Richpeace RF-MJ135 User manual

Magic Ink-jet Plotter User’s Manual
富怡集团. 天津宝盈电脑机械有限公司
Richpeace Group Co., Limited
Tianjin Richpeace Computer & Machinery Co., LTD.
天津工厂地址：天津市宝坻经济开发区宝中道 6号（301800）
Factory Address: No.6 Baozhong Road, Baodi Economic Development Zone, Tianjin City China.
公司网址(Website): www.richpeace.com

1
Content
Make sure to operate safely and accurately ..................................................................................... I
Safe Notice I.................................................................................................................................... II
Safe Notice II..................................................................................................................................IV
Chapter1 Install Plotter....................................................................................................................... 1
1.1 Check accessory....................................................................................................................... 2
1.2 Technical parameter.................................................................................................................. 4
1.3 Structure and installation of new model plotter......................................................................... 5
1.3.1 Structure and parts functions......................................................................................... 5
1.3.2 Installation...................................................................................................................... 6
1.3.3 Install paper ................................................................................................................... 9
1.3.4 Paper cutting................................................................................................................ 13
1.4 Structure and installation......................................................................................................... 13
1.4.1 Structure and parts functions of common model......................................................... 14
1.4.2 Installation.................................................................................................................... 17
1.4.3 Install paper ................................................................................................................. 20
1.4.4 Install ink box............................................................................................................... 25
1.5 Structure and installation of MJ135 plotter.............................................................................. 26
1.5.1 Structure and parts functions....................................................................................... 26
1.5.2 Installation.................................................................................................................... 27
1.6 Connect to computer............................................................................................................... 28
Chapter2 Basic setting and operation............................................................................................ 30
2.1 Origin setting........................................................................................................................... 31
2.2 Plot test graph......................................................................................................................... 32
2.3 Delete file................................................................................................................................ 33
2.4 Sensor check .......................................................................................................................... 34
2.5 Keyboard check ...................................................................................................................... 35
2.6 Collection start and stop.......................................................................................................... 36
2.7 Print head cleaning times........................................................................................................ 37
The function used before the settings file printed,print head cleaning times,setting range”1`5” . 37
2.8Version Info.............................................................................................................................. 38
Chapter3 Plot..................................................................................................................................... 39
3.1 Plotcenter................................................................................................................................ 40
3.2 File........................................................................................................................................... 40
3.3 Tools........................................................................................................................................ 45
3.4 Language ................................................................................................................................ 47
3.5 Setup....................................................................................................................................... 48
3.6 Calibration............................................................................................................................... 54
3.7 Plot sequence ......................................................................................................................... 55
3.8 Print preview ........................................................................................................................... 55
3.9Operation after plotting............................................................................................................. 56
Chapter4 trouble shooting............................................................................................................... 57
4.1 Error indication........................................................................................................................ 58
4.2 Note......................................................................................................................................... 58

Make sure to operate safely and accurately
In order to operating the plotter safely and accurately, please read the manual carefully before using the
plotter.
In order to reading it quickly when you needed, please put it at the place where you can get it conveniently
after reading carefully.
Children are forbidden to touch the plotter.
Please follow the operation explanations strictly when you operate the plotter.
General Usage in the manual
In order to using the plotter safely and accurately and avoiding body injured and property damaged, the
manual prescribes three kinds of safe notice proceedings, please understand the difference.
DANGER
The notice means DANGER, if ignored, it maybe cause deadliness or serious damage to operator.
WARNING
The notice means WARNING, if ignored, it maybe cause deadliness or serious damage to
operator.
CAUTION
The notice means CAUTION, if ignored, it maybe cause damage to operator or weaken physical
capability of the plotter.
Explanation of Safety Symbols
It means caution or warning, the place where should be careful or warned will
be put the symbol or symbol with text indicate.
It means action should be prohibited, the place where should be prohibited
will be put the symbol or symbol with text indicate.
It means the action must be carried out. The action that should be carried out
will be put this symbol or symbol with text indicate.

II
Forbidden
Grounding
Forbidden
Disassemble
Forbidden
Water avoided
Take Care
lectrical Attack
Safe Notice I
WARNING
If the smoke happens from the plotter that due to too much hot and strange smell, or other reasons cause
the machine can‟t work normally, please stop using it. Turn off the power, and pull out the power cable from
the electrical outlet.
Continuing to use the plotter under these situations might cause fire or electrical
attack.
Make sure the plotter is not smoking any longer, please contact the
salesman or Richpeace authorized agent for maintaining.
Please don‟t maintain the plotter yourself; it is very danger to maintain by unfamiliar
person.
It is forbidden to disassemble, maintain or refit the plotter.
These actions might cause electrical attack or fire by creepage.
Touch the high voltage accessory of the plotter might cause electrical
attack.
If it need to be maintained, please contact the salesman or
Richpeace authorized local agent.
Don‟t use the machine in the place where has water,
rain and snow.
These places might cause electrical attack or
fire by creepage.
Make sure the plotter is grounding.
If it hasn‟t ground wire, the operator might get electrical attack by
creepage.
Don‟t connect the machine with non-stable power.
Use different power might cause electrical attack or fire
by creepage.
Don‟t use the broken electrical wire.
Use the broken electrical wire might cause electrical attack or fire by creepage.
Change it to a new electrical wire.

