Richelieu Atmos AT00LD User manual

MG
OL
12.5+OL
TPT
G
32 78-G
Space requirement (mm)
D(mm)
X(mm)
16
Y=FH x 0.29-15+D
19 22 26 28
70 58 49 35 26
Opening angle restrictors
Y=FH x 0.17-15+D
A=FH x 0.26+15-D
Without
o
100 (#AT00ANGLE100)
o
75 (#AT00ANGLE75)
Min200
(cabinet internal height)
Min240(cabinet internal depth)
Ø5(depth 5mm)
TPT: top panel thickness 4 pieces of #6 x 1-1/2" wood screw, flat head
Wooden Door: 4 x flat-head #6 x 5/8" wooden screws
Wide Alu Door: 4 x self-tapping screws (not provided)
OL: door overlay of side panel
G: gap
Cornice/crown moulding clearance
Minimum gap
MG: Minimum gap 2mm
Peg position and space requirement Fixing Position Door Assembly- wooden doors and
wide alu frames
Installation Dimensions(mm)
Installation Dimensions(mm)
Richelieu ai Lift System- Atmos Series
TPT max22
64 37
74
125
37
106
171
35.5
53
142
Included in Kit Pack
#6 x 1-1/2" #6 x 5/8"
Calculating power factor PF
PF=CH x (door weight+2 x handle weight in kg)
CH (200~500)
Model
#AT00LD
#AT00MD
#AT00HD
Power factor PF
580-1105
1105-1920
1920-3500
FH: front height
CH: cabinet height

Assembly
Door Assembly
Caution when opening arm The arm of this device could spring up
and cause injury.
Do not push the arm down without door
attached.
"+" increasing soft-closing time (turn adjustment screw counter-clockwise)
"-" reducing soft-closing time (turn adjustment screw clockwise)
Closing Speed Adjustment
Removal
Lift Mechanism Adjustment
Assembly
Door Position Adjustment
Main adjustment
Fine Tuning
Main adjustment
Fine Tuning
Assembly
Opening Angle Restrictor
100o (#AT00ANGLE100)75o (#AT00ANGLE75)
5o ~15o
