Rhyas 24L 7.3cfm User manual

1
WARNING!!
BEFORE OPERATING
PLEASE READ
THESE INSTRUCTIONS
CAREFULLY.
User’s Manual
RHYAS 4L 7.3cfm Air Compressor

2
115 PSI
7.3 CFM
24 Litres
1.5 KW
2850 rpm
230 V
2HP 50Hz
97 d -A
62x36x64cm
24KG

3

4

5
Air outlets, quick release couplers
Uni Hi Flow
3
2
1
4
5
6
7
10
9
8

6

7

8

9

10

11
January 2011
A Wright
RHYAS, Unit A Southern A e, Leominster, HR6 0QF 01568 620062
PARTS LIST
N O . D ESCRIPTION Q TY N O . D ESCRIPTION Q TY
1 B OLT M6 X 40 4 33 MOTOR COVER 1
2 CYLINDER HEAD 1 34 BOLT M5 X 103 4
3 A IR FILTER 1 35 MOTOR COVER 1
4 CYLINDER HEAD GASKET 1 36 CIRCLIP 1
5 VALVE PLATE 1 37 CONNECTOR 1
6 VALVE PLATE GASKET 1 38 FAN COVER 1
7 VALVE CLACK 1 39 NUT M8 1
8 PIN 2 40 DENTATION WASHER Φ 8 1
9 CYLINDER 1 41 CAPACITANCE 1
10 HEX BOLT M8 X 25 2 42 NUT M8 4
11 CYLINDER GASKET 1 43 UNILATERALISM 1
12 PISTON RING 1 44 RELEASE PIPE 1
13 PISTON 1 45 BOLT M8 X 30 4
14 PISTON PIN 1 46 DISCHARGE PIPE 1
15 CIRCLIP 2 47 NUT M10 2
16 BOLT M5 X 16 4 48 SPRING Φ 8 2
17 CRANK CASE COVER 1 49 WASHER Φ 10 2
18 OIL LEVELER GASKET 1 50 HOLLOW COLUMN Φ 10 2
19 OIL LEVELER 1 51 WHEEL 2
20 BOLT M6 X 10 1 52 BLOT M10 2
21 O CIRCLIP Φ 5.6 XΦ 1.8 1 53 WASHER FOOT 1
22 RUBBER GASKET 1 54 TANK 1
23 CONNCTING ROD 1 55 STEM R P 1/2 2
24 HEX BOLT M8 X 22( LEFT ) 1 56 NUT R P 1/4 1
25 CRANK 1 57 POWR CORD 1
26 CRANK CASE 1 58 INTERMAL WIRE 1
27 SEALING RING 1 59 SAFETY VALVE 1
28 BREARING 6204 1 60 PRESSURE GAUGE 2
29 STATOR 1 61 REGULATOR GAUGE 2
30 ROTOR 1 62 QUICK COUPLERS 1
31 BREARING 6202 1 63 REGULATOR VALVE 1
32 WAVE WASHER D35 1 64 PRESSURE SWITCH 1

12
UK. Subject to change.
Document Ref: 24L 7.3cfm Air Compressor.
Product Code 53359
Copyright: These instructions are the sole property of Rhyas and may not be reproduced.
