RICHTECH PITBOSS+ User manual

Your Sump
Pump plugs
into the top
outlet
Additional outlet
for backup pump,
dehumidier, etc.
Connection for
High Water Sensor
Outlet ring glows
to show WiFi
connection and
pump status
WiFi Connection Required
WiFi Conguration Button
©2021 Richtech Industries
This device complies with part 15 of the FCC and Industry
Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1)this device may
not cause harmful interference, and (2)this device must
accept any interference received, including interference
that may cause undesired operation. FCC NOTE: The
manufacturer is not responsible for any radio or TV
interference caused by unauthorized modications to
this equipment. Such modications could void the user’s
authority to operate the equipment. NOTE: This equipment
has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instructions may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and
receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician
for help.
Important note: To comply with the FCC RF exposure
compliance requirements, no change to the antenna or
the device is permitted. Any change to the antenna or the
device could result in the device exceeding the RF exposure
requirements and void user’s warranty.
Technical Support:
1-833-786-7779
NOTES:

Inspect the power outlet you intend to plug your
PitBoss+ Smart Outlet into. If there is any damage
or excessive wear on the outlet, please contact an
electrician.
To reduce any risks of damage please read and understand
any safety and operation instructions included with the sump
pump and other devices you wish to use with your PitBoss+
Smart Outlet.
Do not plug a sump pump or any other device into the PitBoss+
Smart Outlet if the device’s ground prong has been removed or
damaged.
Do not plug a sump pump or any other device into the PitBoss+
Smart Outlet if the device’s power cord is cut or damaged.
Do not attempt to disassemble or open the PitBoss+ Smart
Outlet. There are no eld serviceable parts or repair options.
UNPACKING
Inspect before beginning installation. Occasionally,
products are damaged during shipping. If the outlet or any
components are damaged, contact your installer.
INSTALLATION
BEFORE INSTALLING THE PITBOSS+ SUMP PUMP
SMART OUTLET, VERIFY THAT YOUR SUMP PUMP IS IN
GOOD WORKING CONDITION! REPLACE IF NECESSARY!
1. CONNECT THE SMART OUTLET TO YOUR WI-FI
NETWORK AND INSTALL THE PITBOSS+ APP ON
YOUR DEVICE.
2. UNPLUG YOUR SUMP PUMP AND ANY OTHER CORDS
FROM THE WALL A/C OUTLET
3. PLUG THE SMART OUTLET INTO WALL A/C OUTLET
A. Remove the existing outlet cover screw and then secure
the Smart Outlet to the power outlet with the included
mounting screw. If removing the screw is not possible
or desired, make sure the outlet is rmly plugged into the
power outlet and is ush as possible with the wall.
B. The PitBoss+ Smart Outlet is not designed to be used
with extension cords or power strips. If you have
multiple devices that require the use of a power strip, a
power strip can be connected to the lower plug outlet
on the Smart Outlet.
4. CONNECT OTHER DEVICES TO THE LOWER
STANDARD OUTLET, IF APPLICABLE.
5. INSTALL THE HIGH WATER SENSOR, CLAMPING
TO THE DISCHARGE PIPE OF YOUR SUMP PUMP.
A. Adjust the position of the mounting bracket so
the high water sensor does not interfere with the
operation of the main sump pump switch.
B. Adjust the height of the mounting bracket so the
high water sensor is activated when the water level
reaches approx. 1” higher than the “on” level of your
main sump pump.
C. If you have a secondary sump pump/battery backup
pump, make sure the high water sensor is activated
BETWEEN the “on” level of the main sump pump and
the “on” level of the secondary/backup pump.
WE HIGHLY RECOMMEND THAT YOU ALWAYS HAVE 2
WORKING SUMP PUMPS INSTALLED IN YOUR HOME,
SPECIFICALLY ONE THAT CAN OPERATE IN THE EVENT OF
A POWER OUTAGE. THE PITBOSS+ SUMP PUMP SMART
OUTLET WILL NOT OPERATE YOUR SUMP PUMP IN THE
EVENT OF A POWER OUTAGE. ALTHOUGH PITBOSS+
WILL SEND YOU ALERTS WHEN YOUR PUMP HAS AN
ISSUE, WE RECOMMEND HAVING A BACKUP PUMP THAT
CAN TAKE OVER PUMPING DUTY UNTIL REPAIRS CAN BE
COMPLETED.
The High Water Sensor
should be mounted 1 ”
higher than the “on” level
of main sump pump
IMPORTANT!
READ ALL INSTRUCTIONS BEFORE USING THIS PRODUCT.
SPECIFICATIONS
WARNING
The PitBoss+ Smart Outlet is for
residential indoor use only.
To reduce the risk of electrical shock, this device
must be properly grounded in accordance with the
National Electric Code (NEC) and all applicable
state and local codes and ordinances. The
receptacle used with the PitBoss+ Smart Outlet
should be protected with a Ground Fault Circuit Interrupter
(GFCI).
Never remove the ground prong from the PitBoss+ Smart
Outlet, or use an adapter that eliminates the ground prong.
Always plug your PitBoss+ Smart Outlet directly into your wall
power outlet. Do not use an extension cord. Extension cords
could present a safety hazard if not properly sized, become
damaged or the connection falls into the sump pit.
Conrm that your PitBoss+ Smart Outlet is completely plugged
into your wall power outlet and secured with the included
hardware. Your device should sit as ush as possible with the
wall outlet. If it seems loose, please contact an electrician.
POWER SUPPLY REQUIREMENTS
INPUT 120V, 15A, 60Hz
OUTPUT 120V, 15A, 60Hz
Wi-Fi Radio...........................802.11 a/b/g/n 2.4 GHz
Operating Temperature............................. 0° to 50° C
Storage Temperature................................ 0° to 70° C
Relative Humidity ..........................................0 to 90%
