasion or wear or if the hose is damaged, it must
be replaced before using the fire table.
Inspect the burner before each use of the appliance.
If there is any evidence that the burner is damaged,
it must replaced before operating. Upon completing
the gas line connection, a small amount of air will be
in the lines. When first lighting the burner, it will take
a few minutes for the lines to purge themselves of
this air. Subsequent lighting of the appliance will not
require such purging.
Never allow the ON/OFF valve to remain in the open
position without placing a burning match on top of
the burner FIRST!
You must have clear and easy access to the ON/OFF
valve AFTER the appliance is installed and connected
to the gas supply in order to safely turn of the burner.
Make sure the burner is in place prior to using
the appliance. If the burner is damaged, install
a replacement burner as specified by the
manufacturer.
FOR YOUR SAFETY, READ BEFORE LIGHTING
• Before operating the fire table, smell
around the appliance area for gas
odors. Be sure to smell the surrounding
floor area as some gases are heavier
than air and will settle on the ground.
• Use only your hand to turn the manual
gas control valve. Never use tools. If
the valve will not turn by hand, do not
try to repair it. Call a qualified service
technician. Force or attempted repair
may result in a fire or explosion.
LIGHTING INSTRUCTIONS
1. Turn the ON/OFF valve located on
the side of fire table completely to
the ON position.
2. Make sure fuel supply (LP or NG) is
properly connected and turned on
at the source. This will be either the
LP tank or the NG valve.
3. When you hear gas flowing, use
either a long stem wooden match
or a butane fireplace lighter to
place a flame near the burner.
4. If the burner does not light, does
not stay lit, or the flame is very
low, shut o the gas supply and
wait five minutes to allow all fumes
to clear. Start again from Step
1, making sure all gas valves are
completely opened.
TURNING OFF GAS
For NG Units: Turn the ON/OFF valve to the OFF
position at the unit for natural gas unit, then close
the valve at the NG source.
For Propane Units: Turn the ON/OFF valve to the
OFF position at the unit and then close the valve on
the propane tank.
NOTE
The propane regulator in this appliance is equipped
with a low flow protection device. Unless the propane
cylinder valve is opened before the valve, the gas flow
will be reduced resulting in a very small flame.
To reset this device, shut o the valve, disconnect
the hose from the cylinder to relieve the pressure,
then close the propane cylinder valve.
PROBLEM POSSIBLE CAUSES REMEDY
Will not light
Air in gas line If new install, may take several
attempts to purge air
Debris in gas line
Confirm gas line is clear
(insulation, dirt, plastic,
excessive pipe sealer, etc.)
Improper gas pressure Confirm proper gas pressure
Will not stay lit
Improper gas pressure Confirm proper gas pressure
Improperly applied media Review media application
Noise
Note: The movement and
combustion of gas will
create low, unavoidable
levels of noise.
Passage of air/gas across
irregular surfaces
Remove any tight bends or
kinks in gas supply line
Excessive gas pressure on
natural gas units
Check or reset gas regulator
pressure
Unit is smoking/sooting
excessively
Note: It is natural and
unavoidable for appliance
sets to produce moderate
levels of carbon (soot)
where flames contact
the media
Poor fuel quality Contact local natural gas
company
Excessive flame impingement
or blockage
Separate the media to allow
more flame passage
Improper fuel and/or air
mixture
Remove any foreign items from
the flame pattern and check for
proper orifice sizing
Burner flame is too low or
too high
Incorrect gas supply or
pressure
Check for proper gas supply
pressure
Blocked burner orifice or
burner ports
Free burner orifice and burner
ports of any debris or blockage
Improper burner orifice size Verify proper burner orifice
sizing
Unit produces unwanted
odors
Gas leak, see Warning
Statement Check for and seal all gas leaks
OPERATING THE FIRE TABLE TROUBLESHOOTING

TOLUCA FIRE TABLE OWNER’S MANUAL 15
CLEANING
Inspect the appliance before initial use. Clean the
appliance at least annually and have it inspected by
a qualified field service person.
Periodically examine the burner. If the burner is dirty,
clean it with a soft wire brush. Also examine the
area around the burner air shutter. Remove any dirt
or debris in this area. This will ensure long life and
trouble-free operation.
The easiest way to clean the fire table burner is to
let it cool completely o and spray the enclosure
o with water. DO NOT spray water directly onto
the burner.
