Rich View M2 User manual
1
HiddenInstalledWiFiCarDVR
OperatingInstruction
2
CarDVRInstructionManualfor1080PHigh‐Definition
InadditiontothegeneralfunctionofthisDVR,itaddsmainlyfourfeatures:
(1) Quicklockthevideorecordingandunlockfunction.
(2) Parkingmonitoringfunction:Afterturnontheparkingmode,DVRwillopento
recording automatically according to around environment for itsown
judgementandalsocansavethefilesautomatically.
(3) Built‐inaccelerometercanrecordthegravitysensinginformationandestimate
anoffsetaccordingtocarupanddown,leftandright,frontandrear.Whenthe
offsetreachesacertainvaluethatthinkofdrivingisabnormalandlockcurrent
videoimmediately.
(4) WithWiFifunctioninside,userscanconnecttotheDVRviamobilephoneWiFi,
throughthephoneAPPtoachievetherelevantsettings,simultaneousshooting
video,filepreviewanddownloadandsoon.
Inordertoplaythemaximumperformanceandbettermeetoperational needs,
pleasereadcarefullyoftheinstructionmanualbeforeuseit(ifthereareany
changesforthedesignsandspecificationsofnativeandwithoutnotice).
3
Contents:
Product appearance and function indicators……………………………………………………4
Buttons function description……………………………………………………………………………5
Memory card preparation………………………………………………………………………………7
Adjust the position of the lens…………………………………………………………………………8
Open on and turn off local machine…………………………………………………………………8
Basic operations of DVR…………………………………………………………………………………8
Usage of WiFi…………………………………………………………………………………………………9
Setup menu…………………………………………………………………………………………………10
Read video……………………………………………………………………………………………………11
Product feature……………………………………………………………………………………………11
Technical specification…………………………………………………………………………………12
Product structure…………………………………………………………………………………………12
4
ProductAppearanceandFunctionIndicators
(1) Menu
(2) ModeKey
(3) PowerSwitch
(4) TheUpArrowKey
(5) DownKey
(6) Pulled‐BackInterface
(7) TFCardSlot
(8) Microphone
(9) BMWLineInterface
(10) USBInterface
(11) ResetHole
(12) RunningLight
5
ButtonsFunctionDescription
1. Menu:
Function1:Menufunction
Inthestandbymode,presstheMENUkeytoenterrecordingmenu,presstwiceto
entersetupmenu,andthenpressmenukeyagainunderthesetupmenumodeto
exittostandbyautomatically.
Inthecameramode,shortpressmenukeytoentercameramenuone time, or
doublepressintosetupmenu.
Inplaybackmode,shortpressmenukeyintofileoperationsmenuatonetime,and
doublepresstoentersetupmenu.
Function2:Manuallockfunction
Atnormallyrecording,shortpressthiskeythancanmanuallockcurrentfiles,and
thenshortpressagaincanbeunlocked.
2. ModeKey:
Function1:Inthecamerastage
Shortpressmodekeytoentercamerastageinthestandbymode.
Function2:Intheplaybackstage
Inthestandbymode,double‐pressintoplaybackstate,andthen press mode key
againtoreturnstandbymodeautomatically.
3. PowerSwitch:
Function1:Switchmachinefunction
Intheshutdownofthestate,byshortpresspowercabeintothe statement of
workinganddormant.Atthepower‐onstatement,throughlongtimepresspower
switchtomakenativesavevideofilesautomaticallyorturnoffbyitselfaftersetup
variousdatecompletely.
Function2:Turnson/offthevideorecordingfunction
Inthevideorecordingmode,shortpresstocontrolthevideostartandstop.
Function3:Picturefunctional
Inthepicturemode,shortpressthisbuttoncantakepictures.
Function4:Fileplaybackfunction
Inthereplaymode,shortpressthisbuttoncanplay/pausevideofiles.
Function5:Confirmfunction
Alloptionsaresetunderthevideomenu,setupmenu,picturemenu,replaymenu
shouldconfirmtosaveactions.
6
4. TheUpArrowKey:
Function1:Presstheupkeyinthemenutooperateupfunction.
Function2:Inthevideoandcamerastatusperformzoommagnificationfunction.
