Rhyno LED RL-WP20-01 Series Service manual

Rhyno LED Lighting Solution Inc. Version: 2013.V1
Your Imagination Is Your Only Limitation
Halifax Nova Scotia Tel: 902.425.LEDs (5337) Fax: [phone]
E-mail: [e-mail] Website: www.RhynoLED.ca
INSTALLATION INSTRUCTION MANUAL
LED WALLPACKS LIGHT, 100-277VAC
SERIES:
RL-WP20-01,02; RL-WP20-01,02;
Model number parameter list:
CAUTION: This product use an input 100-277VAC driver of wide range voltage, but the actual
working voltage is depend on the input voltage of the photocell that installed on the product.
Normally the input voltages of photocell are 120V/208V/240V/277V single range, and also have
120-277VAC wide range. Please pay attention when installation.
1. Introduction
 This LED Wall-Packs light uses the latest in solid state lighting technology for
long life, low maintenance, and high efficiency.
 The same as traditional HID lighting, it could be mounted a standard photocell on
the enclosure, to make it completely suitable for street lighting.
 An internal power-factor-corrected switch-mode supply allows it to be used from
any nominal 100V-277V, 60Hz AC supply without any variation in light output.
Suitable for use in the following locations:
• Ambient Temp: -20~+40°C
• Wet Locations
Note: Save these instructions for future reference.
Item
Model
Input
Voltage
Power
Factor
Watt
Input Current
Weight
A
RL-WP20-01,02
100-277VA
≥0.95
20W
0.3A
--Kg
B
RL-WP30-01,02
30W
0.38A
--Kg

Rhyno LED Lighting Solution Inc. Version: 2013.V1
2
2. Installation
For supply connections use wire rated for at least 80°C
Installation Steps:
Warning:
To avoid the risk of fire, explosion, or electric shock, this product should be installed,
inspected, and maintained by a qualified electrician only, in accordance with all applicable
electrical codes.
Warning:
To avoid electric shock:
•Be certain electrical power is OFF before and during installation and maintenance.
•Luminaire must be connected to a wiring system with an equipment-grounding conductor.
Warning:
To avoid explosion:
•Make sure the supply voltage is the same as the rated luminaire voltage.
•Do not install where the marked operating temperatures exceed the ignition temperature of
the hazardous atmosphere.
•Do not operate in ambient temperatures above those indicated on the luminaire nameplate.
•Keep lens tightly closed when in operation.
Step1: Turn on the
screws on both sides of
the lamp shade, then
take off the lamp shade.
Step2: Loosening the
two screws as shown
in the picture, take
off the driver box.
Step3: Using tools to
open the installation
position of Junctions
Box, then fix the lamp
on Junctions Box.

Rhyno LED Lighting Solution Inc. Version: 2013.V1
Your Imagination Is Your Only Limitation
Halifax Nova Scotia Tel: 902.425.LEDs (5337) Fax: [phone]
E-mail: [e-mail] Website: www.RhynoLED.ca Page 3 of 4
Step4: fix the lamp
on Junctions Box.。
Step5:
wiring,Line(Black)，Neutral(White),
GND(Green),see the below
connection diagram, connect the
connector between the power and the
led board.
Photocell安装位

Rhyno LED Lighting Solution Inc. Version: 2013.V1
4
After installation, please
1. check whether the lighting fixture is firmly fixed.
2. check whether wires are connected correctly.
At last, turn on the power, and check if the lighting fixture works well. If not, please turn
off the power and contact with local dealer.
Warning: the luminaire shall be installed by qualified electrician.
Step6: The driver box back
to its original position.
Step7: Install shade.