III
Forbidden
Take Care
Electrical Attack
Keep Distance
Don’t touch
Don‟t let the dust and the metal material adhibit to the
power plug.
The dirty power plug might cause electrical attack or fire
by creepage.
Please don‟t touch the print head and the moving parts when plotting.
These actions might cause body injured.
When the plotter stops working, please keep your hand and hair far away from the print head and the
moving parts, because the plotter that had received data might move suddenly.
These actions might cause body injured.

IV
Forbidden
Forbidden
Take Care
Electrical Attack
Forbidden
Water avoid
Take Care
Electrical Attack
Pull out the power
cable from the
electrical outlet.
Safe Notice II
TAKE CARE
Don‟t use or hold the machine under sunshine, or the places where have air-condition and heater blowing
directly.
These places might weaken the capability of the plotter.
Don‟t use the plotter at the place where is dusty or damp especially.
Using the plotter in these places might weaken the capability of the
machine.
Don‟t use the plotter at the places that have mechanical shake or
electrical noise.
Using the plotter in these places might weaken the capability of the
plotter.
Don‟t put the container fill with water
or other liquid on the plotter.
Inflooding liquid on the plotter might cause the electrical attack
or fire by creepage.
If there are water or eyewinker in the machine, please stop using it. Turn off power and pull out the power
cable from the electrical outlet.
Using the plotter under these situations might cause electrical attack or
fire by creepage.
Contact the salesman or Richpeace authorized agent to maintain it.

V
Forbidden
Forbidden
Forbidden
Don’t touch
Don‟t pull it forcibly when you need to pull out the power wire or Cable.
These actions might damage electrical wire and cause fire or electrical
attack.
Don‟t try to append lube for the plotter.
These actions might cause mechanical malfunction.
Don‟t use the thinner or gas to clear machine.
These actions might weaken the capability of the plotter.
Make sure there is enough space for working, or else it might cause plotting error.
If touch the machine, it might cause plotting error.
Use indoor daylight lamp or other electrical light, please make sure there is at least one meter distance
between machine and light.
The distance too near might cause sensor malfunction,
and can‟t measure the normal size of the medium.
You must move it slowly when you need to move the print head manually.
Quick movement might damage the plotter.

1
Chapter1 Install Plotter
1.1 Check the accessory
1.2 Technical parameter
1.3 Structure and installation of new model plotter
1.4 Structure and installation
1.5 Structure and installation of MJ 135 plotter
1.6 Connect to computer

2
1.1 Check accessory
Refer to the standard accessory list as follows, check and make sure there is not missing . If there has
missing accessory, please contact the salesman or Richforever authorized local agent.
Power cable one piece
USB data cable one piece
Bolt M6*40,flat&spring washer 4 sets
Allen key M3, M5 one set
Ink box two pieces(four pieces for four heads) Manual book 1
Guarantee card one piece
VCD

3
Whole machine includes parts as follows:
Plotter head one set
Left & right stand each one set
Beam one set
Roll shaft and feed shaft each one set
Paper hold one set two pieces
Balance paper bar two pieces（MJ135 with one
piece）
Bolt M6*20,4 pieces; bar 2 pieces(new
model plotter)
Square bar 2 pieces(for MJ 135 plotter)
Cartridge holder one set
Induction bracket one set

4
1.2 Technical parameter
Plotter technical parameter:
Type
Function
RF-MJ135
RF-MJ180
RF-MJ200
RF-MJ220
RF-MJ300
Max paper width
140cm
185cm
205cm
225cm
305cm
Max plotting width
138cm
183cm
203cm
223cm
303cm
Max cartridges
2
2 or 4
Receiving paper
system
None
Automatic paper receiving
Max paper weight
35 Kg
Max plotting speed
72 square meters per hour(two cartridges),140 square meters per
hour(four cartridges)
Ink box type
HP51645A/B ink box
Plot precision
0.025 mm
Medium type
30-60g paper
Communication
USB port, LAN port
Motor type
Servo motor
Data format
HPGL
Environmental conditions demand:
Power
AC220V（110V）/ 50Hz ±10%
Storage
temperature
－20 ℃～50 ℃
Working
temperature
0 ℃～40 ℃
: We can adjust the power input between 220V and 110V a to the voltage of customer.
Main specialty:
◆Easy to install & use.
◆Special LAN cable port data connection make it easy to use
◆Hp Inkjet head with Hp technology is easy to change
◆Compatible with many other brands Garment CAD HP-GL files.
◆Simplified structure to reduce mechanical stress and insure the easy maintenance
◆Auto alarm when paper jams and uses out
◆Servo motors make the plot high speed and working smoothly