Function3:Whenreplaythevideo,quickrewindvideofile.
5. TheDownKey:
Function1:Pressthedownkeyinvariousmenufordownoperation.
Function2:Inthevideoandcamerastatushavenarrowthezoomfunction.
Function3:Fastspeedtoplayvideofilewhenthevideoisplayed.
Function4:Shortpressthisbuttoninthevideomodetoturnon / off recording
function.
Function5:Longpressinthevideomode,torealizetheswitchingbetweentheLCD
displayandTVdisplay.
6. Reset:
Whenthemachineisabnormal, press thisbuttonwithslender toolstoresetand
closethismachine.
7
StorageCard(TF)Preparation
TFcardrequirement:thisDVRcardcapacityrequiresaspeedofCLASS10orabove.
InstallationandpullouttheTFcard
1. InserttheTFcardintotheTFcardslotinthecorrectdirection,untiltheTFcard
isseatedinthecardslot.
2. RemovetheTFcard,pleasegentlypressdowntheTFcard,TFcardcanbe
removedafterthepop‐up.
Attention:
1. Attention: please don’t remove TF card when the machine was at work to
preventthedamage.
2. PleasenotethatthedirectionofinsertionofTFcard,ifreversed insert, may
damagethemachineandTFcardandcardslot.
3. WhenyouinserttheTFcardintothemachine,themachinewillsettheTFcard
asthedefaultstoragedevice,theoriginalTFcarddatamaynotberead,please
preparedatabackupinadvance.
4. IftheTFcardisincompatiblewiththemachine,usetheFormatoptioninthe
MemorymenutoformattheTFcardorretrytheTFcardandthentryagain.
5. Supportupto32G.
8
AdjustthePositionoftheLens
Thefrontofthecameracanberotatedtoobtainabettershootingangle.
Turnon/offLocalMachine
1. Manualturnon/offmachine:Shortpressthepowerbuttononce, the screen
lightsup,thenpressthepowerbuttontoachieveshutdown.
2. Theautomaticswitchmachineatdrivingstatus:access12Vcarpowersupplyat
first,thecarstartsafterthedelaywillstartthecameraandvideoautomatically.
WhenthecarstopstoclosetheKey,DVRcontinuevideotaping15secondsafter
outageandsavethefilesautomaticallyandthenshutdown.
BasicOperationsofDVR
DVRwithfunctionofvideo/photo/preview,canshortpressmodekeytoswitch.
DVRwillrecordautomaticallywhenthecarstarts.InthecaseofaTFcardwill
automatically start recording, short press the record key to control the video to
startandstop.
Inthestandbymode(whennotrecording),pressmodekeytoswitchmode.Inthe
photostatus,shortpressthevideokey,thenthescreenwillbebeatuntilthescreen
isstable,thepictureiscomplete.
Inthephotomodepressmodekeyonetimetoenterreplaymode,UPandDOWN
button to choose which file you want to play, OK button to confirm. During
playback,pressthemodekeytostoptherecordingandreturnto the playback
mode,thenpressthemodekeytoswitchthemode.
9
UsageoftheWiFi
ThisfunctioncanusephoneapptoachieveconnectionbetweenofDVRandphone.
Usestepsasfollow:
1. DownloadmobilephoneAPP,pleaseusebelow2Dcarcode
2. Connect the machine WiFi, general name is MR‐DVR, enter the default
password:12345678
3. ConnectAPP,openthephoneAPP,clicktheupperrightcornerof the add
setting,asshowinbelowFigure,Appleasanexample:
Afterfinishconnection,comeouttheframeasbelow
Atthistimethroughtheinterfacebuttontocontroltherecordingofthestop
Noconnect
10
andstart, recordingon and off and so on. It also can be resetWiFinameand
password.
SetupMenu
ThisDVRsupportmachinesetupandnavigationinterfacesetup(Optional).
Pressmenubuttonintomenusetup,upanddownbuttontochoose, OK is
confirmation.
Accessnavigation,touchthenavigationbuttontoenterthemachinesettings,at
thistime,The“MenuSettings”fieldisabluebackground.Touchup/downkey
to choose setting options; Touchup/downkeytochoosesetting options;
TouchtheOKbuttontoconfirmthesettingsandtouchBacktoexitthemenu.