For routine cleaning of the fire table, wipe down
with a damp cloth or sponge. Avoid using any
cleaners as they may contain chemicals or color
that could cause discoloration. To remove stains,
use a Marble or Granite stain remover available at
any home improvement store.
When not in use and after cooling, cover your fire
table with a full length cover. The cover will help
protect your fire table from detrimental eects of
weather and environmental pollutants.
Before placing the cover on the fire table, make sure
the unit is shut o, the gas lines are disconnected
and that the unit has had sucient time to cool.
Install the cover and use the tie-down straps to
secure it tightly to the unit to prevent wind from
blowing it o.
More frequent cleaning may be required as
necessary. It is imperative the control compartment,
burner and circulation air passageways of the
appliance be kept clean and free.
MAINTENANCE
Periodically check the hose connecting the propane
gas cylinder to ensure it is not cracked or damaged in
any way. All natural gas hook-ups should be serviced
and inspected only by qualified installers only.
Spiders and insects can nest in the burners and
block the gas and airflow to the burner ports. This
creates a dangerous condition that can result in a
fire from behind the valve panel. Inspect and clean
the burners periodically.
Any guard or other protective device removed for
servicing must be replaced prior to operating the
appliance.
If it is evident there is excessive abrasion or wear
of any of the components, if the fuel supply hose
is cut or cracked, it must be replaced prior to the
appliance being put into operation.
Inspect the fuel supply connection for signs of
leakage (including the hose for propane models)
before each use of the appliance.
Do not repair or replace any part of your fire table.
Have a qualified technician perform all service. Any
repairs made by a non-approved service technician
will void your warranty.
STORAGE
When your fire table is not in use, turn o the gas at
the source.
This appliance can be store indoors only if it has
been disconnected from its fuel supply.
Store propane cylinders outdoors in a well-ventilated
area out of reach of children. Disconnected cylinders
must have threaded valve plugs tightly installed
and must not be stored in a building, garage, or any
other enclosed area.
To extend the life of your fire table, protect and
cover it from the elements when not in use. Ensure
the appliance has ample time to cool o after
use and prior to installing storage cover. Damage
caused to storage cover due to heat or burns are not
covered by warranty.
FIRE TABLE
The fire table is warranted to be free from defects in
material and workmanship for one year from the date
of purchase.
If a part proves to be defective under normal use, the
part will be repaired or replaced. Our obligation under
this warranty is to repair or replace defective parts at our
discretion. If we determine that repair of a covered item is
not feasible, we reserve the right to replace the defective
merchandise with merchandise equal in value to the
original purchase price. Warranty repair or replacement
are the sole discretion of Eldorado Stone and this warranty
does not cover costs therein, including but not limited to:
freight, removal, re-installation, etc.
There will be no charge for parts on a covered item,
however, cost of labor is the responsibility of the owner.
Shipping and handling charges will apply to all warranted
replacement parts. The service agent may assess a
reasonable travel or mileage charge per service call.
This limited warranty applies only to fire tables normally
used for personal, family, or household purposes and
specifically excludes rental or commercial applications.
This warranty is non-transferable.
Decorative stones and decorative glass are not covered by
this warranty.
This warranty is void if the fire table has been subject
to negligence, alteration, misuse, repairs, dings, dents,
scratches, or incorrect and/or prohibited applications as
specified in the owner’s manual.
Natural gas lines must be installed by a licensed plumber
only or local gas company agent.
The original purchaser acknowledges and agrees that
this product is a handmade, hand-finished product. Each
piece is unique. Any samples provided are typical of
texture, finish, individual characteristics, and color but they
should not be considered exact representations of the
final product. There can be up to a 15% variation in color
and texture from piece to piece. In addition, shape detail
can vary as much as ¼" in size. The texture created by
entrapped air ranges from smooth to randomly indented.
Minor chipping, water staining, and non-structural hairline
cracks are also traditional characteristics of this product.
As with natural stone, color will vary on individual orders
and among individual pieces in the same order. As
with natural stone, excessive heat exposure may cause
discoloration. As fire tables age, color may lighten or
darken according to specific field or storage conditions
such as humidity, temperature, and exposure to sunlight.
