Power Vent Kitsfor Gas Commercial Water Heaters
Manufactured by Tjernlund Products,* Rheem-Ruud
commercial gas water heater power vent kits are
your best choice for new construction, electric-to-gas
conversions and renovations.
Construction Features:
•Certified for use on natural and propane gas
models.
•Maximum venting length up to 50 feet equivalent
including the vent terminal.
•Vent terminal can be installed through combustible
or non-combustible surfaces – heat shield is
provided.
•Vent terminal is constructed from heavy-duty
corrosion resistant aluminum.
•Venter can be connected to a vent termination
on an exterior wall.
•Vibration isolators are supplied to provide quiet
operation.
•Safety interlocks standard.
•Complete with mounting hardware.
•Venter is pre-wired with 40 feet of #18-4 copper
wire (24 volt) to minimize field connections.
Certifications and Ratings :
• Power vent kits manufactured by Tjernlund Products,
Inc. are tested and certified by AGA for use on
Rheem-Ruud commercial gas heaters.
Continued on reverse.
Not for use with GN, GP or GX models.
Power Venter (from Tjernlund)
Vent Terminal
*
For technical assistance, please call the Tjernlund Help Line at
1-800-255-4208

Power Vent Kits continued.
Vent Kits
Kit # Part # Applicable Rheem-Ruud Water Heater Model
PV Kit 4 AP11646 G50-98, G75-125, G82-156, G76-180
PV Kit 5 AP11645
G37-200, G76-200, G91-200, G100-200(A), G72-250(A), G(D)100-250(A), G(D)100-270(A), G72-300(A),
G85-300(A), G(D)100-310(A), G65-360(A), GD100-360(A), G65-400(A), G85-400(A), G100-400(A)
Dimensions
Not for use with GN, GP or GX models.
Power Venter
(from Tjernlund)
Motor Motor Max Height Width Depth Inlet
Kit# Watts Amps Vent (H) (W) (D) Outlet
4 95 1.26 50 ft 7-7/8" 11" 7" 4"
5 170 1.51 50 ft 9-1/4" 11-5/8" 8-5/8" 6"
Note: Max Vent Length based on total length of straight vent pipe plus 10
feet for each 90 degree elbow and 5 feet for each 45 degree elbow.
H
DW
Vent Terminal
Rough in
Kit# AB CDimension
4 9" 9-1/2" 7" Sq. 8" Sq.
5 10-1/8" 9-1/2" 8-1/2" Dia. 9" Dia.
A Sq. C
B
Floor
Exterior
Wall
Draft
Vent Hood Vent Vent
Model Kit Outlet Size Adapter*
G50-98 PV Kit 4 5" 4" 5" x 4"
G75-125 PV Kit 4 5" 4" 5" x 4"
G82-156 PV Kit 4 6" 4" 6" x 4"
G76-180 PV Kit 4 6" 4" 6" x 4"
G37-200 PV Kit 5 6" 6" Not Required
G76-200 PV Kit 5 6" 6" Not Required
G91-200 PV Kit 5 6" 6" Not Required
G100-200(A) PV Kit 5 6" 6" Not Required
G72-250(A) PV Kit 5 6" 6" Not Required
G100-250(A) PV Kit 5 8" 6" 8" x 6"
G100-270(A) PV Kit 5 8" 6" 8" x 6"
G72-300(A) PV Kit 5 8" 6" 8" x 6"
G85-300(A) PV Kit 5 8" 6" 8" x 6"
G100-310(A) PV Kit 5 7" 6" 7" x 6"
G65-360(A) PV Kit 5 8" 6" 8" x 6"
G65-400(A) PV Kit 5 8" 6" 8" x 6"
G85-400(A) PV Kit 5 10" 6" 10" x 6"
G100-400(A) PV Kit 5 8" 6" 8" x 6"
GD100-250(A) PV Kit 5 6" 6" Not Required
GD100-270(A) PV Kit 5 6" 6" Not Required
GD100-310(A) PV Kit 5 6" 6" Not Required
GD100-360(A) PV Kit 5 6" 6" Not Required
*Note: Vent Pipe and Vent Adapter are NOT included.
Typical
Application
COMMERCIAL
WATER HEATERS