SystemSetupOptions
Date/time:Date,time,dateformat
Carlicenseplatenumber
Autopower‐off:off3/5/10minutes
Screensaver;off1/3/5/10minutes
Thekeysound:on/off
Language setting: English /French /Spanish /Portuguese / German/Italian/
SimplifiedChinese/TraditionalChinese/Russian/Japanese
TVsystem:P/N
Lightsourcefrequency:50/60Hz
Parkingmonitoring:on/off
Font:systemfonts/personalizefonts
Displayscale:4:3/16:9
Formatting:MemoryCard,yes/no
Defaultsetting:yes/no
Version:displaysoftwareversionnumber
VideoModeMenuOptions
Resolution:FullHD1080P30fps;HD720P30fps;WVGAVGA
Recyclevideo:Off,1minute,3minutes,5minutes,10minutes
WDR:ON/OFF
Gravitysensing:Off,Low,Medium,High
Exposurecompensation:EV‐2.0,EV‐5/3, EV‐4/3, EV‐1.0, EV‐2/3, EV‐1/3, EV
11
+0.0,EV+1/3,EV+2/3,EV+1.0,EV+4/3,EV+5/3,EV+2.0
Motiondetection:on/off
Thevideoaudio:on/off
Datetag:on/off
Videointerval:off,100MS,200MS,300MS,500MS
Dualrecord:on/off
CameraModeMenuOptions
Shootingmode:singleshot,2secondstime,5secondstimer,10secondstimer
Resolution:12M,10M,8M,5M,3M,2MHD,VGA,1.3M
Burstmode:on/off
Imagequality:highquality,standardsandeconomy
Sharpness:strong,standard,soft
WhiteBalance:Auto,Daylight,Cloudy,Tungsten,Fluorescent
Color:Blackandwhite,tan
ISO:automatic,100,200,400
Exposurecompensation:EV‐2.0,EV‐5/3. EV‐4/3, EV‐1.0, EV‐2/3, EV‐1/3,
EV+0.0,EV+1/3,EV+2/3,EV+1.0,EV+4/3,EV+5/3,EV+2.0
Anti‐shake:on/off
QuickPreview:off,2seconds,5seconds
Datetag:off,date,date/time
PlaybackModeMenuOption
Delete:Deletesingle,deleteall
Protection:Protectcurrent,protectall,unlockcurrent,unlockall
Slideshow:setautomaticallybrowsethefileinsideofTFcard,canbesetto2
seconds,5seconds,8seconds
VideoReading
ThisDVRusesTFsavercardwhichyoucandirectlyremovetheTFcardifyou
wanttoreadthevideoorphotos,alsoreadTFcardfilesfromthecarreader.
ProductFeatures:
Prefect combination design of 1080P ultra‐wide‐angle vision lens, more
12
convenientforavarietyofoccasions,multi‐angleandhigh‐resolution video
capture.
Built‐inmicrophone/speaker
SupportforhighcapacityMicroTFcard
Vehiclestartsautomaticvideorecordingfunction
WithadelayedstartfunctionincasethatcurrentstrikedamagetheDVR
G‐SENSOR
TechnologySpecification
Lens 140DegreesUltraWideAngle
OptionLanguages English/French/Spanish/Portuguese/
German/ Italian/ Simplified Chinese/
TraditionalChinese/Russian/Japanese
VideoFormat H.264MOV
TFMemoryCardSlot MicroTF
Microphone/Speaker BuildIn
VehiclePowerSupplyDCInput 12V1.5A
Battery(Optional) On‐BoardBattery
SystemRequirements Windows
2000/XP/Vista/Windows7,MAC
OS*10.3.6above
ProductStructure
ImagingSensor SONY323
Display Local/SmartPhone/NavigationDisplay
Lens 6GGlassA+LevelofHighResolution
Multi‐LayerFilterWide‐AngleLens
VideoFormat H.264MOV
ImageFormat JPG
PowerInterface BMW Dedicated Line/ USB Dedicated
Line
CapacitySupport 32GBMax
BuildinSpeaker 8R1W
BuildinRecording Hi‐FidelitySpeaker
Attention:Specificationsandfeaturesaresubjecttochangewithoutnotice.