BRASS BURNER
Manufacturer warrants the burner to be free from
defective material and workmanship for 10 years from
the date of purchase. The burner warranty covers
manufacturing defects only and does not cover defects
due to normal wear and tear; it does not warrant any
product or part that has been altered, accidentally
damaged, damaged in shipping, disassembled, modified,
misused, neglected, failure to maintain, not installed, or not
kept in continuous service after installation. Manufacturer’s
liability shall be restricted to the purchase price of the
product only and makes no other warranty, express or
implied, but not limited to, the implied warranties of
salability and appropriateness for a specified purpose,
with respect to its products and parts, whether used
along or in combination with others. Manufacturer is
free of liability for any damages caused by the unit,
as well as inconvenience expenses, material or labor
charges incurred by any service call, repair, removal or
re-installation of any unit. Incidental or consequential
damages are not covered by this warranty. All burners
must be covered when not in use or warranty is null and
void. Warranty does not cover damage to systems due to
debris in the gas lines or damage to system due to water.
Owner is responsible for reading and understanding
warranty for full terms and conditions. Manufacturer, at its
discretion, agrees to repair or replace defective product if
returned to manufacturer within the warranty period. The
respective warranty time periods are eective from the
original date of purchase. The warranty is non-transferable
and applies only to the original purchaser. In addition, this
warranty is automatically void if the unit’s serial number
has been removed or altered in any way.
No dealer, distributor, or other person has the authority
to represent or warrant burner product beyond the
terms contained within this warranty, and manufacturer
assumes no liability for such warranty representations. Any
questions concerning this warranty should be directed to
the manufacturer’s corporate oce.
RETURN POLICY OF BURNER PRODUCT
Any burner product deemed by manufacturer as
defective and covered by the warranty may be returned
to manufacturer for assessment to determine if repair or
replacement is necessary. In order to return a product, you
must have a Return Merchandise Authorization number
(RMA#). Please contact a manufacturer representative
at the corporate oce to obtain an RMA#. All returned
merchandise must have the RMA# clearly printed on the
outside of the package. Return shipping costs are the
purchaser’s responsibility. Manufacturer is not responsible
for product damaged or lost in transit. It is recommended
that return items are shipped via a delivery service that
can be tracked and/or insured to confirm receipt.
CLEANING, MAINTENANCE & STORAGE WARRANTY

TOLUCA FIRE TABLE OWNER’S MANUAL 17
TOLUCA FIRE TABLE MODEL 42100167 (LP) & 42100171 (NG)
DIMENSIONS PARTS LIST
NG MODEL
LP MODEL
72"
20"
64"
64"
1½"
Leveling Bolt 1½"
72"
64"
4"
4"
15"
Burner
Support 2"
12"
4"
12"
52"
2"
2"
ITEMNO PART QT Y
 ¾Burner 
 BurnerPlate 
 Coupling 
 OrificeFitting 
 MaleFlaredFitting 
 FlexHose—Length 
 KeyValve 
— FireBowl 
— GasValveKey 
ITEMNO PART QT Y
— LavaRock 
— VinylCover 
LPMODELONLY
 ⅜PropaneHose—Length 
 btuLPRegulator 
 Quick-ConnectFitting 
NGMODELONLY
 btuNGRegulator 
 Street 

TOLUCA FIRE TABLE OWNER’S MANUAL 19
ITEMNO PART QT Y
 RectangularBurner 
 ¾SquareBurnerPlate 
 Coupling 
 OrificeFitting 
 MaleFlaredFitting 
 FlexHose—Length 
 KeyValve 
— SquareFireBowl 
— GasValveKey 
ITEMNO PART QT Y
— LavaRock 
— VinylCover 
LPMODELONLY
 ⅜PropaneHose—Length 
 btuLPRegulator 
 Quick-ConnectFitting 
NGMODELONLY
 btuNGRegulator 
 Street 
DIMENSIONS PARTS LIST
NG MODEL
LP MODEL
24"
24"
1½"
Leveling Bolt 1½"
24"
16"
4"
4"
16"
Burner
Support ¾"
16"4"
12"
24"
24"
24"
1½"
Leveling Bolt 1½"
24"
16"
4"
4"
16"
Burner
Support ¾"
16"4"
12"
24"
24"
24"
1½"
Leveling Bolt 1½"
24"
16"
4"
4"
16"
Burner
Support ¾"
16"4"
12"
24"
24"
24"
1½"
Leveling Bolt 1½"
24"
16"
4"
4"
16"
Burner
Support ¾"
16"4"
12"
24"
TOLUCA FIRE TABLE MODEL 42100190 (LP) & 42100189 (NG)

TOLUCA FIRE TABLE OWNER’S MANUAL 030617
© 2017 RH and RESTORATION HARDWARE, INC. All rights reserved.
Other company names mention herein are trademarks of their respective companies.