5
1.3 Structure and installation of new model plotter
1.3.1 Structure and parts functions
As following figure shows, compared with common model plotter, the difference is feeding system and
receiving system are on same side, save space; low the roll motor near ground, it is more convenient to
install paper. Add two pieces of bar back of plotter.
Stand foot
Pressure wheel
devic
Print head
Left cover
Roll motor
motor
Roll shaft seat
Left stand
Bar slot
Control panel
Right cover
Right stand
Feed shaft
Roll shaft
sensor
Beam
Balance
Front
Back
Paper rod guide Balance bar
Truckle

6
1.3.2 Installation
Stand configuration
Bottom stand:left stand、right stand、beam and bar.
Paper rod guide
Installation
1. Encase the spring washer and flat washer into the six-angle bolt. (See as follows)
2. Lay down the four stand feet of the left and right stands to make it balanced.
3. Plug the bolts into the hole at right stand, fix the right stand with the beam by Allen key, and fasten the
bolts. The left side is in the same way.
Bolt
Flat washer
Spring washer
Allen key
4 sets
Beam
Balance bar
Left stand
Right stand

7
4. After finishing the installation of the left and right stands, install the plotter head on the stand. Lift up the
head, put it on the stand, plug the head angle iron notch on the stand bolts, fasten the butterfly screws
after putting away the both sides of the head, and then fix the head on the stand. Please make sure
there is no gap between the head and the stand.
Whole plotter head
Operation
Screw hole
hole
There are two holes at the stands and
both sides of the beam.
Angle iron
Notch
Bolt
Butterfly screw
Part
Part zooms in

8
5. Connection
Plug the roll and feed motor cable at the left side into the aviation sockets. (Fig1)
Plug the sensor cable at the right side into the aviation socket of the plotter. (Fig2)
Aviation socket
Motor
Plug the motor cables at the left stand
into the aviation sockets on the left side of
the plotter head.
Figure 1
Figure 2
Plug the sensor cable at the
left stand into the aviation
socket on the left side of the
plotter head.
LAN cable port
USB port
Sensor aviation cable

9
1.3.3 Install paper
4. Lift up the feed shaft with paper roll, then put the right side of feed shaft into the right feed shaft seat
(please following fig1), then put the left side of paper feed shaft into the feed shaft seat, please let the motor
driver completely plunge into the left side of the Feed Shaft. (Please following fig2)
Rubber hammer
Paper hub
Feed shaft
2. Put the paper roll on the feed shaft
correctly, push fast paper hub into the
core of paper roll, and then fasten them
by rubber hammer.
3. Fasten screws with Allen key; make sure
the shaft and the paper roll have no opposite
movement.
Fasten screw
Allen key
Paper shaft
Feed shaft
1.Plunge paper feed shaft through
the plotter paper roll, then fix the
paper by fastening hubs on both
sides of paper feed shaft
The dimension of installing
paper as picture, please
don’t make the dimension
oppositely.

10
Caution
The max weight of paper roll is 35kg; it would damage motor if the paper roll is too heavy.
5. Please put the paper under pressure wheels, and put the paper through the plotter head after paper roll
is installed on plotter correctly (please note to lift up the pressure wheels), then pull paper to the front of
the plotter. Please follow the picture.
Feed shaft
Feed shaft seat
Figure 1
Feed shaft
Feed shaft seat
Feed motor driver
Feed motor driver
Figure 2

11
6. After pulling out the paper, please make the paper roll stillness, pull the paper evenly, make sure the
pulling strength is the same on the both sides of paper and then stick the paper on the receive shaft
from middle to both sides. We can stick the paper by 3-5 times, but the sticking times are different by
different paper. (Please follow the picture as follows)
7. Rotate roll shaft manually for 5-8 circles.
8. Please lift up rotation pole by spanner, the pressure wheels and grinding wheels will press the paper
tensely. (See as follows).
Pull the paper to the
front side of the plotter
through the plotter head
From the middle to the other sides

12
9. Please put the balance paper bars on paper and plug them into the balance paper bar slots on both
sides. (See as follows)
10. Please rotate feed shaft and roll shaft to make balance paper bars between top and bottom sensors.
Installation of ink box is same for three model plotters.
Lift up spanner; press the pressure wheels to control the paper
movement.
Running pole
Spanner
Balance bar
Bar slot

13
1.3.4 Paper cutting
Step one
Step two
Step three: Press the number key adjust the best printing paper height
1.4 Structure and installation
At present, our company produces three kinds of plotters with different structure: common model (roll shaft
and feed shaft are on different sides)、MJ135(without receiving system)、new model (roll shaft and feed shaft
are on same side).
